Crane Deming 7365-335-26-10N User manual

A Crane Co. Company
IMPORTANT! Read all instructions in this manual before operating pump.
As a result of Crane Pumps & Systems, Inc., constant product improvement program,
product changes may occur. As such Crane Pumps & Systems reserves the right to
change product without prior written notification.
Form No. 133992-Rev. R
3MA
Monovane Pumps
3 - 7.5HP, 1750RPM
3VC
Vortex Pumps
3 - 5HP, 1750RPM
3VR & 3VRA
Vortex Pumps
2 - 10HP, 3450 &
1750RPM
4M & 4ML
Monovane Pumps
3 - 10HP, 1750RPM
4D & 4DM
Dual Vane Pumps
3 - 10HP, 1750RPM
4VL
Vortex Pumps
2 - 10HP, 3450 &
1750RPM
4VH
Vortex Pumps
2 - 10HP, 3450 &
1750RPM
4VHA
Vortex Pumps
5 - 10HP, 1750RPM
INSTALLATION and OPERATION MANUAL
Solids Handling Submersible Pump
420 Third Street 83 West Drive, Brampton P.O. Box 174515
Piqua, Ohio 45356 Ontario, Canada L6T 2J6 Jebel Ali, Dubai UAE
Phone: [phone] Phone: [phone] Phone: [phone]
Fax: [phone] Fax: [phone] Fax: [phone]
www.cranepumps.com
Series: 7365
This product may be covered by one or more of the following patents and other patent(s) pending: US Patent 7,931,473 & 8,128,360
These pumps are classifi ed as a Class I Division 1 Groups C&D Explosion-Proof by CSA to NEC and CEC specifi cations. Opening
the motor, including maintenance of the upper mechanical seal, must be performed by CP&S to maintain the certifi cation. Internal
maintenance performed by non-certifi ed personnel will void the explosion-proof rating
#2 Frame
Manual Index

2
TABLE OF CONTENTS
SAFETY FIRST ...........................................................................................................................3
A. GENERAL INFORMATION ......................................................................................................... 4
B. INSTALLATION ................................................................................................................... 4 - 17
ELECTRICAL DATA ............................................................................................................. 6 - 16
C. START-UP OPERATION ...........................................................................................................17
D. PREVENTATIVE MAINTENANCE .............................................................................................18
E. SERVICE and REPAIR ...................................................................................................... 18 - 19
F. REPLACEMENT PARTS ...........................................................................................................20
TROUBLE SHOOTING ..............................................................................................................21
RECOMMENDED MINIMUM SUCTION CLEARANCE (Fig. 9) ................................................22
CROSS-SECTIONS (Fig. 10 & 11) ............................................................................................23
EXPLODED VIEWS (Fig. 12 & 13) ............................................................................................24
PARTS LISTS ...........................................................................................................................25
WARRANTY ..............................................................................................................................27
RETURNED GOODS POLICY ................................................................................................. 28
WARRANTY REGISTRATION .................................................................................................. 28
START-UP REPORT ......................................................................................................... 29 - 30
Other brand and product names are trademarks or registered trademarks of their respective holders.
® Deming is a registered trademark of Crane Pumps & Systems, Inc
2018 Alteration Rights Reserved

3
Please Read This Before Installing Or Operating Pump.
This information is provided for SAFETY and to PREVENT
EQUIPMENT PROBLEMS. To help recognize this information,
observe the following symbols:
IMPORTANT! Warns about hazards that can result
in personal injury or indicates factors concerned with
assembly, installation, operation, or maintenance which
could result in damage to the machine or equipment if
ignored.
CAUTION ! Warns about hazards that can or will cause minor
personal injury or property damage if ignored. Used with symbols
below.
WARNING ! Warns about hazards that can or will cause serious
personal injury, death, or major property damage if ignored. Used
with symbols below.
Only qualifi ed personnel should install, operate and repair
pump. Any wiring of pumps should be performed by a qualifi ed
electrician.
WARNING ! - To reduce risk of electrical shock, pumps
and control panels must be properly grounded in
accordance with the National Electric Code (NEC) or the
Canadian Electrical Code (CEC) and all applicable state,
province, local codes and ordinances.
WARNING! - To reduce risk of electrical shock, always
disconnect the pump from the power source before
handling or servicing. Lock out power and tag.
WARNING! Operation against a
closed discharge valve will cause
premature bearing and seal failure on
any pump, and on end suction and
self priming pump the heat build may cause the generation of
steam with resulting dangerous pressures. It is recommended
that a high case temperature switch or pressure relief valve be
installed on the pump body.
CAUTION ! Never operate a pump with a plug-in type
power cord without a ground fault circuit interrupter.
CAUTION! Pumps build up heat and
pressure during operation-allow time
for pumps to cool before handling or
servicing.
WARNING! - DO NOT pump hazardous materials
(fl ammable, caustic, etc.) unless the pump is specifi cally
designed and designated to handle them.
Do not block or restrict discharge hose, as discharge
hose may whip under pressure.
WARNING! - DO NOT wear loose clothing that may
become entangled in the impeller or other moving parts.
WARNING! - Keep clear of suction and discharge
openings. DO NOT insert fi ngers in pump with power
connected.
Always wear eye protection when working on pumps.
Make sure lifting handles are securely fastened each
time before lifting. DO NOT operate pump without
safety devices in place. Always replace safety devices
that have been removed during service or repair.
Secure the pump in its operating position so it can not
tip over, fall or slide.
DO NOT exceed manufacturers recommendation for
maximum performance, as this could cause the motor
to overheat.
DO NOT remove cord and strain relief. Do not connect
conduit to pump.
WARNING! Cable should be protected at all times to
avoid punctures, cut, bruises and abrasions - inspect
frequently. Never handle connected power cords with
wet hands.
WARNING! To reduce risk of electrical shock, all wiring
and junction connections should be made per the NEC
or CEC and applicable state or province and local
codes. Requirements may vary depending on usage
and location.
WARNING! Submersible Pumps are not approved for
use in swimming pools, recreational water installations,
decorative fountains or any installation where human
contact with the pumped fl uid is common.
WARNING! Products Returned Must Be Cleaned,
Sanitized, Or Decontaminated As Necessary Prior
To Shipment, To Insure That Employees Will Not Be
Exposed To Health Hazards In Handling Said Material.
All Applicable Laws And Regulations Shall Apply.
Bronze/brass and bronze/brass fi tted pumps may
contain lead levels higher than considered safe for
potable water systems. Lead is known to cause cancer
and birth defects or other reproductive harm. Various
government agencies have determined that leaded
copper alloys should not be used in potable water
applications. For non-leaded copper alloy materials of
construction, please contact factory.
IMPORTANT! - Crane Pumps & Systems, Inc. is not
responsible for losses, injury, or death resulting from a
failure to observe these safety precautions, misuse or
abuse of pumps or equipment.
SAFETY FIRST!
Hazardous fluids can
cause fire or explo-
sions, burns or death
could result.
Extremely hot -
Severe burns can
occur on contact.
Biohazard can cause
serious personal injury.
Hazardous fluids can
cause hazardous pressure,
eruptions or explosions.
Could also cause personal
injury or property damage.
Rotating machinery
Amputation or severe
laceration can result.
Hazardous voltage can shock,
burn or cause death.

4
SECTION A: GENERAL INFORMATION
A-1) To the Purchaser:
Congratulations! You are the owner of one of the fi nest pumps
on the market today. CP&S pumps are products engineered
and manufactured of high quality components. Over one
hundred years of pump building experience along with a
continuing quality assurance program combine to produce a
pump which will stand up to the toughest applications. This
manual will provide helpful information concerning installation,
maintenance, and proper service guidelines.
A-2) Receiving:
Upon receiving the pump, it should be inspected for
damage or shortages. If damage has occurred, fi le a
claim immediately with the company that delivered the
pump. MAKE CERTAIN TO RETAIN THIS MANUAL!
A-3) Storage:
Short Term- CP&S Pumps are manufactured for effi cient
performance following short inoperative periods in storage.
For best results, pumps can be retained in storage, as factory
assembled, in a dry atmosphere with constant temperatures
for up to six (6) months.
Long Term - Any length of time exceeding six (6) months,
but not more than twenty-four (24) months. The unit should
be stored in a temperature controlled area, a roofed over
walled enclosure that provides protection from the elements
(rain, snow, wind-blown dust, etc.), and whose temperature
can be maintained between +40 deg. F and +120 deg. F.
(4.4 - 49°C). Pump should be stored in its original shipping
container. On initial start up, rotate impeller by hand to
assure seal and impeller rotate freely. If it is required that
the pump be installed and tested before the long term
storage begins, such installation will be allowed provided:
1.) The pump is not installed under water for more than
one (1) month.
2.) Immediately upon satisfactory completion of the test,
the pump is removed, thoroughly dried, repacked in the
original shipping container, and placed in a temperature
controlled storage area.
A-4) Service Centers:
For the location of the nearest Deming Service Center, contact
Crane Pumps & Systems, Inc., Service Department in Piqua,
Ohio, telephone [phone] or Crane Pumps & Systems
Canada, in Brampton, Ontario, [phone].
SECTION B: INSTALLATION
B-1) Location:
These self-contained pumping units are recommended for
use in a sump, lift station or basin. This pump is designed
for submerged continuous duty (15 minutes duty in air
at nameplate horsepower), pumping sewage, effl uent,
wastewater or other nonexplosive or noncorrosive liquids not
above 104°F (40°C). Never install the pump in a trench, ditch
or hole with a dirt bottom; the legs will sink into the dirt and
the suction will become plugged.
B-1.1) Submergence:
It is recommended that the pump be operated in the
Continuous Duty Submergence condition and the sump liquid
level should never be less than the Minimum Submergence
Level (See Fig. 1). The time required to draw the well down
from top of motor to the minimum submergence level should
not be greater than 15 minutes. NOTE: Outer shaft seal
must be in liquid when motor is operated, whether motor is
submerged or in air.
B-2) Discharge:
Discharge piping should be as short as possible. Both a
check valve and a shut-off valve are recommended for
each pump being used. The check valve is used to prevent
backfl ow into the sump. Excessive backfl ow can cause
fl ooding and/or damage to the pump. The shut-off valve
is used to stop system fl ow during pump or check valve
servicing.
Crane Pumps & Systems manufactures a break away
fi tting discharge system designed to allow the submersible
wastewater pump to be installed or removed without requiring
personnel to enter the wet well. Place the Break Away Fitting
(BAF) in position. Temporarily secure the guide rails in the
upper mounting brackets and locate the base elbow on the
bottom of the wet well. Level the base elbow with grout and/
or shims. Install the intermediate support brackets, if required.
Make sure the rails are in a true vertical position so the pump
will clear the access opening and will slide freely down the
rails into place on the discharge base elbow. Once the rails
are in proper alignment, bolt the base elbow into the fl oor
of the station and connect the discharge pipe to the elbow.
Connect the movable portion and other supplied fi ttings of the
BAF onto the pump and lower into wet well. See the Break
Away Fitting manual for more information.
FIGURE 1

5
B-3) Liquid Level Controls:
It is recommended to use a liquid level control system
that allows the on and off point to be separated by at least
twelve inches. An additional set point (lag point) should be
incorporated with an alternator switching system for a duplex
(two pump) station. A high level alarm may be required
to alert maintenance personnel that there is a high water
situation in the wet well should the output of the pump station
drop below the infl ow rate. A low level cut off may be installed
to provide system shutdown if the main level control system
malfunctions. The off point should be positioned so that the
liquid level never drops below the minimum continuous duty
point for the pump shown in fi gure 1.
B-4.1) Electrical Connections:
WARNING! - All model pumps and
control panels must be properly
grounded per the NATIONAL
ELECTRIC CODE or CANADIAN
ELECTRIC CODE, State, Province
and local codes. Improper
grounding voids warranty.
B-4) Power/Control Cord:
The power/control cord used with pump has a patented
“quick disconnect” feature that allows the cord to be easily
attached and disconnected at the pump. The maximum
amperage rating for the cord is cast in the top of the cast
stainless mounting plate. The voltage connection for the
motor is determined by the cord assembly used. Low voltage
cords (208 & 230 Volt) utilize a molded quick connect plug
that is colored black. High voltage cords (460 & 575 Volt)
utilize a molded quick connect cord that is colored orange.
It is important to verify that the cord being used is rated
for the nameplate voltage and amperage rating shown on
the pump nameplate. Refer to Chart on page 7. No internal
wiring adjustments are necessary for dual and tri-voltage
pumps. All jumper connections to set the proper voltage are
made by the cord plug itself.
A fl at alignment mark is molded into the plug and mating
socket on the pump. These should be used as a visual
indication as to the correct orientation of the plug. Insert the
plug into the pump and install the two 12 mm socket head
cap screws into the clamping plate. Slowly tighten the two
screws alternating back and forth until the clamping plate is
drawn down fl ush to the top of the cord boss on the pump.
The two screws should be torqued until the plate is down to
a point where metal to metal contact is made between the
stainless steel plate and pump housing. (See Fig. 2)
The cord assembly mounted to the pump must not be
modifi ed in any way except for shortening to a specifi c
application. Any splice between the pump and the control
panel must be made in accordance with all applicable electric
codes. It is recommended that a junction box (if used) be
mounted outside the sump or be of at least Nema 6 or 6P
construction with NEMA 6 or 6P watertight cord grips if
located within the wet well. A water and vapor tight seal fi tting
MUST be used in conduit leaving the wet well to prevent
moisture and gases from reaching the control panel. Prior to
installation, the pump power cable should be inspected for
nicks or damage. If damaged, the cord should be replaced
before installation.
CORD CLAMPING PLATE SHOULD BE DRAWN METAL
TO METAL (50 FT/LBS BOLT TORQUE). IF A GAP EXISTS
CONTINUE TO TIGHTEN BOLTS. DO NOT USE ANY TYPE
OF SEALANT OR GREASE ON THE CORD ENTRY.
DO NOT USE THE POWER CORD TO LIFT PUMP.
B-4.1) Electrical Connections:
When the electrical connections are made, the lead wires
from the power cable should be stripped so that the ground
wire is at least two inches longer than the power leads. This
will ensure that if the cable is inadvertently pulled out of the
connection point, the ground wire will be the last lead to break
the circuit.
B-4.2) Wire Size:
If additional cable is required consult a qualifi ed electrician for
proper wire size. Voltage drop due to wire resistance between
the pump and power connection point should be limited to 3%
when additional cable is added.
WARRANTY NOTE:
Both the temperature sensor and moisture
detection system must be connected to the motor
circuitry such that the motor will be de-energized
or sound alarm if excessive motor temperatures
are reached and/or if water is detected in the
seal chamber and/or motor chamber. Failure to
have the above mentioned systems installed and
operative, nullifi es warranty.
FIGURE 2bFIGURE 2a

6
MODEL NO. SIZE
IMP. DIA.
INCHES
(MM)
HP VOLT PH HZ RPM
NEMA
START
CODE
FULL
LOAD
AMPS
SERVICE
FACTOR
SERVICE
FACTOR
AMPS
LOCKED
ROTOR
AMPS
DRIVER
FRAME
CORD
P/N ▲
CORD
SIZE
CORD
O.D.
WINDING
RESISTANCE
7365-335-26-10N 3MA 6.89 (175) 3 208 1 60 1750 D 14.9 1.2 18.5 59.1 2 125496 12/4 - 18/4 .86 ± .02 0.88 - 2.14
230 F 14.1 1.2 16.5 66.3 2 125496 12/4 - 18/4 .86 ± .02
7365-335-1P-30N 3MA 6.89 (175) 3
208
3 60 1750 K
9.7 1.2 11.4 58.2 2 125496 12/4 - 18/4 .86 ± .02 1.08
230 9.2 1.2 10.6 65.8 2 125496 12/4 - 18/4 .86 ± .02 1.08 460 4.6 1.2 5.3 32.9 2 125497 12/4 - 18/4 .86 ± .02 4.32
7365-335-71-30N 3MA 6.89 (175) 3 575 3 60 1750 N 4.5 1.2 4.9 37.0 2 125497 12/4 - 18/4 .86 ± .02 4.32 7365-335-27-10N 3MA 7.68 (195) 5 208 1 60 1750 D 27.2 1.2 35.6 99.9 2 125498 8/4 - 18/4 1.12 ± .02 0.50 -- 2.66
230 F 25.4 1.2 30.2 112.4 2 125498 8/4 - 18/4 1.12 ± .02 0.50 -- 2.66
7365-335-1R-30N 3MA 7.68 (195) 5
208
3 60 1750 J
15.8 1.2 18.7 82.4 2 125496 12/4 - 18/4 .86 ± .02 0.72
230 15.0 1.2 17.2 92.4 2 125496 12/4 - 18/4 .86 ± .02 0.72 460 7.5 1.2 8.6 46.2 2 125497 12/4 - 18/4 .86 ± .02 2.88
7365-335-72-30N 3MA 7.68 (195) 5 575 3 60 1750 J 6.0 1.2 6.9 37.0 2 125497 12/4 - 18/4 .86 ± .02 4.32
7365-335-1H-30N 3MA 8.07 (205) 7.5
208
3 60 1750 H
23.8 1.2 28.5 105.9 2 125496 12/4 - 18/4 .86 ± .02 0.43
230 23.7 1.2 27.2 123.6 2 125496 12/4 - 18/4 .86 ± .02 0.43 460 11.9 1.2 13.6 61.8 2 125497 12/4 - 18/4 .86 ± .02 1.72
7365-335-87-30N 3MA 8.07 (205) 7.5 575 3 60 1750 H 9.5 1.2 10.9 49.4 2 125497 12/4 - 18/4 .86 ± .02 2.69 7365-371-26-10N 3VC 5.12 (130) 3.0 208 1 60 1750 D 14.9 1.2 18.5 59.1 2 125496 12/4 - 18/4 .86 ± .02 0.88 - 2.14
230 F 14.1 1.2 16.5 66.3 2 125496 12/4 - 18/4 .86 ± .02 0.88 - 2.14
7365-371-1P-30N 3VC 5.12 (130) 3.0
208
3 60 1750 K
9.7 1.2 11.4 58.2 2 125496 12/4 - 18/4 .86 ± .02 1.08
230 9.2 1.2 10.6 65.8 2 125496 12/4 - 18/4 .86 ± .02 1.08 460 4.6 1.2 5.3 32.9 2 125497 12/4 - 18/4 .86 ± .02 4.32
7365-371-71-30N 3VC 5.12 (130) 3.0 575 3 60 1750 N 4.5 1.2 4.9 37 2 125497 12/4 - 18/4 .86 ± .02 4.32 7365-371-27-10N 3VC 7.25 (185) 5.0 208 1 60 1750 D 27.2 1.2 35.6 99.9 2 125498 8/4 - 18/4 1.12 ± .02 0.50 - - 2.66
230 F 25.4 1.2 30.2 112.4 2 125496 12/4 - 18/4 .86 ± .02 0.50 - - 2.66
7365-371-1R-30N 3VC 7.25 (185) 5.0
208
3 60 1750 J
15.8 1.2 18.7 82.4 2 125496 12/4 - 18/4 .86 ± .02 0.72
230 15 1.2 17.2 92.4 2 125496 12/4 - 18/4 .86 ± .02 0.72 460 7.5 1.2 8.6 46.2 2 125497 12/4 - 18/4 .86 ± .02 2.88
7365-371-72-30N 3VC 7.25 (185) 5.0 575 3 60 1750 J 6 1.2 6.9 37 2 125497 12/4 - 18/4 .86 ± .02 4.32
▲ CORD SOLD SEPARATELY. CORD SUFFIX: XC - 30 FEET, XF - 50 FEET, XJ - 75 FEET, OR XL - 100 FEET.
CHART ‘A’
IMPORTANT ! 1.) MOISTURE AND TEMPERATURE SENSORS MUST BE CONNECTED TO VALIDATE THE CSA LISTING.
2.) A SPECIAL MOISTURE SENSOR RELAY IS REQUIRED IN THE CONTROL PANEL FOR PROPER OPERATION OF THE MOISTURE SENSORS.CONTACT CP&S FOR INFORMATION CONCERNING MOISTURE SENSING RELAYS FOR CUSTOMER SUPPLIED CONTROL PANELS. 3.) THESE PUMPS ARE CSA LISTED FOR PUMPING WATER AND WASTEWATER. DO NOT USE TO PUMP FLAMMABLE LIQUIDS. NOT SUITABLE FOR ENVIRONMENTS CONTAINING GASOLINE OR HEXANE. 4.) INSTALLATIONS SUCH AS DECORATIVE FOUNTAINS OR WATER FEATURES PROVIDED FOR VISUAL ENJOYMENT MUST BE INSTALLED IN ACCORDANCE WITH THE NATIONAL ELECTRIC CODE ANSI/NFPA 70 AND/OR THE AUTHORITY
HAVING JURISDICTION. THIS PUMP IS NOT INTENDED FOR USE IN SWIMMING POOLS, RECREATIONAL WATER PARKS, OR INSTALLATIONS IN WHICH HUMAN CONTACT WITH PUMPED MEDIA IS A COMMON OCCURRENCE. 5.) A NON-SPARKING BREAKAWAY FITTING MUST BE USED TO VALIDATE THE EXPLOSION PROOF LISTING.
6.) WINDING RESISTANCE ± 7.5%. WINDING RESISTANCE MEASURED IN OHMS @ 25°C (BETWEEN LINES) AT MOTOR LEADS. 7.) PUMP RATED FOR OPERATION AT ± 10% VOLTAGE AT MOTOR. ** SELECT IMPELLER DIAMETER WHEN ORDERING.

7
MODEL NO. SIZE
IMP. DIA.
INCHES
(MM)
HP VOLT PH HZ RPM
NEMA
START
CODE
FULL
LOAD
AMPS
SERVICE
FACTOR
SERVICE
FACTOR
AMPS
LOCKED
ROTOR
AMPS
DRIVER
FRAME
CORD
P/N ▲
CORD
SIZE
CORD
O.D.
WINDING
RESISTANCE
7365-327-27-10N 3VR 3.54 (90) 5 208 1 60 3450 E 27.8 1.2 34.1 113.2 2 125498 8/4 - 18/4 1.12 ± .02 0.38 - - 1.66
230 G 25.4 1.2 29.9 131.2 2 125498 8/4 - 18/4 1.12 ± .02 0.38 - - 1.66
7365-327-1P-30N 3VR 3.54 (90) 5
208
3 60 3450 J
14.9 1.2 17.8 85.4 2 125496 12/4 - 18/4 .86 ± .02 0.75
230 13.7 1.2 16.0 95.2 2 125496 12/4 - 18/4 .86 ± .02 0.75 460 6.9 1.2 8.0 47.6 2 125497 12/4 - 18/4 .86 ± .02 3.00
7365-327-72-30N 3VR 3.54 (90) 5 575 3 60 3450 J 5.5 1.2 6.4 38.1 2 125497 12/4 - 18/4 .86 ± .02 4.34
7365-327-1S-30N 3VR 3.94 (100) 7.5
208
3 60 3450 M
24.2 1.2 28.0 173.9 2 125496 12/4 - 18/4 .86 ± .02 0.40
230 25.4 1.2 28.2 201.0 2 125496 12/4 - 18/4 .86 ± .02 0.40 460 12.7 1.2 14.1 100.5 2 125497 12/4 - 18/4 .86 ± .02 1.58
7365-327-87-30N 3VR 3.94 (100) 7.5 575 3 60 3450 M 10.2 1.2 11.3 80.4 2 125497 12/4 - 18/4 .86 ± .02 2.47
7365-327-1J-30N 3VR 4.53 (115) 10
208
3 60 3450 K
30.8 1.2 37.0 173.9 2 125498 8/4 - 18/4 1.12 ± .02 0.40
230 30.1 1.2 34.8 201.0 2 125498 8/4 - 18/4 1.12 ± .02 0.40 460 15.1 1.2 17.4 100.5 2 125497 12/4 - 18/4 .86 ± .02 1.58
7365-327-88-30N 3VR 4.53 (115) 10 575 3 60 3450 K 12.1 1.2 13.9 80.4 2 125497 12/4 - 18/4 .86 ± .02 2.47 7365-328-25-10N 3VR 4.53 (115) 2 208 1 60 1750 G 10.4 1.2 12.1 59.1 2 125496 12/4 - 18/4 .86 ± .02 0.88 - 2.14
230 J 10.7 1.2 11.9 66.3 2 125496 12/4 - 18/4 .86 ± .02 0.88 - 2.14
7365-328-1M-30N 3VR 4.53 (115) 2
208
3 60 1750 P
7.4 1.2 8.3 58.2 2125496 12/4 - 18/4 .86 ± .02 1.08
230 7.4 1.2 8.0 65.8 2 125496 12/4 - 18/4 .86 ± .02 1.08 460 3.7 1.2 4.0 32.9 2 125497 12/4 - 18/4 .86 ± .02 4.32
7365-328-70-30N 3VR 4.53 (115) 2 575 3 60 1750 T 3.9 1.2 4.2 37.0 2 125497 12/4 - 18/4 .86 ± .02 4.32 7365-328-26-10N 3VR 6.30 (160) 3 208 1 60 1750 D 14.9 1.2 18.5 59.1 2 125496 12/4 - 18/4 .86 ± .02 0.88 - 2.14
230 F 14.1 1.2 16.5 66.3 2 125496 12/4 - 18/4 .86 ± .02 0.88 - 2.14
7365-328-1P-30N 3VR 6.30 (160) 3
208
3 t60 1750 K
9.7 1.2 11.4 58.2 2 125496 12/4 - 18/4 .86 ± .02 1.08
230 9.2 1.2 10.6 65.8 2 125496 12/4 - 18/4 .86 ± .02 1.08 460 4.6 1.2 5.3 32.9 2 125497 12/4 - 18/4 .86 ± .02 4.32
7365-328-71-30N 3VR 6.30 (160) 3575 3 60 1750 N 4.5 1.2 4.9 37.0 2125497 12/4 - 18/4 .86 ± .02 4.32 7365-328-27-10N 3VR 6.89 (175) 5 208 1 60 1750 D 27.2 1.2 35.6 99.9 2 125498 8/4 - 18/4 1.12 ± .02 0.50 - - 2.66
230 F 25.4 1.2 30.2 112.4 2 125496 12/4 - 18/4 .86 ± .02 0.50 - - 2.66
7365-328-1R-30N 3VR 6.89 (175) 5
208
3 60 1750 J
15.8 1.2 18.7 82.4 2 125496 12/4 - 18/4 .86 ± .02 0.72
230 15.0 1.2 17.2 92.4 2 125496 12/4 - 18/4 .86 ± .02 0.72
460 7.5 1.2 8.6 46.2 2 125497 12/4 - 18/4 .86 ± .02 2.88
7365-328-72-30N 3VR 6.89 (175) 5 575 3 60 1750 J 6.0 1.2 6.9 37.0 2 125497 12/4 - 18/4 .86 ± .02 4.32
▲ CORD SOLD SEPARATELY. CORD SUFFIX: XC - 30 FEET, XF - 50 FEET, XJ - 75 FEET, OR XL - 100 FEET.
CHART ‘B’
IMPORTANT ! 1.) MOISTURE AND TEMPERATURE SENSORS MUST BE CONNECTED TO VALIDATE THE CSA LISTING.
2.) A SPECIAL MOISTURE SENSOR RELAY IS REQUIRED IN THE CONTROL PANEL FOR PROPER OPERATION OF THE MOISTURE SENSORS.CONTACT CP&S FOR INFORMATION CONCERNING MOISTURE SENSING RELAYS FOR CUSTOMER SUPPLIED CONTROL PANELS. 3.) THESE PUMPS ARE CSA LISTED FOR PUMPING WATER AND WASTEWATER. DO NOT USE TO PUMP FLAMMABLE LIQUIDS. NOT SUITABLE FOR ENVIRONMENTS CONTAINING GASOLINE OR HEXANE. 4.) INSTALLATIONS SUCH AS DECORATIVE FOUNTAINS OR WATER FEATURES PROVIDED FOR VISUAL ENJOYMENT MUST BE INSTALLED IN ACCORDANCE WITH THE NATIONAL ELECTRIC CODE ANSI/NFPA 70 AND/OR THE AUTHORITY
HAVING JURISDICTION. THIS PUMP IS NOT INTENDED FOR USE IN SWIMMING POOLS, RECREATIONAL WATER PARKS, OR INSTALLATIONS IN WHICH HUMAN CONTACT WITH PUMPED MEDIA IS A COMMON OCCURRENCE. 5.) A NON-SPARKING BREAKAWAY FITTING MUST BE USED TO VALIDATE THE EXPLOSION PROOF LISTING.
6.) WINDING RESISTANCE ± 7.5%. WINDING RESISTANCE MEASURED IN OHMS @ 25°C (BETWEEN LINES) AT MOTOR LEADS. 7.) PUMP RATED FOR OPERATION AT ± 10% VOLTAGE AT MOTOR. ** SELECT IMPELLER DIAMETER WHEN ORDERING.

8
CHART ‘C’
MODEL NO. SIZE
IMP. DIA.
INCHES
(MM)
HP VOLT PH HZ RPM
NEMA
START
CODE
FULL
LOAD
AMPS
SERVICE
FACTOR
SERVICE
FACTOR
AMPS
LOCKED
ROTOR
AMPS
DRIVER
FRAME
CORD
P/N ▲
CORD
SIZE
CORD
O.D.
WINDING
RESISTANCE
7365-342-25-10N 3VRA 4.72 (120) 2 208 1 60 1750 G 10.4 1.2 12.1 59.1 2 125496 12/4 - 18/4 .86 ± .02 0.88 -- 2.14
230 J 10.7 1.2 11.9 66.3 2 125496 12/4 - 18/4 .86 ± .02 0.88 -- 2.14
7365-342-1M-30N 3VRA 4.72 (120) 2
208
3 60 1750 P
7.4 1.2 8.3 58.2 2 125496 12/4 - 18/4 .86 ± .02 1.08
230 7.4 1.2 8.0 65.8 2 125496 12/4 - 18/4 .86 ± .02 1.08 460 3.7 1.2 4.0 32.9 2 125497 12/4 - 18/4 .86 ± .02 4.32
7365-342-70-30N 3VRA 4.72 (120) 2 575 3 60 1750 T 3.9 1.2 4.2 37.0 2 125497 12/4 - 18/4 .86 ± .02 4.32 7365-342-26-10N 3VRA 5.12 (130) 3 208 1 60 1750 D 14.9 1.2 18.5 37.0 2 125496 12/4 - 18/4 .86 ± .02 0.88 -- 2.14
230 F 14.1 1.2 16.5 66.3 2 125496 12/4 - 18/4 .86 ± .02 0.88 -- 2.14
7365-342-1P-30N 3VRA 5.12 (130) 3
208
3 t60 1750 K
9.7 1.2 11.4 58.2 2 125496 12/4 - 18/4 .86 ± .02 1.08
230 9.2 1.2 10.6 65.8 2 125496 12/4 - 18/4 .86 ± .02 1.08 460 4.6 1.2 5.3 32.9 2 125497 12/4 - 18/4 .86 ± .02 4.32
7365-342-72-30N 3VRA 5.12 (130) 3 575 3 60 1750 N 4.5 1.2 4.9 37.0 2 125497 12/4 - 18/4 .86 ± .02 4.32 7365-342-27-10N 3VRA 6.30 (160) 5 208 1 60 1750 D 27.2 1.2 35.6 99.9 2 125498 8/4 - 18/4 1.12 ± .02 0.50 -- 2.66
230 F 25.4 1.2 30.2 112.4 2 125498 12/4 - 18/4 .86 ± .02 0.50 -- 2.66
7365-342-1R-30N 3VRA 6.30 (160) 5
208
3 60 1750 J
15.8 1.2 18.7 82.4 2 125496 12/4 - 18/4 .86 ± .02 0.72
230 15.0 1.2 17.2 92.4 2 125496 12/4 - 18/4 .86 ± .02 0.72 460 7.5 1.2 8.6 46.2 2 125497 12/4 - 18/4 .86 ± .02 2.88
7365-342-72-30N 3VRA 6.30 (160) 5 575 3 60 1750 J 6.0 1.2 6.9 37.0 2 125497 12/4 - 18/4 .86 ± .02 4.32
7365-342-1H-30N 3VRA 7.48 (190) 7.5
208
3 60 1750 H
23.8 1.2 28.5 105.9 2 125496 12/4 - 18/4 .86 ± .02 0.43
230 23.7 1.2 27.2 123.6 2 125496 12/4 - 18/4 .86 ± .02 0.43 460 11.9 1.2 13.6 61.8 2 125497 12/4 - 18/4 .86 ± .02 1.72
7365-342-87-30N 3VRA 7.48 (190) 7.5 575 3 60 1750 H 9.5 1.2 10.9 49.4 2 125497 12/4 - 18/4 .86 ± .02 2.69
▲ CORD SOLD SEPARATELY. CORD SUFFIX: XC - 30 FEET, XF - 50 FEET, XJ - 75 FEET, OR XL - 100 FEET.
IMPORTANT ! 1.) MOISTURE AND TEMPERATURE SENSORS MUST BE CONNECTED TO VALIDATE THE CSA LISTING.
2.) A SPECIAL MOISTURE SENSOR RELAY IS REQUIRED IN THE CONTROL PANEL FOR PROPER OPERATION OF THE MOISTURE SENSORS.CONTACT CP&S FOR INFORMATION CONCERNING MOISTURE SENSING RELAYS FOR CUSTOMER SUPPLIED CONTROL PANELS. 3.) THESE PUMPS ARE CSA LISTED FOR PUMPING WATER AND WASTEWATER. DO NOT USE TO PUMP FLAMMABLE LIQUIDS. NOT SUITABLE FOR ENVIRONMENTS CONTAINING GASOLINE OR HEXANE. 4.) INSTALLATIONS SUCH AS DECORATIVE FOUNTAINS OR WATER FEATURES PROVIDED FOR VISUAL ENJOYMENT MUST BE INSTALLED IN ACCORDANCE WITH THE NATIONAL ELECTRIC CODE ANSI/NFPA 70 AND/OR THE AUTHORITY
HAVING JURISDICTION. THIS PUMP IS NOT INTENDED FOR USE IN SWIMMING POOLS, RECREATIONAL WATER PARKS, OR INSTALLATIONS IN WHICH HUMAN CONTACT WITH PUMPED MEDIA IS A COMMON OCCURRENCE. 5.) A NON-SPARKING BREAKAWAY FITTING MUST BE USED TO VALIDATE THE EXPLOSION PROOF LISTING.
6.) WINDING RESISTANCE ± 7.5%. WINDING RESISTANCE MEASURED IN OHMS @ 25°C (BETWEEN LINES) AT MOTOR LEADS. 7.) PUMP RATED FOR OPERATION AT ± 10% VOLTAGE AT MOTOR. ** SELECT IMPELLER DIAMETER WHEN ORDERING.

9
CHART ‘D’
MODEL NO. SIZE
IMP. DIA.
INCHES
(MM)
HP VOLT PH HZ RPM
NEMA
START
CODE
FULL
LOAD
AMPS
SERVICE
FACTOR
SERVICE
FACTOR
AMPS
LOCKED
ROTOR
AMPS
DRIVER
FRAME
CORD
P/N ▲
CORD
SIZE
CORD
O.D.
WINDING
RESISTANCE
7365-424-26-10N 4M 6.10 (155) 3 208 1 60 1750 D 14.9 1.2 18.5 59.1 2 125496 12/4 - 18/4 .86 ± .02 0.88 - - 2.14
230 F 14.1 1.2 16.5 66.3 2 125496 12/4 - 18/4 .86 ± .02 0.88 - - 2.14
7365-424-1P-30N 4M 6.10 (155) 3
208
3 60 1750 K
9.7 1.2 11.4 58.2 2 125496 12/4 - 18/4 .86 ± .02 1.08
230 9.2 1.2 10.6 65.8 2 125496 12/4 - 18/4 .86 ± .02 1.08 460 4.6 1.2 5.3 32.9 2 125497 12/4 - 18/4 .86 ± .02 4.32
7365-424-71-30N 4M 6.10 (155) 3 575 3 60 1750 N 4.5 1.2 4.9 37.0 2 125497 12/4 - 18/4 .86 ± .02 4.32 7365-424-27-10N 4M 6.89 (175) 5 208 1 60 1750 D 27.2 1.2 35.6 99.9 2 125498 8/4 - 18/4 1.12 ± .02 0.50 - - 2.66
230 F 25.4 1.2 30.2 112.4 2 125498 8/4 - 18/4 1.12 ± .02 0.50 - - 2.66
7365-424-1R-30N 4M 6.89 (175) 5
208
3 60 1750 J
15.8 1.2 18.7 82.4 2 125496 12/4 - 18/4 .86 ± .02 0.72
230 15.0 1.2 17.2 92.4 2 125496 12/4 - 18/4 .86 ± .02 0.72 460 7.5 1.2 8.6 46.2 2 125497 12/4 - 18/4 .86 ± .02 2.88
7365-424-72-30N 4M 6.89 (175) 5 575 3 60 1750 J 6.0 1.2 6.9 37.0 2 125497 12/4 - 18/4 .86 ± .02 4.32
7365-424-1S-30N 4M 7.87 (200) 7.5
208
3 60 1750 H
23.8 1.2 28.5 105.9 2 125496 12/4 - 18/4 .86 ± .02 0.43
230 23.7 1.2 27.2 123.6 2 125496 12/4 - 18/4 .86 ± .02 0.43 460 11.9 1.2 13.6 61.8 2 125497 12/4 - 18/4 .86 ± .02 1.72
7365-424-87-30N 4M 7.87 (200) 7.5 575 3 60 1750 H 9.5 1.2 10.9 49.4 2 125497 12/4 - 18/4 .86 ± .02 2.69 7365-410-27-10N 4ML 7.28 (185) 5 208 1 60 1750 D 27.2 1.2 35.6 99.9 2 125498 8/4 - 18/4 1.12 ± .02 0.50 - - 2.66
230 F 25.4 1.2 30.2 112.4 2 125498 8/4 - 18/4 1.12 ± .02 0.50 - - 2.66
7365-410-1R-30N 4ML 7.28 (185) 5
208
3 60 1750 J
15.8 1.2 18.7 82.4 2 125496 12/4 - 18/4 .86 ± .02 0.72
230 15.0 1.2 17.2 92.4 2 125496 12/4 - 18/4 .86 ± .02 0.72 460 7.5 1.2 8.6 46.2 2 125497 12/4 - 18/4 .86 ± .02 2.88
7365-410-72-30N 4ML 7.28 (185) 5 575 3 60 1750 J 6.0 1.2 6.9 37.0 2 125497 12/4 - 18/4 .86 ± .02 4.32
7365-410-1S-30N 4ML 8.07 (205) 7.5
208
3 60 1750 H
23.8 1.2 28.5 105.9 2 125496 12/4 - 18/4 .86 ± .02 0.43
230 23.7 1.2 27.2 123.6 2 125496 12/4 - 18/4 .86 ± .02 0.43 460 11.9 1.2 13.6 61.8 2 125497 12/4 - 18/4 .86 ± .02 1.72
7365-410-87-30N 4ML 8.07 (205) 7.5 575 3 60 1750 H 9.5 1.2 10.9 49.4 2 125497 12/4 - 18/4 .86 ± .02 2.69
7365-410-1T-30N 4ML 8.59 (225) 10
208
3 60 1750 E
32.2 1.2 41.4 105.9 2 125498 8/4 - 18/4 1.12 ± .02 0.43
230 29.8 1.2 35.6 123.6 2 125498 8/4 - 18/4 1.12 ± .02 0.43 460 14.9 1.2 17.8 61.8 2 125497 12/4 - 18/4 .86 ± .02 1.72
7365-410-88-30N 4ML 8.59 (225) 10 575 3 60 1750 E 11.9 1.2 14.2 49.4 2 125497 12/4 - 18/4 .86 ± .02 2.69
▲ CORD SOLD SEPARATELY. CORD SUFFIX: XC - 30 FEET, XF - 50 FEET, XJ - 75 FEET, OR XL - 100 FEET.
IMPORTANT ! 1.) MOISTURE AND TEMPERATURE SENSORS MUST BE CONNECTED TO VALIDATE THE CSA LISTING.
2.) A SPECIAL MOISTURE SENSOR RELAY IS REQUIRED IN THE CONTROL PANEL FOR PROPER OPERATION OF THE MOISTURE SENSORS.CONTACT CP&S FOR INFORMATION CONCERNING MOISTURE SENSING RELAYS FOR CUSTOMER SUPPLIED CONTROL PANELS. 3.) THESE PUMPS ARE CSA LISTED FOR PUMPING WATER AND WASTEWATER. DO NOT USE TO PUMP FLAMMABLE LIQUIDS. NOT SUITABLE FOR ENVIRONMENTS CONTAINING GASOLINE OR HEXANE. 4.) INSTALLATIONS SUCH AS DECORATIVE FOUNTAINS OR WATER FEATURES PROVIDED FOR VISUAL ENJOYMENT MUST BE INSTALLED IN ACCORDANCE WITH THE NATIONAL ELECTRIC CODE ANSI/NFPA 70 AND/OR THE AUTHORITY
HAVING JURISDICTION. THIS PUMP IS NOT INTENDED FOR USE IN SWIMMING POOLS, RECREATIONAL WATER PARKS, OR INSTALLATIONS IN WHICH HUMAN CONTACT WITH PUMPED MEDIA IS A COMMON OCCURRENCE. 5.) A NON-SPARKING BREAKAWAY FITTING MUST BE USED TO VALIDATE THE EXPLOSION PROOF LISTING.
6.) WINDING RESISTANCE ± 7.5%. WINDING RESISTANCE MEASURED IN OHMS @ 25°C (BETWEEN LINES) AT MOTOR LEADS. 7.) PUMP RATED FOR OPERATION AT ± 10% VOLTAGE AT MOTOR. ** SELECT IMPELLER DIAMETER WHEN ORDERING.

10
CHART ‘E’
MODEL NO. SIZE
IMP. DIA.
INCHES
(MM)
HP VOLT PH HZ RPM
NEMA
START
CODE
FULL
LOAD
AMPS
SERVICE
FACTOR
SERVICE
FACTOR
AMPS
LOCKED
ROTOR
AMPS
DRIVER
FRAME
CORD
P/N ▲
CORD
SIZE
CORD
O.D.
WINDING
RESISTANCE
7365-425-26-10N 4D 5.51 (140) 3 208 1 60 1750 D 14.9 1.2 18.5 59.1 2 125496 12/4 - 18/4 .86 ± .02 0.88 - - 2.14
230 F 14.1 1.2 16.5 66.3 2 125496 12/4 - 18/4 .86 ± .02 0.88 - - 2.14
7365-425-1P-30N 4D 5.51 (140) 3
208
3 60 1750 K
9.7 1.2 11.4 58.2 2 125496 12/4 - 18/4 .86 ± .02 1.08
230 9.2 1.2 10.6 65.8 2 125496 12/4 - 18/4 .86 ± .02 1.08 460 4.6 1.2 5.3 32.9 2 125497 12/4 - 18/4 .86 ± .02 4.32
7365-425-71-30N 4D 5.51 (140) 3 575 3 60 1750 N 4.5 1.2 4.9 37.0 2 125497 12/4 - 18/4 .86 ± .02 4.32 7365-425-27-10N 4D 6.30 (160) 5 208 1 60 1750 D 27.2 1.2 35.6 99.9 2 125498 8/4 - 18/4 1.12 ± .02 0.50 - - 2.66
230 F 25.4 1.2 30.2 112.4 2 125498 8/4 - 18/4 1.12 ± .02 0.50 - - 2.66
7365-425-1R-30N 4D 6.30 (160) 5
208
3 60 1750 J
15.8 1.2 18.7 82.4 2 125496 12/4 - 18/4 .86 ± .02 0.72
230 15.0 1.2 17.2 92.4 2 125496 12/4 - 18/4 .86 ± .02 0.72 460 7.5 1.2 8.6 46.2 2 125497 12/4 - 18/4 .86 ± .02 2.88
7365-425-72-30N 4D 6.30 (160) 5 575 3 60 1750 J 6.0 1.2 6.9 37.0 2 125497 12/4 - 18/4 .86 ± .02 4.32
7365-425-1S-30N 4D 7.09 (180) 7.5
208
3 60 1750 H
23.8 1.2 28.5 105.9 2 125496 12/4 - 18/4 .86 ± .02 0.43
230 23.7 1.2 27.2 123.6 2 125496 12/4 - 18/4 .86 ± .02 0.43 460 11.9 1.2 13.6 61.8 2 125497 12/4 - 18/4 .86 ± .02 1.72
7365-425-87-30N 4D 7.09 (180) 7.5 575 3 60 1750 H 9.5 1.2 10.9 49.4 2 125497 12/4 - 18/4 .86 ± .02 2.69
7365-425-1T-30N 4D 7.48 (190) 10
208
3 60 1750 E
32.2 1.2 41.4 105.9 2 125498 8/4 - 18/4 1.12 ± .02 0.43
230 29.8 1.2 35.6 123.6 2 125498 8/4 - 18/4 1.12 ± .02 0.43 460 14.9 1.2 17.8 61.8 2 125497 12/4 - 18/4 .86 ± .02 1.72
7365-425-88-30N 4D 7.48 (190) 10 575 3 60 1750 E 11.9 1.2 14.2 49.4 2 125497 12/4 - 18/4 .86 ± .02 2.69 7365-413-27-10N 4DM 6.69 (170) 5 208 1 60 1750 D 27.2 1.2 35.6 99.9 2 125498 8/4 - 18/4 1.12 ± .02 0.50 - - 2.66
230 F 25.4 1.2 30.2 112.4 2 125498 8/4 - 18/4 1.12 ± .02 0.50 - - 2.66
7365-413-1R-30N 4DM 6.69 (170) 5
208
3 60 1750 J
15.8 1.2 18.7 82.4 2 125496 12/4 - 18/4 .86 ± .02 0.72
230 15.0 1.2 17.2 92.4 2 125496 12/4 - 18/4 .86 ± .02 0.72 460 7.5 1.2 8.6 46.2 2 125497 12/4 - 18/4 .86 ± .02 2.88
7365-413-72-30N 4DM 6.69 (170) 5 575 3 60 1750 J 6.0 1.2 6.9 37.0 2 125497 12/4 - 18/4 .86 ± .02 4.32
7365-413-1S-30N 4DM 7.28 (185) 7.5
208
3 60 1750 H
23.8 1.2 28.5 105.9 2 125496 12/4 - 18/4 .86 ± .02 0.43
230 23.7 1.2 27.2 123.6 2 125496 12/4 - 18/4 .86 ± .02 0.43 460 11.9 1.2 13.6 61.8 2 125497 12/4 - 18/4 .86 ± .02 1.72
7365-413-87-30N 4DM 7.28 (185) 7.5 575 3 60 1750 H 9.5 1.2 10.9 49.4 2 125497 12/4 - 18/4 .86 ± .02 2.69
7365-413-1T-30N 4DM 7.87 (200) 10
208
3 60 1750 E
32.2 1.2 41.4 105.9 2 125498 8/4 - 18/4 1.12 ± .02 0.43
230 29.8 1.2 35.6 123.6 2 125498 8/4 - 18/4 1.12 ± .02 0.43 460 14.9 1.2 17.8 61.8 2 125497 12/4 - 18/4 .86 ± .02 1.72
7365-413-88-30N 4DM 7.87 (200) 10 575 3 60 1750 E 11.9 1.2 14.2 49.4 2 125497 12/4 - 18/4 .86 ± .02 2.69
▲ CORD SOLD SEPARATELY. CORD SUFFIX: XC - 30 FEET, XF - 50 FEET, XJ - 75 FEET, OR XL - 100 FEET.
IMPORTANT ! 1.) MOISTURE AND TEMPERATURE SENSORS MUST BE CONNECTED TO VALIDATE THE CSA LISTING.
2.) A SPECIAL MOISTURE SENSOR RELAY IS REQUIRED IN THE CONTROL PANEL FOR PROPER OPERATION OF THE MOISTURE SENSORS.CONTACT CP&S FOR INFORMATION CONCERNING MOISTURE SENSING RELAYS FOR CUSTOMER SUPPLIED CONTROL PANELS. 3.) THESE PUMPS ARE CSA LISTED FOR PUMPING WATER AND WASTEWATER. DO NOT USE TO PUMP FLAMMABLE LIQUIDS. NOT SUITABLE FOR ENVIRONMENTS CONTAINING GASOLINE OR HEXANE. 4.) INSTALLATIONS SUCH AS DECORATIVE FOUNTAINS OR WATER FEATURES PROVIDED FOR VISUAL ENJOYMENT MUST BE INSTALLED IN ACCORDANCE WITH THE NATIONAL ELECTRIC CODE ANSI/NFPA 70 AND/OR THE AUTHORITY
HAVING JURISDICTION. THIS PUMP IS NOT INTENDED FOR USE IN SWIMMING POOLS, RECREATIONAL WATER PARKS, OR INSTALLATIONS IN WHICH HUMAN CONTACT WITH PUMPED MEDIA IS A COMMON OCCURRENCE. 5.) A NON-SPARKING BREAKAWAY FITTING MUST BE USED TO VALIDATE THE EXPLOSION PROOF LISTING.
6.) WINDING RESISTANCE ± 7.5%. WINDING RESISTANCE MEASURED IN OHMS @ 25°C (BETWEEN LINES) AT MOTOR LEADS. 7.) PUMP RATED FOR OPERATION AT ± 10% VOLTAGE AT MOTOR. ** SELECT IMPELLER DIAMETER WHEN ORDERING.

11
CHART ‘F’
MODEL NO. SIZE
IMP. DIA.
INCHES
(MM)
HP VOLT PH HZ RPM
NEMA
START
CODE
FULL
LOAD
AMPS
SERVICE
FACTOR
SERVICE
FACTOR
AMPS
LOCKED
ROTOR
AMPS
DRIVER
FRAME
CORD
P/N ▲
CORD
SIZE
CORD
O.D.
WINDING
RESISTANCE
7365-429-1S-30N 4VL 5.51 (140) 7.5
208
3 60 3450 M
24.2 1.2 28.0 173.9 2 125496 12/4 - 18/4 .86 ± .02 0.40
230 25.4 1.2 28.2 201.0 2 125496 12/4 - 18/4 .86 ± .02 0.40 460 12.7 1.2 14.1 100.5 2 125497 12/4 - 18/4 .86 ± .02 1.58
7365-429-87-30N 4VL 5.51 (140) 7.5 575 3 60 3450 M 10.2 1.2 11.3 80.4 2 125497 12/4 - 18/4 .86 ± .02 2.47
7365-429-1T-30N 4VL 6.30 (160) 10
208
3 60 3450 K
30.8 1.2 37.0 173.9 2 125498 8/4 - 18/4 1.12 ± .02 0.40
230 30.1 1.2 34.8 201.0 2 125498 8/4 - 18/4 1.12 ± .02 0.40 460 15.1 1.2 17.4 100.5 2 125497 12/4 - 18/4 .86 ± .02 1.58
7365-429-88-30N 4VL 6.30 (160) 10 575 3 60 3450 K 12.1 1.2 13.9 80.4 2 125497 12/4 - 18/4 .86 ± .02 2.47 7365-430-25-10N 4VL 6.89 (175) 2 208 1 60 1750 G 10.4 1.2 12.1 59.1 2 125496 12/4 - 18/4 .86 ± .02 0.88 - 2.14
230 J 10.7 1.2 11.9 66.3 2 125496 12/4 - 18/4 .86 ± .02 0.88 - 2.14
7365-430-1M-30N 4VL 6.89 (175) 2
208
3 60 1750 P
7.4 1.2 8.3 58.2 2 125496 12/4 - 18/4 .86 ± .02 1.08
230 7.4 1.2 8.0 65.8 2 125496 12/4 - 18/4 .86 ± .02 1.08 460 3.7 1.2 4.0 32.9 2 125497 12/4 - 18/4 .86 ± .02 4.32
7365-430-70-30N 4VL 6.89 (175) 2 575 3 60 1750 T 3.9 1.2 4.2 37.0 2 125497 12/4 - 18/4 .86 ± .02 4.32 7365-430-26-10N 4VL 7.48 (190) 3 208 1 60 1750 D 14.9 1.2 118.5 59.1 2 125496 12/4 - 18/4 .86 ± .02 0.88 - 2.14
230 F 14.1 1.2 16.5 66.3 2 125496 12/4 - 18/4 .86 ± .02 0.88 - 2.14
7365-430-1P-30N 4VL 7.48 (190) 3
208
3 60 1750 K
9.7 1.2 11.4 58.2 2 125496 12/4 - 18/4 .86 ± .02 1.08
230 9.2 1.2 10.6 65.8 2 125496 12/4 - 18/4 .86 ± .02 1.08 460 4.6 1.2 5.3 32.9 2 125497 12/4 - 18/4 .86 ± .02 4.32
7365-430-71-30N 4VL 7.48 (190) 3 575 3 60 1750 N 4.5 1.2 4.9 37.0 2 125497 12/4 - 18/4 .86 ± .02 4.32 7365-430-27-10N 4VL 8.07 (175) 5 208 1 60 1750 D 27.2 1.2 35.6 99.9 2 125498 8/4 - 18/4 1.12 ± .02 0.50 - - 2.66
230 F 25.4 1.2 30.2 112.4 2125496 12/4 - 18/4 .86 ± .02 0.50 - - 2.66
7365-430-1R-30N 4VL 8.07 (175) 5
208
3 60 1750 J
15.8 1.2 18.7 82.4 2 125496 12/4 - 18/4 .86 ± .02 0.72
230 15.0 1.2 17.2 92.4 2 125496 12/4 - 18/4 .86 ± .02 0.72 460 7.5 1.2 8.6 46.2 2 125497 12/4 - 18/4 .86 ± .02 2.88
7365-430-72-30N 4VL 8.07 (175) 5 575 3 60 1750 J 6.0 1.2 6.9 37.0 2 125497 12/4 - 18/4 .86 ± .02 4.32
▲ CORD SOLD SEPARATELY. CORD SUFFIX: XC - 30 FEET, XF - 50 FEET, XJ - 75 FEET, OR XL - 100 FEET.
IMPORTANT ! 1.) MOISTURE AND TEMPERATURE SENSORS MUST BE CONNECTED TO VALIDATE THE CSA LISTING.
2.) A SPECIAL MOISTURE SENSOR RELAY IS REQUIRED IN THE CONTROL PANEL FOR PROPER OPERATION OF THE MOISTURE SENSORS.CONTACT CP&S FOR INFORMATION CONCERNING MOISTURE SENSING RELAYS FOR CUSTOMER SUPPLIED CONTROL PANELS. 3.) THESE PUMPS ARE CSA LISTED FOR PUMPING WATER AND WASTEWATER. DO NOT USE TO PUMP FLAMMABLE LIQUIDS. NOT SUITABLE FOR ENVIRONMENTS CONTAINING GASOLINE OR HEXANE. 4.) INSTALLATIONS SUCH AS DECORATIVE FOUNTAINS OR WATER FEATURES PROVIDED FOR VISUAL ENJOYMENT MUST BE INSTALLED IN ACCORDANCE WITH THE NATIONAL ELECTRIC CODE ANSI/NFPA 70 AND/OR THE AUTHORITY
HAVING JURISDICTION. THIS PUMP IS NOT INTENDED FOR USE IN SWIMMING POOLS, RECREATIONAL WATER PARKS, OR INSTALLATIONS IN WHICH HUMAN CONTACT WITH PUMPED MEDIA IS A COMMON OCCURRENCE. 5.) A NON-SPARKING BREAKAWAY FITTING MUST BE USED TO VALIDATE THE EXPLOSION PROOF LISTING.
6.) WINDING RESISTANCE ± 7.5%. WINDING RESISTANCE MEASURED IN OHMS @ 25°C (BETWEEN LINES) AT MOTOR LEADS. 7.) PUMP RATED FOR OPERATION AT ± 10% VOLTAGE AT MOTOR. ** SELECT IMPELLER DIAMETER WHEN ORDERING.

12
CHART ‘G’
MODEL NO. SIZE
IMP. DIA.
INCHES
(MM)
HP VOLT PH HZ RPM
NEMA
START
CODE
FULL
LOAD
AMPS
SERVICE
FACTOR
SERVICE
FACTOR
AMPS
LOCKED
ROTOR
AMPS
DRIVER
FRAME
CORD
P/N ▲
CORD
SIZE
CORD
O.D.
WINDING
RESISTANCE
7365-431-1S-30N 4VH 3.94 (100) 7.5
208
3 60 3450 M
24.2 1.2 28.0 173.9 2 125496 12/4 - 18/4 .86 ± .02 0.40
230 25.4 1.2 28.2 201.0 2 125496 12/4 - 18/4 .86 ± .02 0.40 460 12.7 1.2 14.1 100.5 2 125497 12/4 - 18/4 .86 ± .02 1.58
7365-431-87-30N 4VH 3.94 (100) 7.5 575 3 60 3450 M 10.2 1.2 11.3 80.4 2 125497 12/4 - 18/4 .86 ± .02 2.47
7365-431-1T-30N 4VH 4.33 (110) 10
208
3 60 3450 K
30.8 1.2 37.0 173.9 2 125498 8/4 - 18/4 1.12 ± .02 0.40
230 30.1 1.2 34.8 201.0 2 125498 8/4 - 18/4 1.12 ± .02 0.40 460 15.1 1.2 17.4 100.5 2 125497 12/4 - 18/4 .86 ± .02 1.58
7365-431-88-30N 4VH 4.33 (110) 10 575 3 60 3450 K 12.1 1.2 13.9 80.4 2 125497 12/4 - 18/4 .86 ± .02 2.47 7365-432-25-10N 4VH 4.72 (120) 2 208 1 60 1750 G 10.4 1.2 12.1 59.1 2 125496 12/4 - 18/4 .86 ± .02 0.88 - 2.14
230 J 10.7 1.2 11.9 66.3 2 125496 12/4 - 18/4 .86 ± .02 0.88 - 2.14
7365-432-1M-30N 4VH 4.72 (120) 2
208
3 60 1750 P
7.4 1.2 8.3 58.2 2 125496 12/4 - 18/4 .86 ± .02 1.08
230 7.4 1.2 8.0 65.8 2 125496 12/4 - 18/4 .86 ± .02 1.08 460 3.7 1.2 4.0 32.9 2 125497 12/4 - 18/4 .86 ± .02 4.32
7365-432-70-30N 4VH 4.72 (120) 2 575 3 60 1750 T 3.9 1.2 4.2 37.0 2 125497 12/4 - 18/4 .86 ± .02 4.32 7365-432-26-10N 4VH 5.12 (130) 3 208 1 60 1750 D 14.9 1.2 18.5 59.1 2 125496 12/4 - 18/4 .86 ± .02 0.88 - 2.14
230 F 14.1 1.2 16.5 66.3 2 125496 12/4 - 18/4 .86 ± .02 0.88 - 2.14
7365-432-1P-30N 4VH 5.12 (130) 3
208
3 60 1750 K
9.7 1.2 11.4 58.2 2 125496 12/4 - 18/4 .86 ± .02 1.08
230 9.2 1.2 10.6 65.8 2 125496 12/4 - 18/4 .86 ± .02 1.08 460 4.6 1.2 5.3 32.9 2 125497 12/4 - 18/4 .86 ± .02 4.32
7365-432-71-30N 4VH 5.12 (130) 3 575 3 60 1750 N 4.5 1.2 4.9 37.0 2 125497 12/4 - 18/4 .86 ± .02 4.32 7365-432-27-10N 4VH 5.71 (145) 5 208 1 60 1750 D 27.2 1.2 35.6 99.9 2 125498 8/4 - 18/4 1.12 ± .02 0.50 - - 2.66
230 F 25.4 1.2 30.2 112.4 2 125496 12/4 - 18/4 .86 ± .02 0.50 - - 2.66
7365-432-1R-30N 4VH 5.71 (145) 5
208
3 60 1750 J
15.8 1.2 18.7 82.4 2 125496 12/4 - 18/4 .86 ± .02 0.72
230 15.0 1.2 17.2 92.4 2 125496 12/4 - 18/4 .86 ± .02 0.72 460 7.5 1.2 8.6 46.2 2 125497 12/4 - 18/4 .86 ± .02 2.88
7365-432-72-30N 4VH 5.71 (145) 5 575 3 60 1750 J 6.0 1.2 6.9 37.0 2 125497 12/4 - 18/4 .86 ± .02 4.32
7365-432-1S-30N 4VH 6.50 (165) 7.5
208
3 60 1750 H
23.8 1.2 28.5 105.9 2 125496 12/4 - 18/4 .86 ± .02 0.43
230 23.7 1.2 27.2 123.6 2 125496 12/4 - 18/4 .86 ± .02 0.43 460 11.9 1.2 13.6 61.8 2 125497 12/4 - 18/4 .86 ± .02 1.72
7365-432-87-30N 4VH 6.50 (165) 7.5 575 3 60 1750 H 9.5 1.2 10.9 49.4 2 125497 12/4 - 18/4 .86 ± .02 2.69
7365-432-1T-30N 4VH 7.09 (180) 10
208
3 60 1750 E
32.2 1.2 41.4 105.9 2 125498 8/4 - 18/4 .86 ± .02 0.43
230 29.8 1.2 35.6 123.6 2 125498 8/4 - 18/4 1.12 ± .02 0.43 460 14.9 1.2 17.8 61.8 2 125497 12/4 - 18/4 .86 ± .02 1.72
7365-432-88-30N 4VH 7.09 (180) 10 575 3 60 1750 E 11.9 1.2 14.2 49.4 2 125497 12/4 - 18/4 .86 ± .02 2.69
▲ CORD SOLD SEPARATELY. CORD SUFFIX: XC - 30 FEET, XF - 50 FEET, XJ - 75 FEET, OR XL - 100 FEET.
IMPORTANT ! 1.) MOISTURE AND TEMPERATURE SENSORS MUST BE CONNECTED TO VALIDATE THE CSA LISTING.
2.) A SPECIAL MOISTURE SENSOR RELAY IS REQUIRED IN THE CONTROL PANEL FOR PROPER OPERATION OF THE MOISTURE SENSORS.CONTACT CP&S FOR INFORMATION CONCERNING MOISTURE SENSING RELAYS FOR CUSTOMER SUPPLIED CONTROL PANELS. 3.) THESE PUMPS ARE CSA LISTED FOR PUMPING WATER AND WASTEWATER. DO NOT USE TO PUMP FLAMMABLE LIQUIDS. NOT SUITABLE FOR ENVIRONMENTS CONTAINING GASOLINE OR HEXANE. 4.) INSTALLATIONS SUCH AS DECORATIVE FOUNTAINS OR WATER FEATURES PROVIDED FOR VISUAL ENJOYMENT MUST BE INSTALLED IN ACCORDANCE WITH THE NATIONAL ELECTRIC CODE ANSI/NFPA 70 AND/OR THE AUTHORITY
HAVING JURISDICTION. THIS PUMP IS NOT INTENDED FOR USE IN SWIMMING POOLS, RECREATIONAL WATER PARKS, OR INSTALLATIONS IN WHICH HUMAN CONTACT WITH PUMPED MEDIA IS A COMMON OCCURRENCE. 5.) A NON-SPARKING BREAKAWAY FITTING MUST BE USED TO VALIDATE THE EXPLOSION PROOF LISTING.
6.) WINDING RESISTANCE ± 7.5%. WINDING RESISTANCE MEASURED IN OHMS @ 25°C (BETWEEN LINES) AT MOTOR LEADS. 7.) PUMP RATED FOR OPERATION AT ± 10% VOLTAGE AT MOTOR. ** SELECT IMPELLER DIAMETER WHEN ORDERING.

13
CHART ‘H’
MODEL NO. SIZE
IMP. DIA.
INCHES
(MM)
HP VOLT PH HZ RPM
NEMA
START
CODE
FULL
LOAD
AMPS
SERVICE
FACTOR
SERVICE
FACTOR
AMPS
LOCKED
ROTOR
AMPS
DRIVER
FRAME
CORD
P/N ▲
CORD
SIZE
CORD
O.D.
WINDING
RESISTANCE
7365-444-27-10N 4VHA ** 5 208 1 60 1750 D 27.2 1.2 35.6 99.9 2 125498 8/4 - 18/4 1.12 ± .02 0.50 - 2.66
230 F 25.4 1.2 30.2 112.4 2 125496 12/4-18/4 .86 ± .02 0.50 - 2.66
7365-444-1R-30N 4VHA ** 5
208
3 60 1750 J
15.8 1.2 18.7 82.4 2 125496 12/4-18/4 .86 ± .02 0.72
230 15.0 1.2 17.2 92.4 2 125496 12/4-18/4 .86 ± .02 0.72 460 7.5 1.2 8.6 46.2 2 125497 12/4-18/4 .86 ± .02 2.88
7365-444-72-30N 4VHA ** 5 575 3 60 1750 J 6.0 1.2 6.9 37.0 2 125497 12/4-18/4 .86 ± .02 4.32
7365-444-1S-30N 4VHA 7.09 (180) 7.5
208
3 60 1750 H
23.8 1.2 28.5 105.9 2 125496 12/4 - 18/4 .86 ± .02 0.43
230 23.7 1.2 27.2 123.6 2 125496 12/4 - 18/4 .86 ± .02 0.43 460 11.9 1.2 13.6 61.8 2 125497 12/4 - 18/4 .86 ± .02 1.72
7365-444-87-30N 4VHA 7.09 (180) 7.5 575 3 60 1750 H 9.5 1.2 10.9 49.4 2 125497 12/4 - 18/4 .86 ± .02 2.69
7365-444-1T-30N 4VHA 7.87 (200) 10
208
3 60 1750 E
32.2 1.2 41.4 105.9 2 125498 8/4 - 18/4 1.12 ± .02 0.43
230 29.8 1.2 35.6 123.6 2 125498 8/4 - 18/4 1.12 ± .02 0.43 460 14.9 1.2 17.8 61.8 2 125497 12/4 - 18/4 .86 ± .02 1.72
7365-444-88-30N 4VHA 7.87 (200) 10 575 3 60 1750 E 11.9 1.2 14.2 49.4 2 125497 12/4 - 18/4 .86 ± .02 2.69
▲ CORD SOLD SEPARATELY. CORD SUFFIX: XC - 30 FEET, XF - 50 FEET, XJ - 75 FEET, OR XL - 100 FEET.
IMPORTANT ! 1.) MOISTURE AND TEMPERATURE SENSORS MUST BE CONNECTED TO VALIDATE THE CSA LISTING.
2.) A SPECIAL MOISTURE SENSOR RELAY IS REQUIRED IN THE CONTROL PANEL FOR PROPER OPERATION OF THE MOISTURE SENSORS.CONTACT CP&S FOR INFORMATION CONCERNING MOISTURE SENSING RELAYS FOR CUSTOMER SUPPLIED CONTROL PANELS. 3.) THESE PUMPS ARE CSA LISTED FOR PUMPING WATER AND WASTEWATER. DO NOT USE TO PUMP FLAMMABLE LIQUIDS. NOT SUITABLE FOR ENVIRONMENTS CONTAINING GASOLINE OR HEXANE. 4.) INSTALLATIONS SUCH AS DECORATIVE FOUNTAINS OR WATER FEATURES PROVIDED FOR VISUAL ENJOYMENT MUST BE INSTALLED IN ACCORDANCE WITH THE NATIONAL ELECTRIC CODE ANSI/NFPA 70 AND/OR THE AUTHORITY
HAVING JURISDICTION. THIS PUMP IS NOT INTENDED FOR USE IN SWIMMING POOLS, RECREATIONAL WATER PARKS, OR INSTALLATIONS IN WHICH HUMAN CONTACT WITH PUMPED MEDIA IS A COMMON OCCURRENCE. 5.) A NON-SPARKING BREAKAWAY FITTING MUST BE USED TO VALIDATE THE EXPLOSION PROOF LISTING.
6.) WINDING RESISTANCE ± 7.5%. WINDING RESISTANCE MEASURED IN OHMS @ 25°C (BETWEEN LINES) AT MOTOR LEADS. 7.) PUMP RATED FOR OPERATION AT ± 10% VOLTAGE AT MOTOR. ** SELECT IMPELLER DIAMETER WHEN ORDERING.

14
THREE PHASE 460-575 VOLT AC (orange molded plug)
THREE PHASE 460-575 VOLT AC (orange molded plug)
Power Cable
Power Cable
Motor Lead ID
Motor Lead ID
Green (Ground) Green
Black 1
Red 2
White 3
Jumpered Inside Cord
Automatically (No user jump-
ering required)
T4 & T7 Together
T5 & T8 Together
T6 & T9 Together
THREE PHASE 208-230 VOLT AC (black molded plug)
THREE PHASE 208-230 VOLT AC (black molded plug)
Power Cable
Power Cable
Motor Lead ID
Motor Lead ID
Green (Ground) Green
Black 1
Red 2
White 3
Jumpered Inside Cord
Automatically (No user
jumpering required)
T4, T5 & T6 Together
T11 & T7 Together
T13 & T9 Together
T12 & T8 Together
MOISTURE AND TEMPERATURE SENSORS
MOISTURE AND TEMPERATURE SENSORS
Power Cable
Power Cable
Lead ID
Lead ID
Brown P1 (Temperature Sensor)
Yellow P2 (Temperature Sensor)
Orange W1 (Moisture Sensor)
Blue W2 (Moisture Sensor)
SINGLE PHASE 208-230 VOLT AC (black molded plug)
SINGLE PHASE 208-230 VOLT AC (black molded plug)
Power Cable
Power Cable
Motor Lead ID
Motor Lead ID
Green (Ground) Green
Black 1 (Run)
Red 2 (Start)
White 3 (Common)
Jumpered Inside Cord
Automatically (No user
jumpering required)
T4, T5 & T6 Together
T11 & T7 Together
T13 & T9 Together
T12 & T8 Together
* Requires Start/Run Caps and Start Relay in panel *
FIGURE 3a
External Ground Note:
(Grd symbol) An external ground screw is provided on the side of the motor cap which can be
used for supplemental bonding connection where local codes permit or require such connection.

15
TYPICAL POWER CIRCUIT
Single Phase Cap Chart
HP RPM Cap Kit Start Relay Start Cap Run Cap
5 1750 133042 Mars 64 440MFD @ 330V 50MFD @370V
5 3450 133043 Mars 64 177MFD @ 330V 40MFD @440V
3 1750
Single Phase Start Components
FIGURE 3b

16
B-4.3) Overload Protection:
Current sensing overloads must be provided in the pump
control panel and should be properly sized for the full load
current of the pump. Three normally closed (N/C) thermal
sensors wired in series (one per phase) are embedded in the
motor windings and will detect excessive heat in the event
an overload condition occurs which will then trip and stop the
pump when wired in series with the pump contactor control
circuit. The thermal sensor leads marked P1 and P2 MUST
be connected in series with the stop button of the pilot circuit
of the magnetic motor controller located in the control panel
so that the thermostat will open the circuit before dangerous
temperatures are reached. A manual momentary start switch
is required to prevent the automatic restarting of the motor
when the thermostat resets. For a typical wiring diagram,
refer to Figure 4.
In the event of an over temperature condition, the source
of this condition should be determined and rectifi ed before
the pump is put back into normal operation. DO NOT LET
THE PUMP CYCLE OR RUN IF AN OVER TEMPERATURE
CONDITION OCCURS!
If current through the temperature sensor exceeds the values
listed, an intermediate control circuit relay must be used to
reduce the current or the sensor will not work properly.
TEMPERATURE SENSOR ELECTRICAL RATINGS
Volts Continuous
Amperes
Inrush
Amperes
110-120 3.00 20.0
220-240 2.00 18.0
B-4.4) Moisture Sensors:
A normally open (N/O) detector is installed in the pump seal
chamber, which will detect any moisture present, and a
continuity test resistor built into the motor. The test resistor
is rated 1 watt at 330K ohms. The moisture sensors MUST
be connected to moisture detector control in the control
panel which includes a continuity test circuit, see Figure 4
for typical wiring diagram. The normally closed (N/C) contact
of the moisture detector MUST be connected in series with
the stop button of the pilot circuit of the magnetic motor
controller. Wiring must be provided from the moisture detector
sensor probe leads of the motor designated W1 and W2 to
terminals 9 and 10 of the 2800-XXX control. Terminal pair
1-2 must be continuously energized from an A-C supply
line of electrical characteristics shown on the data table.
In the event of moisture detection, the pump should be
pulled and the source of the failure located and repaired. IF
MOISTURE DETECTION HAS OCCURRED, SCHEDULE
MAINTENANCE AS SOON AS POSSIBLE !
B-4.5) Control Panel and Electrical System:
The control panel and the electrical system MUST be properly
designed and wired to include at least, but not limited to the
following;
a. Proper grounding per NEC.
b. A temperature sensing circuit (See Fig. 4)
c. A moisture detection circuit with continuity test
circuit (See Fig. 5)
d. A level control system.
e. A main power manual disconnect and lock out.
f. A motor starter and overload system.
g. Start Capacitor, Run Capacitor & Start Relay
(single phase only).
B-5) When Used with a Variable Speed Drive:
Maximum turndown should not exceed 2:1. Drive should be set
to operate in constant torque mode.
TYPICAL THERMAL PROTECTION WIRING DIAGRAM
FIGURE 4

17
It is advisable that all three phase control panels be purchased
from the factory.
SECTION: C START-UP OPERATION
C-1) Check Voltage and Phase:
Before operating pump, compare the voltage and phase
information stamped on the pump’s identifi cation plate to the
available power.
C-2) Check Pump Rotation:
Before putting pump into service for the fi rst time, the motor
rotation must be checked. Improper motor rotation can result
in poor pump performance and can damage the motor and/
or pump. To check the rotation, suspend the pump freely,
momentarily apply power and observe the “kickback”.
“Kickback” should always be in a counter-clockwise direction
as viewed from the top of the pump motor housing and will
always be in the opposite direction of the rotation arrows cast
in the pump volute.
C-2.1) Incorrect Rotation for Three-Phase Pumps:
In the event that the rotation is incorrect for a three-phase
installation, interchange any two power cable leads at
the control box. Recheck the “kickback” rotation again by
momentarily applying power.
C-2.2) Test Procedure For Moisture Sensor Control:
With a moisture detection control, a normally closed push
button and neon indicating lamp is typically provided as a
means of checking the moisture sensing components. When
the push button is depressed, the indicating lamp will be
illuminated to indicate (A) power is supplied to the control,
(B) the control is operative, and (C) wiring to the moisture
sensing probes in the motor is intact. This procedure should be
performed periodically to confi rm integrity of the circuit.
C-3) Start-Up Report:
Included at the end of this manual is one start-up report sheet,
this sheet is to be completed as applicable. Return a copy to
Deming and store the second in the control panel or with the
pump manual. It is important to record this data at initial start-
up since it will be useful to refer to should servicing the pump
be required in the future.
C-3.1) Identifi cation Plate:
Record the numbers from the pump’s identifi cation plate on
the START-UP REPORT provided at the end of the manual for
future reference.
C-3.2) Insulation Test:
Before the pump is put into service, an insulation (megger)
test should be performed on the motor. The resistance values
(ohms) as well as the voltage (volts) and current (amps) should
be recorded on the start-up report. Pumps/systems with an
insulation value of less than 5 M-Ohms should be investigated
for moisture or damaged cables before proceeding.
C-3.3) Pump-Down Test:
After the pump has been properly wired and lowered into the
basin, sump or lift station, it is advisable to check the system
by fi lling with liquid and allowing the pump to operate through
it’s pumping cycle. The time needed to empty the system, or
pump-down time along with the volume of water, should be
recorded on the start-up report.
IMPORTANT! THE MAXIMUM ALLOWABLE STARTS PER
HOUR IS 15, EVENLY SPACED.
FIGURE 5

18
SECTION D: PREVENTATIVE MAINTENANCE
As the motor and seal chamber are oil-fi lled, no lubrication or
other maintenance is required, and generally Deming Pumps
will give very reliable service and can be expected to operate
for years of normal sewage pumping without failing. However,
as with any mechanical piece of equipment a preventive
maintenance program is recommended and suggested to
include the following checks:
1) Test moisture detector control “Test Switch” for
continuity of circuit. Water in the seal chamber will
energize a seal leak warning light at the control
panel. This is a warning light only and does not
stop the motor. It indicates the seal has leaked
and must be repaired. This should be done within 2
or 3 weeks to prevent further damage. See section
C-2.2.
2) Inspect impeller and body for excessive build-up or
clogging and repair as required per section E-2.
3) Inspect outer shaft seal and replace as required per
section E-3.
4) Check motor for ground leakage and proper amp
draw.
SECTION E: SERVICE AND REPAIR
NOTE: All item numbers in ( ) refer to Figures 10, 11, 12 & 13.
WARNING ! - Electrical power to the pump
motors must be disconnected and locked
out to prevent any dangerous electrical
hazards or personnel danger before any
service work is done to the pump.
CAUTION ! - Operating pump
builds up heat and pressure;
allow time for pump to cool
to room temperature before
handling or servicing.
E-1) Lubrication
E-1.1) Checking Oil
1. Place pump on it’s side, and drain oil into a clean, dry
container.
2. Check oil for contamination using an oil tester with a range
to 30 Kilovolts breakdown.
3. If oil is found to be clean and uncontaminated (measure
above 15 KV. breakdown), refi ll the seal chamber as per
section E-1.2.
4. If oil is found to be dirty or contaminated (or measures below
15 KV. breakdown), the pump must be carefully inspected
for leaks at the shaft seal (4), before refi lling with oil. To
locate the leak, perform a pressure test as per section E-1.3.
After leak is repaired, refi ll with new oil as per section E-1.2.
E-1.2) Replacing Oil:
Seal Chamber - Drain all oil from seal chamber and dispose
of properly. Refi ll with (see parts list for amount) (Oil amount
for seal chamber for 18 frame pumps = 47oz. +/- 1 oz.)
new cooling oil as per Table 1. An air space must remain to
compensate for oil expansion (See Fig. 10 and Fig. 11). Set
unit on side and fi ll.
IMPORTANT! - Do not overfill oil.
Overfilling of seal chamber with oil can
create excessive and dangerous hydraulic
pressure which can destroy the pump
and create a hazard. Overfilling oil voids
warranty.
E-1.3) Pressure Test:
Seal Chamber - Before checking the pump for leaks around
the shaft seal, the oil level should be full. Remove pipe plug.
Apply pipe sealant to pressure gauge assembly and tighten
into pipe plug hole. Pressurize motor housing to 10 P.S.I. Use
a soap solution around the sealed area and inspect joints for
“air bubbles”. If, after fi ve minutes, the pressure is still holding
constant, and no “bubbles” are observed, slowly bleed the
pressure and remove the gauge assembly. Replace the pipe
plug using a sealant. If the pressure does not hold, then the
leak must be located.
CAUTION! - Pressure builds up extremely
fast, increase pressure by “tapping” air
nozzle. Too much pressure will damage
seal. Do Not exceed 10 P.S.I. in seal
chamber.
TABLE 1 - COOLING OIL - Dielectric
SUPPLIER GRADE
BP Enerpar SE100
Conoco Pale Paraffi n 22
Mobil D.T.E. Oil Light
G & G Oil Circulating 22
Imperial Oil Voltesso-35
Shell Canada Transformer-10
Texaco Diala-Oil-AX
Woco Premium 100
E-2) Impeller and Volute Service:
E-2.1) Disassembly and Inspection:
To clean out the volute (11), or clean out or replace impeller
(6), disconnect power, remove cap screws (2) then vertically
lift motor assembly from the pump body (11). Clean out the
volute, if necessary, clean and examine impeller (6) for pitting
or wear, replace if required. To remove Impeller (6), remove
cap screw (8) and washer (8A). The impeller is keyed onto the
shaft with a square key (7) and to remove, pull impeller straight
off the shaft using a wheel puller if required. Inspect o-ring (9)
and replace if cut or damaged. Before reinstallation, check the
motor shaft and impeller bore for damage.
E-2.2) Reassembly:
To install impeller (6), apply a thin fi lm of oil to motor shaft
and slide impeller straight onto shaft, keeping keyways
lined up. Drive key (7) into keyway. Thread cap screw (8)
and washer (8A) into shaft and torque to 45 ft. lbs. Rotate
impeller to check for binding. Place o-ring (9) on seal plate
pilot diameter lining up holes and install impeller and motor
assembly onto volute (11). Loctite cap screws (2), insert into
volute and motor assembly and torque to 35 ft. lbs. Check for
free rotation of motor and impeller.

19
E-3) Outer Shaft Seal Service:
CAUTION ! - Handle seal parts with extreme care.
DO NOT scratch or mar lapped surfaces.
E-3.1) Disassembly and Inspection:
To expose outer shaft seal (4) for examination, remove
Impeller and Volute per Section E-2.1. Set motor assembly
(1) in the inverted position to prevent loss of oil. Remove
snap ring from motor shaft, then retaining ring (5), spring (4C)
and rotating member (4B) from shaft, See Figure 6. Examine
all seal parts and especially contact faces. Inspect seal for
signs of wear such as uneven wear pattern on stationary
members, chips and scratches on either seal face. DO NOT
interchange seal components, replace the entire shaft seal
(4). If replacing seal, remove stationary (4A) from mounting
plate by prying out with fl at screw driver.
E-3.2) Reassembly:
Lightly oil (DO NOT use grease) outer surface of stationary
member (4A). Press stationary member (4A) fi rmly into
mounting plate using a seal pusher but the seal pusher is to
come in contact with seal face (See Fig. 7).
Make sure the stationary member is in straight and that
the rubber ring is not out of it’s groove. Lightly oil (DO NOT
use grease) shaft and inner surface of bellows on rotating
member (4B) see Figure 8. With lapped surface of rotating
member (4B) facing inward toward stationary member (4A),
slide rotating member (4B) onto shaft using a seal pusher,
until lapped faces of (4A) and (4B) are together. (See Fig. 8).
IMPORTANT ! - It is extremely important to keep
seal faces clean during assembly. dirt particles
lodged between these faces will cause the seal to
leak.
Place spring (4C) over shaft and in place on rotating member
(4B), making sure it is seated on retainer and not cocked or
resting on bellows tail. Slide retaining ring (5) over shaft and
let rest on spring (4C). Replace snap ring onto motor shaft.
Inspect gasket (9) and replace if cut or damaged. Assemble
impeller and volute as outlined in paragraph E-2.2.
FIGURE 8
Rotating Member (4B)
Bullet
Motor
Seal Pusher
Stationary
FIGURE 7
Stationary Member (4A) Pol-
ished Face Out
Motor Mounting Plate Seal Pusher
FIGURE 6

20
SECTION: F REPLACEMENT PARTS
F-1 ORDERING REPLACEMENT PARTS:
When ordering replacement parts, ALWAYS furnish the
following information:
1. Pump serial number and date code. (Paragraph F-4)
2. Pump model number. (Paragraph F-3)
3. Pump part number. (Paragraph F-2)
4. Part description.
5. Item part number.
6. Quantity required.
7. Shipping instructions.
8. Billing Instructions.
F-2 PART NUMBER:
This number is used for ordering and obtaining information.
F-3 MODEL NUMBER:
This designation consists of numbers and letters which
represent the discharge size, series, horsepower, motor phase
and voltage, speed and pump design. This number is used for
ordering and obtaining information.
F-4 SERIAL NUMBER:
The serial number block will consist of a six digit number, which
is specifi c to each pump and may be preceded by an alpha
character, which indicates the plant location. This number will
also be suffi xed with a four digit number, which indicates the
date the unit was built (Date Code).
EXAMPLE: A012345 0490.
Reference the six digit portion (Serial Number) of this number
when referring to the product.
