Quick Start Guide
T40
GIGAWORKS®
SERIES II
High-end Speakers

• Connectivity Diagram
[ • Optional (sold separately)
1Right Speaker
2Left Speaker
To Wall Outlet
(Disconnect when not in use
for several days)
3
To Analog Audio
Source
5
Power Supply Adapter
(Types of adapter may vary in
different countries)
4
Headphone Jack
10
8Treble Level Control
6Volume Control with
Power ON/OFF Switch
5a Optional:
Audio / Video Cable is normally
provided with TV,DVD or
game console
9Bass Level Control
Object And Liquid Entry
Never push any object
through the openings, as
this can result in a fire,
electric shock or damage.
Do not spill liquids on
the product.
7Auxiliary Line-in
For Audio Devices
Red
White
Yellow
Lime
5a
5a
5
G
G
2
3
4
1
[
10
1
6
7
89
The speaker enters power saving
mode when no audio is detected
for approx 10 mins. t will
automatically power up when
audio is detected. Alternatively
you can power OFF and ON your
speaker. *
Specifications
Creative GigaWorks T40 Series II
Power ou pu
Sa elli e speaker 16 watts RMS per channel
Signal o Noise Ra io (SNR) 80dB
Frequency Response 50Hz - 20kHz
For 20V AC input
This produc opera es from he supplied 20V AC
2 8A power adap er
For 27V DC input
This produc opera es from he supplied 27V DC
1 7A power adap er
This speaker has an au o power managemen
fea ure which complies wi h energy efficiency
regula ion required by cer ain regions (Europe)
