Crelling Harness 27 User manual

Model 27 Press
Designed to oer postural support and a certain degree of restraint to children and adult
to keep them in an upright sing posion.
Model 27 will t:
 Single vehicle seats, including low or high backed
 Split Backed double seats, including low or high backed
 Aircra seats by many leading Airlines
 Other types of single seang.
The harness consists of a full body harness connected to a
back pad which is ed horizontally around the vehicles seat
back with two horizontal xing straps.
Model 27 is used on aircra seats by many leading
airlines. The two horizontal straps do not interfere with
the passenger behind using the drop down trays.
We always advise our clients to seek permission from the
airlines to use our harnesses prior to departure.
Available in three Sizes:
Up to 5 yrs 27I
5 yrs to 8 yrs 27A
9 yrs to Adult 27B
IMPORTANT:
This harness is not classed as a safety harness.
The vehicle safety belt MUST be worn over the top of our
harness unless they are exempt for medical reasons.
The waist belt on this harness is ed with a Press Release
buckle for those passengers who won’t undo the buckle
or need to be released quickly from the harness
Oponal Extra
A Houdini Stop can be ed to this harness.
This chest strap ensures the passenger stays safely
and correctly posioned within their harness.
It simply clips on to each shoulder strap of the
harness to help prevent the passenger from
separang the shoulder straps in order to escape.
M.27A ed to an aircra seatM.27A - 5 yrs to 8 yrs M.27 Fixing Straps
Crelling Harnesses For Disabled Ltd.
12 Crescent East, Thornton-Cleveleys, Lancashire, FY5 3LJ
Tel: [phone] Fax: [phone] Email: [email protected] Website: www.crelling.com

Model 27 Fing Instrucons
5. Unfasten the Waist Belt & posion the Understrap [f] centrally on the seat cushion
6. If the passenger is under 135cm place a Booster Seat or Cushion on top of the Understap to comply with child seat safety
legislaon (See last page for further informaon).
7. Posion the Back Pad [g] & Body Harness on the seat so that the waist belt will be in line with the waist when the passenger sits
down.
8. The harness is now ready for the passenger to be seated.
9. With the passenger sing in the most upright posion as possible, bring their arms through the shoulder straps [d].
10. Now bring the understrap [f] up between the legs and loop it back onto the waist belt over the buckle [e].
11. Connect the waist belt buckle [e] to fasten the harness. Posion the buckle centrally at waist level on the passenger.
Nb. The Waist Belt can move freely through the leatheree Back Pad [g]
12. Adjust all straps to t ghtly yet comfortably by pulling the tail-ends of strapping through the Adjuster Buckles [i].
13. If using the Houdini Stop Chest Strap [j], aach to Shoulder Straps underneath the Adjuster Buckles [i]. See instrucon provided.
14. Ensure that the three Comfort Pads [g] are in posion over the Adjuster Buckles [i] on the Shoulder & Under Straps.
15. Fasten the vehicle safety belt over the top of the Model 27 Harness.
16. To remove the passenger from the harness - Unfasten the buckle on the waist belt at the centre-front.
NB. A ng video can be found on our website - hps://crelling.com/model-27.html
1. If ng a brand new harness, remove any Rubber Bands & unfasten the two Horizontal Fixing Straps [a].
2. Place the back pad [g] of the harness against the front of the back rest & pass the two the Horizontal Fixing Straps around the seat
back.
3. Feed the tail-ends of the two Horizontal Fixing straps through the Aluminium Bar Buckles (see diagram [b]) & pull to ghten
around the seat back as securely as possible.
4. Each tail end should then be passed through the Sliplock Slide [c] to prevent the Fixing Straps [a] from loosening during transit.
[b] 50mm Aluminium
[c] 50mm Sliplok slide
[a] Horizontal Fixing Straps
[d] Shoulder Straps
c/w Velcro
Comfort Sleeves
[e] Waist Belt Buckle
[f] Understrap [g] Back Pad

Emergency Seat Belt Cuer (Oponal Extra)
We strongly recommend that a seat belt cuer is kept in the vehicle
as a safety precauon for those harnesses ed with a Steel Safety Buckle.
A simple but eecve device for ensuring the occupants of a car are able
to exit quickly and safely, parcularly in the overturned car.
It is perfectly safe as the blade is encased.
Cat. Ref: SK
Webbing is threaded through the sliding bar buckle
Loose ends of webbing are oen passed back through these slides to prevent slippage
& to prevent the Fixing Straps from loosening during transit.
50mm Aluminium Bar Buckle
Sliplock Slide
[h]
To Tighten Straps
Simply pull the tail-end of
the webbing strap.
The Adjuster will lock the
webbing into posion
To Extend Straps
The 40mm Adjuster is slightly spring loaded
to lock the webbing into posion.
To release the webbing you need to squeeze the
Adjuster whilst pulling on the lower
webbing strap.
[g]
[j] [i]
Comfort Sleeves
Velcro Comfort Sleeves will be supplied with each harness.
These can be ed around the shoulder Straps & under strap where required.
Squeeze Adjuster
to release webbing
40mm Adjuster Buckle

Model 27 Being ed to a Monarch Aircra Seat
Accepted for passengers with special needs by many airlines Including:

Booster Seats
IMPORTANT: Our harnesses must NOT be used with child car seats already ed with the 5 point harness.
 The model 27 harness is ed directly onto the vehicle seat rst, prior to ng the high backed booster seat.
 The high backed booster seat is then ed onto the vehicle seat.
 The shoulder straps and waist belt of the Crelling harness are then brought around the booster seat.
 The shoulder straps should slot between the shoulder of the booster seat & the head rest.
 The harness is now ready for the child to get into.
 Place the child into the booster seat & fasten the harness according to the Model 27 ng instrucons.
 Once the child is securely & comfortably fastened in the harness, fasten the vehicle seat belt over the top of our
 harness ensuring that it passes through the ‘belt guides’.
 Please ensure that the high backed booster seat is ed according to the manufacturers instrucons & the head rest
is adjusted correctly. A properly adjusted headrest ensures the opmum distribuon of the diagonal belt & provides
your child with the desired protecon and comfort.
All our range of children’s vehicle harnesses can
be used in conjuncon with booster cushions
Booster cushions
The Model 27 harness can be used on some high backed booster seats
with height-adjustable headrests, which extend to grow with the child
such as the Britax Adventure.
Some of our customers have found that they work very well together
oering postural support or extra security for those with learning
dicules.
NB. It is oen necessary to purchase Model 27 harness in a larger
size harness to accommodate the child car seat.
IMPORTANT: This harness is not classed as a safety harness.
The vehicle safety belt MUST be worn over the top of our harness unless they are exempt for medical reasons.
The combinaon of the exisng safety belt & the secondary harness oers added security for the passenger.
Britax Adventure
15 to 36kg (approx. 4 to 11 years)
Height-adjustable
headrest
