Caliber 13576 User manual

- Page 1 - Assembled on May 19, 2020 CI05067, rev E
Caliber Sled Wheels Assembly
Instructions for PN 13576 and 13579
Caution:
•Read all instructions before assembling or using Sled Wheels. Follow the steps in order.
•Only use Sled Wheels as intended, following all instructions contained herein for assembly and adjustment.
•Do not exceed 12 miles per hour when driving a snowmobile with Sled Wheels.
•The handle is a lever used to raise the skis by pushing down on it; do not lift the handle while Sled Wheels are
engaged on ski. Lift the ski loop instead, if necessary.
•Relieve the load on the latch before releasing it by pushing the handle and ski to the ground.
•Always use the safety pin to lock the latch in place.
•Remove Sled Wheels from the ski when not in use.
Tools needed: Torx T-55 wrench, 5/32” Hex wrench (supplied), #2 Phillips screwdriver
Assembly time: about 20 minutes
Parts list:
Item
Description
QTY
Item
Description
QTY
1
Wheel
4
12
BHCS, Hex, 1/4-20 x
0.5”
2
2
Axle bolt
4
13
BHCS, Hex, 1/4-20 x
1.0”
8
3
Washer, ½”
4
14
Nut, Locking, Hex,
1/4-20
8
4
Nut, Locking,
Hex, ½-13
4
15
Nut, Square, 1/4-20
4
5
Saddle/Latch
assembly
2
16
Washer, ¼”
12
6
Arm, Left
2
17
Extender, Finger,
Right
1
7
Arm, Right
2
18
Extender, Finger, Left
1
8
Hex Wrench, 5/32
1
19
Screw, Thread
Forming, #8-16
4
9
Telescoping
Handle
2
20
Safety Pin w/ lanyard
and Caution Card
2
10
T-Handle
2
21
Grease, 1cc
1
11
BHCS, Hex, 1/4-
20 x 1.5”
2
Table 1

- Page 2 - Assembled on May 19, 2020 CI05067, rev E
Assembly:
1. Remove the arms from the T-handles, which have been installed in the storage position for shipping. Use a flat
blade screwdriver to spread the arm clamp apart if necessary to ease removal.
2. Use Table 2 to determine which
type of ski you are using to
determine the finger covers you
will use. If your ski is not listed,
use the following instructions.
Most snowmobile skis have a
center keel/carbide on the
bottom, some also have two
raised guides on the ski
undersides to help grip. A third
type is uneven. The image to the
right shows the skis from the
rear.
3a. For skis that are flat or have even guides, assemble the
finger extenders (17 and 18 - be sure to use the left cover on the left
arm, and right on right). Tap the rubber on a hard surface to ensure
it is fully seated. Secure with a self-tapping screw (19).
3b. For skis with uneven keels or carbides (i.e. SkiDoo Pilot skis
and others), use a finger extender (17 and 18) as before, but cut the
extender on the carbide side of the ski using a sharp blade. Use
the horizontal lines on the extenders as a guide. Tap the rubber on
a hard surface to ensure it is fully seated. Secure with self-tapping
screws (19). This will make your Sled Wheels left or right
handed, so be sure to use them on the correct ski, or your skis will
not sit flat.

- Page 3 - Assembled on May 19, 2020 CI05067, rev E
3. Apply one fourth of the grease
(22) to each axle (2) and
assemble a wheel (1), ½”
washer (3), arm (6 and 7), and
locking hex nut (4). Tighten
the axle until snug, then
tighten the axle 1/4 - 1/2 turn
more (approximately 20 ft-lbs)
with a T-55 Torx wrench (a
5/16” or 8mm hex wrench can
be used in a pinch). Repeat
for each of the three remaining
wheels.
4. Slide the assembled arms onto the splined T-Handle (10) and adjust the arm width per Table 2 (on last page of
instructions) and your ski type, or adjust approximately ¼”-½” wider than the ski. Some sleds have spindle bolts
that stick beyond the edge of the ski, for these sleds adjust the arms wider to avoid the bolt (or cut the excess bolt
off). The arm angle can also be adjusted 15° to accommodate tall or short ski loops. Most sleds work best at 15°.
Use two ¼-20 x 1.0” bolts (13), two ¼” washers (16), and two ¼ locking hex nuts (14) to secure each arm in
place using the supplied 5/32” hex wrench (8) (approximately 4 ft-lbs). Do not overtighten. Make sure both arms
are installed at the same angle.

- Page 4 - Assembled on May 19, 2020 CI05067, rev E
5. Slide the Saddle/Latch assemblies (5) over the Telescoping Handles (9) with the latch side first. Slip a ¼” square
nut (15) into the Telescoping Handle T-slot, and secure with a ¼-20 x 1.5” screw (11), and a ¼” washer (16). Use
Table 2 to find the location of the saddle for your ski. Move the saddle to the correct location per the table. The
image below shows a saddle at 4”. If your ski is not in the table, the saddle/latch should be at about 7”, and will
be adjusted later. Leave the safety pin out of its hole in the latch.

- Page 5 - Assembled on May 19, 2020 CI05067, rev E
6. Place a ¼” square nut (15) in the T-slot of the T-Handle and then slide a Telescoping handle onto the T-handle,
lining up the nut with the hole in the Telescoping Handle. Install a ¼-20 x 0.5” screw (12) and ¼” washer (16).
Use Table 2 to find the extension for your ski. Move the telescoping handle to the correct location per the table.
The image below shows the end of the telescoping handle at 7”. Tighten the screw (approximately 4 ft-lbs). If
your ski is not in the table, the saddle/latch should be at about 7-8”, and the handle will be adjusted to fit the ski
later.

- Page 6 - Assembled on May 19, 2020 CI05067, rev E
Adjustment:
Key adjustments
1. If you have used Table 2 to pre-set your Sled Wheels, proceed to step 5 below.
2. If not done previously, adjust the width of each Sled Wheel assembly to be approximately ½” wider than the ski.
Include space to avoid the ski spindle bolt if it sticks out past the ski. Tighten, but do not over tighten the arm
clamp screws (approximately 4 ft-lbs).

- Page 7 - Assembled on May 19, 2020 CI05067, rev E
3. Position one Sled Wheel assembly
above the ski so that the Sled Wheels
axle is directly above the ski spindle
axle. Loosen the Telescoping handle
screw and move the handle so it hits the
end of the ski. Tighten the screw
(approximately 4 ft-lbs).
4. Adjust the saddle/latch assembly so that
the latch will close at the peak of the ski
loop. Tighten the saddle screw
(approximately 4 ft-lbs).
5. Loosen the latch adjustment screw three
turns so that the lower portion of the
latch is moveable. Slide the latch all the
way down.

- Page 8 - Assembled on May 19, 2020 CI05067, rev E
6. Grab one Sled Wheel assembly by the handle, hold it vertically, and slide the fingers under the ski until the wheel
axle is in line with the spindle bolt. You may need to lift the ski loop to create space under the ski. Rotate the
assembly down to raise the ski and check the length of the telescoping handle. Adjust as necessary to keep the
Sled Wheels axle and the spindle axle in line.
7. When the handle and saddle(Upgraded in
Black Nylon) are in place, and the Sled
Wheels assembly is installed onto the ski,
the latch should swing open and close
around the ski loop. Slide the latch up
until it just touches the ski loop and
tighten the screw (approximately 4 ft-
lbs). Do not over-tighten.
8. Fine adjustment: If the ski tips forward or backward, Sled Wheels need slight adjustments. If the ski tips
forward, the Sled Wheels axle is behind the ski spindle axle. Shorten the telescoping handle until the two axles
line up. Conversely, if the ski tips backwards, lengthen the telescoping handle. Also, check your ski bushings;
they should be tight and not worn. Good bushings will help your ride and help keep your ski horizontal when
riding with Sled Wheels.
9. Adjust the second assembly to the same locations as the first.

- Page 9 - Assembled on May 19, 2020 CI05067, rev E
Attach to skis:
1. Grab one Sled Wheel assembly by the handle, hold it vertically, and slide the fingers under the ski until the wheel
axles are in line with the spindle axle. You may need to lift the ski loop to create space under the ski. Rotate the
assembly down to raise the ski until the latch closes around the ski loop. Install and lock the safety pin. Repeat
for the second ski.
Caution: Do not exceed 12 miles per hour while driving on Sled Wheels.
Detach from skis:
1. Remove safety pin from latch. Push down on handle to remove the weight of the snowmobile, and push the latch
lever to release the ski loop.
2. Slowly move the handle up. Remove Sled Wheels from the ski, lifting the ski loop if necessary. Close latch and
replace safety pin. Store fully assembled, ready for your next ride!

- Page 10 - Assembled on May 19, 2020 CI05067, rev E
SKI-DOO
SKI
Ski Stop
Extension
Saddle
Position
Arm
Width
Extenders
SKI
Ski Stop
Extension
Saddle
Position
Arm
Width
Extenders
DS 2
6
6 3/8
6 3/4
Do not cut
PILOT 5.9
6
5 1/2
6 1/4
Cut one
extender to fit
DS 3
6
6 3/8
6 3/4
Do not cut
PILOT TS
5 1/2
6 3/8
6 1/4
Cut one
extender to fit
POLARIS
GRIPPER
5 1/2
6 7/8
7 1/4
Do not cut
PRO-STEER
5 1/2
6 7/8
7
Do not cut
ARCTIC CAT
PROCLIMB 7
8 1/2
6 3/8
7 3/8
Do not cut
PROCROSS 6
7 5/8
6 3/8
6 5/8
Do not cut
YAMAHA
GEN 3 TUNER
5 1/2
6 7/8
6 1/2
Do not cut
MOUNTAIN
5 1/2
6 7/8
6 1/2
Do not cut
C&A PRO
MINI
0
3 7/8
5 1/4
Do not cut
XPT
7 1/8
3 7/8
7 1/2
Do not cut
XT
7 1/2
3 7/8
7 1/2
Do not cut
RZ
7 1/8
3 7/8
6 1/2
Do not cut
SLP
MoHawk
3
6 3/8
7 1/2
Do not cut
Table 2
Check http://www.caliberproductsinc.com/snowmobile-trailer-accessories/SledWheels.php for updated instructions.
CALIBER, INC. LIMITED LIFETIME WARRANTY
Caliber, Inc. warrants that this product will be free from defects in material or workmanship under normal use, installation and service. Several parts of Sled Wheels are
considered wear items: the wheels, rubber finger covers and extenders, rubber hook plate, and rubber latch cover, and are available for purchase from Caliber dealers.
Caliber, Inc. reserves the right, before having any obligation under this limited warranty, to inspect the damaged Caliber product. All warranty shipping costs for inspection
shall be borne solely by the purchaser. This limited warranty is non-transferable. Contact Caliber, Inc. at www.caliberproductsinc.com or at 952-985-9999 for warranty
service procedures.
DISCLAIMER
Caliber, Inc. shall not be liable for any special, incidental or consequential damages, including, but not limited to, lost revenues, lost profits, personal injury, damage to
property, and third-party claims, arising out of any warranty, contract, statutory or tort. Notwithstanding the term of any limited warranty or any warranty implied by law, or
in the event that any limited warranty fails of its essential purpose, in no event will Caliber’s entire liability exceed the purchase price of this product.
CALIBER®
952-985-9999
www.caliberproductsinc.com
Notice: The Hook & Saddle assembly for this kit has been upgraded to a 2.5X stronger nylon(Black) material.
For best results on loading and unloading in your trailer please use Caliber Edge Glides 2.0(#13390-13392) on
your Door Transitions.
