Cres Cor R171S1828 Manual

5925 Heisley Road • Mentor, OH 44060-1833
Series R-171-S
Refrigerated Cabinets FL-2314
Rev. 3 (10/06) Page 1 of 4
OPERATING and MAINTENANCE INSTRUCTIONS
for Cres Cor Refrigerated Cabinets,
Model R-171-S Series
Call Toll-free: 877-CRES COR (273-7267) • Fax: [phone] • www.crescor.com
Model No. Volts Amps Hertz Phase NEMA
R171SUA10
R171S1828 120 7.8 60 1 5-15P
R171SUA10240
R171S1828240 240 3.7 60 1 6-15P
R171SUA20
R171S1856 120 8.6 60 1 5-15P
R171SUA20240
R171S1856240 240 4.2 60 1 6-15P
Note: The above model numbers are basic models. They may be followed by letters: M, L, D or
ending with S, Zand/or CAN.
CONTROL PANEL
HOW TO INSTALL THE CABINET:
Remove all packing material from inside the1.
cabinet.
INSTALL ALL ANGLES2. BEFORE UNIT IS
TURNED ON
Allow enough clearance around cabinet for air3.
flow.
HOW TO OPERATE:
Plug cord into proper wall outlet.1.
Turn the power switch to “ON”. Light will come2.
on and compressor will start.
Listen closely for the compressor. It will be slightly
loud at first, then quiet down.
HOW TO OPERATE (Continued):
If you do not hear the compressor running, turn power
switch to “OFF” right away. See “Troubleshooting”
(page 3).
3. Pre-chill the cabinet for approximately 40 minutes
or until the temperature reaches approximately
38°F. Load the food.
DO NOT PUT HOT FOOD INTO COLD
CABINET!
TO SHUT UNIT OFF:
Turn power switch to “OFF”.

5925 Heisley Road • Mentor, OH 44060-1833
OPERATING and MAINTENANCE INSTRUCTIONS
for Cres Cor Refrigerated Cabinets,
Model R-171-S Series
Series R-171-S
Refrigerated Cabinets FL-2314
Rev. 3 (10/06) Page 2 of 4
Call Toll-free: 877-CRES COR (273-7267) • Fax: [phone] • www.crescor.com
Unplug cord from wall.1. Do NOT hose cabinet with water.2. Do NOT get water into bottom compartment.3. Do NOT use abrasives or harsh chemicals.4.
■Wipe up spills as soon as possible.
■Clean regularly to avoid heavy dirt build-up.
Cleaning Hints:
Use the mildest cleaning procedure that will do the1.
job.
Always run in the direction of polish lines to avoid2.
scratching the surface.
Use only a soft cloth, sponge, fibrous brushes,3.
plastic or stainless steel pads for cleaning and
scouring.
Rinse thoroughly with fresh water after every4.
cleaning operation.
Always wipe dry to avoid water marks.5.
HOW TO CLEAN THE CABINET:
BEFORE cleaning
the cabinet:
Soil Cleaner Method
CABINET
Inside
and
Outside
(Stainless Steel)
ROUTINE CLEANING Soap, Ammonia, or mild
*detergent and water.
1. Sponge on with cloth.
2. Rinse with water.
3. Wipe dry.
STUBBORN SPOTS
AND STAINS Mild abrasive made for
stainless steel. 1. Apply with damp sponge or cloth. 2. Rub lightly.
GREASE, OIL Chemical oven cleaner for
stainless steel. Follow oven cleaner manufacturer’s directions.
HARD WATER
SPOTS & SCALE Vinegar 1. Swab or wipe with cloth.
2. Rinse and dry.
*Mild detergents include soaps and non-abrasive cleaners.
HOW TO REVERSE DOOR HARDWARE FOR OPPOSITE HAND:
(Single Door Cabinet ONLY)
Remove hinge covers with a screwdriver.1.
Open door and lift up to remove door from cabinet.2.
Unscrew and re-mount the hinges and latch strike to the opposite3.
sides of the cabinet.
Remove the door hinges and the door latch. Turn hinges and handle4.
over and remount in the same holes
Remove plastic cam from each hinge, rotate cam 180° with “V”5.
groove on cam toward inside of cabinet. Reseat cam into hinge.
Plug all the extra holes with screws.6.
Put door onto cabinet and adjust as necessary.7.
Snap on hinge covers..8.
WARNING

5925 Heisley Road • Mentor, OH 44060-1833
Series R-171-S
Refrigerated Cabinets FL-2314
Rev. 3 (10/06) Page 3 of 4
OPERATING and MAINTENANCE INSTRUCTIONS
for Cres Cor Refrigerated Cabinets,
Model R-171-S Series
Call Toll-free: 877-CRES COR (273-7267) • Fax: [phone] • www.crescor.com
MAINTENANCE:
HOW TO CHARGE AND SERVICE THE REFRIGERATION SYSTEM
Note: The refrigerator is shipped fully charged.
The high-side pressure should be approximately 175 PSI;
low pressure should be approximately 18 PSI at 75° F (24° C) room temperature.
The charge should be 18 ounces of R134a.
Service valves are located on the condenser/compressor assembly.
Failure Probable Cause
1. Power light off 1. Power Cord
2. Compressor off 2. Power supply down
3. Evaporator fan on, Power
light on and Compressor off
3a. Thermostat defective
3b. Defective start relay (compressor)
4. Compressor on and cabinet
not cooling
4a. Low charge
4b. Frost build-up on evaporator coil
4c. Evaporator fan defective
4d. Thermostat defective
5. Compressor starts and stops;
cabinet not cooling
5a. Low Charge
5b. Faulty start capacitor (compressor)
5c. Faulty start relay (compressor)
6. Noisy compressor 6a. Low charge
6b. Defective
TROUBLE-SHOOTING GUIDE
Unit Condition:
Unit is plugged in. Switch is ON.
NOTES:
1. Thermostat is pre-set at approximately 38°F (3.8°C). Temperature adjustment can only be made by a Service Agency.
2 For replacement of the electrical parts, refer to our list of authorized service centers (FL-1400).

5925 Heisley Road • Mentor, OH 44060-1833
OPERATING and MAINTENANCE INSTRUCTIONS
for Cres Cor Refrigerated Cabinets,
Model R-171-S Series
Series R-171-S
Refrigerated Cabinets FL-2314
Rev. 3 (10/06) Page 4 of 4
Call Toll-free: 877-CRES COR (273-7267) • Fax: [phone] • www.crescor.com
REPLACEMENT PARTS:
Description 120V 240V
Condenser/Compressor Assembly 0854-040 0854-041
Cord Set 0810-029-05 0810-039-06
Door Assembly 1221-553-K 1221-553-K
Evaporator Assembly for R171SUA10, 1828 1416-068-K 1416-070-K
Evaporator Assembly for R171SUA20, 1856 1416-069-K 1416-071-K
Gasket Kit 0861-261 0861-261
Hinge Kit 0519-087-K 0519-087-K
Pilot Light “Power ON” 0766-094 0766-095
Post 0696-237 0696-237
Receptacle 0713-057 0713-058
Switch, ON/OFF 0808-116 0808-116
Terminal Block 0852-091 0852-091
Thermometer Kit 5238-035-K 5238-035-K
Thermostat (cold control) 0854-043-K 0854-043-K
Valve, Thermal Exp. (R171SUA10, 1828) 0854-042-K1 0854-042-K1
Valve, Thermal Exp. (R171SUA20, 1856) 0854-042-K2 0854-042-K2
Vent Fan (R171SUA20, 1856 ONLY) 0769-045-K 0769-029-K
