Cres Cor H135WUA11 Manual

5925 Heisley Road • Mentor, OH 44060-1833
Call Toll-free: 877-CRES COR (273-7267) • Fax: [phone] • www.crescor.com
OPERATING and MAINTENANCE INSTRUCTIONS
for H135WUA11 Hot Cabinet (Aluminum)
H135WSUA11 Hot Cabinet (Stainless Steel)
Hot Cabinets FL-2334
Rev. 2 (3/13) Page 1 of 4
Model No. Volts Watts Amps Hertz Phase NEMA
H135WUA11
H135WSUA11 120 2000 16 60 1 5-20P
H135WUA11208
H135WSUA11208 208 2000 9.6 60 1 6-15P
H135WUA11240
H135WSUA11240 240 2000 8.6 60 1 6-15P
All are designed for AC service. The above model numbers may be followed by “M”, “L”, “D”, “R”
and ending with “S” or “Z”.
HOW TO INSTALL UNIT:
1. Place cabinet near warm ovens. Do NOT place
cabinet in drafty areas or near ventilating systems.
2. Plug end into proper wall outlet.
3. Fill with 2 qts.(1.8 liters) of clean, hot water.
HOW TO PROOF:
1. Fill water pan (See “How to Install”)
2. Push “POWER” switch to “ON.” The yellow light
will come on.
3. Push “MODE SELECTION” switch to “PROOF”.
The yellow light will come on.
4. Turn “HUMIDITY” dial to No. 8.
5. Turn “AIR” dial to “OFF.”
6. Preheat for 30 minutes. “
7. Put fresh or fully thawed dough into cabinet.
NOTE: The cabinet temperature will drop tempera-
ture inside cabinet if cold dough is added.
Do NOT put frozen dough into cabinet
CONTROL PANEL PARTS IDENTIFICATION
1. Switch-Power 5. Yellow Light-Proof
2. Yellow Light-Power 6. Red Light-Heat
3. Thermostat-Humidity 7. Switch-Mode Selection
4. Thermostat-Air 8. Thermometer
NOTE: No. 8 setting will give you an approximate
temperature of 95°F (35°C), and 90-95%
humidity. Experiment with different “HU-
MIDITY” and “AIR” settings to get the exact
temperature and humidity you need. The
thermometer shows the temperature inside
the cabinet.
NOTE: Check water level in water pan if you are
proong longer than 90 minutes. Fill with
clean, hot water.
CAUTION Use of treated or soft
water may be required
for proper operation and to maintain warranty.

5925 Heisley Road • Mentor, OH 44060-1833
Call Toll-free: 877-CRES COR (273-7267) • Fax: [phone] • www.crescor.com
OPERATING and MAINTENANCE INSTRUCTIONS
for H135WUA11 Series Hot Cabinet
Hot Cabinets FL-2334
Rev. 2 (3/13) Page 2 of 4
HOW TO HOLD
1. Push “POWER” switch to “ON.” The yellow light
will come on.
2. Push “MODE SELECTION” switch to “HEAT.”
The red light will come on.
3. Turn “AIR” dial to temperature needed.
NOTE: No. 8 is about 175°F (79°C).
No. 6 is about 165°F (74°C).
Proper food holding temperature
is 140°F (60°C) or higher.
4. Preheat cabinet for 30 minutes.
5. Put food into cabinet.
HOW TO TURN UNIT OFF:
Push “POWER” switch to “OFF” position.
MAINTENANCE:
HOT UNIT REMOVAL INSTRUCTIONS:
1. Unplug power cord from wall outlet.
2. Pull entire unit out the front of the cabinet.
BEFORE CLEANING THE CABINET:
1. Allow cabinet to cool.
2. Remove Hot Unit from cabinet.
3. Do NOT use abrasives or harsh chemicals.
Cleaning Notes:
1. Wipe up spills as soon as possible.
2. Clean cabinet regularly to avoid heavy dirt build-up.
3. Make a test spot with cleaner.
4. Follow manufacturer’s directions on cleaner.
5. Do not mix cleaners.
6. Avoid drips and splashes.
7. Empty water pan at least once a week.
WARNING
DELIME OR DESCALE RESERVOIR PARTS AS
REQUIRED TO PREVENT DAMAGING BUILD-UP.
WARRANTY COVERAGE MAY BE AFFECTED WITHOUT PROPER CLEANING.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK)
NO USER-SERVICEABLE PARTS INSIDE
REPAIR SHOULD BE DONE BY AUTHORIZED SERVICE
PERSONNEL ONLY
RISK OF FIRE OR ELECTRIC SHOCK
DO NOT OPEN
WARNING

5925 Heisley Road • Mentor, OH 44060-1833
Call Toll-free: 877-CRES COR (273-7267) • Fax: [phone] • www.crescor.com
OPERATING and MAINTENANCE INSTRUCTIONS
for H135WUA11 Hot Cabinet (Aluminum)
H135WSUA11 Hot Cabinet (Stainless Steel)
Hot Cabinets FL-2334
Rev. 2 (3/13) Page 3 of 4
HOW TO CLEAN UNIT:
Soil Cleaner Method
DOORS
Vinyl (Out)
Aluminum (In)
Dirt, Grease and Oil Mild Detergent* and water. 1. Wipe with soft, damp cloth.
2. Rinse well.
CABINETS
(H137WUA11 is
Aluminum)
(H137WSUA11
is
Stainless Steel)
Dirt
Mild detergent* and hot water, or
mild abrasive cleaner.
1. Use soft, damp cloth.
2. Rinse with hot water.
3. Wipe dry.
Steam (No strong alkaline additive) 1. Rinse after steam cleaning.
2. Wipe dry.
Fingerprints, Grease
and Oil
Chemical oven cleaner for cabinet
material
Follow oven cleaner manufacturer’s
directions
Mild abrasive cleaner; oily or waxy
cleaner
Apply with clean, soft cloth. Wipe with
damp cloth.
Water Spots Mild abrasive cleaner.
Oily or waxy cleaner.
Apply with soft, clean cloth.
Wipe with damp cloth.
*Mild detergents include soaps and non-abrasive cleaners.
TROUBLE-SHOOTING CHART:
FAILURE POSSIBLE CAUSE
1. Indicator lights do NOT light.
1a. Circuit breaker/fuse to wall outlet blown.
2a. Cord unplugged from wall outlet or cabinet.
3a. Switch is “OFF.”
2. Unit does not heat 2a. Thermostats set too low or are off.
2b. Switch is “OFF.”
3. Unit gets too hot or won’t shut off 3a. Defective electrical parts.
3b. UNPLUG UNIT FROM WALL OUTLET
4. Humidity is low. 4a. Water in pan may be low
4b. Thermostat set too low
5. Blower does not work or makes noise. 5a. Defective Blower
NOTE: Optional digital thermometer will ash if cabinet temperature is below 140°F or above 250°F.
Call the Factory if you need different settings.
If cause is none of the above, refer to our list of Authorized Service Centers, FL-1400.
CABINET W/BLACK FRAME W/O BLACK FRAME
Door Assembly, Aluminum 1200-495-BL-K 1221-571-K
Door Assembly, Red 1200-499-BL-K 1221-571-RK
Door Assembly, Stainless Steel - 1221-571-SS
Door Gasket 0861-259-K 0861-271-K
Door Hinge 0519-104-K 0519-104-K
Door Latch 1006-154-01-K 1006-154-01-K
Pan Slides 0621-281-K 0621-281-K

5925 Heisley Road • Mentor, OH 44060-1833
Call Toll-free: 877-CRES COR (273-7267) • Fax: [phone] • www.crescor.com
OPERATING and MAINTENANCE INSTRUCTIONS
for H135WUA11 Series Hot Cabinet
Hot Cabinets FL-2334
Rev. 2 (3/13) Page 4 of 4
REPLACEMENT PARTS:
DESCRIPTION 120 VOLT 208 VOLT 240 VOLT
Hot Unit (135WUA11) PHU-747-071 PHU-747-072 PHU-747-073
Hot Unit (135WSUA11) PHU-747-080 PHU-747-081 PHU-747-082
Heater (Reservoir) 0811-285 0811-286 0811-287
Pan (Reservoir) 1017-097 1017-097 1017-097
Heater (Air) 0811-214-K 0811-250 0811-215
Thermostat Kit 0848-062-K 0848-062-K 0848-062-K
Thermometer Kit (Analog) 5238-030-K 5238-030-K 5238-030-K
Power Cord 0810-065-1 0810-039 0810-039
Proof & Heat Lights 0766-093 0766-093-1 0766-093-1
Power Light 0766-094 0766-095 0766-095
Switch (Power) 0808-116-K 0808-116-K 0808-116-K
Switch (Mode Selection) 0808-117-K 0808-117-K 0808-117-K
Blower Kit 0769-180-K 0769-182-K 0769-182-K
Drip Pan Kit 1017-058 1017-058 1017-058
