Crest Audio CC-4707WS-21 User manual

CC-4707WR-21 Color Camera
Indoor IR Dome Color Camera
Specification
Packing List
No Name Model Number
1.
Indoor IR Dome Color Camera CC-4707WS-21 1
2.
User Guide CC-4707WS-21
1
 ALLIANCE DRIVE
GREENSBORO, NC -
--CREST/--
FAX: --
www.crestelectroics.co
Model CC-4707WS-21
Pick up Element 1/4” Aptina 1.0MP CMOS Sensor
Effective Picture Elements
(H×V) NTSC:976(H)×494(V)
Horizontal Resolution 720 TV Line
0.001 Lux/F1.2
Minimum Illumination
0Lux (with IR LED ON)
S/N Ratio More than 50dB
Scanning System 2:1 interface
Synchronous System Internal, Negative sync.
Auto Electronic Shutter NTSC: 1/60s~1/100,000s
Gama Characteristic 0.45
IR Distance 65 FT (with ￠5X21 PCS Infrared LED)
Video Output 1Vpp, 75Ω
Auto Gain Control Auto
Power/Current DC12V(+/-10%)/500mA
Lens 6-22mm Manual Zoom Lens
Dimension (in) ￠5.1x3.9(H)
Weight (lb) 1.66
Storage Temperature -22°F~140°F RH95% MAX
Operating Temperature 14°~140°F RH95% MAX NOTE:
Please read this guide
BEFORE installing

INTRODUCTION
The Crest Electronics CC-4707WS-21 camera is based on
the latest high-resolution 960H sensor and is capable of
delivering a resolution of 720TVL. The Wide Dynamic
Range of the sensor allows the camera to capture detailed
images even in challenging lighting conditions. With built
in Smart IR, varifocal lens and OSD menu, this camera
can be adjusted to suit a wide variety of needs.
Please read this instruction manual carefully to ensure
proper use of the camera.
CONNECTING
BRIEF OF PRODUCT
* Sensor (CCD)
1/4” Aptina 1.0MP CMOS Sensor
* Auto Gain Control (AGC)
Built-in auto gain control (AGC) circuit. The color camera
can get high definition picture in low Lux condition.
* Scanning Mode
NTSC or PAL mode.
* Support UTC function
With UTC Remote Controller for the convenience of OSD menu
setting.
* OSD SETTING
DC12V Power Supply
Monitor
CC-4707WS-21
TROUBLE AND SOLUTION
Link wire rule：
Power
Video
Note:
● Please note the camera’s operating temperature is -4°F~140°
F .
Use of the product outside this range is not recommended.
● This installation should be made by a qualified service person
and conform to all local codes. Crest Electronics will not be
responsible for damages or injuries as a result of improper
installation.
NOTICE: For best results, please read this instruction
booklet prior to installing the CC-4707WS-21 camera.
Video
DC12V
CAUTION:
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVER OR BACK NO USER
SERVICEABLE PARTS INSIDE. REFER SERVICING
TO OUALIFIED SERVICE PERSONNEL.
RISK OF ELECTRIC. DO NOT OPEN
CAUTION: CSA CERTIFIED/UL LISTED CLASS 2 POWER
ADAPTORS MUST BE USED IN ORDER TO
COMPLY WITH ELECTRICAL SAFETY STANDARDS.
MENU
UP
DOWN
RIGHT
LEFT
PRESS
KEY BOARD
OSD
SET
SCENE
SELECT
FULL AUTO
SHUTTER/AGC
WHITE BAL
HLC/BLC
ATR-EX
DNR
DAY/NIGHT
IR OPTIMIZER
LENS SHD COMP
DEFOG
FLK LESS
ANTI CR
INDOOR
OUTDOOR
BACKLIGHT
ITS
CUSTOM
PICT AD-
JUST
BRIGHTNESS
CONTRAST
SHARPNESS
HUE
COLOR GAIN
EZOOM
MAG 0-255
PAN
TILT
DIS ON/OFF
PRIVACY
MASK
AREA SEL 1-15
DISPLAY ON/OFF
POSITION
COLOR 8
TRANSP 0-1
MOSAIC ON/OFF
MOTION
DET
DETECT SENSE
INTERVAL
BLOCK DISP
MASK AREA
MONITOR AREA
SYSTEM
SETTING
SYNC MODE
LENS
FLIP
LCD/CRT
COMMUNICATION
CAMERA ID
LANGUAGE ENGLISH,JAPANESE,CHINESE,RUSSIAN,
FRENCH,GERMAN,SPANISH, PORTUGUESE
MAINTE-
NANCE
W.PIX MASK
CAMERA RESET
INSTALLATION NOTES
During installation, please make sure the lens seal ring is tightly fitted
to the cover; this reduces the chance of IR reflection during low light
viewing.
TROUBLESHOOTING
NO VIDEO
◆Power Supply
Check input power
connections at the
terminal (AC/DC input
wires)
◆Voltage Range
Measure the voltage at
the terminal block. The
supply range is:
12VDC.
◆Video Connection
Determine if wiring
polarity at “Video
Connector” is correct.
If ok, the problem may be
with the interconnections/
splices.
ROLLING PICTURE
◆Check to make sure the
coax shield is not
touching “ground”
POOR PICTURE
◆Ensure that the video
cable is terminated with
75 ohms at each end.
