Crest Audio CCA-2810WF-20 User manual

CCA-2810WF-20 Color Camera
Vandalproof IR Dome Color Camera
AHD/960H Analog
Specification
Packing List
No Name Model Number
1. Weatherproof
IR Dome Color Camera CCA-2810WF-20 1
2.
User Guide CCA-2810WF-20
1
Model CCA-2810WF-20
Pick up Element 1/4” Aptina 1.0MP CMOS Sensor
Effective Picture Elements
(H×V) NTSC: 1280(H)×720(V)
Resolution 720p
0.01 Lux/F1.2
Minimum Illumination
0Lux (with IR LED ON)
S/N Ratio More than 50dB
Scanning System Progressive Scan
Synchronous System Internal, Negative sync.
Auto Electronic Shutter NTSC: 1/30s~1/60,000s
Gama Characteristic 0.45
IR Distance 65 Feet (with ￠5X24 PCS Infrared LED)
Video Output 1Vp-p, 75Ω (AHD & 960H)
Auto Gain Control Auto
Power/Current DC12V(+/-10%)/500mA
Lens Board Lens 3.6mm
Dimension (in) 3.8” x 2.8”
Weight (oz) 14.5
Storage Temperature -22~+140°F RH95% MAX
Operating Temperature +14~+122°F RH95% MAX
 ALLIANCE DRIVE
GREENSBORO, NC -
 -CREST/--
FAX: --
www.crestelectroics.co
NOTE:
Please read this guide BEFORE
installing

INTRODUCTION
The Crest Electronics CCA-2810WF-20 camera is based
on the latest high-resolution 960H sensor and is capable
of delivering a resolution of 720p. The Wide Dynamic
Range of the sensor allows the camera to capture detailed
images even in challenging lighting conditions. With built
in Smart IR and varifocal lens, this camera can be used to
suit a wide variety of needs.
Please read this instruction manual carefully to ensure
proper use of the camera.
CONNECTING
BRIEF OF PRODUCT
* Sensor (CCD)
1/4" Aptina 1.0MP CMOS Sensor
* Auto Gain Control (AGC)
Built-in auto gain control (AGC) circuit. The color camera
can get high definition picture in low Lux condition.
* Scanning Mode
NTSC
TROUBLE AND SOLUTION
Note:
● Please note the camera’s operating temperature is 14°F~122°
F .
Use of the product outside this range is not recommended.
● This installation should be made by a qualified service person
and conform to all local codes. Crest Electronics will not be
responsible for damages or injuries as a result of improper
installation
TROUBLESHOOTING
NO VIDEO
◆Power Supply
Check input power
connections at the
terminal (AC/DC input
wires)
◆Voltage Range
Measure the voltage at
the terminal block. The
supply range is: 24VAC
or 12VDC.
◆Video Connection
Determine if wiring
polarity at “Video
Connector” is correct.
If ok, the problem may be
with the interconnections/
splices.
ROLLING PICTURE
◆Check to make sure the
coax shield is not
touching “ground”
POOR PICTURE
◆Ensure that the video
cable is terminated with
75 ohms at each end.
NOTICE: For best result, please read this instruction
booklet prior to installing the CCA-2810WF-20 camera.
CAUTION:
RISK OF ELECTRIC. DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVER OR BACK NO USER
SERVICEABLE PARTS INSIDE. REFER SERVICING
TO OUALIFIED SERVICE PERSONNEL.
CAUTION: CSA CERTIFIED/UL LISTED CLASS 2 POWER
ADAPTORS MUST BE USED IN ORDER TO
COMPLY WITH ELECTRICAL SAFETY STANDARDS.
