  9. Crestron FreeSpeech MP-FS100 PAK User manual

Crestron FreeSpeech MP-FS100 PAK User manual

quickstart guide
MP-FS100 PAK
www.crestron.com
888.273.7876 201.767.3400
Specifications subject to change
without notice.
MP-FS100 PAK
For details, refer to the latest version of the
MP-FS-RX1/RX2 Operations Guide, Doc. 7164.
QUICKSTART DOC. 7161B (2030815) 08.11
FreeSpeech®Single-Channel Wireless Mic System
1
The outer jacket of the cable must
extend into the molded plastic channel
of the MP-FSIR and under the wire
retaining guides, as shown.
Connect the T, R, and Sterminals of
the MP-FSIR to the T, R, and Sterminal
positions of the supplied 3-pin
detachable connector for the BEACON
SENSOR T, R, and Sterminals of the
MP-FS-RX1 receiver, and plug in the
connector.
If using the CBL-PWR-CTRL-P-TL-50
cable, connect drain and black together
to the Spin, connect red to Tand white
to R. Blunt cut both ends of the blue
conductor and do not use.
If using a shielded cable, also connect
the shield to the Spin at the receiver
end only.
System Components
1
The following items are included in the MP-FS100 PAK kit:
• One single-channel receiver, MP-FS-RX1
• One dual docking station/charger, MP-FSDS2
• One IR beacon sensor, MP-FSIR
• One wireless microphone, MP-FSMIC, with lanyard and LED
code chart
• One power pack: 2.0 Amps @ 24 Volts DC, 100-240 Volts AC,
50/60 Hz (for MP-FS-RX1)
• One power pack: 1.2 Amps @ 5 Volts DC, 100-240 Volts AC,
50/60 Hz (for MP-FSDS2)
The following items are available separately:
• PA audio sensor, MP-FS-PAS
• Tabletop mic stand, MP-FSTTS
• Ceiling-mount speakers, FSDI8 (Pair)
• Surface-mount speakers, FS6 (Pair)
• Speaker wire, CBL-SPK-P-35
• CBL-PWR-CTRL-P-TL-50
Install the dual docking station/charger as follows:
1. Select an appropriate location (tabletop, desk, shelf).
2. Connect the supplied power pack to the docking station and then to
line power.
3. The green LED on the docking station indicates power is applied.
Install the wireless microphone (mic) as follows:
1. Make sure power is applied to the docking station/charger
(the green LED is on).
2. Place the
MP-FSMIC
in either position of the docking station, and
allow it to charge for at least two hours. When the battery is fully
charged, the mic's Status LED blinks green.
NOTE: The mic is “keyed” and only fits into the charger in the orientation
shown in the following illustration.
3. Use the included magnetic clip for lapel or lanyard attachment, or
place the mic in the tabletop stand accessory (available separately).
During operation, the mic should be positioned approximately four
inches (100 mm) below the speaker's chin.
FS
FS
MP-FSIR
FSDI8
FSDI8
MP-FS-RX1
Desk,
Table,
Shelf . . .
Instructor
Students
w/ MP-FSMIC
Install MP-FSDS2 Dual Docking Station/Charger
2
Power Pack
Green
LED
1.2 Amps @
5 Volts DC
100-240 Volts AC
50/60 Hz
Install MP-FSMIC Wireless Microphone
3
Room Setup and Speaker Placement
4
Status LED
Use the diagram below as a guide for placing the FreeSpeech®system
components in the classroom.
1. Locate the MP-FS-RX1 receiver on any flat surface such as a desk, table,
or shelf.
2. Crestron®recommends using FS6 surface mount speakers OR FSDI8
ceiling mount speakers. Place FS6 speakers on the walls between the
instructor’s usual location and the students, aimed toward the students;
place FSDI8 ceiling mount speakers at the rear of the room behind the
students.
3. The MP-FSIR IR beacon sensor(s) should be centrally located on the
ceiling or wall, away from fluorescent lighting and windows, with direct line
of sight to the MP-FSMIC wireless microphone.
System Hookup
5
Install all accessory hardware and all required interconnecting cables.
1. Install 2-conductor cables between the MP-FS-RX1 receiver and the speaker
locations. Crestron recommends its plenum rated 16 AWG speaker cable
CBL-SPK-P-35. Use the supplied connectors at the receiver end, and connect to
the speakers following their included instructions.
2. Install any optional devices, such as the MP-FS-PAS audio sensor, following their
included instructions.
3. Attach the supplied antenna to the receiver.
4. Install a 3- or 4-conductor cable (minimum 24 AWG) up to 50 feet (~15 meters)
maximum, between the MP-FSIR location and the receiver. Refer to the illustration
below for mounting and hookup details.
As an alternative, use Crestron's CBL-PWR-CTRL-P-TL-50 or equivalent cable.
NOTE: Up to two MP-FSIR units can be connected in parallel to each of the two
MP-FS-RX1 BEACON SENSOR ports, allowing for a total of four MP-FSIRs.
5. Connect the included power supply to the receiver and then to line power.
Mount the IR beacon sensor directly to
the ceiling or wall using the supplied
1-1/2" 8-16 Phillips head screws and
plastic wall anchors (if required). It can
also be mounted to a single-gang
electrical box or an octagonal electrical
box.
MP-FSIR Hookup & Mounting
l
nal
N
3.53 in
(90 mm)
3.23 in
(82 mm)
S R T
quickstart guide
MP-FS100 PAK
www.crestron.com
888.273.7876 201.767.3400
Specifications subject to change
without notice.
MP-FS100 PAK
For details, refer to the latest version of the
MP-FS-RX1/RX2 Operations Guide, Doc. 7164.
QUICKSTART DOC. 7161B (2030815) 08.11
FreeSpeech®Single-Channel Wireless Mic System
2
During the following procedures, refer to the above illustration and to the included
Microphone LED Code Reference Guide (Doc. 7165).
A. Pair Microphone with Receiver
1. Hold the MP-FSMIC ON button until the mic Status LED rapidly flashes green.
2. The mic will begin pairing with the receiver. Make sure the mic has line of sight to the
MP-FSIR. When pairing is complete, the Status LED will slowly blink green. Time to
pair is typically between five and ten seconds.
The mic must be turned off and turned on again to pair to another receiver.
B. Mute and Volume Adjustments
1. Press the MUTE button to mute the mic (observe the blink pattern); press it again to
un-mute. When muted, the mic automatically turns off after two minutes.
2. When the mic is not muted, the VOL button can be used to adjust the mic volume.
3. When the mic is muted, the VOL button adjusts the line level audio volume.
4. Line volume is automatically “ducked” (reduced) when the user talks into the mic.
5. Hold the MUTE button for five seconds to turn off the mic (turns off automatically if
muted for two minutes, or when placed in the charger.)
6. If the mic loses sight of the MP-FSIR for seven seconds, the mic will automatically
mute (turns off automatically if muted for two minutes).
7. If the RF link is lost for 10 seconds, the mic turns off.
C. Emergency Trigger
Hold the ALERT button for eight seconds to generate two beeps from the speakers and
close the alert relay contacts until the button is released.
D. Receiver Controls - Default Settings
1. BASS and TREBLE: Typically, set these controls to their center detent positions.
Slightly reducing treble can help to reduce feedback.
2. MASTER VOLUME: With the control in its center detent position, have the instructor
speak from the most likely position in the room and adjust this control clockwise so
that the speakers just begin to exhibit feedback, and then reduce the setting by
turning counterclockwise.
BEACON SENSOR:
From Up To Four
IR Beacon Sensors
(Two In Parallel Per
Input Connector)
MUTE SENSOR:
From Optional
MP-FS-PAS
PA Audio Sensor or
Contact Closure
ALERT OUT:
To Building
Management Alert
System or Control
System Input
LINE IN:
From Unbalanced
Line-Level Audio
Outputs
LINE OUT:
To Unbalanced
Line-Level Audio
Inputs
SPEAKER OUT4/8Ω:
To Left and Right
Channel Speaker
Inputs
Ground
Basic Operation
6
Crestron, the Crestron logo, and FreeSpeech, are trademarks or registered trademarks of Crestron
Electronics, Inc. in the United States and other countries. Other trademarks, registered trademarks, and
trade names may be used in this document to refer to either the entities claiming the marks and names
or their products. Crestron disclaims any proprietary interest in the marks and names of others.
©2011 Crestron Electronics, Inc.
Ensure that the MP-FS-RX1 receiver is installed and connected as instructed on page 1,
that power is on (the green LED is on), that line level audio is supplied from a DVD
player, a laptop computer, or other device, and that the MP-FSMIC microphone has
been fully charged.
24VDC @ 2.0A:
From Power Pack
(Included)
