Crestron CCS-UCA-MIC Original operating instructions
CCS-UCA-MIC
Table Microphone for CCS-UC-1
Installation & Operation Guide
Description
The CCS-UCA-MIC is an accessory microphone for use
with the CCS-UC-1 Mercury™ Tabletop Conference
System. When placed on a conference room table,
these low-profile microphone pods provide enhanced
pickup of every participant at the table. This accessory
also extends the capability of muting the room from the
far end of a table as each pod contains the ability to
mute the CCS-UC-1.
Installation
NOTE: When the CCS-UCA-MIC is used, the
CCS-UC-1 must be powered with the AC power pack
(included with CCS-UC-1 W/PS KIT, CCS-UC-1-AV
W/PS KIT, and CCS-UCA-MIC W/PS KIT).
NOTE: The CCS-UC-1 supports the use of no more
than two microphone pods. Additional microphone
pods cannot be connected.
The microphone pods can be connected directly to the
CCS-UC-1 or daisy chained together for longer
conference tables.
NOTE: Use the two 12-foot (3.7 m) cables (included)
to connect the microphone pods to the CCS-UC-1.
Additional Resources
Visit the product page on the
Crestron website (www.crestron.com)
for additional information and the
latest rmware updates. Use a QR
reader application on your mobile
device to scan the QR image.
OUT
IN
OUT:
To microphone pod
(if daisy-chained)
IN:
From
CCS-UC-1
∏
∑ ∑
∏
IN
IN
∑∏
IN
π
∫
IN
OUT
Direct Connection
1. Connect each of the included cables to the MIC
POD ports on the the rear of the CCS-UC-1.
2. Connect each cable to the IN port of a mic pod.
Daisy Chain Connection
1. Connect one of the included cables to the IN port
on a microphone pod.
2. Connect the other end of the cable to the OUT
port on the other microphone pod.
3. Connect the other included cable to the IN port on
the same microphone pod.
4. Connect the cable to the MIC POD port on the
rear of the CCS-UC-1.
Operation
The microphone pods work in conjunction with the
CCS-UC-1 to mute and unmute the conference
system’s microphones.
During a call, the status of the microphone is displayed
on the microphone pods. When the microphone is in
use, the indicator lights green. When it is muted, the
mute indicator lights red.
To mute all of the microphones in the system, tap the
green icon. The icon turns red.
To unmute all of the microphones in the system, tap the
red icon. The icon turns green.
As of the date of manufacture, the product has been tested
and found to comply with specications for CE marking.
Federal Communications Commission (FCC) Compliance
Statement
This device complies with part 15 of the FCC Rules.
Operation is subject to the following conditions: (1) This
device may not cause harmful interference and (2) this device
must accept any interference received, including interference
that may cause undesired operation.
CAUTION: Changes or modications not expressly approved
by the manufacturer responsible for compliance could void
the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV
technician for help.
Industry Canada (IC) Compliance Statement
CAN ICES-3 (B)/NMB-3(B)
Product warranty can be found at
www.crestron.com/warranty.
The specic patents that cover Crestron products are listed at
patents.crestron.com.
Certain Crestron products contain open source software.
For specic information, please visit
www.crestron.com/opensource.
Crestron, the Crestron logo, and Mercury are either
trademarks or registered trademarks of Crestron Electronics,
Inc. in the United States and/or other countries. HDMI is
either a trademark or registered trademark of HDMI Licensing,
LLC in the United States and/or other countries. Other
trademarks, registered trademarks, and trade names may be
used in this document to refer to either the entities claiming
the marks and names or their products. Crestron disclaims
any proprietary interest in the marks and names of others.
Crestron is not responsible for errors in typography or
photography.
