CRL/S MACA BELT SANDER
M DELS 2300RP, AU2300 and AU23
F R 4" X 106" SANDING BELTS
(starting with Serial No. 71239)
PERATING INSTRUCTI NS
06-17

crlaurence.com / somaca.com / crlaurence.ca / crlaurence.co.uk / crlaurence.de / crlaurence.eu / crlaurence.com.au
CRL Glass Machinery • [phone] • Fax [phone] Int. Phone: [phone]
CALL TOLL FREE ANYWHERE IN THE U.S. AND CANADA • ALL PRODUCTS F.O.B. NEAREST WAREHOUSE
CRL/S MACA BELT SANDER
M DELS 2300RP, 2300, AU2300 and AU23
Page 1
INTRODUCTION
Your new CRL/SOMACA Belt Sander was developed and improved through the years until it can now be called the finest piece of equipment available
in its price range. The machine incorporates many fine features such as a direct drive, 1 H.P. motor, a gas cylinder-tensioned upper pulley, safety shield,
totally sealed ball bearings eliminating weekly lubrication, and a unique, rust-proof, thick-walled HDPE (High Density Polyethylene) water tank.
Like any good machine, it will give best results if it is properly cared for. It is not necessary to pamper this equipment, but reasonable maintenance will
increase the machine’s life.
We put sealed bearings in our machines because we found that most shops do not take the time to grease the bearings on a routine basis. However,
even sealed bearings do sometimes go bad, and should be inspected on a weekly basis for noise or rough spots. Scrubbing the machine occasionally
will prevent glass and sludge build-up, and any areas where rust is starting to show should be scraped, primed, and repainted to get the maximum life out
of the machine. The AU2300 machine has a 50 Hz, 220V motor with Australian cord and plug but no roller platen or guide wheels. The AU23 has
the roller platen and guide wheels and a 50 Hz, 220V motor with Australian cord and plug.
The instructions on the following pages will guide you through the initial setup, maintenance, and replacement of parts on your machine. Should you
run into any problem or procedure you do not understand, please feel free to call our toll free number [phone], and we will be glad to help you.
Parts and expert advice can also be obtained directly from CRL Glass Machinery at [phone]. International: [phone].
BELT SANDER SET U
UNCRATING THE MACHINE
Remove the shipping cover and inspect for any damage. If you find any part of your machine has freight damage, save all shipping material and
call the delivering carrier immediately. Tell them you want to file a damage claim and have them send out an inspector. If everything is okay, completely
remove the shipping crate, including the wooden base.
SETTING U THE BELT SANDER
1. Position the sander in your desired location. For best results, the sander should be level and secured to the floor with anchors, fastened through the
holes provided in the sander base.
2. With the belt sander switch in the OFF position, plug the sander into a grounded outlet of the correct voltage. Electrical Specifications for each model
are located on the Serial Number Plate near the belt tensioner and on the top of this page. NOTE: A ground plug is provided for your safety.
LEASE DO NOT ALTER IT IN ANY WAY. Now turn the switch on to see if the motor will run. If it does, go to the next step. If it does not run, check all
electrical connections and try again. If you still have a problem, please call us before going any further.
3. Unplug the sander before going any further. Now you can connect the sander to your city water supply, using copper tubing and a 1/4" NPT
(National Pipe Thread) male connection to the 1/4" NPT female connection in the electric water valve (Photo 1 on Page 4). Note the “flow direction”
marked on the valve with an arrow. Turn the water on and check for leaks. Position a bucket or pan under the drain pipe on the machine, or connect
a hose for discharging into a flume or other device to allow sediment to settle and water to drain off. NOTE: If drained into a sewer, abrasive sand
grindings may accumulate and plug the drain.
4. Plug the machine in again. Be sure the manual water flow control valve (after the electric water valve) has the handle turned in the direction the water
is flowing; this is the OPEN position. Turn the switch ON and the water will begin to spray. The spray pattern on the sander is not adjustable. If the
spray pattern decreases or changes, remove and clean the spray nozzle. The manual water flow control valve (Photo 1 on Page 4) can be adjusted to
reduce the water flow. Do not use any more water than needed to keep the belt wet. Turn the machine OFF. Unplug the sander and go to the next step.
5. Pull the handle to open the side door. Now install a belt over the top and bottom pulley by pulling down on the black handle on the tensioner
mechanism. Be sure the belt is not wrapped over the water nozzle.
NOTE: When grinding glass, only “wet or dry” belts with silicon carbide grain should be used. They come with two types of splices:
overlapping or butt splices. Butt splices can be run in either direction (such as CRL’s finger splice). Overlapping splices can be run only in
the direction indicated by arrows on the inside of the belt. The most common way to put lapped spliced belts on a belt sander is to put the
belt over the pulleys so you can see the arrow pointing up on the back side of the belt. This will give you the proper rotation.
6. With the sander still unplugged, pull the belt through by hand several cycles to adjust the tracking mechanism. Do this as follows: On the left side of
the machine is a blue ratcheting lever. Loosen the locknut behind the lever. Rotate this lever clockwise to move the belt to the right. Rotate the lever
counterclockwise to move the belt to the left. Adjust the blue ratchet lever until you have adjusted the belt so it will stay in the middle of both pulleys
when pulling the belt by hand. If the blue ratchet lever hits an obstruction, pull the handle out toward you and it will rotate without affecting the tracking.
7. Now plug the machine back in, turn the switch ON, and perform the fine tracking adjustments. The goal is to have the belt track in the middle of both
the upper and lower pulleys. Hold the lever and use a 1/2” wrench to tighten the locknut behind the blue lever. If the contact roller does not match up
with the belt at this time, loosen the Square Head Screws in the Platen Bracket and tap the Roller Platen shaft until it aligns even with the belt, then
tighten the screws.
8. The belt tension is not adjustable and is controlled by the tensioner spring. No adjustment is needed. The spring is available as a replacement part.
2300R /2300 ELECTRICAL S ECS: 115V AC 1/60 Hz .74 kW / 1 H 12.2 FLA 15 AM SERVICE 1750 R M MAX
AU2300/AU23 ELECTRICAL S ECS: 230V AC 1/50 Hz .74 kW / 1 H 6.1 FLA 10 AM SERVICE 1750 R M MAX

crlaurence.com • Toll Free [phone] • Fax [phone]
CRL Glass Machinery • [phone] • Fax [phone] Int. Phone: [phone]
CALL TOLL FREE ANYWHERE IN THE U.S. AND CANADA • ALL PRODUCTS F.O.B. NEAREST WAREHOUSE
CRL/S MACA BELT SANDER
M DELS 2300RP, 2300, AU2300 and AU23
Page 2
NOTE: After a year or two of continued machine use, the pulleys will wear and need to be replaced or have a new crown
machined in them. This is usually evident when you cannot get the belt to track and pulley adjustment will not correct the
tracking. To check this, lay a straight edge across the pulley. A new pulley will have a noticeable hump or crown in the middle
of it. A worn-out pulley will be flat or even have a valley in its center. If the pulley is worn, a one degree crown should be
remachined into the surface or the pulley should be replaced with a new one.
recautions:
1. Do not allow hands to come in contact with the belt while it is moving.
2. Be sure safety shield is properly positioned.
3. Do not overload your shop electrical circuits. Be sure wiring is adequate.
4. Be sure your service plug has grounding provisions to be sure the belt sander is grounded at all times.
GENERAL GUIDELINES
USING THE BELT SANDER
The application of the glass and the choice of belt grits are largely a matter of the individual operator’s preference, but the following procedures are
submitted as a guide for general work.
To obtain a round or pencil edge, use a coarse grit belt and lightly bevel the sharp edges left from cutting by running or swiping glass quickly across the
belt. This helps to reduce chipping the glass during succeeding grinding. Draw the glass slowly across the unsupported area of the belt above the platen,
and at the same time tilt the glass up and down until the desired contour is obtained. Finish the edge on a smoothing belt and then polish if desired.
For a flat, seamed edge, use a belt of medium grit and lightly bevel the edges as above. Next, grind the entire edge flat by applying the glass squarely
to the platen. Change to a finishing or smoothing grit and go over the flat edge again, then seam both sides of the glass by tilting it about 45° and running
it across the belt on the platen.
Rough grinding can be done by using abrasive belts in grit sizes 40, 60, 80, and 120. Belts of 150, 180, 220 and 280 grits are for smoothing; grits 320
and 400 for satin finishing; 600 grit and cork belts are for extra high polishing.
LUBRICATION
The only bearings on the sander that may require lubrication are the motor bearings. Check to see if there are grease fittings for applying lubrication.
Time interval: Every six months. NOTE: Apply grease sparingly as overly greased bearings
can create seal failure and eventually cause bearing failure.
Type of grease: CRL Cat.No.WL14 No.2 lithium base grease.
Use CRL Cat.No.1200 Metal Lube weekly on the front rest roller axles.
HOW TO REMOVE AND RE LACE THE ELECTRIC WATER VALVE
1. IM ORTANAT!!! Unplug the machine power supply.
2. Turn off water supply to the machine and disconnect the water supply line from the valve (see Photo 1
on Page 4).
3. Disconnect the water line from the valve to the nozzle by pushing in on the green quick-connect collar and
pulling out on the plastic water line.
4. Open connection box on the motor and disconnect the two gray wires from the wire bundles. See photo.
5. Rotate the conduit nipple under the solenoid counterclockwise (as viewed from under the solenoid). This will
allow the valve to be removed.
6. Unscrew the complete valve assembly from the connection box. Remove the shut-off valve and quick-connect
fitting from the old valve and, using thread sealer, install it into the “OUT” side of the new valve (the “OUT” side
is indicated by the small arrow on the side of the valve, see Photo 2 on Page 4).
7. Apply a thin coat of silicone sealant to the base of the solenoid and feed the two gray wires from the new valve
into the connection box and screw the valve onto the fitting. Tighten the conduit nipple by turning it clockwise against the valve. DO NOT OVER-
TIGHTEN. IMPORTANT: Be sure that the valve is situated as shown in Photo 1 on Page 4, with the arrow on the brass fitting pointing left. The
quick-connect fitting should be pointing left.
8. Connect the nozzle water tube by pushing it into the quick-connect fitting.
9. Inside the box, connect the gray wires; one to each bundle. It does not matter which gray wire is attached to which bundle. Be sure to wrap the
wire connections with electrical tape. (note: the Black wire is EXTRA and only used for 220 Volt applications)
10. Replace the cover to the motor connection box and reconnect the water supply. Plug in the machine power supply.
11. Turn on water supply. Turn on the machine and check for leaks. Check that there is water spraying from the nozzle.
12. Make sure the nozzle is NOT spraying when the power is shut off, and make a final check for leaks on all connections.
Gray WireGray Wire
Water Supply
In

crlaurence.com • Toll Free [phone] • Fax [phone]
CRL Glass Machinery • [phone] • Fax [phone] Int. Phone: [phone]
CALL TOLL FREE ANYWHERE IN THE U.S. AND CANADA • ALL PRODUCTS F.O.B. NEAREST WAREHOUSE
CRL/S MACA BELT SANDER
M DELS 2300RP, 2300, AU2300 and AU23
Page 3
Remove and Install Motor
NOTE: This is a straight-forward job that requires a basic knowledge of electrical wiring. If you do not feel confident in your ability to connect
wires, have a qualified electrician change the motor for you.
1. Unplug the machine, turn off the water supply, and remove the sanding belt.
2. Before removing the bottom pulley, measure the distance from the back side of the pulley to the side of the tank (Photo 4, Page 4). Record this
measurement so you can replace the pulley at this same distance. This will help keep the belt alignment to original specs.
3. Loosen two set screws on the pulley with a long 5/32” Hex/Allen wrench. These can be accessed through the two holes in the pulley. Remove the pulley.
4. Disconnect the wiring from the motor by removing two screws on the connection box cover on the motor. Remove the water solenoid (page 2).
5. On 120 volt motors, pull the Brown wire from motor lug No. 1 (per the drawing on the motor) and the Yellow and Blue wires from motor lug No. 2.
6. Disconnect the Green ground wire from the ground screw. (See wiring diagrams on page 8)
7. Those are the three power wires plus a green ground wire coming from the power line in. Mark which motor connection each one goes to for rewiring.
8. With the power wires disconnected from the motor, the power cable can be disconnected from the motor.
9. The four bolts holding the motor to the machine can now be loosened.
10. The motor itself weighs about 40 lbs (18 kg). Use a small jack or have a helper hold the motor up while the bolts are loosened. Slowly pull the motor
from the machine.
11. Align the new motor with the bolts. Capacitor should be facing up. Tighten the bolts from inside the tank. Mount the solenoid and water lines as
indicated on page 2.
12. Reconnect the power cable and connect the four wires to the motor lugs as removed and replace the metal cover. Plug in the power cord and check
for motor operation. The motor should turn counterclockwise as viewed from the shaft end in the tank. Reverse wires #5 and #8 to correct rotation.
13. After motor operation is confirmed. UNPLUG the power cord, apply a small amount of light grease to the motor shaft to prevent rust, and replace the
lower pulley and the sanding belt. Remember to refer to the “pulley to tank” measurement that was made in step #2. The water supply can now be
turned back on.
14. Turn the belt through two complete rotations by hand and check the alignment. Adjust as needed to make the belt track straight on all three wheels.
Remove and Replace Sanding Belt, Upper and Lower ulleys, and Roller laten
Always UN LUG the machine before doing ANY work on it. The sanding belt should be removed before attempting any work on ulleys or the
Roller laten.
Sanding Belt
The sanding belts are easy to replace. With the belt door on the right side of the machine open, firmly pull down on the black tensioner handle.
This will allow the belt to be removed from the top pulley and then from the lower pulley. Belt installation is just as simple. Hold the belt with one hand,
gripping the middle, and loop the bottom of the belt around the lower pulley. Make sure that the belt is not between the water spray nozzle and the tank
side. Slide one side of the belt over the platen roller and pull down on the tensioner handle. This will allow you to put the top of the belt over the top pulley.
Check that the nozzle is not hooked on the belt and pull the belt through two complete rotations to check the tracking.
Lower ulley
Before removing the lower pulley, measure and record the distance from the back edge of the pulley (closest to the motor) to the side of the tank, as
shown in Photo 4 on Page 4. The Lower Pulley is removed by first removing the sanding belt and then removing two set screws, accessed through two
holes in the pulley, with a 5/32” Hex/Allen wrench (Photo 5, Page 4).
Upper ulley
The Upper Pulley is mounted on a shaft with two sealed bearings and lock rings. It is recommended that the pulley, shaft, and bearings be replaced as
a unit. Loosen the two square head screws on the pulley shaft support on the tensioner (Photo 3, Page 4). Slide the shaft out toward the pulley.
Lightly coat the new shaft with grease and insert the new shaft and pulley into the support with the end of the shaft protruding about 1/16" past the end of
the support. (Photo 3, Page 4) Tighten the square head screws. On older machines you may need a wood or plastic hammer to tap the shaft out. Do not
hit the pulley itself with anything.
Roller laten
The Roller Platen is made as an assembly with the roller, two sealed bearings, and the shaft. It is best to measure and record the distance from the
inside edge of the roller to the bracket (Photo 6, Page 4) so the new Roller Platen can be placed close to the same position.
To replace the Roller Platen, remove the sanding belt, then loosen two square head set screws on the Roller Platen bracket (Photo 6, Page 4), and
remove the assembly. Fit the new assembly at the same distance from the bracket as the old Platen, then tighten the two set screws. Replace the belt,
turn on the machine and check that the platen and belt are running true.

crlaurence.com • Toll Free [phone] • Fax [phone]
CRL Glass Machinery • [phone] • Fax [phone] Int. Phone: [phone]
CALL TOLL FREE ANYWHERE IN THE U.S. AND CANADA • ALL PRODUCTS F.O.B. NEAREST WAREHOUSE
CRL/S MACA BELT SANDER
M DELS 2300RP, 2300, AU2300 and AU23
Page 4
ROLLER LATEN, U ER ULLEY, SHAFT AND BEARINGS
For ease of maintenance and durability, the Roller Platen and Top Pulley Assemblies are supplied as one-piece assemblies. Replacing the bearings or
shaft alone requires a press and an experienced operator. Because the roller platen, top crowned pulley itself, and the bearings are some of the few parts
of the 2300RP that may need replacement, they are sold as unit assemblies. These assemblies can be replaced quickly with simple hand tools by following
the instructions on Page 3 of this manual. Assistance with any maintenance operation on the 2300RP is avaliable by calling the CRL/Sommer & Maca
Machinery Division at [phone]. Parts can be ordered online at: crlaurence.com
hoto 1. Electric Water Solenoid, Valve and
Quick-Connect Fitting. Connect water supply
at “A” -1/4" NPT. Water Flow Control Valve
“H” can be used to regulate water spray.
hoto 4. Measure Pulley to tank distance
“D” before removing Lower Pulley.
hoto 5. Loosen two set screws on the
Lower Pulley with a 5/32" Hex/Allen wrench.
Holes in the Pulley “E” line up with the two
set screws.
hoto 6. Measure Pulley to bracket
clearance “F” before removing the Roller
Platen. Loosen two Square Head screws
“G” to remove the Roller Platen.
hoto 2. Electric Water Solenoid showing
flow direction arrow “B” on fitting.
hoto 3. Square Head Screws “C” holding
the Upper Pulley Shaft “ ”. Loosen these
to remove the Upper Pulley Assembly.
A
B
C
J
H
DE
F
G

crlaurence.com • Toll Free [phone] • Fax [phone]
CRL Glass Machinery • [phone] • Fax [phone] Int. Phone: [phone]
CALL TOLL FREE ANYWHERE IN THE U.S. AND CANADA • ALL PRODUCTS F.O.B. NEAREST WAREHOUSE
Page 5
REF. QUAN. CAT. NO. DESCRI TION
21 330023 TENSIONER ASSEMBLY WELDMENT
31 330024 TENSIONER MOUNTING KIT
4 1 310041200 GUARD, TENSIONER SPRING
5 1 46104340 HANDLE, AD USTABLE 5/16-18
61 2200802 TANK, WATER BUCKET, MOLDED
71 2200803 TANK DRAIN FITTING
81 3300SS EYESHIELD
91 30016600 LOWER PULLEY
10 1 330011 UPPER PULLEY ASSEMBLY
11 1 46104660 14 LB PULL MAGNET, ADHESIVE BACKED
12 1 46104650 PHENOLIC TWO ARM THREADED KNOB
14 1 41423250 TERM FORK, 12-10 GA, 10 STUD NONINSULATED
15 4 41423210 TERM FORK, 18-14 GA, 10 STUD INSULATED
17 1 11401670 CORD GRIP FITTING, 1/2
18 1 41420280 TOGGLE SWITCH
19 1 36957501 UNCTION BOX
20 1 37028601 ELECTRICAL CONTROL BOX COVER
21 1 41900630 SOLENOID VALVE
22 1 42053492 BALL VALVE, 1/4NPT
23 1 46104660 14 LB PULL MAGNET, ADHESIVE BACKED
24 2 42101880 QUICK CONNECT FITTING, 3/8"
25 20" 49900020 TUBING, 3/8" OD, BLACK (.50m)
27 1 12028614 BRASS COUPLING, FULL, 1/4"
28 1 42001614 BRASS NIPPLE, 1/4" x 1-1/2
29 1 42011014 BRASS ELBOW, 1/4", 90°
30 1 12012014 BRASS STREET ELBOW, 1/4", 90°
31 1 42201953 BRASS NOZZLE
32 1 41400550 STRAIGHT CONNECTOR, 3/8", BLACK NYLON
33 37” 23600590 CONDUIT, LIQUID TIGHT 3/8” PVC BLACK
40 1 37965400 CAUTION PLATE
41 1 42700140 LABEL CRL GLASS MACHINERY 2” X 9”
42 1 42700090 STRIPE 1” X 28” SET OF 2, R&L
51 1 330010 ROLLER PLATEN ASSEMBLY
52 1 330015 SET, WHEELS, BOLTS, NUT, GUIDE BAR
53 1 46902390 PLUG, 1-3/4” SQUARE TUBE, BLACK
54 1 46902380 1-1/8” SQUARE CAP, BLACK
55 1 42700230 LABEL, CRL MODEL 2300RP 5” X 6”
44 4 15000560 HEX HEAD CAP SCREW, 3/8"-16 x 1.25"
45 4 15113950 WASHER, 3/8"
71 1 11428010 CORD, PLUG SET GRD. 15A
76 1 41427110 CORDSET,AU/NZ 8FT 10A 250V
500 1 45113762 WASHER. FLAT 1/2 NAS 7/8” OD SS
Minimum order for all parts is one each.
30 500 27 28 29
31
24
22
25
RE LACEMENT ARTS FOR THE 2300rp BELT SANDER
CRL/S MACA BELT SANDER
M DEL 2300rp
18
20
17
32
33
71
76
3
2
19
7
REF. NUMBERS REFER TO DRAWINGS ON AGE 6
21
5

crlaurence.com • Toll Free [phone] • Fax [phone]
CRL Glass Machinery • [phone] • Fax [phone] Int. Phone: [phone]
CALL TOLL FREE ANYWHERE IN THE U.S. AND CANADA • ALL PRODUCTS F.O.B. NEAREST WAREHOUSE
Page 6
CRL/S MACA BELT SANDER
M DEL 2300rp
RE LACEMENT ARTS DIAGRAM FOR THE 2300rp BELT SANDER

crlaurence.com • Toll Free [phone] • Fax [phone]
CRL Glass Machinery • [phone] • Fax [phone] Int. Phone: [phone]
CALL TOLL FREE ANYWHERE IN THE U.S. AND CANADA • ALL PRODUCTS F.O.B. NEAREST WAREHOUSE
CRL/S MACA BELT SANDER
M DELS 2300RP, 2300, AU2300 and AU23
Page 10

crlaurence.com • Toll Free [phone] • Fax [phone]
CRL Glass Machinery • [phone] • Fax [phone] Int. Phone: [phone]
CALL TOLL FREE ANYWHERE IN THE U.S. AND CANADA • ALL PRODUCTS F.O.B. NEAREST WAREHOUSE
CRL/S MACA BELT SANDER
M DELS 2300RP, 2300, AU2300 and AU23
Page 7
RE LACEMENT ARTS FOR THE 2300rp BELT SANDER
Typical se of Different Grits Available and Results of Their se
CAT.NO. GRIT
CRL4X10636X 36X
CRL4X10640X 40X
CRL4X10650X 50X
CRL4X10660X 60X
CRL4X10680X 80X
CRL4X106100X 100X
CRL4X106120X 120X
CRL4X106150X 150X
CRL4X106180X 180X
CRL4X106220X 220X
CRL4X106320X 320X
CRL4X106400X 400X
CRL4X106600X 600X
CRL4X106CORK POLISH
Five belts per box, except cork, which has two
GRIT TYPE APPLICATION EXAMPLE
60X Extra Rough For removing glass fast Mitered edge
80X Rough For quick contouring Auto glass edge
120X Smooth For seaming and polishing Desk top edge
220X Extra Smooth For fine frosted finish Step used before 400X belt
400X Fine For satin finish Finest opaque edge
CAT. NO. DESCRIPTION
330011 Upper Pulley Assembly
CAT. NO. DESCRIPTION
330015 Set of 5 Wheels and Bolts for Guide Bar
CAT. NO. DESCRIPTION
330024 ensioner Mouonting Kit
CAT. NO. DESCRIPTION
2200110VMTR 1/60Hz 110 Volt 1 HP Motor
2200220VMTR (for AU22)1/50Hz 220 Volt 1 HP Motor
CAT. NO. DESCRIPTION
41900630 Water Solenoid Valve
42201953 Water Spray Nozzle
Minimum order for all parts is one each.
CAT. NO. DESCRIPTION
2622028 Lower Pulley
CAT. NO. DESCRIPTION
330010 Roller Platen Assembly
CRL 4" x 106"
Wet or Dry Abrasive Belts
Your motor may look different than above

crlaurence.com • Toll Free [phone] • Fax [phone]
CRL Glass Machinery • [phone] • Fax [phone] Int. Phone: [phone]
CALL TOLL FREE ANYWHERE IN THE U.S. AND CANADA • ALL PRODUCTS F.O.B. NEAREST WAREHOUSE
CRL/S MACA BELT SANDER
M DELS 2300RP, 2300, AU2300 and AU23
Page 8
2300R Electrical Specs:
115V AC 1/60 Hz
.74 kW
15 Service Amps
AU23 Electrical Specs:
230V AC 1/50 Hz
.74 kW
10 Service Amps

crlaurence.com • Toll Free [phone] • Fax [phone]
CRL Glass Machinery • [phone] • Fax [phone] Int. Phone: [phone]
CALL TOLL FREE ANYWHERE IN THE U.S. AND CANADA • ALL PRODUCTS F.O.B. NEAREST WAREHOUSE
CRL/S MACA BELT SANDER
M DELS 2300RP, 2300, AU2300 and AU23
Page 11
ACCESSORIES FOR CRL/SOMACA 2300rp BELT SANDER
CRL Universal “One-Man” Movable
Glass Table
• Makes it Possible for One Person to
Sand Large Pieces of Glass
• Fits Any Make pright Belt Sander
(Table Shown in Front of 2300rp Sander)
One person can sand large pieces of glass without having
to support the weight of the glass by using this CRL Universal
“One-Man” Movable Glass Table. It rolls on a support rail in
front of the sander, so the operator controls the amount of
pressure the glass applies against the belt. The table top is
carpeted, and has four pop-up ball casters, allowing easy glass
rotation. All sides can then be sanded without having to lift the
glass. The legs are adjustable to allow use with any upright belt
sander. Table Guide Rail is 156" (3.96 m) long; Table Top is 36"
x 60" (914 x 1524 mm). Minimum order is one each.
CAT. NO. 3LTRT
Legs Adjust to Fit Any Belt Machine
CRL Belt Guard Safety Shields for the 2300rp Upright Belt
Sanders protect your face and eyes from flying debris, giving you
an added degree of safety. The 2200SS is standard equipment on
early 2200rp Sanders up to Serial Number 67982. It can also be
retro-fitted on older 2200rp Sanders. The 3300SS is standard on
the 2200RP and 2300RP machines starting with Serial Number
67983. This is a safety attachment no shop should be without.
Minimum order is one each.
CAT. NO. 2200SS Fits 2200rp Machines up to serial no. 67982
CAT. NO. 3300SS Fits 2200 and 2300rp Machines starting with serial
no. 67983
CRL Belt Guard Safety Shields
CAT. NO. 2200SS CAT. NO. 3300SS
CRL latens
CAT. NO. FP2002 CAT. NO. 3MP2002
CAT. NO. BP2001CAT. NO. PA100
CRL Platens below can only be used on the 2300 machine.The A100 adapter must be fitted. These accessories DO NOT
fit the 2300R , which has a Roller latten attached. The BP2001 Bar Platen will produce a slightly rounded edge. The
FP2002 Flat Platen will work best when flat edges are desired. The 3MP2200 3M Platen provides a hard metal plate with a soft
rubber pad behind it for working both types of edges. The 330010, Roller Platen (page 9) can be used on the 2300 by using the
PA100 below. Minimum order is one each.

crlaurence.com • Toll Free [phone] • Fax [phone]
CRL Glass Machinery • [phone] • Fax [phone] Int. Phone: [phone]
CALL TOLL FREE ANYWHERE IN THE U.S. AND CANADA • ALL PRODUCTS F.O.B. NEAREST WAREHOUSE
CRL/S MACA BELT SANDER
M DELS 2300RP, 2300, AU2300 and AU23
Page 12
TROUBLE ROBABLE CAUSE REMEDY
1. Won’t Start With Switch On Power Failure a. Check your electric power source.
b. Check power to switch on machine.
c. Check power at motor
d. Check starting capacitor on motor.
2. Water Does Not Flow Electric Solenoid Failure a. Flip switch on Belt Sander on and off, while holding hand
on solenoid. If “snap” is felt, go to step 3. If not, check
steps 1a, b, c.
3. Water Does Not Flow Water Restriction a. Ensure source water is on.
b. Ensure manual water valve is open.
c. Remove and clean nozzle.
4. Belt Does Not Track Out of Adjustment a. Adjust according to operating instruction manual.
b. If it still does not adjust, replace crowned pulleys/assemblies
with Cat. Nos. 330011 Upper and Cat. No. 2622028 Lower
5. Vibration or Noise Bad Bearing a. Check by feeling roller platen shaft and top pulley shafts for
vibration from bearing problem. Replace Top Pulley Assembly
or Roller Platen Assembly.
b. Feel motor while running with and without belt. If vibrating,
replace motor per operating instructions.
6. Guide Rollers Won’t turn Frozen Sleeve Bearings. a. Replace rollers and bolts.
b. Lubricate rollers and bolts.
7. Excessive belt “wandering” when sanding Weak Tension Spring a. Replace Tension Spring Kit. Order Cat. No.330012
TROUBLESHOOTING CHART

crlaurence.com • Toll Free [phone] • Fax [phone]
CRL Glass Machinery • [phone] • Fax [phone] Int. Phone: [phone]
CALL TOLL FREE ANYWHERE IN THE U.S. AND CANADA • ALL PRODUCTS F.O.B. NEAREST WAREHOUSE
C.R. Laurence Customer Services
Who May Buy C.R. Laurence is a manufacturer and wholesale distributor. Possession of our catalogs, or
any other CRL sales literature, does not constitute an offer to sell. Orders from individuals
(except professional tradesmen) may not be accepted.
We are always pleased to receive your orders, and anxious to fill them as promptly as
possible. You can place your order at CRL in a number of ways. Our people will do their
best to make your shopping experience at CRL pleasant and time-efficient.
Online at crlaurence.com
Many of our customers have found the most convenient method of
ordering from CRL is through our full service web site. When you use
crlaurence.com to place your orders you have so many options that other
methods don’t provide. You set the schedule and the pace because you
can log on 24 hours a day, seven days a week. You can build a personal
catalog; even make changes or additions to your orders online. There’s no
easier way!
Toll Free Customer Service Order Desk
For over 30 years CRL has provided toll free ordering at [phone].
When you call our Customer Service Order Desk you’ll find CRL people
who are trained to provide assistance with CRL products and services.
They have instant access to pricing, stock availability, and the status of your
account, plus they can connect you to CRL Technical Sales personnel if you
need specialized product assistance. Order Desk hours are 6 am to 5 pm
(Pacific Time) Monday through Friday, and 7 am to 12 pm Saturdays.
AUSTRALIA: Sydney, NSW. - hone: [phone]
Melbourne, VIC. - hone: [phone]
Toll Free hone: 1800 424 275
Toll Free Fax Service
When we introduced toll free fax service in the ‘80’s we had no idea
how popular it would become, but now our customers send us up to
1,000 orders or quote requests every business day! Fax ordering is very
convenient because you can fill out your own purchase orders and then
just fax them to us. You can be specific about shipping instructions or
other details that will help us serve you. To send your orders or quote
requests by toll free fax from anywhere in the U.S. or Canada, just dial
[phone]./ Australia: 1800 813 013
Will Call/Trade Counter
Every CRL regional warehouse has a Will Call/Trade Counter where
you can place and pick up your orders in person. And when you place
your order in advance by phone, fax, or over the Internet we can have
it ready and waiting for you, which can save you a lot of time. Will Call/
Trade Counter hours are 7 am to 5 pm Monday through Friday, and 8 am
to 12 pm Saturdays. Some of our most experienced people staff our Will
Call/Trade Counters, and they are always happy to see you.
Remember, to save time place your order in advance.
Methods of Ordering

crlaurence.com • Toll Free [phone] • Fax [phone]
CRL Glass Machinery • [phone] • Fax [phone] Int. Phone: [phone]
CALL TOLL FREE ANYWHERE IN THE U.S. AND CANADA • ALL PRODUCTS F.O.B. NEAREST WAREHOUSE
CRL/S MACA BELT SANDER
M DELS 2300RP, 2300, AU2300 and AU23
SM2200_04/12
Important Information
Model Number____________________
Serial Number____________________
Build Date_______________________
Date of Delivery__________________
Serial Number
Model Number
TERMS AND C NDITI NS
MACHINERY WARRANTY STATEMENT
C.R. LAURENCE C ., INC. (“SELLER”) WARRANTS PR DUCTS F ITS MANUFACTURE T BE FREE FR M DEFECTS IN MATERIALS R W RKMANSHIP IN N RMAL USE F R (12) M NTHS
FR M THE DATE F SHIPMENT (UNLESS A SH RTER PERI D IS PR VIDED ELSEWHERE IN THIS D CUMENT). SELLER’S BLIGATI N AND BUYER’S EXCLUSIVE REMEDY SHALL BE
LIMITED T REPAIR R REPLACEMENT, AT SELLER’S S LE PTI N, F DEFECTIVE PARTS WITHIN THE WARRANTY PERI D, PR VIDED BUYER GIVES SELLER IMMEDIATE WRITTEN N TICE
F SUCH ALLEGED DEFECTS, AND, IF REQUESTED BY SELLER, RETURNS THE DEFECTIVE PARTS T SELLER’S FACT RY PREPAID BY BUYER F R SELLER’S INSPECTI N. THE WARRANTIES
C NTAINED HEREIN ARE IN LIEU F ANY THER WARRANTY, EXPRESSED R IMPLIED, INCLUDING ANY WARRANTY F MERCHANTABILITY R FITNESS F R PURP SE. SELLER SHALL
IN N EVENT BE LIABLE F R C NSEQUENTIAL DAMAGES. WARRANTIES HEREUNDER SHALL N T APPLY T ANY EQUIPMENT THAT HAS BEEN DAMAGED BY MISUSE, NEGLECT, ACCIDENT,
R FAILURE T PERF RM MAINTENANCE. THIS WARRANTY SHALL BE NULL AND V ID (1) IF THE MACHINE IS USED IN A MANNER C NTRARY T INSTRUCTI NS R AFTER MALFUNCTI N
IS N TICED; (2) IF THE BUYER D ES N T H N R TERMS F PAYMENT; (3) IF THE MACHINE IS M DIFIED R ALTERED.
EQUIPMENT RES LD BY SELLER
IN THE CASE F EQUIPMENT FURNISHED BY SELLER BUT N T F SELLER’S MANUFACTURE, SELLER’S LIABILITY T BUYER HEREUNDER IS LIMITED T SUCH WARRANTY AS THE
MANUFACTURER MAKES T SELLER, BUT IN N CASE GREATER THAN (12) M NTHS FR M DATE F SHIPMENT BY SELLER.
LIMITATI N F LIABILITY
SELLER’S S LE REMEDY SHALL BE REPAIR R REPLACEMENT F DEFECTIVE PR DUCT. IN N EVENT SHALL SELLER BE LIABLE F R ANY THER REMEDY (INCLUDING, BUT N T
LIMITED T , INCIDENTAL R C NSEQUENTIAL DAMAGES F R L ST PR FITS, L ST SALES, INJURY T PERS NS R PR PERTY R ANY THER INCIDENTAL R C NSEQUENTIAL L SS)
R PUNITIVE DAMAGES.
DISPUTE RES LUTI N
ANY DISPUTE BETWEEN THE CUST MER AND SELLER SHALL BE SETTLED BY ARBITRATI N BETWEEN THE PARTIES, UNDER THE RULES F THE AMERICAN ARBITRATI N ASS CIATI N,
CHICAG , IL SUCH ARBITRATI N SHALL TAKE PLACE IN CHICAG , IL, USA WITHIN 90 DAYS AFTER A REQUEST F R ARBITRATI N HAS BEEN FILED BY NE F THE PARTIES. B TH
PARTIES IRREV CABLY C NSENT T JURISDICTI N IN C K C UNTY, ILLIN IS.
LAW
ALL C NTRACT AND THER CLAIMS (WHETHER BASED N C NTRACT, T RT, EQUITY, TREATY, R C DE) WITH RESPECT T THE PR DUCTS S LD AND ALL CLAIMS WITH RESPECT T
THE PERATI N AND USE F THE PR DUCTS SHALL BE G VERNED BY, AND C NSTRUED IN ACC RDANCE WITH THE LAWS F THE STATE F ILLIN IS, USA. THE SALES C NTRACT
SHALL N T BE G VERNED BY THE UNITED NATI NS C NVENTI N N C NTRACTS F R THE INTERNATI NAL SALES F G DS.
INVALIDITY F PR VISI NS
IF ANY PR VISI NS F THESE TERMS AND C NDITI NS ARE HELD T BE INVALID, ILLEGAL R UNENF RCEABLE, THE REMAINING PR VISI NS F THESE TERMS AND C NDITI NS
SHALL N T IN ANY WAY BE AFFECTED R IMPAIRED THEREBY.
C.R. Laurence Co., Inc.
Glass Machinery Division
5501 West gden Avenue, Cicero, IL 60804, U.S.A.
