Crofton Item# 7256 User manual

Cordless Hand Vacuum
Item# 7256
PLEASE READ THESE AND SAVE ALL INSTRUCTIONS TO ENSURE THE
SAFE AND EFFECTIVE USE OF THIS APPLIANCE.

1
TABLE OF CONTENTS
Index P.1
Important Safeguards P. 2, 3
General Safety Instructions P.4
List of Main Parts, Tech. Specifications,
Contents of Packaging P.5
Before First Use, Assembly and Operation P.6
Installing wall mount, Charging the Hand
Vacuum
P. 7
Maintenance P. 8
Removing Rechargeable Battery P. 9
Trouble Shooting, Service Center P. 10
Warranty Information P. 11
Warranty Card P. 12
Order Form P. 14

2
IMPORTANT SAFEGUARDS
When using an electrical appliance, basic safety precautions should also be observed,
including the following.
PLEASE READ AND SAVE ALL INSTRUCTION BEFORE USING THE CORDLESS
HAND VACUUM.
WARNING: To reduce the risk of fire, electrical shock, or injury.
1. Do not charge this unit outdoors.
2. Do not use outdoors or on wet surfaces.
3. Do not allow to be used as a toy. Close attention is necessary when used by or
near children.
4. Use only as described in this manual. Use only manufacturer’s recommended
attachments.
5. Do not use charger if power cord has been damaged. Do not use cordless hand
vacuum or charger if it has been dropped, damaged, left outdoor, or dropped in
water.
6. Do not abuse the charger cord. Never carry the charger or base by the cord or
yank to disconnect from an outlet; instead grasp the plug and pull to disconnect.
7. Keep charger cord away from heated surfaces.
8. This product includes a rechargeable lead acid battery. Batteries must be
recycled or disposed properly. Do not incinerate batteries or expose to high
temperatures, as they may explode.
9. Do not handle plug or appliance with wet hands.
10.Do not put any object into openings. Do not use with any opening blocked; keep
free of dust, lint, hair and anything that may reduce air flow.
11.Keep hair, loose clothing, fingers, and all parts of body away from openings and
moving parts.
12.Do not pick up anything that is burning or smoking, such as cigarettes, matches,
or hot ashes.
13.Do not attempt to change accessories while unit is running.
14.Use extra care when cleaning on stairs.
15.Do not use to pick up flammable or combustible liquids such as gasoline or use in
areas where they may be present.
SAVE THESE INSTRUCTIONS

3
16.Look on your hand vacuum and follow all label and marking instruction.
17.Do not use charger with an extension cord. Plug charger directly into an
electrical outlet. Use charger only in a standard (12V, 60Hz) electrical outlet.
18.Do not use the hand vacuum cleaner without the dust cup filter in place.
19.Store the cordless vacuum cleaner indoors. Put the cordless vacuum cleaner
away after use to prevent accidents.
20.Leaks from battery cells can occur under extreme conditions. If the liquid gets
on the skin- wash immediately with soap and water or neutralize with a mild acid
such as lemon or vinegar. If the liquid gets into the eyes, flush them immediately
with clean water for a minimum of 10 minutes and seek medical attention.
21.Use only on dry, indoor surfaces.
22.Do not use for any purpose other than described in this user’s guide.
23.Do not attempt to use the charger with any other product nor attempt to charge
this product with another charger.
24.The battery must be removed from the appliance before it is discarded.
25.The battery is to be recycled or disposed of safely.
26.The appliance must be disconnected from the supply when removing the battery.
For Household Use Only
SAVE THESE INSTRUCTIONS

GENERAL SAFETY INSTRUCTIONS
WARNING! Read and understand all instructions. Failure to follow all instructions
listed below may result in electric shock, fire or serious personal injury. The warnings,
cautions, and instruction discussed in this instruction manual cannot cover all possible
conditions and situations that may occur. It must be understood by the operator that
common sense and caution are a factor which cannot be built into this product, but must
be supplied by the operator.
SAVE ALL INSTRUCTIONS!
CAUTION: A short power supply cord is provided to reduce the risk of personal injury
resulting from becoming entangled in or tripping over a longer cord.
ELECTRIC POWER
If electric circuit is overloaded with other appliances, your appliances may not operate
properly. The appliances should be operated on a separate electrical circuit from other
operating appliances.
SAFETY WARNING
Although your appliance is easy to operate, for your safety, the below warnings must be
followed:
1. Do not place the appliance near a heat source.
2. Use the appliance on a stable surface.
3. Do not unplug the adapter by pulling on the supply cord.
4. The appliance must be unplugged:
A. Before emptying
B. Before any cleaning or maintenance
C. If it appears to be faulty
THIS PRODUCT IS INTENDED FOR HOUSEHOLD USE ONLY.
4

LIST OF MAIN PARTS
1. On/Off Switch
2. Dust Cup Release Button
3. Wall Mount
4. Power Adapter
5. Dust Cup Filter 4
6. Dust Cup
7. Dusting Brush 9
8. Crevice Tool
9. Power cord
2 1 3
8 7 6 5
TECHNICAL SPECIFICATIONS:
Model Number 7256
Rating Voltage 6 Volt, DC
Weight 4 lbs
Charger Ratting 120 60 Hz AC only
Charger Voltage 7.2 Volt DC 350mA
Charger Rate 3-4 Hours
CONTENTS OF PACKAGING
a. Instruction Manual
b. Power Adapter
c. One Dusting Brush
d. One Crevice Tool
e. One Wall Mount with 2 screws and 2 wall anchors
f. One Rechargeable Lead Acid Battery
If any of the above items are missing, please contact our service department at 1-888-
367-7373 (http://wwwk.wk-usa.com) for replacement.
5

BEFORE THE FIRST USE
Before using the vacuum cleaner the cleaner needs to be charged at least 20
hours. To extend the life time of this appliance the battery may be recharged
after every use. NEVER FULLY DISCHARGE THE BATTERY.
Before using or cleaning the hand vacuum cleaner, please always unplug the
charger and take the unit out of the charger.
ASSEMBLY, OPERATION AND CHARGING HAND VACUUM
ASSEMBLY
Note: Dust cup filter must always be used when operating the hand vacuum
cleaner.
1. To open the dust cup compartment press the
dust cup release button and remove the dust cup
container (see FIG. 1). Slide the dust cup
container forward to remove dust cup.
FIG. 1
2. Verify that the dust cup filter is inside, then re-
attach the dust cup container to the hand vacuum
cleaner (see FIG. 2).
FIG. 2
3. To attach the crevice tool or the dusting brush
to the hand vacuum push the attachment into the
suction hole in front of the dust container. (see
FIG. 3)
FIG.3
6

USING THE CORDLESS HAND VACUUM CLEANER
1. Remove the vacuum cleaner from the
charging base.
2. To use the hand vacuum cleaner slide the
on/off button forward.
3. To turn the unit off, slide the on/off button
backwards.
4. A crevice tool is provided for cleaning narrow, hard to reach places. A dusting brush
is provided for cleaning upholstery and furniture.
CAUTION: The suction hole must be open and free of any obstruction at all
times. Otherwise, the motor will overheat and could become damaged.
INSTALLATION OF WALL MOUNT
Hold the wall mount on to a spot you wish to install the wall mount and draw drill points
through the wall mount holes. Please make sure to be close enough to the next
power outlet to connect the cord. Drill 2 holes at the marked points. Prior to drilling
verify that no water, gas or power lines are close to the holes to be drilled. Install the
wall mount with the supplied screws and wall anchor. Please check if the wall anchor and
screws match your wall type (wood, concrete, and drywall). You might need to use
different screws and wall anchors that fit your application better.(see FIG 4)
FIG. 4
CHARGING THE HAND VACCUM CLEANER
NOTE: Ensure that the On/Off switch is in the “Off” position before charging.
A. Connect the cable to the charging station with the power source at the vacuum
cleaner. Now connect the power cord to a 120 volt power outlet.
OR
B. Connect the cable to the wall mounted charging station as
displayed in FIG. 4. Now connect the power cord to a 120 Volt
power outlet. (see FIG. 5)
FIG. 5
7

Slide the vacuum cleaner onto the charging station. Be sure that
it is seated all the way in (see FIG. 6).
FIG. 6
By connecting the vacuum cleaner to the power source, the charging process will begin.
The red light on the unit will indicate that the vacuum cleaner is in the charging process.
As long as the vacuum cleaner is connected to a power source the red light will
stay on. If the vacuum cleaner is used daily it can be left in the charging station. If the
unit is not used for an extended period or not frequently used it is recommended to
remove the unit from the charging station and unplug it from the power source.
If rechargeable battery of the hand vacuum cleaner is not fully discharged, it usually can
be recharged within 3 hours to reach the maximum capacity. During the charging
process the unit may get slightly warm which is normal.
To extend the life time of this appliance always recharge after every use. NEVER FULLY
DISCHARGE THE BATTERY.
For replacement rechargeable batteries see attached order form.
CAUTION: NEVER use the unit without the battery compartment cover in place.
MAINTENANCE
CAUTION:
Always be sure that the appliance is switched OFF before cleaning the appliance or
attempting to store the item.
CLEANING THE DUST CUP AND FILTER
1. Remove the dust cup container by pressing the button on the top of the unit.
2. Remove by pulling the dust cup forward, away from the unit.
3. Empty the dust cup from the dust cup container.
4. Rinse the dust cup filter in cold water, and then wait until it dries completely
before replacing it back into the dust cup container. DO NOT use a washing
machine to clean the dust cup filter. DO NOT use a hair dryer to dry filter. AIR
DRY ONLY.
5. Replace the dust cup filter carefully into the dust cup compartment. NEVER
operate hand vacuum without dust cup filter in place.
6. Attach the dust cup container to the cordless vacuum.
7. The housing of the unit can be cleaned with a damp cloth and mild detergent.
8. Do not use abrasive powders, hard abrasive scourer or steel wool.
IMPORTANT: Make sure that the Dust Cup Filter is completely air dried before
re-installing back into the hand vacuum.
NOTE: It is recommended that the dust cup filter be replaced every three
months to ensure peak performance of unit. See attached order form.
8

STORING
Allow the appliance to cool completely before storing. Store the appliance in a dry
location. Do not place any heavy items on top of appliance during storage as this may
result in possible damage of appliance.
Store the cord in a clean, dry location away from metal objects. Always check the plug
before use to assure metal items have not become attached.
REMOVING THE RECHARAGEABLE BATTERY
In case the battery has reached the end of life cycle (approx. 1000 charges) it can be
replaced by a replacement battery. Replacement batteries can be ordered from our
Service Department (see attached order form).
To remove the battery unplug the charger and remove the vacuum cleaner from
the charging station.
Discharge the battery by switching the unit on and running the vacuum cleaner
to a full stand still of the motor.
To remove the battery open the battery compartment
at the bottom of the vacuum cleaner with a screw
driver. (see FIG. 7)
FIG. 7
Open the battery compartment lid and pull the battery
as far as possible out of the unit. Now disconnect the
power cables on the battery. (see FIG. 8)
FIG. 8
NOTE: Please bring the used battery to your next recycle station for proper
disposal. Do not dispose the battery into your normal household
waste/garbage.
9

TROUBLE SHOOTING
PROBLEM POSSIBLE SOLUTION
HAND VACUUM WILL NOT OPERATE 1. Charge unit
2. Check fuse or breaker of your
household circuit. Replace
fuse/reset breaker.
HAND VACUUM WILL NOT PICK UP OR
SUCTION IS WEAK 1. Empty dust cup. 2. Remove dust cup filter and check
for object(s) in the air duct and
remove. Clean or replace dust cup
filter.
3. Charge unit.
DUST ESCAPING FROM HAND VACUUM 1. Empty dust cup container.
2. Review dust cup filter installation
instruction.
3. Replace clean dust cup filter.
SERVICE CENTER
If you have any question in regards to the operation of this appliance or are in need of a
spare part please contact our service center at:
Wachsmuth & Krogmann, Inc.
Tel: [phone]
(Business hours Mon-Fri 9:00am - 4:00pm CT)
Website: http://www.wk-usa.com
ENVIRONMENTAL PROTECTION
If the appliance should no longer work at all, please make sure that it is disposed in an
environmentally friendly way. Please do not put it with your household waste.
NOTE: Please bring the used battery to your next recycle station for proper
disposal. Do not dispose the battery into your normal household
waste/garbage.
10

11
LIMITED WARRANTY
Thank you for purchasing a top quality Crofton product. This Crofton
Rechargeable Cordless Hand Vacuum Cleaner item #7256 was tested and
meets our stringent quality standards. This product is warranted to be free from
manufacturing defects in original materials, including original parts, and
workmanship until May 23, 2006 or 1 year with proof of purchase.
The warranty is void if the defect is due to accidental damage, misuse, abuse,
neglect, improper repair or alteration by unauthorized persons or failure to follow
operation instructions provided with the product. This warranty does not apply to
commercial use.
The warranty is non-transferable and applies only to the original purchase and
does not extend to subsequent owners of the product. Liability under this
warranty is limited to repair, replacement or refund. In no event shall liability
exceed the purchase price paid by the purchaser of the product. Under no
circumstances shall there be liability for any loss, direct, indirect, incidental,
special or consequential damage arising out of in connection with use of this
product. This warranty is valid only in the United States of America. This Warranty
gives you specific legal rights. However you may have other rights that vary from
state to state. Some states do not allow limitation on implied warranties or
exclusion of consequential damages therefore these restrictions may not apply to
you.
In case you find the product to be defective please send it within the warranty
period to our service center. To avoid transport damages please send the product
in the original packaging. In return you will either receive your repaired item, a
new product or a refund. Please fill out the Warranty Card and send it together
with the product and purchase receipt
To arrange pick-up of the defective item please call our service center:
Wachsmuth & Krogmann Inc.
Tel: [phone] (Business hours Mon-Fri 9:00am-4:00 pm CT)
Website: http://www.wk-usa.com
123 Sivert Court,
Bensenville,IL 60106,
USA
WARRANTY INFORMATION

12
WARRANTY CARD
Crofton Rechargeable Cordless Hand Vacuum Cleaner, Item #7256
In case you find this product to be defective please send it within the
warranty period to our service center. To avoid transport damages please
send the product in the original packaging. In return you will receive your
repaired item, a new product or a refund.
Customer Name
Street
City
State
ZIP Code
Purchase Date
Description of Defect :
PLEASE DETACH THIS SECTION AND RETURN IT WITH YOUR PRODUCT
To arrange pick-up of the defective item please call our service center:
Wachsmuth & Krogmann Inc.
Tel: [phone] (Business hours Mon-Fri 9:00am-4:00 pm CT)
Website: http://www.wk-usa.com
123 Sivert Court,
Bensenville,IL 60106,
USA
WARRANTY CARD

ORDER FORM
FOR Rechargeable Batteries
Price per Set (includes shipping and handling $10.00)
Please send a MONEY ORDER only (no cash or personal checks) ,
payable to Wachsmuth & Krogmann Inc. to the following address:
Wachsmuth & Krogmann Inc,
123 Sivert Court
Bensenville, IL 60106
Kindly fill in your information below and send together with your
Money Order
Name
Street
City
State
ZIP
Date
Quantity of Battery Battery @ $ 10.00
Total amount $
13
