Crosley XUF14 Operating instructions

Upright, No-Frost Freezers Owner’s Manual
and Installation
Instructions
Contents
Safety Information.................3
Using the Freezer
Temperature Control ..............5
Features ........................7
Care And Cleaning ................9
Installation Instructions
Installing the Freezer .............12
Troubleshooting Tips .............13
Limited Warranty .................15
Consumer Support ...............16
Models: XUF14, XUF17, XUF21
49-1000101 Rev. 0 07-18 GEA
Write the model and serial numbers here:
Model # _______________________________
Serial # _______________________________
Find these numbers on a label on the top inner
case liner of the unit toward the front. English/Español

249-1000101 Rev. 0
America's iconic brand, backed by America's best appliance warranty!
10 Year Limited Warranty FREE on all Crosley Appliances!
Visit Crosley.com/mycrosley to register the extended limited warranty.
APPLIANCE COMPONENT MANUFACTURER'S
LIMITED WARRANTY CROSLEY'S EXTENDED LIMITED WARRANTY
Refrigerator or
Freezer Compressor 1 Year
10 Years
Including 1 year Manufacturer's
Coverage
Top-Load Washer Gearcase/
Transmission 1 Year
Front-Load
Washer Motor 1 Year
Compact Washer Motor 1 Year
Washer/Dryer
Stack Unit
Motor/Heating
Element 1 Year
Dishwasher Motor 1 Year
Gas/Electric Dryer Motor/Heating
Element 1 Year
Electric Range Bake/Broil/Surface
Elements 1 Year
Gas Range Ignitors and Spark
Modules 1 Year

49-1000101 Rev. 0 3
CAUTION To reduce the risk of injury when using your freezer, follow these basic safety precautions.
■ Donotcleanglassshelvesorcoverswithwarm
water when they are cold. Glass shelves and
covers may break if exposed to sudden temperature
changes or impact, such as bumping or dropping.
Tempered glass is designed to shatter into many
small pieces if it breaks.
■ Keepfingersoutofthe“pinchpoint”areas;
clearances between the doors and between the
doors and cabinet are necessarily small. Be careful
closing doors when children are in the area.
■ Donottouchthecoldsurfacesinthefreezer
compartment when hands are damp or wet, skin
may stick to these extremely cold surfaces.
■ Donotrefreezefrozenfoodswhichhavethawed
completely.
SAFETY INFORMATION
READ AND SAVE THESE INSTRUCTIONS
WARNING To reduce the risk of fire, explosion, electric shock, or injury when using your upright
freezer follow these basic safety precautions:
■ Thisfreezermustbeproperlyinstalledandlocatedin
accordance with the Installation Instructions before it
is used.
■Unplugthefreezerbeforemakingrepairsorcleaning.
NOTE: Power to the freezer cannot be disconnected
by any setting on the control panel.
NOTE: Repairs must be performed by a qualified
Service Professional.
■Replaceallpartsandpanelsbeforeoperating.
■Donotstoreorusegasolineorotherflammable
vapors and liquids in the vicinity of this or any other
appliance.
■Donotstoreexplosivesubstancessuchasaerosol
cans with a flammable propellant in this appliance.
■Donotuseanextensioncord.
■Topreventsuffocationandentrapmenthazardsto
children, remove the door from any freezer before
disposing of it or discontinuing its use.
■Toavoidseriousinjuryordeath,childrenshouldnot
stand on, or play in or with the appliance.
■Childrenandpersonswithreducedphysical,sensory
or mental capabilities or lack of experience and
knowledge can use this appliance only if they are
supervised or have been given instructions on safe
use and understand the hazards involved.
■Thisapplianceisintendedtobeusedinhousehold
and similar applications such as: staff kitchen areas
inshops,officesandotherworkingenvironments;
farmhouses;byclientsinhotels,motels,bed&
breakfastandotherresidentialenvironments;catering
and similar non-retail applications.
IMPORTANT SAFETY INFORMATION
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE
WARNING EXPLOSION HAZARD
Keepflammablematerialsandvapors,suchasgasoline,awayfromfreezer.Failuretodosocanresultinfire,
explosion, or death.

449-1000101 Rev. 0
PROPER DISPOSAL OF YOUR OLD APPLIANCE
Do not, under any circumstances, cut or remove the third (ground) prong from the power cord.
For personal safety, this appliance must be properly grounded.
The power cord of this appliance is equipped with a
3-prong (grounding) plug which mates with a standard
3-prong (grounding) wall outlet to minimize the
possibility of electric shock hazard from this appliance.
Have the wall outlet and circuit checked by a qualified
electrician to make sure the outlet is properly
grounded.
Where a standard 2-prong wall outlet is encountered, it
is your personal responsibility and obligation to have it
replaced with a properly grounded 3-prong wall outlet.
Do not use an adapter.
The freezer should always be plugged into its own
individual electrical outlet which has a voltage rating
that matches the rating plate.
A 115 Volt AC, 60 Hz, 15- or 20-amp fused, grounded
electrical supply is required. This provides the best
performance and also prevents overloading house
wiring circuits which could cause a fire hazard from
overheated wires.
Never unplug your freezer by pulling on the power
cord. Always grip plug firmly and pull straight out from
the outlet.
Immediately discontinue use of a damaged supply
cord. If the supply cord is damaged, it must be
replaced by a qualified service professional with an
authorized service part from the manufacturer.
When moving the freezer away from the wall, be
careful not to roll over or damage the power cord.
CONNECTING ELECTRICITY
WARNING ELECTRICAL SHOCK HAZARD
Plug into a grounded 3-prong outlet
Do not remove the ground prong
Do not use an adapter
Do not use an extension cord.
Failure to follow these instructions can result in death, fire, or electrical shock.
SAFETY INFORMATION
IMPORTANT SAFETY INFORMATION
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE
READ AND SAVE THESE INSTRUCTIONS
WARNING SUFFOCATION AND ENTRAPMENT HAZARD
Failure to follow these disposal instructions can result in death or serious injury
IMPORTANT: Child entrapment and suffocation are not
problems of the past. Junked or abandoned appliances
arestilldangerouseveniftheywillsitfor“justafew
days.”Ifyouaregettingridofyouroldappliance,
please follow the instructions below to help prevent
accidents.
Before You Throw Away Your Old Appliance
■Take off door.
■Leave the shelves in place so that children may not
easily climb inside.
Refrigerant and Foam Disposal:
Dispose of appliance in accordance with Federal and Local Regulations. Flammable insulation material used
requires special disposal procedures. Contact your local authorities for the environmentally safe disposal of your
appliance.

49-1000101 Rev. 0 5
Starting the Freezer with Electronic Control
1. If desired,clean the inside of the freezer with a mild
solution of baking soda and water (see Care and
Cleaning).
2. Connect cord to power outlet. The 7-segement
display will come on and flash with the default setting
temperatureof0°F,andthe“HighTemp”Alarmwillbe
displayed on the electronic temperature control with
anaudiblewarning.Pressing“AlarmReset”onthe
control will silence the alarm, and stop the flashing,
butthe“HighTemp”LEDwillstayonuntilyourfreezer
reaches a safe storage temperature.
3.Press“-”or“+”toreachdesiredtemperature.
4.Press"+"and"-"buttonsatthesametimefor3
seconds to switch the display temperature unit
between °F and °C.
5. Allow freezer to operate for at least four hours before
placing food inside.
Temperature Control
USING THE FREEZER: Temperature Control
For safe food storage, allow 4 hours for the freezer to
cool down completely. The freezer will run continuously
for the first several hours. Foods that are already frozen
may be placed in the freezer after the first few hours of
operation. Unfrozen food should NOT be placed in the
freezer until it has operated for 4 hours. Allow several
hours after each one-step adjustment for the freezer
temperature to stabilize.
When loading the freezer, freeze only 3 pounds of
fresh food per cubic foot of space at a time. Distribute
packages evenly throughout the freezer. It is not
necessary to turn the control knob to a colder setting
while freezing food.
°F
°C
Demo
ON
ON
High Temp
Door open
Hold 3 Sec
Turbo Freeze
Control Lock
Alarm Reset

649-1000101 Rev. 0
Temperature Control
USING THE FREEZER: Temperature Control
This electronic temperature control is located on the
front of the freezer door. The temperature is factory-
preset to provide satisfactory food storage temperatures.
To adjust the temperature setting, press - to decrease
temperaturesand+toincreasetemperatures.Allow
several hours for the temperature to stabilize between
adjustments.
High Temp Alarm
This electronic control has a high temperature alarm
feature. An alarm will sound if the freezer temperature
is high. To silence the alarm, press Alarm Reset on the
control panel.
The High Temp will continue to be displayed on the
control panel until set temperature has been restored.
The alarm will sound again if the temperature is not
restored and remains high in six hours.
Turbo Freeze
To enable Turbo Freeze, press Turbo Freeze until
Turbo Freeze ON light turns on. The unit will be in
“TurboFreeze”modefor8hoursandtheON light for
Turbo Freeze will stay illuminated. After the 8 hours is
completed, Turbo Freeze turns off automatically. The
ON light will be off to show that Turbo Freeze is off. To
exit Turbo Freeze before the 8 hour automatic shutoff,
press Turbo Freeze until ON light for Turbo Freeze is off.
Control Lock
To lock the controls, press Control Lock and hold for 3
seconds until the ON light for Control Lock turns on.
To unlock, press and hold Control Lock for 3 seconds.
The ON light for Control Lock turns off and the control
panel will be unlocked. Control setting cannot be
changed when the control is locked.
Power Fail
If a power outage has caused the internal temperature
to be high, the high temp alarm will sound and the
temperature display will flash. Pressing Alarm Reset on
the control will silence the alarm and stop the flashing,
but High Temp LED will stay on until your freezer
reaches a safe storage temperature.
If the internal temperature has been restored before you
press Alarm Reset, the sound alarm will stop on its own,
and the High Temp LED will go off automatically. The
temperature display will continuing flashing to remind
you that a power outage has occurred. Press Alarm
Reset to stop the flashing.
Door Open Alarm
If your door has been left open for more than 2 minutes,
the control panel will display Door Open and will sound
an alarm until the door has been closed or Door Open
is pressed on the control panel. If Door Open has been
pressed but the door has not been closed, Door Open
will continue to be displayed on the control panel until
the door has been closed. If 10 minutes after Door
Open has been pressed, the door is still open, the door
open alarm will sound again.
C or F Setting
TochangebetweenC°orF°,pressandholdthe-and+
pads at the same time for 3 seconds.
Control Dormant
The control settings are displayed at normal condition.
Press and hold Control Lock and Turbo Freeze for
3 seconds. The electric control will enter into Dormant
Mode and will not show the control settings. The control
settings will be displayed for 30 seconds if one of the
buttons on the control is pressed or the door is opened
while in Dormant Mode. Press and hold Control Lock
and Turbo Freeze for 3 seconds again will disable
Dormant Mode.
°F
°C
Demo
ON
ON
High Temp
Door open
Hold 3 Sec
Turbo Freeze
Control Lock
Alarm Reset
High Temp Light
Door Open Light
Alarm Reset
Pad
Turbo Freeze Light
Lock Controls Light
Increase Pad
Decrease Pad

49-1000101 Rev. 0 7
Features
USING THE FREEZER: Features
Key-Ejecting Lock
The lock is spring loaded so the key cannot be left in the lock. To lock or unlock, press the key in while turning.
If the key is lost, you can order a replacement by calling GE Appliances at 800.492.2737 during normal business
hours. Provide the model and serial number of the freezer when requesting a replacement key.
WARNING
To prevent a child from being entrapped, keep the key out of reach of children and away from the freezer.
Drawers/Basket
The drawers or basket provide separate storage spaces
for items that are difficult to store on shelves. To remove
the drawers or basket, pull out and lift up.
Adjustable Shelves
The shelves are adjustable, some are full depth and the
others are partial depth.
The full depth shelf shall be installed to a higher position
wheretheunitisdeeper;andthepartialdepthshelf
shall be installed to a lower position where the unit is
shallower.
Top Drawer
Bottom
Drawer Bottom
Basket
Bottom
Drawers
Partial Depth
Shelf
Full Depth
Shelf

849-1000101 Rev. 0
Features
USING THE FREEZER: Features
Door Bins
There are 3 full depth door bins and one partial depth
door bin on the unit. The partial depth door bin should
always be installed at the bottom.
Partial Depth
Door Bin
Door Bins
Clear Door Bins Opaque Door Bins

49-1000101 Rev. 0 9
Care and Cleaning
CARE AND CLEANING
Cleaning the Outside
Door Handles and Trim. Clean with a cloth dampened
with soapy water. Dry with a soft cloth.
Keep the outside clean. Wipe with a clean cloth lightly
dampened with kitchen appliance wax or mild liquid dish
detergent. Dry and polish with a clean, soft cloth. Do not
wipe the freezer with a soiled dish cloth or wet towel.
These may leave a residue that can erode the paint. Do
not use scouring pads, powdered cleaners, bleach or
cleaners containing bleach because these products can
scratch and weaken the paint finish.
Cleaning the Inside
To help prevent odors, leave an open box of baking
soda in the freezer.
Unplug the freezer before cleaning. If this is not practical,
wring excess moisture out of sponge or cloth when
cleaning around switches, lights or controls. Use warm
water and baking soda solution--about a tablespoon
(15 ml) of baking soda to a quart (1 liter) of water. This
both cleans and neutralizes odors. Thoroughly rinse and
wipe dry.
CAUTION Do not clean glass shelves with warm
water when they are cold. Glass shelves may break if
exposed to sudden temperature changes or impact such as
bumping or dropping. Tempered glass is designed to shatter
into many small pieces if it breaks.
Do not wash any plastic freezer parts in the dishwasher.
Do not clean with any products containing detergent,
bleach or ammonia. They may damage the freezer.
After cleaning the door gaskets, apply a thin layer of
petroleum jelly to the door gaskets at the hinge side.
This helps keep the gaskets from sticking and bending
out of shape.
No Defrosting
You never have to defrost your new No-Frost freezer.
It has been pre-set at the factory to defrost itself
automatically.
During defrosting, a slight noise may be noticed if the
door is opened while the freezer is in the automatic
defrosting cycle.

10 49-1000101 Rev. 0
Care and Cleaning
CARE AND CLEANING
To Remove the Freezer Door
1. Remove the plastic hinge cover by removing one
screw, disconnect the wiring connector and remove
the ambient thermistor from the hinge cover, and then
lifting it off.
2. Remove the screws holding the hinge to the top of the
cabinetusingaPhillipsscrewdriveror5/16”socket
driver. Be carefully not to damage the wiring nearby.
3. Remove the top hinge from the cabinet and lift the
door up and off the lower hinge pin. Set the door
aside.
4. Remove the screws from the bottom hinge.
To replace the doors, reverse the order of the above
instructions.
NOTICE: It is very important that all hinge screws are
securely tightened to ensure a secure assembly and
prevent hinge slippage. Do not overtighten the hinge
screws. Tighten them until they are just snug, and then
turn them another one-half turn.
NOTE: The door swing is not reversible.
Wiring Connector
Top
Hinge
Hinge
Screws
Plastic
Hinge
Cover
Replacing the LED Light
The LED light is located behind a light lens in the celling
of the Freezer section.
To replace the LED light:
1. Remove the top shelf (if necessary).
2. Gently push the three snap-in tabs at the front of
the lens, release the lens from the liner, and pull to
remove.
3. Remove the LED assembly from the mounting tabs.
4. Gently pull the leads out and disconnect from the unit.
5. Replace with new LED assembly and slide assembly
back into mounting tabs.
6. Replace the light lens by sliding the tabs at the back
of the lens into the slots and push up on the lens until
the tabs at the front of the lens snap into place.
To order the LED assembly, please call
GE Appliances at 800.492.2737 during normal
business hours.
LED Assembly
Disconnect Leads
Light Lens in Freezer

49-1000101 Rev. 0 11
In Case of Extended Power Failure
■Keepfreezerdoorclosed.Yourfreezerwillkeepfood
frozen for 24 hours provided warm air is not admitted.
■If freezer is out of operation for 24 hours or more, add
dry ice. Leave ice in large pieces. Add more ice as
required.
CAUTION Handling of dry ice can cause
freezing of the hands—gloves or other protection is
recommended.
■If dry ice is not available, move food to a frozen food
locker temporarily—until power is restored.
Preparing to Move
Disconnect the power cord plug from the wall outlet.
Remove foods and clean the freezer.
Secure all loose items such as baskets and shelves by
taping them securely in place to prevent damage.
Be sure freezer stays in upright position during actual
moving and during transportation. The freezer must be
secured during transportation to prevent movement.
Protect outside of freezer with blanket.
Preparing for Vacation
To maintain freezer in operation during vacations,
be sure your house power is not turned off. For sure
protection of freezer contents, you may want to ask
a neighbor to check the power supply and freezer
operation every 48 hours.
For extended vacations or absences, you may prefer to
move your frozen foods to a storage locker temporarily.
If your freezer is to be left empty, disconnect power cord
plug from wall outlet. To prevent formation of odors,
place open box of baking soda in freezer and leave
freezer door open.
When the freezer is not operating, it can be left in an
unheated house or room without damage to cabinet or
mechanism.
Save Money/Save Energy
■The freezer should be located in the
coolest area of the room, away from
heat-producing appliances or heating
ducts, and out of direct sunlight.
■Let hot foods cool to room
temperature before placing in the
freezer. Overloading the freezer forces the compressor
to run longer. Foods that freeze too slowly may lose
quality or spoil.
■Be sure to wrap foods properly, and wipe containers
dry before placing them in the freezer. This cuts down
on frost buildup inside the freezer.
■Organize and label food to reduce door openings
and extended searches. Remove as many items as
needed at one time, and close the door as soon as
possible.
Care and Cleaning
CARE AND CLEANING

12 49-1000101 Rev. 0
Installing the Freezer
INSTALLATION INSTRUCTIONS
Freezer Location
Your freezer should be conveniently located for
day-to-day use in a dry, well-ventilated room.
Do not install the freezer where the temperature will go
below 0°F or above 110°F, because it will not maintain
proper temperatures.
Be sure to install your freezer on a floor strong enough
to support it when it is fully loaded.
Do not install the freezer in a location exposed to rain
water or direct sunlight.
Adjustable Legs
Legs at the front corners of the freezer should be set so
the freezer is firmly positioned on the floor, and the front
is raised just enough so the door closes easily when
opened about halfway.
Level Freezer
Use a carpenter’s level to level the freezer from back to
front. Adjust the plastic leveling feet in front 1/2 bubble
higher so the door closes easily when left open.
Unit Loading
NOTICE: To allow the door to close and seal properly,
DO NOT let food packages extend past the front of the
shelves.
Clearances
Onallmodels,allow3”(76mm)ontop,backandsidesforproperaircirculation.
Turn
right to
lower
Turn left
to raise
Door Handle
Shape of handle may vary on your model.
1. Align the handle with fasteners.
2. Push the handle over fasteners until it touches the
door.
3. Use the allen wrench to turn set screw clockwise to
fasten the handle to the door. Fasteners
Set Screw
Allen Wrench

49-1000101 Rev. 0 13
Problem Possible Causes What to Do
Freezer does not operate Freezer is unplugged. Push the plug completely into the outlet.
The fuse is blown/circuit breaker is
tripped.
Replace fuse or reset the breaker.
"Demo" LED light is on and
Freezer is in Demo mode.
Pleasepress“AlarmReset”first,andthenpress
the“-”and“+”immediatelywhileholding"Control
Lock" at the same time for 5 seconds and
release. "Demo" LED light will be off.
Freezer starts/stops too
frequently
Door left open. Check to see if package is holding door open.
Too frequent or too long door
openings.
Open the door less often.
Temperature control set too cold. See Temperature Control.
Freezer operates too long Door left open. Check to see if package is holding door open.
Too frequent or too long door
openings.
Open the door less often.
Temperature control set too cold. See Temperature Control.
Inadequate air circulation space
around cabinet.
See Installing the Freezer.
Room or outside weather is hot. It’s normal for the freezer to work harder under
these conditions.
Freezer has been disconnected
recently for a period of time.
It takes 4 hours for the freezer to cool down
completely.
Large amounts of warm or hot
food have been stored recently.
Warm food will cause the freezer to run more
until the desired temperature is reached
Noisy operation or cabinet
vibrates
Floor may be weak, causing
freezer to vibrate when
compressor is on.
Check to make sure freezer is located on solid
floor and adjust leveling legs as needed.
Cabinet is not positioned solidly
on floor.
Adjust legs. See Installing the Freezer. Or use
shims for uneven floor.
Freezer is touching the wall. Level freezer or move slightly. See Level
Freezer.
Freezer temperature too
warm Door left open. Check to see if package is holding door open.
Too frequent or too long door
openings. Open the door less often.
Temperature control is set too
warm. Turn control to a colder setting. Allow several hours for the temperature to stabilize.
Large amounts of water or hot food
may have been stored recently. Wait until the freezer has had a chance to reach its selected temperature.
Freezer has been disconnected
recently. Freezer requires 4 hours to cool down completely.
Foods defrosting High temp alarm is on and
temperature display is flashing. Power outage may have caused high internal temperature.
Freezer is unplugged. Push the plug completely into the outlet.
The fuse is blown/circuit breaker is
tripped. Replace fuse or reset the breaker.
Door left open. Check to see if package is holding door open.
Too frequent or too long door
openings. Open the door less often.
Freezer temperature too
cold Temperature control set too cold. See About the operation of your freezer.
TROUBLESHOOTING TIPS
Save time and money! Review the charts on the following pages first and you may not need to call for service.
Troubleshooting Tips... Before you call for service

14 49-1000101 Rev. 0
Troubleshooting Tips... Before you call for service
TROUBLESHOOTING TIPS
Problem Possible Causes What to Do
Moisture forms on outside of
cabinet Not unusual during periods of high humidity. Wipe surface dry.
Door may not be seating properly,
causing cold air from inside the
freezer to meet warm moist air
from the outside.
See Preparing to install the freezer.
Interior light does not work No power at outlet. Replace fuse or reset the breaker.
Freezer is unplugged. Push the plug completely into the outlet.
LED light burned out. Replace the LED.
Door won’t fully close by itself Legs need adjusting. See Preparing to install the freezer.
Package holding door open. Move package to a different location.
Slow starting time after being off Built-in overload protection. This is normal after being off.
Excessive frost buildup Door left open. Check to see if package is holding door
open.
Too frequent or too long door
openings. Open the door less often.
Not unusual during periods of high
humidity. Wipe surface dry.
Freezer external surface
temperature is warm The external freezer walls can be as much as 30°F warmer than
room temperature.
This is normal while the compressor
works to transfer heat from inside the
freezer cabinet.
Louder sound levels whenever
freezer is on Modern freezers have increased storage capacity and more stable
temperatures. They require a high-
efficiency compressor.
This is normal. When the surrounding
noise level is low, you might hear the
compressor running while it cools the
interior.
Higher sound levels when
compressor comes on Freezer operates at higher pressures during the start of the
ON cycle.
This is normal. Sound will level off or
disappear as freezer continues to run.
Popping or cracking sound when
compressor comes on
Metal parts undergo expansion and
contraction, as in hot water pipes. This is normal. Sound will level off or disappear as freezer continues to run.
Bubbling or gurgling sound, like
boiling water
Refrigerant (used to cool freezer) is
circulating throughout the system. This is normal.
Moisture forms on inside freezer
walls Weather is hot and humid, which increases internal rate of frost
buildup.
This is normal.
Door may not be seating properly. See Preparing to install the freezer.
Door is kept open too long, or is
opened too frequently. Open the door less often.
Odors in freezer Interior needs to be cleaned. Clean interior with sponge, warm water
and baking soda.
Foods with strong odors are in the
freezer. Cover the food tightly.
Normal Operating Characteristics
■A warm cabinet exterior as the refrigeration system
transfers heat from the inside to the outside through
the exterior cabinet walls.
■The sound of the high-efficiency compressor motor.
■The sound of water dripping as it melts from the
evaporator and escapes to the drain pan during defrost
cycle.
■The sound of the fan circulating air within the interior
of the cabinet providing a consistent temperature
throughout.

49-1000101 Rev. 0 15
For the Period of: GE Appliances Will Replace
One Year
From the date of the
original purchase
Any part of the freezer which fails due to a defect in materials or workmanship.
During the limited one-year warranty, GE Appliances will also provide, free of charge, all
labor and related service to replace the defective part.
Staple your receipt here. Proof of the original purchase date is needed to obtain service under the warranty.
LIMITED WARRANTY
■Servicetripstoyourhometoteachyouhowtouse
the product.
■Improperinstallation,deliveryormaintenance.
■Failureoftheproductifitisabused,misused,or
used for other than the intended purpose or used
commercially.
■Lossoffoodduetospoilage.
■Damagecausedafterdelivery.
■Replacementofhousefusesorresettingofcircuit
breakers.
■Damagetotheproductcausedbyaccident,fire,
floods or acts of God.
■Incidentalorconsequentialdamagecausedby
possible defects with this appliance.
■Productnotaccessibletoproviderequiredservice.
This warranty will not cover:
Crosley.com
Your appliance is covered by a limited warranty, as listed below, by GE Appliances. All warranty service is provided by
our GE Appliances Factory Service Centers, or an authorized service technician. To schedule service, call Crosley at
800.544.4780. Please have your serial number and your model number available when calling for service.
Crosley®Corporation Refrigerator Limited Warranty
EXCLUSION OF IMPLIED WARRANTIES
Your sole and exclusive remedy is product repair as provided in this Limited Warranty. Any implied warranties,
including the implied warranties of merchantability or fitness for a particular purpose, are limited to one year or the
shortest period allowed by law.
This limited warranty is extended to the original purchaser and any succeeding owner for products purchased for
home use within the USA. If the product is located in an area where service by a GE Appliances Authorized Servicer
is not available, you may be responsible for a trip charge or you may be required to bring the product to an Authorized
GE Appliances Service location for service. In Alaska, the limited warranty excludes the cost of shipping or service
calls to your home.
Some states do not allow the exclusion or limitation of incidental or consequential damages. This limited warranty
gives you specific legal rights, and you may also have other rights which vary from state to state. To know what your
legal rights are, consult your local or state consumer affairs office or your state’s Attorney General.
Warrantor: GE Appliances, a Haier company
Louisville, KY 40225
Crosley®Extended Warranty
In addition to the warranty shown above, ask your dealer or visit us at Crosley.com/warranty regarding the
Crosley 10-Year Extended Limited Warranty that comes to you at no extra charge. This warranty will cover
your product after the initial manufacturer’s warranty expires up through 10 years. Please contact Crosley at
Crosley.com or call Crosley at 800.356.5268 for specific details.

16 49-1000101 Rev. 0
Consumer Support
CONSUMER SUPPORT
Crosley Website
Have a question or need assistance with your appliance? Try the Crosley Website 24 hours a day, any day of the
year at Crosley.com. You can also shop for more great Crosley products on our website.
Register Your Appliance
Register your new appliance on-line at your convenience at crosley.com/mycrosley. Timely product registration will
allow for enhanced communication and prompt service under the terms of your warranty, should the need arise. You
may also mail in the pre-printed registration card included in the packing material.
Schedule Service
Crosley repair service is only one step away from your door. Call 800.544.4780 during normal business hours to
schedule service.
CROSLEYCARE®10 Year Limited Warranty
When you buy a Crosley appliance, you receive one of the best warranties available in the appliance industry.
For more information visit Crosley.com/warranty. Visit Crosley.com/mycrosley to register the extended limited
warranty.
Parts and Accessories
Individuals qualified to service their own appliances can have parts or accessories sent directly to their homes (VISA,
MasterCard and Discover cards are accepted). Order on-line today 24 hours every day.
Visit GEApplianceparts.com or by phone at 877.959.8688 during normal business hours.
Instructions contained in this manual cover procedures to be performed by any user. Other servicing
generally should be referred to qualified service personnel. Caution must be exercised, since improper
servicing may cause unsafe operation.

Congelador Vertical, Modelos con
sistema No-Frost
Manual del
Propietario
e Instalación
Contenido
Información de seguridad ..........3
Usando el congelador
Control de Temperatura............5
Características ...................7
Cuidado y limpieza ................9
Instrucciones de instalación
Cómo poner el congelador
en funcionamientor ............12
Solucionar problemas.............13
Garantía limitada .................15
Servicio al consumidor............16
Modelos: XUF14, XUF17, XUF21
49-1000101 Rev. 0 07-18 GEA
Escriba los números de modelo y de serie aquí:
Número de modelo : ________________
Número de serie:___________________
Puede encontrarlos en una placa en la pared
superior izquierda dentro del congelador. Español

249-1000101
¡La icónica marca estadounidense apoyada por la mejor garantía de electrodomésticos
estadounidense! ¡Garantía Limitada por 10 Años GRATUITA en todos los
Electrodomésticos Crosley!
Visite Crosley.com/mycrosley y registre la garantía limitada extendida.
ELECTRODO-
MÉSTICO COMPONENTE GARANTÍA LIMITADA DEL FABRICANTE GARANTÍA LIMITADA EXTENDIDA DE CROSLEY
Refrigerador o
Freezer Compresor 1 Año
10 años
Incluyendo Cobertura del
Fabricante por 1 Año
Lavadora de
Carga Superior
Caja de engranajes/
Transmisión 1 Año
Lavadora de
Carga Frontal Motor 1 Año
Lavadora
Compacta Motor 1 Año
Unidad de
Almacenamiento
de Lavadora/
Secadora
Motor/Elemento de
Calefacción 1 Año
Lavavajillas Motor 1 Año
Secadora a Gas/
Eléctrica
Motor/Elemento de
Calefacción 1 Año
Cocina Eléctrica
Elementos para
Hornear/ Asar/ de la
Supercie
1 Año
Cocina a Gas Arrancadoras y
Módulos de Chispa 1 Año

49-1000101 3
PRECAUCIÓN Para reducir el riesgo de lesiones al usar el freezer, siga estas precauciones básicas.
■ Nolimpieestantesdevidrionitapasconaguacaliente
cuando estén fríos. Los estantes de vidrio y las tapas
se pueden romper si son expuestos a cambios de
temperatura repentinos o impactos, tales como sacudones
o caídas. El vidrio templado está diseñado para destruirse
en pequeñas piezas en caso de rotura.
■ Mantengalosdedosfueradelosespaciosde“riesgode
lastimaduras”; los despejes entre las puertas y entre las
puertas y el gabinete son necesariamente pequeños.
Tenga el cuidado de cerrar las puertas cuando los niños
se encuentren en el área.
■ Notoquelassuperficiesfríasdelcompartimientodel
freezer cuando las manos estén húmedas o mojadas,
ya que la piel se podrá adherir a estas superficies
extremadamente frías.
■ Novuelvaacongelarcomidasquehayanestado
totalmente congeladas en forma previa.
INFORMACIÓN DE SEGURIDAD
LEA Y GUARDE ESTAS INSTRUCCIONES
ADVERTENCIA A fin de reducir el riesgo de incendio, explosión, descargas eléctricas o lesiones al usar su
congelador vertical, siga estas precauciones básicas de seguridad:
■ Estefreezersedeberáinstalaryubicaradecuadamente
de acuerdo con las Instrucciones de Instalación antes de
ser usado.
■Desenchufeelfreezerantesdehacerreparaciones,yasea
reemplazar una lámpara de luz o hacer una limpieza.
Nota: La corriente que va al freezer no puede ser
desconectada por ninguna configuración del panel de
control.
Nota: Las reparaciones deberán ser realizadas por un
Profesional del Servicio Técnico calificado.
■Reemplacetodaslaspiezasypanelesantesdeluso.
■Noguardeniusegasolinauotrosvaporesinflamablesy
líquidos cerca de este ni de otro electrodoméstico.
■Noguardesustanciasexplosivastalescomolatas
de aerosoles con propelentes inflamables en este
electrodoméstico.
■Nouseunprolongador.
■Afindeevitarriesgosdequelosniñossufranasfixia
o queden atrapados, retire la tapa del freezer antes de
deshacerse o dejar de usar el mismo.
■Paraevitarlesionesgravesolamuerte,losniñosnose
deberán parar sobre ni jugar en o con el electrodoméstico.
■Losniñosylaspersonasconcapacidadfísica,sensorialo
mental reducida o con falta de experiencia y conocimiento
podrán usar este electrodoméstico sólo si son
supervisados o les fueron dadas instrucciones sobre un
uso seguro y entienden los riesgos involucrados.
■Esteelectrodomésticofuediseñadoparausohogareñoy
para aplicaciones similares tales como: áreas de personal
de cocina en tiendas, oficinas y otros espacios laborales;
casas de campo; por clientes en hoteles, moteles, hostales
y otros espacios residenciales, catering y aplicaciones no
minoristas similares.
INFORMACIÓN IMPORTANTE DE SEGURIDAD
LEA TODAS LAS INSTRUCCIONES ANTES DE USAR
ADVERTENCIA RIESGO DE EXPLOSIÓN
Mantenga cualquier material y vapores inflamables, tales como gasolina, alejados del freezer. Si no se cumple con esto se
podrá producir una explosión, incendio o la muerte.

449-1000101
FORMA ADECUADA DE DESCARTAR SU ANTIGÜO CONGÉLATEUR
Nunca, bajo ninguna circunstancia, corte o elimine el tercer cable (tierra) del cable de corriente.
Para su seguridad personal, este electrodoméstico debe estar adecuadamente conectado a tierra.
El cable de corriente de este electrodoméstico cuenta con
un enchufe de 3 cables (conexión a tierra) que se conecta a
un tomacorriente de pared estándar de 3 cables (conexión a
tierra) para minimizar la posibilidad de riesgos de descargas
eléctricas por parte del mismo.
Contrate a un electricista calificado para que controle el
tomacorriente y el circuito eléctrico, a fin de asegurar que el
enchufe esté correctamente conectado a tierra.
En caso de contar con un tomacorriente de pared de 2
cables, es su responsabilidad y obligación reemplazarlo
por un tomacorriente de pared de 3 cables correctamente
conectado a tierra. No use un adaptador.
El freezer deberá estar siempre conectado a un enchufe
específico con un índice de voltaje equivalente al que figura
en la placa de calificación.
Se requiere un suministro eléctrico con fusible y conexión
a tierra de 115 voltios de CA, 60 Hz, 15 o 20 amperes.
Esto garantiza el mejor funcionamiento y además previene
la sobrecarga de los circuitos del hogar, lo cual podría
ocasionar riesgos de incendio debido al recalentamiento de
cables.
Nunca desenchufe el congelador tirando del cable de
corriente. Siempre tome su enchufe firmemente y empuje el
mismo hacia fuera para retirarlo.
Inmediatamente interrumpa el uso de un cable de suministro
de corriente dañado. Si el cable de corriente se encuentra
dañado, su reemplazo deberá ser realizado por un
profesional calificado del servicio técnico, utilizando una
pieza del servicio técnico autorizada por el fabricante.
Al alejar el freezer de la pared, se deberá tener cuidado de
que no ruede sobre ni dañe el cable de corriente.
CONEXIÓN DE LA ELECTRICIDAD
ADVERTENCIA RIESGO DE DESCARGA ELÉCTRICA
Enchufe en un tomacorriente con conexión a tierra de 3 cables.
No elimine el cable de conexión a tierra.
No use un adaptador.
No use un prolongador.
Si no se siguen estas instrucciones se podrá producir la muerte, incendios o descargas eléctricas.
INFORMACIÓN DE SEGURIDAD
INFORMACIÓN IMPORTANTE DE SEGURIDAD
LEA TODAS LAS INSTRUCCIONES ANTES DE USAR
LEA Y GUARDE ESTAS INSTRUCCIONES
Cómo Eliminar Refrigerantes y Gomaespumas:
DescarteelelectrodomésticodeacuerdoconlasRegulacionesFederalesyLocales.Elmaterialaislanteinflamableusado
requiere procedimientos de descarte especiales. Comuníquese con las autoridades locales para descartar su electrodoméstico
de forma ambiental mente segura.
ADVERTENCIA PELIGRO DE SUFFOCATION Y ENTRAPMENT
El incumplimiento de estas instrucciones de eliminación
puede causar la muerte o lesiones graves.
IMPORTANTE: Que un niño quede atrapado o que sufra una
asfixia no son problemas del pasado. Los electrodoméstico
antiguos o abandonados aún son peligrosos, incluso aunque
seconservenpor“sólounospocosdías”.Sisedesharáde
su antiguo electrodoméstico, siga las siguientes instrucciones
a fin de evitar accidentes.
Antes de Descartar su Antiguo Refrigerador o
Congélateur:
■Retire la tapa del congelador.
■Dejelosestantesensulugardemodoquelosniñosno
puedan trepar dentro con facilidad.
