Crumar MOJO 61 User manual

OPTIONAL
LOWER MANUAL
USER'S MANUAL
www.crumar.it
CRUMAR LOWER MANUAL FOR MOJO 61 - USER'S MANUAL - Page 1/4

SAFETY INFORMATION
–Do not open the in trument. The in trument can be opened and repaired only
by qualified per onnel. Unauthorized opening void the warranty.
–Do not expo e the in trument to rain or moi ture.
–Do not expo e the in trument to direct unlight.
–Be careful not to infiltrate powder and liquid in ide the in trument. Nor on
the out ide.
–If liquid get in ide the unit, remove the power immediately to prevent the ri k
of electric hock and contact a ervice center a oon a po ible.
–Do not clean u ing abra ive cleaner a they may damage the urface.
–Plea e keep all packaging in ca e you need to tran port the in trument to a
ervice center.
WARRANTY
–Crumar Lower Manual for Mojo 61 i ubject to 12 month manufacturer'
warranty.
–Warranty exten ion are at the di cretion of the retailer.
–Damage cau ed by mi u e, improper maintenance or tran portation are not
covered by thi warranty.
–During the warranty period, the cu tomer i entitled to repair or replacement
of any part con idered defective at no charge.
–The po ible replacement of the entire product i at the manufacturer'
di cretion.
1. INTRODUCTION
The Lower Manual for Mojo 61 i an additional keyboard that turn the portable
ingle-manual Mojo 61 into a complete dual manual organ con ole, giving the player
the experience of a real combo organ etup adding the ver atility of two different
choice for different ituation .
Thi additional keyboard i ba ed on the ame “waterfall” keybed a the Mojo 61 in
order to pre erve the integrity of the organ experience, re ulting in a very natural
feel for both manual .
The y tem i perfectly integrated, allowing the player to control both manual with
ju t one et of drawbar without any particular complication. On the Mojo 61 control
panel, pre and hold the MODE button until the yellow LED marked “EXT-LOWER”
light up. Thi will keep the upper manual ound on the upper keyboard even when
the LOWER button i active, allowing the player to adju t the lower manual drawbar
regi tration u ing the phy ical drawbar .
CRUMAR LOWER MANUAL FOR MOJO 61 - USER'S MANUAL - Page 2/4

2. CONNECTION AND MOUNTING PROCEDURE
Lay the Lower Manual on a keyboard tand, then place the Mojo 61 above it paying
attention to the rubber feet, they mu t match the underlying hole o that the two
piece are firmly tied together.
Locate the MIDI port on the back of the in trument and u e one of the two
provided pecial cable to attach the lower manual to one of the two MIDI IN port of
the Mojo 61. The cable carrie both MIDI and Power by mean of the two additional
wire that are not u ed by the MIDI protocol.
The optional Half Moon Switch for controlling the Rotary Speaker imulation can be
attached on the bottom front left of the lower manual.
PLEASE NOTE: THE HALF MOON SWITCH FOR THE DUAL MANUAL MOJO ORGAN IS
NOT COMPATIBLE WITH MOJO 61.
CRUMAR LOWER MANUAL FOR MOJO 61 - USER'S MANUAL - Page 3/4

. SPECIFICATIONS
Technical pecification :
–power rating: power over midi.
–weight: 8 Kg / 17,6 lb
Crumar Mojo 61 and Lower Manual for Mojo61 are digital Mu ical In trument de igned and built in Italy. All right
re erved.
All trademark u ed herein are the property of their re pective owner .
Crumar i a trademark owned by:
V.M. Connection
Via Pa coli, 44/A - 30020 Quarto d'Altino (VE) - Italy
www.Crumar.it
La t update: October 2017.
