CruzPro RP110 User manual

CruzPro
RP110
Trainable NMEA 0183
Data Repeater

Table of Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Key Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Backlight Intensity . . . . . . . . . . . . . . . . . . . . . . . . . 7
Selecting the NMEA Sentence to Display . . . . . . . . .7
Adding A Sentence To the List . . . . . . . . . 8
Deleting A Sentence From the List . . . . . . . . . 8
Manually Selecting A Data Channel . . . . . . . . . . . 9
Selecting Different Sentences With Identical ID's . . . 9
Downloading (Training) New NMEA Sentences. . . . . . . . 9
NMEA 0183 Sentences - Table 1 . . . . . . . . . 11
Other CruzPro Products . . . . . . . . . . . . . . . . . . . 16
2003 BV Engineering RP110AC
http://www.cruzpro.com Made in New Zealand
Page 2

Introduction
The RP110 remote data repeater is capable of displaying over
200 standard NMEA 0183 and proprietary sentences. The
RP110 can monitor up to 4 separate data channels and can be
trained to learn new sentences.
The RP110 is trainable to recognize and display new NMEA
0183 sentences not currently defined. Up to ten new sentence
formats can be downloaded into non-volatile memory using the
RS-232 serial data port of a PC compatible running Windows
95, 98, NT, SE, ME or 2000. A program is supplied on floppy
diskette and the latest versions can always be downloaded from
the CruzPro website.
Up to 12 sentence ID’s can be stored in a list of often viewed
sentences. You can select a sentence from this list quickly using
the tand s keys to scroll through the selections. You can
add and delete sentences to/from this list as often as desired.
Five levels of backlighting can be selected and remotely
switched ON/OFF. All settings are automatically saved to non-
volatile memory.
The RP110 works on both 12 and 24 VDC systems and with
its large display digits draws only .035 amps and only .075 amps
with full backlighting.
Page 3

Specifications
Power supply: 9.5 to 33.0 VDC, .035 amps nominal
Operating temperature: 32 to 122 F ( 0 to 50 C)
Size: 4.3" x 4.3” x 3.5” deep (110 x 110 x 89 mm).
Display: 4 digit LCD, 5 levels of backlighting.
Input Format: NMEA 0183, standard and proprietary sen-
tences.
Baud Rate: 4800
Input Channels: 4
Data Input voltage range: 0 to 5 V Nominal, -20V to +20V
maximum.
Data Memory: Storage for 10 new sentences (may be
overwritten).
Page 4

Page 5
Installation
Before starting the installation, please read this entire section
first. Finger tighten the screws that mount the instrument
bracket - It is not necessary or recommended to use tools.
lDrill a 2-1/8" (55mm) mounting hole where you desire to
mount the instrument (Figure 1).
lConnect the various wires as shown in Figure 2 and 3.
lCarefully check all your wiring against figures 2 and 3 and
then mount the instrument in the hole. Use only finger tension
to tighten the bracket hold-down nuts
Figure 1

Page 6
Figure 3
Figure 2

Operation
Key Functions
The t, :and skeys are used to select and set backlight levels,
and set/change constants such as which NMEA sentences to
display, select a data channel, save and delete NMEA sentences
from the favorites list and prepare the instrument to receive new
sentences from a PC. New information is automatically saved
to non-volatile memory.
Backlight Intensity
Press :the key 1/2 second to adjust the backlight level for
night viewing. Each time you press the :key 1/2 second, the
level will get brighter 1, 2, 3, 4, OFF, 1, 2, ... etc. The blue
backlight ON/OFF control wire must be switched to +12/24V
for the backlights to work and offers external backlight ON/
OFF control. If ON/OFF control is not required, connect the
blue wire to +12/24VDC permanently.
Selecting a NMEA Sentence to Display
Up to 12 sentences can be stored in a list of often viewed
sentences. You can select a sentence from the list using the t
and s keys. The RP110 comes pre-programmed with the
following list:
142 $SDDPT DEPTH RELATIVE TO TRANSDUCER MTRS
163 $VWVHW SPEED KNOTS
160 $VWMTW WATER TEMPERATURE DEGREES
98 $GPRMC COURSE OVER GROUND DEGREES TRUE
Page 7

36 $AGWNC DISTANCE WAYPT TO WAYPT N.MILES
125 $PBVE T-30 TEMPERATURE DEG. FAHRENHEIT
129 $PBVE OP-30 PRESSURE P.S.I.
124 $PBVE RH-30 ENGINE RPM
You can add and delete sentences to/from this list as often as
desired. Pressing the tor skey will step you through the list.
"- - - -" will be displayed until the selected sentence is found on
one of the channels.
Adding A Sentence To the List
Press and hold the :and skeys for 10 seconds until a long beep
is heard. "c011" is displayed. Use the tand s keys to select
a sentence from Table 1. Once the desired table entry is
displayed, hold down the :key for 1/2 second to save the
sentence to the list. The RP110 will immediately start searching
for the new sentence on all four channels.
If "FULL" is displayed in place of "c011", a sentence will first
have to be deleted from the list (see "Deleting A Sentence From
the List").
Deleting A Sentence From the List
If all 12 list positions are full, one sentence will have to be deleted.
Press and hold the tand :keys for 10 seconds. Use the t
and skeys to scroll through the list. When the sentence to
be deleted is displayed, press the : key for 1/2 second.
Page 8

Page 9
Manually Selecting A Data Channel
The RP110 searches each of the four data channels for the
desired sentence. When a matching sentence is found the
RP110 stops at that channel and displays the data. To select
between two or more data channels containing the same
sentence, press and hold the :key for 3 seconds. The RP110
will search the other channels for the sentence. If the sentence
is only available on the one channel, it will return back to the
original.
Selecting Different Sentences With Identical ID's
Some CruzPro instruments (such as the V30 triple volts gauge
and the TL30 triple tank level gauge) transmit more than one
sentence with the same identifier but different data. The TL30
Digital Tank Level Gauge for three tanks transmits one sentence
per tank but each have the same NMEA identifier "$IIXDR".
When viewing data from one of these CruzPro instruments you
can step through the different values with a quick press the :
key.
Downloading New NMEA Sentences
You can add up to 10 new sentences to Table 1 using a PC and
a serial data cable connected to channel 4 on the back of the
RP110 as shown in Figure 4. To upload a new sentence to the
RP110, press and hold the tand s keys for 10 seconds. The
instrument is ready for data transfer when "rdY" is displayed.

Page 10
Execute the program called RP110.EXE on the supplied floppy
diskette. Check www.cruzpro.com for any later versions.
When a beep is heard check the display for the status of the
transfer, if "good" is displayed, the process was successful. If
"bAd" is displayed, the process was unsuccessful, try the
download process again.
Figure 4 - RP110 to PC Connections
Note: Check for possible newer versions of this software on our
website www.cruzpro.com

Page 11
NMEA 0183 Sentences - TABLE 1
1 USER PROGRAMMED
2 USER PROGRAMMED
3 USER PROGRAMMED
4 USER PROGRAMMED
5 USER PROGRAMMED
6 USER PROGRAMMED
7 USER PROGRAMMED
8 USER PROGRAMMED
9 USER PROGRAMMED
10 USER PROGRAMMED
11 $AGAAM WAYPOINT ARRIVAL ALARM RADIUS
12 $AGAPB MAGNITUDE OF CROSSTRACK ERROR
13 $AGAPB BEARING ORIGIN TO DESTINATION
14 $AGAPB BEARING PRESENT TO DESTINATION
15 $AGAPB HEADING TO STEER TO DESTINATION
16 $AGBEC BEARING DEGREES TRUE
17 $AGBEC BEARING DEGREES MAGNETIC
18 $AGBEC DISTANCE NAUTICAL MILES
19 $AGBOD BEARING TRUE
20 $AGBOD BEARING MAGNETIC
21 $AGBWC BEARING TO WAYPOINT DEGREES TRUE
22 $AGBWC BEARING TO WAYPOINT DEGREES MAG.
23 $AGBWC DISTANCE NAUTICAL MILES
24 $AGBWC BEARING TO WAYPOINT DEGREES TRUE
25 $AGBWR BEARING TO WAYPOINT DEGREES MAG.
26 $AGBWR DISTANCE NAUTICAL MILES
27 $AGBWW BEARING WAYPOINT TO WAYPOINT TRUE
28 $AGBWW BEARING WAYPOINT TO WAYPOINT MAG.
29 $AGHSC COMMANDED HEADING DEGREES TRUE
30 $AGHSC COMMANDED HEADING DEGREES MAG.
31 $AGVBW LONGITUDNAL WATER SPEED KNOTS
32 $AGVBW TRANSVERSE WATER SPEED KNOTS
33 $AGVBW LONGITUDNAL GROUND SPEED KNOTS
34 $AGVBW TRANSVERSE GROUND SPEED KNOTS
35 $AGWCV WAYPOINT CLOSURE VELOCITY KNOTS
36 $AGWNC DISTANCE WAYPT TO WAYPT N.MILES
37 $AGWNC DISTANCE WAYPOINT TO WAYPOINT KM.
38 $APAAM WAYPOINT ARRIVAL ALARM RADIUS
39 $APAPB MAGNITUDE OF CROSSTRACK ERROR
40 $APAPB BEARING ORIGIN TO DESTINATION

41 $APAPB BEARING PRESENT TO DESTINATION
42 $APAPB HEADING TO STEER TO DESTINATION
43 $APBEC BEARING DEGREES TRUE
44 $APBEC BEARING DEGREES MAGNETIC
45 $APBEC DISTANCE NAUTICAL MILES
46 $APBOD BEARING TRUE
47 $APBOD BEARING MAGNETIC
48 $APBWC BEARING TO WAYPOINT DEGREES TRUE
49 $APBWC BEARING TO WAYPOINT DEGREES MAG.
50 $APBWC DISTANCE NAUTICAL MILES
51 $APBWR BEARING TO WAYPOINT DEGREES TRUE
52 $APBWR BEARING TO WAYPOINT DEGREES MAG.
53 $APBWR DISTANCE NAUTICAL MILES
54 $APBWW BEARING WAYPOINT TO WAYPOINT TRUE
55 $APBWW BEARING WAYPOINT TO WAYPOINT MAG.
56 $APHSC COMMANDED HEADING DEGREES TRUE
57 $APHSC COMMANDED HEADING DEGREES MAG.
58 $APVBW LONGITUDNAL WATER SPEED KNOTS
59 $APVBW TRANSVERSE WATER SPEED KNOTS
60 $APVBW LONGITUDNAL GROUND SPEED KNOTS
61 $APVBW TRANSVERSE GROUND SPEED KNOTS
62 $APWCV WAYPOINT CLOSURE VELOCITY KNOTS
63 $APWNC DISTANCE WAYPT TO WAYPT N.MILES
64 $APWNC DISTANCE WAYPOINT TO WAYPOINT KM
65 $DEDCN POSITION UNCERTAINTY N.MILES
66 $DFAPB BEARING ORIGIN TO DISTANCE
67 $DFAPB BEARING PRESENT TO DESTINATION
68 $DFAPB HEADING TO STEER TO DESTINATION
69 $DFABE BEARING DEGREES TRUE
70 $DFBEC BEARING DEGREES MAGNETIC
71 $DFBEC DISTANCE NAUTICAL MILES
72 $DFBOD BEARING TRUE
73 $DFBOD BEARING MAGNETIC
74 $DFBWC BEARING TO WAYPOINT DEGREES TRUE
75 $DFBWC BEARING TO WAYPOINT DEGREES MAG.
76 $DFBWC DISTANCE NAUTICAL MILES
77 $DFBWR BEARING TO WAYPOINT DEGREES TRUE
78 $DFBWR BEARING TO WAYPOINT DEGREES MAG.
79 $DFBWR DISTANCE NAUTICAL MILES
80 $DFBWW BEARING WAYPOINT TO WAYPOINT TRUE
81 $DFBWW BEARING WAYPOINT TO WAYPOINT MAG.
82 $DFHDG MAGNETIC SENSOR HEADING DEGREES
Page 12

83 $DFHDT HEADING DEGREES TRUE
84 $DFWCV WAYPOINT CLOSURE VELOCITY KNOTS
85 $DFWNC DISTANCE WAYPT TO WAYPT N.MILES
86 $DFWNC DISTANCE WAYPOINT TO WAYPOINT KM
87 $GPBWC BEARING WAYPT TO WAYPT DEG. TRUE
88 $GPBWC BEARING WAYPT TO WAYPT DEG. MAG.
89 $GPBWC DISTANCE NAUTICAL MILES
90 $GPBWR BEARING WAYPT TO WAYPT DEG. TRUE
91 $GPBWR BEARING WAYPT TO WAYPT DEG. MAG.
92 $GPBWR DISTANCE NAUTICAL MILES
93 $GPRMB CROSS TRACK ERROR NAUTICAL MILES
94 $GPRMB RANGE TO DESTINATION NAUT. MILES
95 $GPRMB BEARING TO DESTINATION DEG. TRUE
96 $GPRMB DESTINATION CLOSING VELOCITY KTS
97 $GPRMC SPEED OVER GROUND KNOTS
98 $GPRMC COURSE OVER GROUND DEGREES TRUE
99 $HCBOD BEARING TRUE
100 $HCBOD BEARING MAGNETIC
101 $HEBOD BEARING TRUE
102 $HEBOD BEARING MAGNETIC
103 $HNBOD BEARING TRUE
104 $HNBOD BEARING MAGNETIC
105 $IIXDR,A ANGULAR DISPLACEMENT DEGREES
106 $IIXDR,C TEMPERATURE DEGREES CELCIUS
107 $IIXDR,D LINEAR DISPLACEMENT METERS
108 $IIXDR,F FREQUENCY HERTZ
109 $IIXDR,G GENERIC
110 $IIXDR,H HUMIDITY PERCENT
111 $IIXDR,I CURRENT AMPERES
112 $IIXDR,N FORCE NEWTONS
113 $IIXDR,P PRESSURE PASCAL OR BAR
114 $IIXDR,R FLOW RATE LITERS/SECOND
115 $IIXDR,S SWITCH OR VALVE
116 $IIXDR,T TACHOMETER RPM
117 $IIXDR,U VOLTAGE VOLTS
118 $IIXDR,V VOLUME CUBIC METERS
119 $INBOD BEARING TRUE
120 $INBOD BEARING MAGNETIC
121 $PBVE RH-30 ELAPSED TIME HOURS
122 $PBVE RH-30 ELAPSED TIME MIN. AND SEC.
123 $PBVE RH-30 ENGINE HOURS AND MINUTES
124 $PBVE RH-30 ENGINE RPM
Page 13

125 $PBVE T-30 TEMPERATURE DEG. FAHRENHEIT
126 $PBVE CH-30 WINDLASS BATTERY VOLTAGE
127 $PBVE CH-30 RHODE OUT
128 $PBVE CT-30 TIME 24 HOURS
129 $PBVE OP-30 PRESSURE P.S.I.
130 $PBVE FU-30 FUEL REMAINING LTRS OR GALS
131 $PBVE FU-30 FUEL USED LITRES OR GALLONS
132 $PBVE FU-30 CONSUMPTION LTRS OR GAL./HR
133 $SDDBK DEPTH BELOW KEEL FEET
134 $SDDBK DEPTH BELOW KEEL METERS
135 $SDDBK DEPTH BELOW KEEL FATHOMS
136 $SDDBS DEPTH BELOW SURFACE FEET
137 $SDDBS DEPTH BELOW SURFACE METERS
138 $SDDBS DEPTH BELOW SURFACE FATHOMS
139 $SDDBT DEPTH BELOW TRANSDUCER FEET
140 $SDDBT DEPTH BELOW TRANSDUCER METERS
141 $SDDBT DEPTH BELOW TRANSDUCER FATHOMS
142 $SDDPT DEPTH RELATIVE TO TRANSDUCER MTRS
143 $TIROT RATE OF TURN DEGREES/MINUTE
144 $TIRPM SPEED RPM
145 $TIRPM PROPELLER PITCH % OF MAX
146 $VDMTW WATER TEMPERATURE DEGREES CELCIUS
147 $VDVHW HEADING DEGREES TRUE
148 $VDVHW HEADING DEGREES MAGNETIC
149 $VDVHW SPEED KNOTS
150 $VDVHW SPEED KM/HOUR
151 $VDVLW TOTAL DISTANCE N.MILES
152 $VDVLW DISTANCE SINCE RESET N.MILES
153 $VMMTW WATER TEMPERATURE DEGREES CELCIUS
154 $VMVHW HEADING DEGREES TRUE
155 $VMVHW HEADING DEGREES MAGNETIC
156 $VMVHW SPEED KNOTS
157 $VMVHW SPEED KM/HOUR
158 $VMVLW TOTAL DISTANCE N.MILES
159 $VMVLW DISTANCE SINCE RESET N.MILES
160 $VWMTW WATER TEMPERATURE DEGREES CELCIUS
161 $VWVHW HEADING DEGREES TRUE
162 $VWVHW HEADING DEGREES MAGNETIC
163 $VWVHW SPEED KNOTS
164 $VWVHW SPEED KM/HOUR
165 $VWVLW TOTAL DISTANCE N.MILES
166 $VWVLW DISTANCE SINCE RESET N.MILES
167 $WIMDA BAROMETRIC PRESS. INCH. OF MERCURY
Page 14

168 $WIMDA BAROMETRIC PRESSURE BARS
169 $WIMDA AIR TEMPERATURE DEGREES CELCIUS
170 $WIMDA RELATIVE HUMIDITY %
171 $WIMDA ABSOLUTE HUMIDITY %
172 $WIMDA DEWPOINT DEGREES CELCIUS
173 $WIMDA WIND DIRECTION DEGREES TRUE
174 $WIMDA WIND DIRECTION DEGREES MAGNETIC
175 $WIMDA WIND SPEED KNOTS
176 $WIMDA WIND SPEED METERS/SECOND
177 $WIMWD WIND DIRECTION DEGREES TRUE
178 $WIMWD WIND DIRECTION DEGREES MAGNETIC
179 $WIMWD WIND SPEED KNOTS
180 $WIMWD WIND SPEED METERS/SECOND
181 $WIMWV WIND ANGLE DEGREES
182 $WIVWR RELATIVE WIND DIRECTION DEGREES
183 $WIVWR SPEED KNOTS
184 $WIVWR SPEED METERS/SECOND
185 $WIVWR SPEED KM/HOUR
186 $YXDBK DEPTH BELOW KEEL FEET
187 $YXDBK DEPTH BELOW KEEL METERS
188 $YXDBK DEPTH BELOW KEEL FATHOMS
189 $YXDBS DEPTH BELOW SURFACE FEET
190 $YXDBS DEPTH BELOW SURFACE METERS
191 $YXDBS DEPTH BELOW SURFACE FATHOMS
192 $YXDBT WATER DEPTH BELOW TRANSDUCER FT.
193 $YXDBT WATER DEPTH BELOW TRANSDUCER MTRS
194 $YXDBT WATER DEPTH BELOW TRANSDUCER FATH
195 $YXDPT DEPTH RELATIVE TO TRANSDUCER MTRS
196 $YXXDR,A ANGULAR DISPLACEMENT DEGREES
197 $YXXDR,C TEMPERATURE DEGREES CELCIUS
198 $YXXDR,D LINEAR DISPLACEMENT METERS
199 $YXXDR,F FREQUECY HERTZ
200 $YXXDR,G GENERIC
201 $YXXDR,H HUMIDITY PERCENT
202 $YXXDR,I CURRENT AMPERES
203 $YXXDR,N FORCE NEWTONS
204 $YXXDR,P PRESSURE PASCAL OR BAR
205 $YXXDR,R FLOW RATE LITRES/SECOND
206 $YXXDR,S SWITCH OR VALVE
207 $YXXDR,T TACHOMETER RPM
208 $YXXDR,U VOLTAGE VOLTS
209 $YXXDR,V CUBIC METERS
210 TO BE DEFINED
Page 15

Other CruzPro Products
lDepthsounders/wKeelOffset,Deep/Shallow/AnchorDragAlarms
lPCBased DSPFishfinder forWindows98, NT,SE,XP, 2000
lSpeed/Temperature/Logs
lDigitalDCVoltsGauge/wAlarms
lDigitalDCVoltsGauge/wAlarmsfor3BatteryBanks
lDigitalAmpsGauge
lDCVolts/Amps/Amp-HourMonitors
lACVolts/Amps/Freq/kWMonitors
lLPG/PetrolGasDetectors/Alarms
lBilgeWaterAlarms/wStainlessSteelWaterSensor
lIntelligentBilgePumpControllers/wStainlesssSteelWaterSensors
lIntelligentWindlassController/ChainCounters
lDigitalFuelGauges&FuelConsumptionCalculator
lDigitalTank LevelGaugesfor1or 3Tanks/wSeparateAlarms
lSmart4stepAlternatorRegulator
lMarineSecuritySystem/wReliableIntrusionSensors
lRPM/EngineHours/ElapsedTimeGauges/wAlarm
lDigital EngineTemperature Gauge/wAlarms
lDigitalOilPressureGauge/wAlarms
lDigitalTemperatureGaugesfor1or3Areas/wAlarms
lDigitalClock/Watch/RaceTimers/w8Alarms
l8and 16AmpLightDimmers/ MotorSpeedController
lSolarPanel ChargeControllers6/8/9&20Amps
l4&8ChannelNMEACombiners/RS-232Convertors
lEngine/ExhaustTemp.Monitor&DigitalPyrometer
lNMEA0183RemoteDataRepeater/w 4InputChannels
email: [email protected]
website: www.cruzpro.com
Page 16
