Ctc union Ipcam-8318p User manual

IPCAM-8318P

Dual Stream Network High-speed Dome Camera

LEGAL

The information in this publication has been carefully checked and is believed to be

entirely accurate at the time of publication. CTC Union Technologies assumes no

responsibility, however, for possible errors or omissions, or for any consequences

resulting from the use of the information contained herein. CTC Union Technologies

reserves the right to make changes in its products or product specifications with the

intent to improve function or design at any time and without notice and is not required to

update this documentation to reflect such changes.

CTC Union Technologies makes no warranty, representation, or guarantee regarding the

suitability of its products for any particular purpose, nor does CTC Union assume any

liability arising out of the application or use of any product and specifically disclaims any

and all liability, including without limitation any consequential or incidental damages.

CTC Union products are not designed, intended, or authorized for use in systems or

applications intended to support or sustain life, or for any other application in which the

failure of the product could create a situation where personal injury or death may occur.

Should the Buyer purchase or use a CTC Union product for any such unintended or

unauthorized application, the Buyer shall indemnify and hold CTC Union Technologies

and its officers, employees, subsidiaries, affiliates, and distributors harmless against all

claims, costs, damages, expenses, and reasonable attorney fees arising out of, either

directly or indirectly, any claim of personal injury or death that may be associated with

such unintended or unauthorized use, even if such claim alleges that CTC Union

Technologies was negligent regarding the design or manufacture of said product.

TRADEMARKS

Microsoft is a registered trademark of Microsoft Corp.

Please check CTC Union's website for any updated manual or contact us by E-mail at

[email protected]. Please address any comments for improving this manual or to point out

omissions or errors to [email protected]. Thank you.

CTC Union maintains a support web site (support.ctcu.com) where you may obtain the

latest manual, quick installation guide, and operational firmware. Membership to this web

site is free, however, you must be a registered member in order to access any software

updates.

CTC Union Technologies Co., Ltd.

Table of contents

1. INSTALLATION & PRODUCT SPEC.......................................................... 6

2. USING IP CAMERA VIA MOBILE PHONE OR MEDIA PLAYER............. 10

3. HOW TO USE INTELLIGENT IP INSTALLER...........................................11

3.1. Initial use Intelligent IP Installer ........................................................................... 11

3.2. Configuration of Main Menu.................................................................................12

3.3. Camera................................................................................................................13

3.3.1. Setup...................................................................................................................................14

3.3.2. Upgrade ..............................................................................................................................21

3.3.3. Factory Default....................................................................................................................22

3.3.4. Reboot.................................................................................................................................23

3.4. User.....................................................................................................................24

3.4.1. Info......................................................................................................................................27

3.4.2. User.....................................................................................................................................28

3.4.3. Date/Time............................................................................................................................29

3.4.4. TCP/IP.................................................................................................................................30

3.4.5. PPPoE.................................................................................................................................31

3.4.6. DDNS..................................................................................................................................33

3.5. About ...................................................................................................................34

4. USING IP CAMERA VIA WEB BROWSER .............................................. 35

5. CONFIGURATION .................................................................................... 36

5.1. Initially accessing the IPCAM...............................................................................37

5.2. Configuration of Main Screen ..............................................................................38

5.2.1. Setting.................................................................................................................................38

5.2.2. Client Setting.......................................................................................................................39

5.2.3. Image Setup........................................................................................................................39

5.2.4. PTZ Control.........................................................................................................................40

5.2.5. Live View.............................................................................................................................41

5.3. Basic Setting........................................................................................................42

5.3.1. System................................................................................................................................42

5.3.1.1. Information..........................................................................................................42

5.3.1.2. Date & Time Setting............................................................................................43

5.3.1.3. Initialization.........................................................................................................45

5.3.2. Camera ...............................................................................................................................46

5.3.2.1. General...............................................................................................................46

5.3.2.2. MPEG-4..............................................................................................................47

5.3.2.3. M-JPEG..............................................................................................................50

5.3.3. Network...............................................................................................................................51

5.3.3.1. Information..........................................................................................................51

5.3.3.2. PPPoE................................................................................................................52

5.3.3.3. DDNS..................................................................................................................53

5.3.3.4. UPnP ..................................................................................................................54

5.3.3.5. IP Notification .....................................................................................................55

5.3.4. Security...............................................................................................................................57

5.3.4.1. Accounts.............................................................................................................57

5.3.4.2. HTTPS................................................................................................................58

5.4. Advanced Settings...............................................................................................59

5.4.1. PTZ Control.........................................................................................................................59

5.4.2. Preset Position....................................................................................................................60

5.4.3. Patrol...................................................................................................................................61

5.4.4. FTP Client...........................................................................................................................62

5.4.4.1. General...............................................................................................................62

5.4.4.2. Alarm Sending....................................................................................................63

5.4.4.3. Periodical Sending..............................................................................................65

5.4.5. SMTP..................................................................................................................................66

5.4.5.1. General...............................................................................................................66

5.4.5.2. Alarm Sending....................................................................................................68

5.4.5.3. Periodical Sending..............................................................................................70

5.4.6. HTTP Event.........................................................................................................................72

5.4.6.1. General...............................................................................................................72

5.4.6.2. Alarm sending.....................................................................................................73

5.4.7. Alarm Output.......................................................................................................................74

5.4.8. Schedule.............................................................................................................................76

5.4.9. Alarm Input..........................................................................................................................77

5.4.10. Alarm Buffer........................................................................................................................78

5.4.11. Motion Detection.................................................................................................................79

5.4.12. System Log.........................................................................................................................81

1. Installation & Product SPEC

Installation Steps

Follow these steps to install the CTC Union IPCAM-8318P on your LAN:

1. Check the package contents against the list below.

2. Setup the device. See Chapter 3.1 on the available methods.

Package Contents

IP Speed Dome CTC Union IPCAM-8318P

Power Adapter Country-specific

CD User manual/IP Installer and Documents

Printed Document Quick installation guide

Accessories Wall Mount

Accessories Screws gears

Accessories RJ-45 Female / RJ-45 Female gender changer

Setup the Device

Outlook

The look of the outdoor camera is composed of 3 main sections

1. Double-layer housing

2. Transparent dome cover

3. Metal bracket (holder)

The height of the main body (combining the housing and the dome cover) is a little bit

more than 10 inches (262mm). It has diameter of 8-9/16 inches (219mm) for the outer

housing and 6 inches (150mm) for the dome cover.

Total weight of this device is 4 kg without camera, and 5.8kg with camera.

Connecting Wires

The cables, wires and connector attached to the speed dome are categories into these

major functions of:

1. Power (AC24V)

2. Cable (Gray ): GND

3. Cable (purple): N.C

4. Cable (blue): Relay Com

5. Cable (orange): Relay N.O

6. Cable(yellow): Speaker

7. Cable(brown): Alarm

8. Cable(green): Mic

9. RJ-45

Product Appearance

Mountthehousing

There are 2 (two) ways to mount the PTZ camera, which are:

1. Mounted to wall through a bracket

2. Held to ceiling surface through a bracket (Option)

Please read the accessory list to get understand of what components are for which type

of mountings.

Mount the bracket and housing

1. Remove the metal cover (sheet) from the bracket（Fig-1）

2. Mount the bracket onto wall (Fig-2)

3. Put cables through the bracket (Fig-3). Be sure the wall is strong enough to hold the

entire device (i.e. housing + camera)

Fig-1 Fig-2 Fig-3

4. Fasten the housing to the bracket with supplied screws（Fig-4）

Fig

5. Put the cover back to holder（Fig-5）。

-5

The Mounting Holders

Two different holders and their accessories are supplied with the camera

For Wall-mount (standard) --- crane type bracket

For Ceiling-mount (optional) --- cane type bracket

262 300

Φ7

Product Specification

2. Using IP Camera via Mobile Phone or Media

Player

To use IP cameras via mobile phones, please make sure your RTSP is set to “ON”.

(Default is “ON”) To change the settings of IP cameras, please see “Settings” for details.

3G Mobile Phone viewing

For 3G mobile phone viewing, type “rtsp://<IP>:<PORT>/video.3gp” into your 3G web

browser. <IP> is the IP address of your IP camera, <PORT> is the RTSP port of your IP

camera (Default value is 8554.)

Example: rtsp://100.10.10.1:8554/video.3gp

Note:

You can also use RTSP clients (RealPlayer, MPlayer, Windows Media Player,

Quicktime…etc.) to view RTSP streaming, just type in “rtsp://<IP>:<PORT>/video.3gp”

as the Player’s URL

2.5G Mobile Phone viewing

For 2.5G mobile phone viewing, type “<IP>/mobile.wml” into your 2.5G web browser.

<IP> is the IP address of your IP camera.

Computer viewing

You can also use RTSP clients (RealPlayer, MPlayer, Windows Media Player,

Quicktime…etc.) to view RTSP streaming, just type in “rtsp://<IP>:<PORT>/video.mp4”

as the Player’s URL.

3. How to Use Intelligent IP Installer

This chapter introduces how to monitor the image from the camera using Intelligent IP

Installer. The IP cameras can be used with Microsoft web browsers and Intelligent IP

Installer in Windows operating systems. This document focuses on introducing you to

Intelligent IP Installer. If you want to know how to use IP cameras with Microsoft web

browsers, please check the camera user manuals.

3.1. Initial use Intelligent IP Installer

1. Install the program of Intelligent IP Installer.

Note:

• If you’re using Windows 98 or ME, please install IP Installer before using WEB UI to

ensure the system runs normally.

• If you can’t view the recorded video file (missing video decoder), please install Xvid

codec while installing Intelligent IP Installer. (For Windows 98, ME or 2000 server, the

codec might not work properly. You’ll need to download Xvid codec 1.0 from the

internet.)

2. Click Start -> Program Files ->CTCU-> Intelligent IP Installer -> Intelligent IP Installer

to start using the program.

3.2. Configuration of Main Menu

Main Menu

Camera

Click this button to get into common information of all Network Cameras in local

network. You can connect the specific Network Cameras to get live video and to

optimize video setting.

User

Click this button to get into user basic setting information of all Network Cameras in

network. You can connect the specific Network Cameras to get and set basic values.

This section includes Info, User, Date Time, TCP/IP, PPPoE and DDNS.

Note:

• Only the administrator has access to the Settings.

About

Click this button to get the information of Intelligent IP Installer.

3.3. Camera

The Camera page provides you all Network Cameras in the network with product

factory information, including product Name, IPAddress, MAC, Mod. Name and Mod.

ID.

Search：Click it to search Network Cameras in the network, it displays Network

Cameras information including Name, IPAddress, MAC, Mod. Name and Mod. ID.

Note:

If the camera is not located in local network, it will appear in red text. Some

information is not available when the IP camera is not in local network.

The IP addresses shown in the "IP Address" field reflect those on the local network.

They may be from the DHCP server. If there is no DHCP server, the IP Camera will

try to find a free IP address (this takes from 15 second to 3 minutes, depending on

the LAN status). The method of finding IP address is seeking from 192.168.1.2, to

192.168.1.254. If any of the address inside this range is free, the Network IP

Camera will be assigned to this IP address, and its subnet mask would be

255.255.255.0.

Link to IE：After searching Network Cameras in network, you can click to specific

Network Cameras in search area and press Link to IE to use IP cameras with

Microsoft web browses.

3.3.1. Setup

Choose a network camera, click on Setup to change the

configurations. You have to key in the username and password of the

administrator to enter the setup page.

The following screen will display:

Note:

For IP cameras not in local network area (which appears in red in the search

screen), you can still use setup to change the configurations of these cameras.

System Information: The system information is displayed.
