CTC Union iSAP5100 User manual

1
iSAP5100
Integrated Service Access Platform

2
LEGAL
The information in this publication has been carefully checked and is believed to be entirely accurate at the time of
publication. CTC Union Technologies assumes no responsibility, however, for possible errors or omissions, or for any
consequences resulting from the use of the information contained herein. CTC Union Technologies reserves the right to
make changes in its products or product specifications with the intent to improve function or design at any time and
without notice and is not required to update this documentation to reflect such changes.
CTC Union Technologies makes no warranty, representation, or guarantee regarding the suitability of its products for
any particular purpose, nor does CTC Union assume any liability arising out of the application or use of any product
and specifically disclaims any and all liability, including without limitation any consequential or incidental damages.
CTC Union products are not designed, intended, or authorized for use in systems or applications intended to support or
sustain life, or for any other application in which the failure of the product could create a situation where personal injury
or death may occur. Should the Buyer purchase or use a CTC Union product for any such unintended or unauthorized
application, the Buyer shall indemnify and hold CTC Union Technologies and its officers, employees, subsidiaries,
affiliates, and distributors harmless against all claims, costs, damages, expenses, and reasonable attorney fees arising
out of, either directly or indirectly, any claim of personal injury or death that may be associated with such unintended or
unauthorized use, even if such claim alleges that CTC Union Technologies was negligent regarding the design or
manufacture of said product.
WARNING:
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency
energy and if not installed and used in accordance with the instruction manual may cause harmful interference in which
case the user will be required to correct the interference at his own expense. NOTICE: (1) The changes or modifications
not expressively approved by the party responsible for compliance could void the user's authority to operate the
equipment. (2) Shielded interface cables and AC power cord, if any, must be used in order to comply with the emission
limits.
CISPR PUB.22 Class A COMPLIANCE:
This device complies with EMC directive of the European Community and meets or exceeds the following technical
standard. EN 55022 - Limits and Methods of Measurement of Radio Interference Characteristics of Information
Technology Equipment. This device complies with CISPR Class A.
WARNING:
This is a Class A product. In a domestic environment this product may cause radio interference in which case the user
may be required to take adequate measures.
CE NOTICE
Marking by the symbol CE indicates compliance of this equipment to the EMC directive of the European Community.
Such marking is indicative that this equipment meets or exceeds the following technical standards: EN
55022:1994/A1:1995/A2:1997 Class A and EN61000-3-2:1995, EN61000-3-3:1995 and EN50082-1:1997

3
CTC Union Technologies Co., Ltd.
Far Eastern Vienna Technology Center (Neihu Technology Park)
8F, No. 60, Zhouzi St.
Neihu, Taipei, 114
Taiwan
Phone: [phone]
FAX: [phone]
iSAP5100
Integrated Service Access Platform
User Manual
Version 1.0 November 2017
This manual supports the following models:
iSAP5100
This document is the current official release manual. Please check CTC Union's website for any updated manual or
contact us by E-mail at [e-mail]. Please address any comments for improving this manual or to point out
omissions or errors to [email protected]m. Thank you.
2017 CTC Union Technologies Co.,Ltd.
All Rights Reserved
The contents of this document are subject to change without any prior notice.

Table of Contents
4
CHAPTER 1. INTRODUCTION ...................................................................................................................................6
1.1 PRODUCT DESCRIPTION.............................................................................................................................................6
1.2 SUPPORTED MODULES ...............................................................................................................................................6
1.2.1 Overall Functions........................................................................................................................................7
1.2.2 5100-MS-DM-96 Card................................................................................................................................7
1.2.3 5100-MS-DM-155 Card..............................................................................................................................8
1.2.4 iSAP-FOM Card..........................................................................................................................................8
1.2.5 iSAP-E1 Card..............................................................................................................................................8
1.2.6 iSAP-FXO Card ..........................................................................................................................................9
1.2.7 iSAP-FXS Card ...........................................................................................................................................9
1.2.8 iSAP- E&M Card ........................................................................................................................................9
1.2.9 iSAP-G703/64K Card..................................................................................................................................9
1.2.10 iSAP-RS232 Card........................................................................................................................................9
1.2.11 iSAP-RS232-C Card....................................................................................................................................9
1.2.12iSAP-ET100 Card........................................................................................................................................9
1.2.13iSAP-N x 64K Card.....................................................................................................................................9
1.3 SPECIFICATIONS ......................................................................................................................................................10
1.3.1 Chassis Hardware Spec. ...........................................................................................................................10
1.3.2 5100-MS-DM-96 Card..............................................................................................................................10
1.3.3 5100-MS-DM-155 Card............................................................................................................................10
1.3.4 iSAP-FOM01 Card....................................................................................................................................10
1.3.5 iSAP-FOM02 Card....................................................................................................................................11
1.3.6 iSAP-8E1 Card..........................................................................................................................................11
1.3.7 iSAP-16E1 Card........................................................................................................................................11
1.3.8 iSAP-FXO Card ........................................................................................................................................12
1.3.9 iSAP-FXS Card .........................................................................................................................................12
1.3.10 iSAP-E&M Card .......................................................................................................................................12
1.3.11 iSAP-G703/64K Card................................................................................................................................13
1.3.12 iSAP-RS232 Card......................................................................................................................................13
1.3.13 iSAP-RS232-C Card..................................................................................................................................13
1.3.14 iSAP-ET100 Ethernet Bridge Line Card..................................................................................................13
1.3.15 iSAP-N x 64K Card ...................................................................................................................................13
CHAPTER 2. PANEL DESCRIPTIONS.....................................................................................................................14
2.1 5100- MS-DM CARD ..............................................................................................................................................14
2.1.1 5100-MS-DM-96 Card..............................................................................................................................14
2.1.2 5100-MS-DM-155 Card............................................................................................................................14
2.2 ISAP-FOM CARD ...................................................................................................................................................15
2.2.1 iSAP-FOM01 Card....................................................................................................................................15
2.2.2 iSAP-FOM02 Card....................................................................................................................................16
2.3ISAP-E1 CARD........................................................................................................................................................17
2.3.1 iSAP-8E1 Card..........................................................................................................................................17
2.3.2 iSAP-16E1 Card........................................................................................................................................17
2.4IO CARD..................................................................................................................................................................17
2.4.1 iSAP-RS232 Card......................................................................................................................................17
2.4.2 iSAP-RS232-C Card..................................................................................................................................18
2.4.3 iSAP-G703/64K Card................................................................................................................................18
2.4.4 iSAP-E&M Card .......................................................................................................................................19
2.4.5 iSAP-FXO Card ........................................................................................................................................19
2.4.6 iSAP-FXS Card .........................................................................................................................................20
2.4.7 iSAP-ET100 Card......................................................................................................................................20
2.4.8 iSAP-N× 64K Card ....................................................................................................................................21
2.4.9 iSAP-AC/DC Power Card.........................................................................................................................21
CHAPTER 3. INSTALLATION...................................................................................................................................23
3.1 RACK MOUNTING....................................................................................................................................................23
3.2 INSTALL THE MANAGEMENT CARD.........................................................................................................................23
3.2.1 Connect SNMP Management to Network..................................................................................................23
3.2.2 Console Terminal Connection...................................................................................................................24

Table of Contents
5
3.2.3 STM1 Interface..........................................................................................................................................24
3.3 E1 CARD .................................................................................................................................................................24
3.4 IO CARD..................................................................................................................................................................25
3.4.1 FXO Card Pinouts.....................................................................................................................................25
3.4.2 FXS Card Pinouts .....................................................................................................................................25
3.4.3 E&M Card Hardware Setup (DIP SWITCH)............................................................................................25
3.4.4 RS232/RS232-C Card Pinouts...................................................................................................................26
3.4.5 G703/64K Card Pinouts............................................................................................................................28
3.4.6 N×64K Card Pinouts ................................................................................................................................28
3.5 ALARM RELAY CONNECTIONS ................................................................................................................................30
CHAPTER 4. PROVISIONING...................................................................................................................................32
4.1 OVERVIEW OF THE PROCEDURE ..............................................................................................................................32
4.1.1 Login .........................................................................................................................................................32
4.1.2 Configure the Clock Source ......................................................................................................................33
4.1.3 E1 Framing Configuration........................................................................................................................33
4.1.4 Set up the Digital Cross Connection .........................................................................................................34
4.2 MULTIPLEXING CONFIGURATIONS ..........................................................................................................................34
4.2.1 E1 Cross Connect to SDH.........................................................................................................................34
4.2.2 IO Card Cross Connect to E1 ...................................................................................................................34
4.2.3 IO Card Cross Connect to E1 in SDH ......................................................................................................34
4.3 MIRRORING AN E1 CHANNEL ..................................................................................................................................35
4.4 BROADCAST E1.......................................................................................................................................................35
4.4.1 Configure Broadcast Source .....................................................................................................................35
4.4.2 Configure Broadcast Listener ...................................................................................................................35
4.5 CONFIGURING REDUNDANCY..................................................................................................................................36
4.5.1 Optical Port Redundancy Setup................................................................................................................36
4.5.2 E1 Redundancy Setup................................................................................................................................36
4.6 SNMP MANAGEMENT.............................................................................................................................................36
4.6.1 SNMP Setup ..............................................................................................................................................36
4.6.2 IP Address Setup .......................................................................................................................................36
4.6.3 SNMP Server IP Address Setup.................................................................................................................36
4.6.4 SNMP TRAP Address Setup......................................................................................................................36
4.6.5 Network Level Setup..................................................................................................................................36
4.6.6 Configure Time Slot ..................................................................................................................................37
4.7 CONFIGURE SYSTEM PARAMETERS .........................................................................................................................37
4.7.1 Save...........................................................................................................................................................37
4.7.2 Set Time.....................................................................................................................................................37
4.7.3 Line............................................................................................................................................................37
4.8 DIAGNOSTICS CONFIGURATION...............................................................................................................................37
4.8.1 E1 Card Loopback Setup...........................................................................................................................37
4.8.2 E1 card BERT setup..................................................................................................................................38

CHAPTER 1. INTRODUCTION
6
Chapter 1. Introduction
1.1 Product Description
iSAP5100 is an integrated service access platform, housed in a 19 inch rack mountable chassis that
offers 18 card slots, 2 card slots for management, and 2 modular power card slots.
iSAP5100 employs Time Division-Multiplexing with support for up to 96 E1 channels (6x16E1) that
provide functions of multiplexing and cross-connection of data/voice/CAS-signaling. The MUX is designed
for multiplexing Nx64Kbps, 64K/128Kbps, 9.6Kbps synchronous data, asynchronous data below 19.2Kbps ,
G703/64K data and FXO, FXS, E&M voice signals into 2.048Mbps ITU-T G.703 E1 frames. The cross-
connecting function includes the intercrossing of CAS-signaling.
The types and quantity of subscriber's data and voice interface modules can be flexibly selected
according to needs. The modules can be plugged into any of the 18 available card slots according to specific
maintenance and application methods. All time slots may be user defined.
iSAP5100 supports SNMP network management. When SNMP management mode is available and
selected, the Web based GUI provides an intuitive and easy to use graphical interface to provision and
monitor all operations of the iSAP5100. A console terminal mode is supported as well for local
configuration via a Command Line Interface.
1.2Supported modules
NMS Card: 5100- MS-DM-96 (E1), 5100 - MS-DM-155 (STM-1)
FOM Modules: iSAP-FOM01, iSAP-FOM02
E1 Modules: 5100-8E1 (8-CH), 5100-16E1 (16-CH)
AC Power Module: 5100-AC240 (100~240VAC)
DC Power Module: 5100-DC240 (-48VDC)
I/O Modules:
5100-RS232 (6-CH RS-232 SYNC),
5100-RS232-C (6-CH RS-232 ASYNC),
5100-N *64K (4-CH Nx64K SYNC V.35),
5100-G703/64K (6-CH 64K G.703 co-directional),
5100-ET100 (2-CH Ethernet Bridge),
5100-E&M (8-CH E&M Voice),
5100-FXS (8-CH FXS),
5100-FXO (8-CH FXO),
Figure 1: Front View

CHAPTER 1. INTRODUCTION
7
1.2.1 Overall Functions
iSAP5100 provides resilient operation through redundancy. The front of the chassis can house up of
two management cards, two power modules and two fan modules. When two power modules are inserted,
power redundancy is provided in case of a single power module failure. The power modules can be selected
from either AC or DC power types. By mixing and matching the designer can select AC+AC, AC+DC or
DC+DC redundant combinations.
The management card provides the configuration management for all other cards, including E1 cards
and various IO cards. A pair of management cards provides 1+1 protection, keeping one card always in a
working state and minimizing any loss due to management downtime.
Figure 2: Rear View
The rear of the chassis offers 18 slots in total. E1 cards can be inserted in Slot 1~6 which support 16-
channel E1. Slot 7-18 are extension slots for E1 which support 4-channel 8E1/16E cards. IO cards
(including FXO card, FXS card, E&M card, G703-64K card, RS232 card, R232-C card, N *64K card,
ET100 card, RS485 card) can be placed in Slot 1-18.
Figure 3: Rear Panel of the Chassis
1.2.2 5100-MS-DM-96 Card
This management card inserted in the front of chassis provides the 10/100M out-band Ethernet network
management interface.
Users can manage IO cards via RS232 console port.
The chassis also supports voice, data, non-blocking switching functions as follows:
Maximum 144 E1 (E1 slot, IO slot access E1 quantity) non-blocking switching.
Support E1 multiplexing, timeslot, broadcast functions.

CHAPTER 1. INTRODUCTION
8
Support synchronous exchange between CAS signaling of 16 timeslots and voice timeslots.
Support 144 x E1 the recovered clock optional synchronization function.
The management card supports card failover backup function:
The management card supports card failover with switching time of <50mS.
All clock synchronization follows the main working management card.
If fault occurs in the main working card, the backup card will automatically switch to restore the main
operation.
1.2.3 5100-MS-DM-155 Card
MS-DM-155 card supports one 155M SDH for 63 x E1 interfaces. The 155M interface provides
management that prepares against and aids and switches over the function independently.
The front panel offers a 10/100M out-band Ethernet network management interface.
Configuration can be done via RS232 serial console and CLI for native E1 and low-speed IO cards.
Supports voice, data, non-blocking switching function as follows:
Maximum 144 E1 (E1 slot, IO slot access E1 quantity) non-blocking switching.
155M optical port provides a total of 63xE1 non-blocking switching.
Support E1 multiplexing, timeslot, and broadcast the function.
Support synchronous exchange between CAS signaling of 16 timeslots and voice timeslots.
Support bi-directional add-drop connection between 63E1*32TS of 155M optical port and 144E1*32TS
of E1/IO slot.
Support alarm and error statistics:
STM-1 Alarm indication: LOS, LOF, RDI, HP-AIS, HP-LOP, LP-AIS, LP-LOP; BER: B1, B2, B3
E1 Alarm indication: LOS, LOF, AIS, RAI; BER: FRR, CRC
Support BERT line loopback test function.
Support the flexible clock synchronization function:
Support any one of 144 E1 lines as recovery clock source.
The management card supports card failover backup function:
The management card supports card failover with switching time of <50mS.
All clock synchronization follows the main working management card.
If fault occurs in the main 155M working card, the backup 155M card will automatically switch to
restore the main operation.
1.2.4 iSAP-FOM Card
iSAP-FOM card contains iSAP-FOM01 and iSAP-FOM02 types. Both types can support uplink single fiber
and dual fiber. The fiber adheres to PDH155M standard 1x9 fiber with FC connector. The distance can
reach up to 20km (changeable upon request). iSAP-FOM provides two shared 100M Ethernet connectors
and supports isolation, switching mode, 4E1 ports, VLAN. The iSAP-FOM card also supports frame,
unframe, E1 module interconnection, 1+1 redundancy for uplink fiber ports and flexible setup for 4E1 and
I/O module.
1.2.5 iSAP-E1 Card
Support 8 E1 and 16 E1 (RJ-45 interface).
Support CRC checksum.
Support 120 ohm and 75 ohm.
Sensitivity: -20dB, -43dB (selectable).
System clock modes: Any one of the channels in 8/16 E1 can be selected as system synchronization
clock.
Support E1 module backup.
Support local, remote and bidirectional loopback test.
Support BERT test function.
Support E1 alarm and checksum monitoring and statistics:
Alarm: LOS, LOF, AIS, RAI
Checksum: ERR, CRC

CHAPTER 1. INTRODUCTION
9
1.2.6 iSAP-FXO Card
Each card provides 8-channel FXO.
1.2.7 iSAP-FXS Card
Each card provides 8-channel FXS and can be interflowed with the other side FXO interface under the
ordinary way. Hot Line mode can support point-to-point connection.
1.2.8 iSAP- E&M Card
Each card provides 8-channel E&M ports. Each channel supports 2 or 4 wires for voice transmission and
E&M signaling with TYPE1 to TYPE5 for selection.
Supports data, voice, and civil aviation working modes.
Input and output gains are adjustable.
Supports local and remote loopback test.
1.2.9 iSAP-G703/64K Card
Each card supports 4-channel G703/64Kbps Co-directional, Contra-directional and Centra-directional
connectors.
Each channel’s speed is 64Kbps and supports local and remote loopback test.
1.2.10 iSAP-RS232 Card
Each card supports 6-port RS232 connector.
Each port supports speed of ≦38.4kbps (asynchronous).
Each port supports speed of 2.4/4.8/9.6/19.2/38.4/64kbps (synchronous).
DCE interface.
Supports local and remote loopback test.
1.2.11 iSAP-RS232-C Card
Each card supports 6-port RS232 connector.
Each port supports speed of ≦38.4kbps (asynchronous).
Each port supports speed of 64/128kbps (synchronous).
DCE interface.
Supports local and remote loopback test.
1.2.12 iSAP-ET100 Card
Each card supports 4 x 10/100Base-T Auto MDI/MDIX channels.
Supports speed of n x 64kbps.
Supports Flow Control function.
Ethernet Bridge Tributary card provides Ethernet over E1 capability.
Supports local and remote loopback test.
1.2.13 iSAP-N x 64K Card
Each card supports 4 N x 64kbps (N= 1~31) high-speed channels.
Supports DCE interface.

CHAPTER 1. INTRODUCTION
10
1.3Specifications
1.3.1 Chassis Hardware Spec.
Dimensions:
440 mm (W) x 350 mm (D) x 187 mm (H)
Temperature:
0~60℃(working temperature), -25~70℃(storage temperature)
Humidity
10%~90% (non-condensing)
Power
AC 220V: 165~265V, 50~60Hz
AC 110/220V: 90~265V, 50~ 60Hz
DC -48V: -36~ -72VDC
Consumption
<90W (fully loaded chassis)
1.3.2 5100-MS-DM-96 Card
NMS interface: Ethernet 10/100Base-TX, RJ45 (Auto-Negotiation)
Console port: Serial RS232 interface, DB9 (Female)
Cross connect capacity: 144 E1s non-blocking connections. Support E1 mirror and broadcast function.
CAS signaling exchange: Cross connect between CAS signals of 16 timeslots and voice timeslots.
1.3.3 5100-MS-DM-155 Card
Data port: Offer one 155M SFP interface.Two SFP fiber ports react as backup for each other.
NMS interface: Ethernet 10/100Base-TX, RJ45 (Auto-Negotiation)
Console port: Serial RS232 interface, DB9 (Female)
Cross connect capacity: 144 E1 has no non-blocking exchange. 155M fiber 63E1 and 144 E1 have no
non-blocking exchange. Support the replication of E1, time slot, broadcast function.
CAS signaling exchange: Cross connect between CAS signals of 16 timeslots and voice timeslots.
STM-1/E1 multiplexing and de-multiplexing: Support bi-directional cross connection between 63E1
*32TS of STM-1 and 144E1 *32TS of E1/IO slot.
1.3.4 iSAP-FOM01 Card
Uplink Fiber
The number of port: 1
Data rate: 155M
Connector: FC
Ethernet
The number of port: 2
Connector: RJ-45
Speed: 10/100Mbps Full Duplex, Auto-Negotiation
E1 Port
The number of port: 4 channels
Connector: RJ45 or BNC (via RJ45 to BNC cable)
Line code: HDB3
Line impedance: 75 ohms (Unbalanced) or 120 ohms (Balanced)
"Pulse" amplitude: Nominal 2.37V (75 ohms) or Nominal 3.00V (120 ohms)
ITU standards: G.703, G.704, G.732, G.823
