Cub Cadet 53AB5BBP750 Setup guide

Hydrostatic Zero-Turn
Riding Mower
ILLUSTRATED PARTS LIST
MODEL
23HP
53AB5BBP750
50" Stamped Deck

2
This Page Left Blank Intentionally

3
TABLE OF CONTENTS
50" Formed Cutter Deck . . . . . . . . . . . . . . . . . . . . . . . 4 and 5
Hydro Pump Assembly . . . . . . . . . . . . . . . . . . . . . . . . 6 and 7
Brake Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 and 9
Fuel Tank Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Rear Bumper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Front Caster Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Wheel Assembly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Control Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . 14 and 15
Drive Assembly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Seat Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
23 HP Kohler Engine Assembly . . . . . . . . . . . . . . . 18 and 19
23 HP Electrical Engine Assembly . . . . . . . . . . . . . . . . . . . 20
Floor Panel Assembly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Lift Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 and 23
Assembly Pump Right Hand. . . . . . . . . . . . . . . . . . . . . . . . 24
Assembly Pump Left Hand . . . . . . . . . . . . . . . . . . . . . . . . . 25
Frame Assembly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

4
50" Formed Cutter Deck - Figure 1
12
41
17
60
26
6
12
68
66
39
12
652
56
4
17
49
65
6
67
9
13
59
61
22
15
14
1
36
27
6
35
3
47
31
34
33
38
18
59
53
24
21
64
33
62
50
58
46
29
11
48
37
51
5
37
55
43
25
32
10
19
6
2
28
44
30
57
54
20
6
70
45
42
23
62 8
14
16
40
19
63
67
62
19
69
GD: 02000420-12/14/04

5
50" Formed Cutter Deck - Parts List for Figure 1
Ref.
No. Part No. Description Qty.
Ref.
No. Part No. Description Qty.
1 00003107 Cotter Pin, .125 Dia x 1.0 2 36 01008593 Idler Arm Assembly 1
2 00008495 Capscrew, 3/8-16 x 1-3/4 1 37 01008620 Self Tapping Screw 5/16-18 x .750 6
3 00012226 Grease Fitting, 1/4-28, 90° 1 38 00012428 Hex Nut, 1/2-13, Insert Lock 4
4 00012470 Cable Tie, 3/16 x .05 x 7.4 1 39 01009102 Hinge Pin, .375 x 14.06 1
5 00013406 Hex Cap Screw, 5/16-18 x 3/4 1 40 01009253 Flat Washer, .390 x 1.5 x .134 1
6 00022560 Hex Nut Flange lock, 3/8-16 12 41 01009705 Chute Deflector 1
7 00027279 Nut 7/16-14, Nylock 1 42 01010168 Hi-Lift Blade, 17.9 3
8 00034167 Hex Cap Screw, 3/8-16 x 5.00 1 43 01010173 Spacer, .39 ID x .875 OD x 1.00 1
9 01005011 V-Belt, B-Section 1 44 02000407 Deck Assembly 50" 1
10 00060078 Grease Fitting, 1/4-28 x 3/16 1 45 02000402 Flange Hex Nut, 3/4-16 3
11 01009635 Extension Spring, 1.0 OD x 5.00 1 46 02000417 Spring Tension Rod Assembly 1
12 01000372 Carriage Bolt, 3/8-16 x .75 Lg 5 47 02000481 Hex Cap Screw, 3/4-16 x 8.00 1
13 01000375 Roller Pin, 1/2 Dia x 7.31 Lg 1 48 02000626 Left Hand Belt Cover 1
14 01000385 Front and Rear Roller 3 49 02000667 Right Hand Belt Cover 1
15 01000387 Torsion Idler Spring 1 50 618-3129B Blade Spindle Assembly 3
16 01000393 Flat Washer, .469 ID x .875 OD x .105 1 51 01004109 Tension Rod Stop Bracket 1
17 01000628 Screw, TT, 1/4-20 x .5, Hex Index Washer 7 52 703-3511 Finger Guard 1
18 01000635 Hex Flange Lock Nut, 5/16-18 1 53 710-1852 Spindle Bolt 3/4-16 x 5.37 2
19 01000723 Flat Washer, .406 ID x 1.0 OD x .105 3 54 712-0641 Hex Nut, M16-1.5 2
20 01001169 Short Roller 2 55 721-04041 Adaptor, Water Nozzle 1
21 01001745 Pin, 5/8 Dia x 1.2 Lg 4 56 703-1890 Deck Wheel, 5.00 Dia. 2
22 01002010 Carraige Screw, 3/8-16 x 1.25 1 57 736-0760 Lock Washer, 17 x 23.8 x 1.9 2
23 01002564 Spacer, .76 ID x 2.00 OD x .477 3 58 737-04003B Nozzle, Deck Water 2
24 01003123 Spacer, .812 ID x .218 Lg. 2 59 737-3000 Grease Fitting 3
25 01003245 Spacer, .39 ID x .625 OD x 2.75 1 60 738-3056 Shoulder Screw .498 x 1.53 2
26 01003253 Torsion Spring 1 61 738-3172 Shoulder Screw .68 x 2.11 1
27 01004081 Flat Pulley with Flanges 1 62 748-3065 Spindle Spacer 6
28 01004101 Idler Pulley, 4.06 OD with Deep Flange 1 63 750-3119 Spacer .406 ID x 1.00 OD x 0.38 1
29 01004118 Shoulder Screw, .50 x .27 Lg; 3/8-16 1 64 02000653 V-Belt, 1/2 x 91 LG 1
30 01004751 Roller Pin Rod 1 65 02000668 Skirt, Center, 50" 1
31 01005201 V-Pulley, 4.75 OD 1 66 02000669 Skirt, Right Hand, 50" 1
32 01006181 Idler Arm Assembly, Flat Top Bearing 1 67 783-04470 Chute Mounting Bracket 1
33 01006535 Pulley, A Sect x 4.90 3 68 777S30145 Decal, Danger Hands & Feet 1
34 01006680 Spacer, .760 ID x 1.75 OD x 1.969 1 69 02000813 Spindle Plate 3
35 01008456 Spacer .760 ID x 1.5 OD 1 70 02000762 Self Tapping Screw 5/16-18 x 1.00 12

6
Hydro Pump Assembly - Figure 2
1
19
10
3
5
14
12
13
8
11
8
16
4
18
9
15
17
7
6
GD: 01004266-03/29/01

7
Hydro Pump Assembly - Parts List for Figure 2
Ref.
No. Part No. Description Qty.
1 00006144 Hex Cap Screw, 3/8-16, 1 4
2 00012529 Protective Hose Cover (not shown) 1
3 00013131 Hex Cap Screw, 1/4-20, .75 2
4 00017665 Filter Head 3/4 includes: 1
01004166 33 Micron Filter
5 00022560 Hex Nut Flange Lock, 3/8-16 8
6 00030261 Cap, Hydro Oil Tank 1
7 00031994 Decal Oil Only 20W50 1
8 01000372 Carriage Bolt, 3/8-16 x .75 LG. 4
9 01004516 Hydraulic Tank Assembly 1
10 01001650 Mounting Plate Oil Filter 1
11 01004192 Oil Pan Drain w/ Seal and Plug 1
12 01004267 Gearbox to Tank Hose Assembly 2
13 01004268 Tank to Filter Hose Assembly 1
14 01004269 Filter to Left Hand Pump Hose
Assembly
1
15 01004270 Filter to Right Hand Pump Hose
Assembly
1
16 01004272 Fitting, 45° 1
17 01006959 Fitting Tee, 3/4 x 1/2 x 1/2 1
18 01004702 Fitting Elbow, 1/2 x 1/2 1
19 01006353 Fitting, 3/8 NPT, 1/2 Flare 2
NOTE: Lubricant, SAE 20W50 Gallons, 3.25

8
Brake Assembly - Figure 3
25
15
21
26
20
28
8
29
19
13
11
24
18
10
7
22
17
1
2
5
4
23
33
12
6
27
14
9
16
30
GD: 01001609-04/21/03

9
Brake Assembly - Parts List for Figure 3
Ref.
No. Part No. Description Qty.
1 00006131 Hex Nut, 3/8-16 4
2 00009678 Clevis Pin, 3/8 x 1, 1/8 2
3 00011888 HHCS, Standard, 3/8-16 x 3-1/2 1
4 00021955 Yoke, 3/8-16, Female 2
5 00021956 Hair Pin, 3/8"-1/2" 2
6 00012226 Grease Fitting, 1/4-28, 90° 1
7 01000100 Shoulder Nut 2
8 00022560 Nut, Flange Lock, 3/8-16 3
9 01000628 Screw, TT, 1/4-20 x .5, Hex Index
Washer
4
10 01000723 Flat Washer, .406 ID x 1.0 OD x .105 4
11 01000872 Flat Washer, .411 x 1.25 x .100 2
12 01002751 Spacer, .39 ID x .63 OD x 1.75 1
13 01002771 Hair Pin, INT .072 x 1.12 Lg. 4
14 01002772 Spacer, .375 x .50 x 1.02 Lg. 1
15 01002980 Mounting Shaft, Bellcrank 1
16 01003591 Holder Shaft, Park Brake 2
17 01003410 Rod Connector, 3/8 OD x 33 2
18 01003593 Brake Bracket 1
19 01008886 Rod Brake, Connect To Handle 1
20 01003417 Connecting Rod, 3/8 OD x 5.75 2
21 01003595 Weldment, Brake Handle 1
22 01003574 Brake Spring, Neutral 2
23 01003575 Brake Spring, Force 2
24 01003576 Brake Hose, Center 2
25 01003716 Grip, Park Brake 1
26 01003730 Weldment Hub, Brake Bearing
Includes:
1
01004265 Bearings 2
27 01002511 Jam Nut, 3/8-16 2
28 00012173 Lock Nut, Nylon Insert, 3/8-16 2
29 01006350 Shaft collar, .625 ID x 1" OD x .438 Lg 2
30 01008889 Park Brake Mounting Bracket 1

10
Fuel Tank Assembly - Figure 4 and Parts List
Ref.
No. Part No. Description Qty.
1 01000723 Flat Washer, .406 ID, 1.0 OD, .105 8
2 -- Hose, 1/4" Fuel Line (in inches) 79.5
3 00012235 Clamp, Union 6
4 01000069 Fuel Cap, 3.5 2
5 01000368 Hex, Cap Screw, 3/8-16, .88 8
6 00012157 Lock Washer, 3/8 8
7 01004350 Fuel Tank 2
8 01003116 Fuel Fitting 2
9 01000281 Grommet, Fuel Tank 2
10 01003473 Tee Fitting, Fuel 1
11 00031081 Clamp, 1/2 Tubing 1
12 00012470 Cable Tie 2
13 01000600 Flat Washer, 1.4 x .630 x .0515 1
8
2
9
3
4
7
1
6
5
10
1111
13
12
GD: 01002568-01/18/01

11
Rear Bumper - Figure 5 and Parts List
Ref.
No. Part No. Description Qty.
1 00012428 Hex Nut, 1/2-13, Insert Lock 2
2 00022560 Nut, Hex 3/8-16 Flange Lock 2
3 00030046 HHCS, 1/2-13, 3.00 2
4 01000364 Carriage Bolt, 3/8-16 x 1.75 2
5 01007362 Rear Bumper Bracket 1
6 01009992 Bar Weight 1
1
4
3
5
6
2
GD: 01007365-04/08/04

12
Front Caster Assembly - Figure 6 and Parts List
Ref.
No. Part No. Description Qty.
1 00006144 Hex Cap Screw, 3/8-16, x 1 2
2 01000872 Flat Washer, .411 x 1.25 x 1.00 2
3 00012157 Lock Washer, 3/8 2
4 00023287 Center Lock Nut, 1/2-20 2
5 00023793 Flange Bearing, 1.013 4
6 02000588 Flat Washer, 1.00 ID x 2.00 OD x .075 2
7 00060078 Grease Fitting, 1/4-28 x 3/16 3
8 01000678 Jam Lock Nut, 1.0-14 1
9 01002611 Hex Cap Screw, 1/2-20 x 7.00 2
10 01004128 Spacer, .51 ID x .75 OD x 5.83 Lg 2
11 01007364 Caster Wheel Bracket Assembly 2
12 02000570 Narrow Front Axle Assembly 1
13 01006294 Belle Washer, 1.25 ID x 2.500 OD x .1 2
14 01006309 Hex Cap Screw, 1-14 x 5.0 1
15 02000589 Spacer, 1.005 ID x 1.25 OD x 3.6 1
16 01006559 Wheel Assembly, 11 x 4-5.00 2
17 01009997 Retainer Extension, Self Locking 1
9
813
6
11
10
16
4
17
1
7
5
3
12
7
2
6
14
15 13
02000588
GD: 02000572-10/21/04
Front Plate
02000588
01006294
Frame
01006294
Front Axle
01009997
Washer Order and
Orientation

13
Wheel Assembly - Figure 7 and Parts List
Ref.
No. Part No. Description Qty.
1 00012187 Lug Nut, 1/2-20 8
2 01006541 Wheel Assembly, 23 x9.5-12, Dr,
White: Includes
2
Tire, Turf Saver, 23 x 9.50-12, 2-Ply
Rim, 12 Dia x 7.00 width, 4x4 Bolt
2
1
GD: 01006503-06/09/04

14
Control Assembly- Figure 8
43
31
41
49
29
2
7
58
3
17
87
6
53
15
10
9
23
25
24
26
12
25
10
22
3
48
21
16
46
34
30
18
33
12
50
13
19
44
45
40
11
51 35
11
39
321
53
1
1
5
25
4
28
11
20
10
10
46
42
6
36
37
27 14
38
55
47
56 52
GD: 02000569-01/12/05

15
Control Assembly - Parts List for Figure 8
Ref.
No. Part No. Description Qty
.
Ref.
No. Part No. Description Qty.
1 00003107 Cotter Pin .125 Dia x 1.0 6 28 01005770 Side Panel, Control, Right 1
2 00011861 Hex Cap Screw, 3/8-16, 2.5 4 29 01010176 Mounting Handle 2
3 00022560 Hex Nut, 3/8-16, Lock Flange 31 30 01003011 Lever, Safety Switch 2
4 00060078 Grease Fitting, 1/4-28 x 3/16 2 31 01004889 Control Panel, LH 1
5 00013131 Hex Cap Screw, 1/4-20, .75 2 32 01004890 Control Panel, RH 1
6 01000369 Hex Cap Screw, 3/8-16, 1.25 10 33 02000164 Switch Mounting Bracket, Lapbar 2
7 01000372 Carriage Bolt, 3/8-16 x .75 17 34 01001968 Link Mounting Control Shaft, Bracket 1
8 00012152 Lock Hex Nut, 1/4-20 2 35 01003199 Stop, RH 1
9 01000450 Hex Jam Nut, 3/8-24 4 36 01003200 Stop, LH 1
10 01000451 B/Joint, 3/8-24, Right Hand Female 4 37 01003591 Holder Shaft, Park Brake 4
11 01000628 Screw, TT, 1/4-20, 0.5, Hex Index Washer 19 38 02000162 Decal , Warning & Throttle 1
12 01000635 Nut, Lock, HexFlange, 5/16-18 7 39 02000163 Decal, Warning & Key Switch 1
13 00013406 Hex, Cap Screw, 5/16-18 x 3/4 4 40 01003451 Decal Right Hand Control 1
14 01000960 Belle Washer, .325 x .930 x .045 2 41 01003452 Decal, Left Hand Control 1
15 01002990 Belle Crank Assembly, includes: 2 42 01003561 Nut, Hex, Center Lock, M8 x 1.2 4
16 01000308 Bushing 4 43 00022223 Grip, 1 2
17 01001727 Cylinder Return to Neutral 2 44 750-3119 Spacer, .406 ID x 1.00 OD x .38 4
01003044 Hub Assy, Control LH Bearing 1 45 01007359 Lapbar Handle, One Position 2
18 01004265 Bearings 2 46 01005870 Side Label, CCC 2
19 01003045 Hub Assy, Control RH Bearing 1 47 01005784 Bracket Assembly, Mount Dampener 2
01004265 Bearings 2 48 01004003 Flat Washer, 5/8 Nylon 8
20 01002511 Nut, 3/8-16, Jam 2 49 01004127 HHCS, 3/8-16, 3.00 2
01002980 Shaft Mounting Belle Crank 2 50 00009812 Flat Washer, 5/16 4
21 01002982 Rod Connector 3/8 OD x 10.125 2 51 00012226 Grease Fitting, 90°, 1/4-28 2
22 01002983 Rod Connector, 3/8 OD x 4.28 LG LH 1 52 00013092 HHCS, 5/16-18 x 1.0 1
23 01002984 Rod Connector, 3/8 OD x 8.06 LG RH 1 53 01006350 Shaft Collar, .625 ID, 1.00 OD, .438 Lg 2
24 01002986 Nut, 3/8-24, Jam, LH Third 4 54 01003947 U-Nut, 3/8-16 x .75 2
25 01002987 B/Joint, 3/8-24, LH Female 4 55 01005851 External Lock Washer 2
26 01002988 Screw, Shoulder Control Rod 2 56 01000629 Screw, TT, 1/4-20, 0.75, Hex Index
Washer
1
27 01005769 Side Panel, Control, Left 1

16
Drive Assembly- Figure 9 and Parts List
Ref.
No. Part No. Description Qty.
Ref.
No. Part No. Description Qty.
1 00002528 Hex Cap Screw, 3/8-16 x 2 9 16 01001620 Skid Plate 1
2 00011459 Flat Washer, 1/2 2 17 01002602 Elbow Fitting, 3/8 x 3/8 2
3 00011861 Hex Cap Screw, 3/8-16 x 2.5 1 18 01002606 Fitting, 1/2 x 3x8 1
4 00012157 Lock Washer, 3/8 2 19 01002771 Cotter Pin, .072 x 1.12 Long 2
5 00012169 Flat Washer, 5/16 2 20 01003268 Pump Release Rod 2
6 00013198 Hex Cap Screw, 5/16-18 x 2 4 21 01003732 Slotted Hydro Pulley 2
7 00022560 Flange Lock Hex Nut, 3/8-16 16 22 01005339 Pulley Hydro Fan 2
8 01000372 Carriage Bolt, 3/8-16 x .75 Long 5 23 01004542 Elbow Fitting, O-Ring 3/8, 1/2 Flare 2
9750-3119 Spacer, .406 ID x 1.00 OD x .38 1 24 01005114 Belt Guide 1
10 01000635 Hex Flange Lock Nut, 5/16-18 5 25 01005851 Washer 1
11 01000643 Carriage Bolt, 3/8-16 x 1 1 26 01005852 Screw, 5/16-18 x 1.00 1
12 01000723 Washer, .406 ID x 1.0 OD x .105 10 27 01006165 Support Mount Bracket 2
13 01001623 Nut Cap, 3/8 2 28 01007238 Flat Washer, .385 x 1.0 OD x .13 2
14 01001975 Elbow Fitting, 3/8 - 1/2 x 45° 1 29 01008229 Nut, 1/2-20, Center Lock 2
15 01001618 Frame Strut 2
8
9
13
16
26
25
27 18
24
3
20
5
3
123
19
29
22
21
2
11
7
4
15
8
12
514
17 10
28 6
27
GD: 01002578-01/12/05

17
Seat Assembly- Figure 10 and Parts List
Ref.
No. Part No. Description Qty.
1 00022560 Nut, Hex 3/8-16 Flange Lock 2
2 01000635 Lock Nut, Hex Flange, 5/16-18 4
3 01001630 Mounting Bracket, Seat 2
4 01002634 Shoulder Screw, .50x2.345, 3/8-16 2
5 01002753 Grommet, 2.5 OD x 1.0 Long 2
6750-3119 Spacer, .406 ID x 1.00 OD x .38 2
7 01006545 Adjustable Seat, Black 1
8 01000960 Flat Washer, .406 ID, 1.00 OD, .105 2
7
3
5
2
6
1
4
8
GD: 01007314-01/10/05

18
23HP Kohler Engine Assembly - Figure 11
34
16 4
35
29
2
20
18
31
15
21
14
23
9
13
28
12
6
33
27
24 7
22
37
25
3
32
10
11
1
13
8
26
17
5
19
7
36
30
GD: 02000424-01/04/05
Description Part Number
Air Filter KH-24-083-03-S
Pre Filter KH-24-083-05-S
Fuel Filter KH-24-050-10-S
Oil Filter KH-12-050-08
Spark Plug 759-3336
Gasket Exhaust (2) --

19
23HP Kohler Engine Assembly - Parts List for Figure 11
Ref
No Part No. Description Qty.
1 00005763 Hex Nut, 7/16-14 1
2 00006129 HHCS, 5/16-18, 1-3/4 4
3 01007533 Key, 1/4 x 1/4 x 2.75 1
4 00012169 Flat Washer, 5/16 2
5 00014602 Round Hd. Machine Screw, 10-32 x 3/4 2
6 00014608 Lock Nut, Nylon Insert, 10-32 2
7 00022560 Flange Lock, Hex Nut, 3/8-16 2
8 00060056 Nut Washer, W/Star, 8-32 2
9 00060078 Grease Fitting, 1/4-28 x 3/16 1
10 00072586 Flat Washer 1
11 00073094 Engine Spacer 1
12 01000199 Extension Spring, 1.0 OD x 5.00 1
13 01000302 Shoulder Screw, 7/16-14 1
14 01000364 Hex Carriage Screw, 3/8-16, 1.75 1
15 01000389 Lock Washer, 7/16 2
16 01000635 Hexflange Lock Nut, 5/16-18 4
17 01000721 Machine Screw, 8-32, .375 2
18 01008434 Electric Clutch 1
19 01000728 Clip, Heat Shield Cable 1
20 01000737 Transmission Drive Pulley 1
21 01000813 Capscrew, 7/16-20 x 3.00 1
22 01002601 Hex Cap Screw, 3/8-16, .750 1
23 01007358 Retainer Clutch Assembly, Ogura 1
24 01003269 Flat Washer, 7/16 ID x 1.75 OD x .25 1
25 01003273 Throttle, Control Cable, 45.0 1
26 01004004 Control Throttle Knob 2
27 01004081 Flat Pulley with Flanges 1
28 01005006 Engine Idler Arm Assembly Includes: 1
01000308 Bearing 2
29 01005010 V Belt, A Section x 47.3 1
00023887 Belt: To be used with new sub-frame 1
30 01000811 Tube Clamp, 1.375 1
31 01005314 Flat Washer, 7/16 IDx 1.750 OD x .250T 1
32 01006221 Oil Drain 1
33 01006223 Oil Drain Hose 1
34 KH-PA-75592 23HP Kohler Engine 1
35 01006566 23HP Kohler Exhaust 1
36 01008623 Muffler Accessory Exhaust Tube 1
37 01008256 Choke, Control Cable, 38.0 1
Note: Use 10W40 Engine Oil

20
18HP Electrical Engine Assembly - Figure 12 and Parts List
Ref.
No. Part No. Description Qty.
Ref.
No. Part No. Description Qty.
1 00012032 Battery 1 13 01003649 Strap, Battery 1
2 00012289 Cable, Battery, Red, 36" 1 14 01004040 Grommet, .75 ID 1
3 00012470 Tie, Cable, 3/16 x .05 x 7.4" 5 15 01004078 Cable, Battery Black, 24" 1
4 00013131 Screw, Hex, Cap, 1/4-20 x .75 2 16 01005389 Meter, Hour 1
5 00013258 Boot, 1" OD Rubber Battery-PST, Red 1 17 01009905 Bracket, PTO Switch Retainer 1
6 00032097 Nut, W/Cap, 5/8-32 Ignition 1 18 01009995 Mount Bracket, Battery 1
7 01000628 Screw, TT, 1/4-20 x .500, Hex Index
Washer
4 19 02000024 Switch, Safety 2
8 01001811 Hourmeter, Harness (not shown) 1 20 02000165 Switch, Plunger 1
9 01002111 Switch, Electric, PTO 1 21 02000167 Harness Assembly, kohler (not
shown)
1
10 01002766 Nut, 1/4-20, Hex Flange Lock Nut 2 22 02000349 Switch Bracket Mount 1
11 01003277 Switch, Seat N/C 1 23 02000348 Switch Clamp 1
12 01003581 Switch, Ignition, 6 Pin 1
15
10
4
1
11
7
5
2
14
3
16
6
9
12
17
13 19
18
23 20 22
7
GD: 02000573-10/22/04
