Cube UP 6000 Series User manual

UP - Serie 6000
a product by Cube Design®
Phone
Email
Website
[phone]
[email protected]
www.cube-design.dk
Assembly Manual
1080 - 1800 mm
This assembly manual is valid for tables in serie 6000. The columns are rectangular.

11 step assembly manual for the UP frame
WARNING Carefully arrange all the cables not to be damaged by tabletop screws.
EXAMPLE OF OVERHANG
Table top L 1200 mm - frame must have a length of 1080 mm
Table top L 1400 mm - frame must have a length of 1280 mm
Table top L 1600 mm - frame must have a length of 1480 mm
Table top L 1800 mm - frame must have a length of 1680 mm
Table top L 2000 mm - frame must have a length of 1800 mm
Place the frame in the center of the table top.
PACKING LIST
Frame
Column
Feet
End rail
Frame 1
Frame 2
Conection rail
Cable clamp
Control box
Control box
Handset with cable
Power cable, 3 m
Connecting cable, 1 m
Screws
Hexagon screw for motor house/end rail, M6x14 mm
Screw for feet, M8x14mm
Hexagon screw for motor house/frame, M6x10
Set screws for connection pipe, M6x8mm
Screw for tabletop and handset, Ø5x20mm
pcs
2
2
2
1
1
2
4
1
1
1
2
4
4
8
8
RESET THE DESK BEFORE USE
Press and hold the “down” button on the handset. Continue pressing
until the desk has reached the lowest position. Press the “down” button
in 5 seconds until the desk enters the reset state, and the handset is
going down to complete the reset. Now the system is operational.
In normal state, the indicator light is off. In the error state, the indicator
light is on. In the reset state, the indicator light ashed.
HOW TO ASSEMBLE THE DESK
Step 0: Open the box. Step 1: Ad both end rails to the frame.
Step 4: Ad 8 M6x10 hexagon screw through the frame into the motor
house of the columns. Tighten the screws.
Step 2-3: Raise the columns and tighten the screws to the end rail
through the frame. Start with the left column followed by the right
column.
01
1
2
3
x4
4
x8

Step 5: Ad the feet on to the columns and fasten each with 2 M8x14 mm
screws. Tighten the screws.
Step 8-9: Mount the frame to the table top with 7 5x20 mm wood
screws and the handset with 2 5x20 mm wood screws. Tighten the
screws.
Step 6-7: Place the frame on the table top. Pull out the frame and make
sure that it is placed 60 mm from the edge, if you have a 1200-1800 mm
table, and 100 mm form the edge if you have a 2000 mm table. Make
sure that the connection rails are centered.
Step 10: Tighten all 8 screws in the frame.
Step 11: Ensure that the cables are placed properly and plug the cables
into the control box. Use the cable clamps to fasten the cables for the
control box.
Important
Make sure to tighten all screws,
also after a period of time.
10
x8
11
5x4
6
7
8
9
x7
x2

User manual
1. Preface
Congratulations on your new Cube Design UP sit-stand desk. The desk is an
electrically driven desk, intended for indoor use in ofce environments. The
desk is also suitable for home ofces. Carefully read this manual before using
the desk. The instruction manual must always follow the sit-stand desk.
2. Table information
The height adjustment of the sit-stand desk is driven by Jiecang, where
each column is equipped with an engine. These are controlled from a
control box which is connected to the control panel. The control box must
be plugged into 230 volt power outlet and has built-in electronic overload
protection that can not be replaced. The sit-stand desk is double insulated
and does not need grounding.
3. Important information
A sit-stand desk must always be reset after assembly. This adjustment
is performed to ensure that the built-in motors work synchronously. It is
recommended that the procedure must take place when the UP desk asks
to be reset and every time the sit-stand desk is moved. Please follow the
procedure described here:
1. Connect the power
2. Press and hold the “down” button on the handset. Continue pressing until
the desk has reached the lowest position.
3. Press the “down” button in 5 seconds until the desk enters the reset state,
and the handset is going down to complete the reset.
Now the system is operational.
4. In normal state, the indicator light is off. In the error state, the indicator
light is on. In the reset state, the indicator light ashed.
4. Prohibitions, warnings and advice
• The sit-stand desk must not be used for lifting persons (eg. when replacing
light bulbs in ceiling lamps)
• The sit-stand desk must be leveled. If the ground is not level use the
adjustable shoes under the feet
• The sit-stand desk is intended to be activated continuously max. 2 min
at a time or a maximum of 6 minutes per. hour at full load
• Be aware of the risk of entrapment in the height of the table movement
• Pay special attention to children when they are near the sit-stand desk
• The entire table top must be free (minimum 25 mm) of shelving, frames,
tables and other similar objects
• The power cord must not be damaged or trapped
• Ensure that the wires for the computer, phone and network, etc. are long
enough. Gently run the sit-stand desk to the highest and lowest position
• The power must be switched off at the power outlet (eg. at night) if the
power consumption must be reduced to the maximum
5. Operating
The sit-stand desk can only be operated from the control panel mounted
under the table top. The panel has two buttons respectively up and down.
Arrow buttons show the direction. The table will move as long as one of the
buttons is pressed.
It is possible to reset the sit-stand desk by using this control panel (see section 3).
Be aware of crushing danger when using the height adjustment. The table
has no separate power switch - use the power outlet when the sit-stand desk
must be disconnected. If there is a malfunction or similar, see the Error table.
6. Maintenance
The moving mechanism must not be lubricated with oil or otherwise. Main-
tenance is limited to wiping the table top and frame with cloth dampened
in a mild soap. Stubborn stains may be removed with rubbing alcohol. Do
not allow water into the electrical parts.
7. Assembly of the table
The parts of the sit-stand desk are removed from all packaging. Make sure
that all parts, shown on the drawing, are represented. If parts are missing
please contact Cube Design.
8. Setup
The sit-stand desk should be placed on a at surface and the table top adjusted
level with the adjustable shoes under the feet. It is necessary to reset the table
after adjusting the shoes (see section 3). All cables for the sit-stand desk must
be arranged and assembled, eg. in a exible cabling, so that the cables do not
disturb the user and the function of the sit-stand desk.
9. Moving
The sit-stand desk should be run in the lowest position before moving it and
all conduit should be removed. Installation procedure is repeated for the
establishment of the new space.
10. Repair
Repair of the sit-stand desk must be made by authorized repairer / technician,
because the sit-stand desk does not contain serviceable parts which the user
can repair.
11. Warranty
Cube Design’s warranty covers manufacturing and material defects discovered
during normal use of the sit-stand desk. The warranty does not cover defects
or damages directly or indirectly caused by misuse, violence or interference
by other than an authorized repairer / technician.
12. Disposal
The sit-stand desk must be disposed as follows:
• Table top to incineration
• Metal structure for metal recycling
• Electronics for reception facilities for electronics
13. Technical specifications
Dimensions Following the table top, but a maximum of 200 cm x 110 cm
Electrical con. 230 V, 50 Hz, dobbelt insulated, no need for grounding
Power input 200 W
Standby 0,1 W
Sound level maximum 50 dB(A)
Load A maximum of 125 kg located centrally on the table
Operating temp. 0 degrees C to +40 degrees C
Air humidity 10 - 80 % RH (Relative Humidity)
Height variation 59,5-124,5 cm
Speed up/down A maximum of 40 mm./sec.
Continuous operation - Max. 2 min. continuously at full load or 6 min. per. hour (10%)
14. Error
The sit-stand desk does not respond:
• Check connection to power input. Is it turned on?
• Check, that the wirring from the control box is connected
• Check, that the wire from the control device is connected
• Check, that the connectors are completely mounted in
• Check, that no wires have been cut / disconnected
• Check, that the mains fuses are OK
• If the sit-stand desk still does not respond please contact the supplier for service
The sit-stand desk does not run smoothly:
• Switch off at the power input and unplug
• Try to restart and initialize the sit-stand desk
• If the error still occurs please contact the supplier for service
The sit-stand desk is no longer level:
• Check adjustable shoes. If OK, run the sit-stand desk in the bottom of the
new initialization
The sit-stand desk makes an unusual noise:
• Check that the sit-stand desk is not rubbing against other sit-stand desks
or elements
• Locate the noise and if it is coming from the desk column, contact supplier
for service - Do not use the height adjustment until the service is completed
15. Contact information
Cube Design A/S
Vadstedvej 212
DK-8450 Hammel
Phone no. [phone]
Mail [email protected]
Web www.cube-design.dk
