Cuchen IH VE06 Series User manual

1
Cuchen IH Electric Pressure Rice Cooker – User Manual
●
Read this manual carefully before use to ensure the proper use of your Cuchen electric pressure rice cooker.
●
Once you have finished reading it, keep the manual at a place where other people would be able to find it easily.
With Cuchen, quality is always priority number one.
WHA-VE0601GD Series ENG-0308.indd 1 2013-03-19 �� 1:12:13

2
Thank you for purchasing a Cuchen electric pressure rice cooker. In order to ensure proper use
and maintenance of this product, please read and follow the instructions contained in this docu-
ment carefully. Also, refer to this document if you experience issues or problems while using the
product.
Product Specifications
※These specifications are subject to minor change for product performance enhancement purposes.
Rated Voltage & Frequency
Rated Power Consumption
Max. Cooking Capacity
Regulator Pressure/Safety Device Pressure
Dimensions (Length X Width X Height)
Weight
AC 120V, 60Hz
1100W (Cooking)
1.08L (6 Servings)
88.3kPa / 166.7kPa
355 X 264 X 267 mm (13.98 X 10.39 X 10.51 inches)
5.1kg (11.24 lbs)
Product Name IH Electric Pressure Rice Cooker
VE06 Series (LCD Type)
WHA-VE0601GD Series ENG-0308.indd 2 2013-03-19 �� 1:12:14

3
Before Getting Started
Safety Precautions …………………………………………… 04
Name and Features of Each Part ……………………………… 07
Operating Instructions
Suggestions…………………………………………………… 09
Setting the Clock ……………………………………………… 10
Cook Control ………………………………………………… 11
Cooking Rice ………………………………………………… 13
Cooking with Cuchen ………………………………………… 15
Preset ……………………………………………………… 18
Steam and Slow/Preset …………………………………… 19
Volume Control/Auto Clean ………………………………… 20
Keeping Warm ………………………………………………… 21
Care and Maintenance ……………………………………… 23
Troubleshooting
Troubleshooting before Contacting the Service Center ……… 27
Table of Contents
WHA-VE0601GD Series ENG-0308.indd 3 2013-03-19 �� 1:12:14

4
Safety Precautions
Power
Installation
※ Information contained in this section serves to protect the user’s safety and prevent damage to property.
※ Carefully read and follow all safety precautions.
Danger
Danger
Danger Risk of severe injury or even death is assumed if the instructions are not followed.
Warning Risk of serious injury or property damage is assumed if the instructions are not followed.
Caution Risk of minor injury or property damage is assumed if the instructions are not followed.
This product is dedicated to AC
120V. Use this product only for
outlets dedicated to 120V at
rated 15A or higher.
Avoid exposure to direct
sunlight and heat-radiating
appliances.
Do not use or store
combustible gases or
inflammable materials in the
product’s vicinity.
Do not install the product in a
place (e.g. a sink or a
bathroom) where water might
make its way into the product.
Do not install the product in a
place with a large amount of dust
or where chemicals are stored.
An electric
shock and fire
may occur.
Do not plug in if the power
plug is damaged or the
power outlet is loose.
An electric
shock and fire
may occur.
Do not touch the power plug
with a wet hand.
An electric shock and
fire may occur.
An electric
shock and fire
may occur.
Do not pull on the power cord to
unplug.
An electric shock and
fire may occur.
Do not splice or modify the
power cord or plug.
Keep the power plug clean of
debris.
Protect the cord and the plug
from pets and sharp metallic
objects such as nails.
While the product is in use,
keep a minimum distance of 30
cm from the product.
Do not excessively bend, tie, or
pull the power cord.
Do not plug into an outlet that
is powering multiple products.
Use a dedicated outlet.
If placing the product on top of
a rice cabinet or a shelf, ensure
that the power cord is not
caught anywhere.
An electric shock and
fire may occur.
Fire may occur.
May cause electric
shock or fire.
Fire, deformation, and discoloration may
occur. Fire may occur. Short-circuiting and an
electric shock may
occur.
An electric shock
and fire may
occur. In addition,
product
performance may
be degraded.
The product may
generate a magnetic
field.
An electric shock and fire may occur.
Overheating,
ignition, an
electric shock,
and fire may
occur.
An electric shock and
fire may occur.
Do not plug in and pull out the
power cord repeatedly.
An electric
shock and fire
may occur.
Do not move the product by
pulling on the power cord.
Unplug the product if not
intending to use for an extended
period of time.
An electric
shock, short-
circuiting,
and fire may
occur.
AC 120V
WHA-VE0601GD Series ENG-0308.indd 4 2013-03-19 �� 1:12:20

5
Before Use
During Use
Installation
Unplug the power cord before
cleaning, do not spray water
directly on the product, and do not
use benzene or thinner to clean. If
water has gone inside the product,
contact the service center.
Install the product on an even
surface and protect the
product from excessive force
and impact.
Be cautious against tripping
on the power cord and
knocking off the product.
Do not drop or give shock to the
product or the inner pot.
Secure at least 1.64yd of
clearance above the product.
An electric
shock, fire,
and
discoloration
may occur.
Danger
Warning
Caution
If you sense strange noise,
burning smell, or smoke from the
product, unplug the power cord
right away, depressurize by
tilting the pressure cap back,
and then contact the service
center.
Fire may occur.
Do not place a stainless steel
plate, a planch, a Korean
cushion, an electric blanket, a
steel plate, tinfoil, a copper
pipe, or a platter made of steel
or aluminum under this product.
Fire or product
malfunction may
occur.
An electric shock,
fire, and
discoloration may
occur.
Do not disassemble, repair, or
modify the product on your own.
An electric shock,
fire, and product
damage may occur.
Do not clog the product’s inlets
or other openings with debris. If
clogged, unplug the power cord
and contact the service center.
Do not use without the inner pot
inside the rice cooker.
Do not use the inner pot for
purposes other than as intended,
or do not place it over flame from
the gas range.
Do not place your face or
hands near the rice cooker’s
steam vent during or right after
cooking, or do not block the
steam vent.
Do not use a deformed or
undedicated inner pot.
Do not touch the inner pot or
clean cover with a hand right
after cooking is completed or
while the cooker is in Keep
Warm mode.
Do not use a cooking or warming
feature with a decorative cover or
a dish towel placed on top of the
rice cooker.
Do not unplug the cooker or
press other control buttons
while cooking is in progress.
The rice cooker remains in a highly pressurized state during and right after cooking. Do not open the lid by force.
Do not place foreign objects
inside the product.
An electric shock, fire,
and bodily harm may
occur.
There is risk of electric shock, fire, and
product malfunction.
If you add rice or water
inside the rice cooker
without using the inner
pot, have the unit
inspected by the service
center right away.
Product malfunction may
occur.
Bodily injury
and product
damage may
occur.
Bodily injury and product
damage may occur.
Bodily injury and product
damage may occur.
May cause product malfunction.
A burn may occur.
Take extra caution
with children.
If you must open the lid while cooking is in progress, press the CANCEL button and wait until the rice cooker is completely depressurized before opening the lid.
Fire or product malfunction may occur.
Bodily harm
may occur.
Product performance
may degraded, and
the rice cooker may
explode.
Product malfunction may occur.
Bodily harm including getting burned may occur.
An electric shock and
fire may occur
(especially important
for children)
Do not allow children to operate
the product unsupervised, or
keep the product out of
children’s reach.
An electric shock, burn, and bodily
harm may occur.
Do not use this product with
aluminum foil or other metallic
materials attached to the outer
surface of the inner pot.
Close the lid by pushing all the
way down until you hear a click.
Also, turn the lid lock handle to
the lock position before cooking.
Bodily harm may occur. In addition, product
performance may be degraded.
Close the lid as
shown in the
figure on the
right:
Do not Use for the Wrong
Purposes!!
Use the Dedicated Inner Pot
With Two Hands!
Benzene, thinner,
, sprayer, etc.
1.5m or
Greater
Use the
Inner Pot!!
WHA-VE0601GD Series ENG-0308.indd 5 2013-03-19 �� 1:12:31

6
Safety Precautions
During Use
Contact the service center if the
inner pot’s coating has been
damaged or peeled.
The inner pot’s coating may come off after
long use. Also, cleaning the inner pot with a
rough or metallic scrubbing brush can peel
the coating. Use a neutral dish detergent
and a sponge only.
Caution
Do not overfill the inner pot. Do not place magnetic objects
on top of the lid, or use the
cooker in the vicinity of highly
magnetic objects.
Product malfunction
may occur.
Remove the collected water from
inside the cooker after each use.
May cause the
product to
discolor, develop
a foul odor, or
perform poorly.
Firmly close the lid before
cooking or warming.
Do not lift the rice cooker by
the inner pot’s handles. Doing
so may cause the lid to open
accidentally.
Do not spray pesticides and
other chemicals inside the
cooker.
Do not immerse the cooker in
water or any other liquid.
Do not use rough or metallic
scrubbing pads, brushes, or
abrasives to clean the
product’s exterior, especially
metallic parts, or clean cover.
Do not use outdoors.
Do not place the inner pot
inside the cooker if there are
grains of rice or other foreign
substances stuck on the outer
surface of the pot.
Always attach the clean cover
when using the cooker.
Do not place the clean cover
or other metallic objects
inside the cooker without the
inner pot.
Persons with an artificial heart
or who rely on a pacemaker
should consult with a doctor
before using this product.
When placing the inner pot
inside the cooker, align the
pot’s handles to the cooker’s
handle grooves.
Always clean the rice cooker
after cooking in the STEAM or
SLOW mode.
Ensure that the area above the
cooker is clear of objects such
as a rice cabinet or a shelf.
May cause the product to discolor,
develop a foul odor,
or perform
poorly.
Product malfunction, product damage, or
bodily harm may occur.
May cause fire. If an insect has made
its way inside the cooker, please
contact the service center.
An electric shock and fire may occur
There is risk of product damage and
deformation.
An electric shock and fire may occur
Product malfunction may occur.
The clean cover protects the cooker
against discoloration and foul odors.
An electric shock and fire may occur
The product, while in operation, may
interfere with pacemakers.
Product malfunction may occur.
Cooking or keeping rice warm without
cleaning the cooker after using the Steam
feature can cause the rice to take on the
previously prepared food’s smell. Thoroughly
wash the inner pot, the inner pot lid, and the
pressure packing before use.
Steam discharged from the cooker may
cause damage to the cabinet or shelf.
Frequently wash and clean
the inner pot, pressure
packing, clean cover packing,
and clean cover.(p.20~p.23)
Product
performance
may be
degraded.
If the power goes out while
cooking is in progress, the
content may spill out through
the steam vent.
Do not use the product for
purposes other than cooking,
warming, or other functions.
Failure to do so
may cause the
product to
malfunction or to
develop a foul
odor.
The rice may not cook properly and
can lead to water spilling over while
cooking.
In the Event of
Power Failure
LOCK
WHA-VE0601GD Series ENG-0308.indd 6 2013-03-19 �� 1:12:38

7
Name and Features of Each Part
Front and Inside
Pressure Cap
Regulates the cooker’s internal
pressure.
Auto Pressure Regulator
(Steam Vent)
Automatically discharges pressure from
inside the cooker.
Auto Temperature Sensor
Monitors the temperature in the event of
cooking or keeping rice warm.
Inner Pot Handle
Safety Sensor
Monitors the temperature inside the inner
pot.
Pressure Lid
Steam Cap
Lid Lock Handle
Inner Pot (Diamond Coating)
Features a special quintuple layer coating
that doesn’t come off easily or let food
stick.
Controls/Display
Includes buttons for controlling all of
the cooker’s features.
Environment Sensor
Monitors the temperature in the event of
cooking or keeping rice warm.
Lid Release Button
Releases the lid.
Clean Cover
Clean Cover Handle
Clean Cover Packing
Pressure Packing
Forms a tight seal to prevent steam from escaping
inside the cooker. The pressure packing should be
replaced once a year.
※ Replace the pressure packing with a new one
purchased from the service center or a large
supermarket.
Accessories
User Manual Measuring Cup Rice Spatula Clean Cover
Power Plug
Water Tray
Empty the collector after each use and
regularly wash it as well (detached from
the cooker).
LCD Display
WHA-VE0601GD Series ENG-0308.indd 7 2013-03-19 �� 1:12:42

8
Name and Features of Each Part
Controls / Display
※ Sleep Mode
●
If the rice cooker is not operated for the given amount of time while the power cord of the rice cooker is connected, the rice cooker will switch to Sleep mode.
●
If the lid of the rice cooker is open or close in Sleep mode, the mode will be disabled.
※ Voice Navigation and Volume Control
●
Performs voice notifications when cooking starts or ends, or steam is ventilated. Also informs you of the next step.
AUTO CLEAN Button
Used to select Auto Clean/Sterilization.
To use the Sterilization feature, press the
AUTO CLEAN button twice in
succession.
CANCEL Button
Used to disable all the features.
WARM/REHEAT Button
Used to activate the Smart Warm or
Reheat feature.
PRESET
Button
Used to enter Preset or Preset
Warm mode.
SET Button
Used to set features.
OK Button
Used to check features.
HOUR/MENU Button
Used to select the cooking option while in standby
mode.
(Cycles through PLAIN→SLOW→STEAM … )
Increase hours in Preset / Preset Warm / Timer
Setting Used to decrease the setting in Cook
Control.
MIN/MENU Button
Used to select the cooking option while in standby mode.
(Cycles through PLAIN→PLAIN QUICK→MIXED… )
Increase minutes in Preset / Preset Warm / Timer Setting
Used to decrease the setting in Cook Control.
PRESSURE/QUICK Button
●
Used to start cooking in each of the menus.
●
Quickly press the PRESSURE/QUICK button twice to cook in Turbo
mode. This will lead to a reduction in cooking duration. Soak rice in
water before cooking, and cook the rice in QUICK mode. Then, you will
be able to serve much tastier rice.
※Quick is enabled in Plain and Mixed menus only.
※Fill the water using the Plain or Mixed menu scale and cook.
WHA-VE0601GD Series ENG-0308.indd 8 2013-03-19 �� 1:12:43

9
Suggestions
● If the Cooked Rice Smells
▶Not cleaning the inner pot and other cooker parts allows bacteria to spread and cause the rice to develop an odor. In this case, fill the inner pot with a
mixture of water and vinegar, disinfect the pot by running the Sterilization feature for 40 minutes, and then thoroughly wash the pot. (Ratio of Mixture: Water
to 3 servings level on the plain scale and 1 tablespoon of vinegar)
▶Regularly clean the lid to get rid of debris and buildup.
● Getting Rid of the Odor when Cooking Old Rice
After being cooked, old rice tends to develop an unpleasant smell that only gets worse when
kept warm. On the evening before cooking the rice, soak the uncooked rice in water and add
a drop of vinegar. Rinse the rice clean and then rinse it once more using lukewarm water right
before cooking to prevent the rice from smelling.
● Storing Rice (determines the flavor of rice)
※Old or dried-out rice may develop poor texture or even end up undercooked. Also, they are prone to develop an odor when kept warm.
※Freshly polished rice can quickly become dry unless stored properly.
② To prevent bugs from mixing in with the rice, add cloves of garlic in the rice container.
① Storing Rice
Good Bad
- Cool and Dry
- Low Humidity and Good Ventilation
It is recommended that rice should be purchased in small quantities between 5kg and
10kg and should be consumed within two weeks of breaking the packaging seal.
Storage Place
Rice Purchase
Storage Period
- Areas with boiler pipes passing through
- Direct Sunlight
- Underneath a Sink
● Cooking flavorful rice starts from using the right amount of water.
Cooking fresh/soaked rice or
to get an hard-boiled result
Cooking old rice or
to get fluffy rice
Slightly below the scale
Slightly above the scale
- 4 Servings of Plain Rice -
Water Level
Old Rice
Fresh Rice
Soaked Rice
Hard-Boiled Rice
Fluffy Rice
Slightly above the scale
Slightly below the scale
Slightly below the scale
Slightly below the scale
Slightly above the scale
Type of Rice
※ If using polished and ready to boil rice, use the standard water level.
(Polished and Ready to Boil Rice: Prewashed rice)
WHA-VE0601GD Series ENG-0308.indd 9 2013-03-19 �� 1:12:45

10
▶Power Outage Compensation
Cuchen electric pressure rice cookers feature a power outage compensation function that remembers the operation that was being
performed before a power outage occurs. In the event of a power outage, this feature enables the operation that was taking place to be
resumed once the power is restored.
Caution: Power outage during rice cooking activates forced steam ventilation. (to prevent steam-related accidents)
▶Lithium Ion Battery
Cuchen electric pressure rice cookers feature a lithium ion battery that powers the power outage compensation and clock features.
The battery’s lifecycle is approximately 3 years. This figure can vary depending on the product’s specifications.
▶Melanoizing
Cooking rice with a Cuchen electric pressure rice cooker leaves rice at the bottom of the pot slightly brown in color.
This is known as melanoizing and adds savory flavor and aroma to the cooked rice.
If using the timer to cook, starch released from the rice can settle to the bottom of the pot and lead to more evident melanoizing effect.
Setting the Clock (Example: Setting the Clock to 9:30 AM)
Press SET button.

Adjust the time using HOUR/MENU and MIN/MENU buttons.
Press the HOUR/MENU button to change the hour setting in 1-hour increments.
Verify the AM/PM setting.
Press the MIN/MENU button to change the minute setting in 1-minute increments.
※The CANCEL button exits the time setting mode and restores the previous time
setting.

Press OK button to apply the time setting.
If you do not press OK button, the new setting will automatically apply in 25
seconds.
※Pressing the CANCEL button within 15 seconds after applying the new setting
will cancel the change and restore the previous time setting.

Setting the Clock
WHA-VE0601GD Series ENG-0308.indd 10 2013-03-19 �� 1:12:47

11
3 Pressure Settings
Adjusting the Pressure Setting (Regular+Plain)
※These 3 pressure settings are enabled in PLAIN mode only.
※While cooking is in progress, the three pressure settings are disabled.
Iron Pot-Style Sticky Rice
Produces sticky and plump rice by cooking in an iron pot.

A Right Balance of Sticky and Perfectly Cooked
Produces a blend of sticky rice and perfectly cooked rice.

Perfectly Cooked
Produces perfectly cooked rice. Ideal for making rice rolls and sushi.

The rice cooker may release steam while operating in this
mode. This is the result of the cooker regulating its internal
pressure, and is completely normal.
Caution
Cook Control
Press the SET button twice. This will activate the Cook
Control mode, as indicated by a message.
●
Cook Control indicator will turn on, along with five other indicators:
STICKY, 1, 2, 3, and REGULAR.

Use the HOUR/MENU or MIN/MENU button to scroll
through the options.
●
From the available options (1, 2, 3) the selected one will be flashing.

Choose the desired option and press OK button to set.
●
Your pressure setting preference for cooking in PLAIN mode is now set.

Select PLAIN mode and start cooking.
●
Pressing the PRESSURE button after making a selection saves the Cook
Control setting to memory and starts cooking in PLAIN mode.
●
Pressing the PRESSURE button from standby mode starts cooking the rice in
PLAIN mode and using the configured pressure setting.

WHA-VE0601GD Series ENG-0308.indd 11 2013-03-19 �� 1:12:48

12
Fine-Tuning (MIXED Mode – 2 minutes for Soak and 2°C for Heat)
※Fine-tuning is disabled in the Preset option.
※Fine-tuning is enabled in PLAIN, MIXED, BROWN, BARLEY, and NURUNGJI modes only.
Use the HOUR/MENU or MIN/MENU button to
select the desired Heat setting and press OK
button.
●
Available Heat settings are -4°C, -2°C, 0°C, 2°C, 4°C, and 6°C.
●
Pressing the OK button saves the settings and returns the
cooker to standby mode.
Use the HOUR/MENU or MIN/MENU button to
adjust the Soak time and press OK button.
●
Available additional Soak settings are 0 minutes, 2 minutes, 4
minutes, 6 minutes, and 8 minutes.
●
Once the Soak setting has been configured, the additional Heat
option is displayed.
Press the SET button three times. This will activate
the fine-tuning mode, as indicated by a message.
●
The display will indicate the available modes and show the
current Soak setting.
Press the HOUR/MENU or MIN/MENU button to
select a mode and then press OK button.
●
The selected mode is displayed along with the additional Soak
time.
Select a desired mode and start cooking.
●
You can set fine-tune settings exclusive for each cooking mode. These settings will
automatically load when the corresponding mode is selected.
●
Pressing the PRESSURE button instead of the OK button while configuring fine-tuning settings saves the settings and begins
cooking right away in the selected mode.
●
While configuring fine-tuning settings, the selected settings will be automatically saved if no other action is taken for 25 seconds.
●
To cancel, press the CANCEL button.
Cook Control
WHA-VE0601GD Series ENG-0308.indd 12 2013-03-19 �� 1:12:50

13
Cooking Rice
Instructions
Press the PRESSURE/QUICK button.
●
The remaining cooking time is displayed.
※The pressure cap may not spin if the maximum number of
servings is cooked. However, this does not indicate a product
malfunction.


Plug in the cooker, close the lid, and turn the Lid
Lock to the Lock position.
●
Make sure the pressure packing is seated properly and that the
pressure cap is on flat.
●
Pressing the PRESSURE/QUICK button while not having the Lid
Lock in the Lock position will not start cooking the rice.
●
If the surface of the temperature sensor has debris, remove it.
●
Ensure that the outer surface of the inner pot is dry before placing
it inside the cooker.

Once cooking is completed, the cooker will
automatically go into WARM mode.
●
Once the steaming stage begins, the remaining time will be
displayed.

Use the HOUR/MENU and MIN/MENU buttons to
select a cooking mode.
●
Enabling this option cooks the rice without using any pressure, resulting in al dente style rice.
Regular Option
●
Quickly press the PRESSURE/QUICK button twice to cook in QUICK mode. This will lead to the reduction of cooking
duration.
●
Cooking in Turbo mode is recommended for servings of less than 4. Also note that rice cooked in Turbo mode may not
taste as good as rice cooked in normal mode.
●
The QUICK option is available for PLAIN and MIXED modes only.
PLAIN/MIXED
Mode
●
Activating brown rice increases the amount of antioxidants and other nutrients in the rice and loosens the molecular bonds
for rice that’s softer to chew and easier-to-digest.
●
Wash brown rice and fill with water using the GABA scale.
●
It takes approximately 3 hours to cook activated brown rice.
●
Preset is disabled in the GABA menu.
GABA Menu
●
Before the steam automatically releases, a voice guidance
message such as “Now, the steam will release. Please be
careful." is made. Do not be alarmed, but beware that you do
not get burned by the steam.
●
Once finished cooking, you will hear a message telling you that
"Cooking has finished. Keeping rice warm will start. Fluff the rice
before keeping it warm."
●
Once cooking is completed, make sure to fluff and mix the rice
right away.
WHA-VE0601GD Series ENG-0308.indd 13 2013-03-19 �� 1:12:52

14
Instructions
2 Servings
~
6 Servings
2 Servings
~
5 Servings
2 Servings
~
4 Servings
2 Servings
~
4 Servings
2 Servings
~
4 Servings
2 Servings
~
4 Servings
2 Servings
~
4 Servings
2 Servings
~
4 Servings
2 Servings
~
4 Servings
For detailed cooking
instructions by mode, see
p.15 through p.17.
PLAIN
STICKY Misc.
Approx. 2
hours and 35
mins
~
3 hours
Approx.
37mins
~
Approx.
45mins
Approx.
29mins
~
Approx.
34mins
Approx.
50mins
~
Approx.
58mins
Approx.
32mins
~
Approx.
45mins
Approx.
40mins
~
Approx.
58mins
Approx.
26mins
~
Approx.
36mins
Approx.
30mins
~
Approx.
40mins
Approx.
15mins
~
Approx.
26mins
Jujube tea,
fruit punch,
pumpkin
porridge,
vegetable
soup
Braised short
ribs, boiled
beef, sweet
potatoes,
potatos, eggs,
healthy rice,
braised
chicken, squid
blood sausage
Rice,
rice+potatoes
and black
sesame seeds,
rice+vegetables
and
mushrooms,
sticky
rice+sweet
pumpkin,
rice+bean
sprouts,
seafood rice
Rice Brown Activated
brown rice BARLEY NURUNGJI
Rice+beans,
rice+cereals
Rice+beans,
rice+cereals
Rice,
rice+octopus,
rice+vegetables,
rice+curry,
rice+beef,
rice+fried bean
curd, rice rolls,
kimchi fried rice
Menu
Category
Servings
Time
Required
for
Cooking
by Mode
Types
of
Dishes
PLAIN
QUICK BROWN MIXED SLOWSTEAM
NURUNGJI
BARLEY
MIXED
QUICK
GABA
※The actual cooking time may vary depending on the type of dish being prepared.
※When cooking barley, add water using the following plain scale conversion:
(2 servings = 3 servings on plain scale, 3 servings = 5 servings on plain scale, 4 servings = 6 servings on plain scale, 5 servings = 8 servings on plain scale,
and 6 servings = 9 servings on plain scale)
※In PLAIN QUICK or NURUNGJI mode, use the plain scale for the amount of water to add.
※When using MIXED QUICK mode, use the MIXED scale for the amount of water to add.
※Adding water in excess of the maximum line may cause the water to spew out through the steam vent.
※The actual cooking duration may vary if the Cook Control feature is enabled.
※In QUICK mode, using water in excess of the scale can prolong the overall cooking duration.
※Cooking or warming rice after using the Slow feature can cause the new rice to take on a smell. (Use the cooker by referring to p.9)
Cooked mixed grains in 20 minutes!
※Select MIXED mode and quickly press the PRESSURE/QUICK button twice to cook in QUICK mode and to reduce cooking duration.
※The MIXED QUICK option enables 2 servings to be cooked in 20 minutes.
※Cooking in MIXED QUICK mode is recommended for 4 servings or less. Also note that the mixed rice cooked in MIXED QUICK mode may not taste as good as rice
cooked normally.
※Cooking rice mixed with thoroughly soaked black or red beans in normal MIXED mode can produce a mushy result. In this case, use the MIXED QUICK option to
harden the rice.
※The actual cooking duration may vary depending on the ratio of grains, water temperature, amount of water used, and other factors.
MIXED QUICK Menu
Cooking Rice
WHA-VE0601GD Series ENG-0308.indd 14 2013-03-19 �� 1:12:54

15
Cooking with Cuchen
Create amazing dishes with Cuchen!
● Ingredients: 2 cups of sticky rice and black bean
1/2 cup of red bean, 1/2 tablespoon of salt, 1 cup of waxy sorghum+glutinous millet+glutinous Chinese millet
(1 part each), and 3 cups of water used to boil the red beans and regular water
● Directions
1. Thoroughly wash and set aside the sticky rice, glutinous millet, and glutinous Chinese millet.
2. Wash the red beans thoroughly, and place them in a pot. Add cold water to the pot. Boil the beans, drain
them, add a sufficient amount of cold water to them, and boil them again. Cook until the beans are
about to burst.
3. Soak the waxy sorghum in warm water for twenty minutes. Scrub to peel the skin off and rinse until the
water runs clear (not red).
4. Add the rice and grains to the inner pot. Dilute the red bean water with regular water, and add to the pot.
Add salt.
5. Place the inner pot inside the rice cooker, and close the lid.
6. Select MIXED using the MENU button, and start cooking.
※Soak the peas in lukewarm water for at least 15 minutes.
Five-Grain Rice
Cook in MIXED mode
●
Ingredients: 3 cups of rice, 150g of bean sprouts, 100g of ground beef, 5 tablespoons of soy sauce, 1
tablespoon of cayenne, 1 tablespoon of chopped green onions, 1 teaspoon of minced garlic, 2 teaspoons of
salt with parched sesame, and 1 teaspoon of sesame oil.
● Directions
1. Trim off the tails from the bean sprouts. Thoroughly wash and drain the bean sprouts.
2. Add washed rice to the inner pot, fill with water to the 3 serving level on the plain scale, and top off with
the bean sprouts and the ground beef.
3. Place the inner pot inside the rice cooker and close the lid.
4. Set COOK CONTROL to STICKY and start cooking.
5. Mix the bean sprouts and ground beef well into the rice and serve with the seasoned soy sauce to be
mixed with the rice on the side.
※The end result may take on a yellowish tinge due to juices from the meat and salt content.
Rice with Bean Sprouts (4 servings max.)
Cook in STICKY Mode
Cook in STEAM Mode
● Ingredients: 600g of chicken, 4 cloves of garlic, 1 to 2 green ginseng roots, sticky rice, 2 jujubes, and salt
and pepper (to taste)
● Directions
1. Cut open the chicken’s belly with a knife.
2. Pull out the innards and clean. Stuff the chicken with steepened sticky rice. (soak the sticky rice in
water for about two hours)
3. Add the ginseng roots, jujubes, and garlic inside the chicken. Cross the legs of the chicken in place. For
a thicker broth, take out half the sticky rice from the chicken and cook in the broth.
4. Place the stuffed chicken of 3. inside the inner pot, and cover with water about half way.
5. Select STEAM mode, and start cooking. See the table above for the recommended cooking duration.
※The end result may take on a yellowish tinge due to juices from the meat and salt content.
Ginseng Chicken Soup
Servings 6 10
Amount of water 55 minutes 60 minutes
WHA-VE0601GD Series ENG-0308.indd 15 2013-03-19 �� 1:12:54

16
Cooking with Cuchen
● Ingredients: 180g of jujubes, ginger, and honey (sugar)
● Directions
1. Thoroughly rinse and tear the jujubes, and slice the ginger. Place the jujubes in the inner pot, along with
little bit of the ginger. Fill the pot with water and cook for 8 to 10 hours in SLOW mode.
2. You may choose to strain out the bits of jujubes and ginger.
3. Add honey or sugar to the brewed jujube tea depending on your taste.
Jujube Tea
Cook in SLOW Mode
● Ingredients: 30g of whole cinnamon, 40g of ginger, brown rice, dried persimmon, and pine nuts
● Directions
1. Peel the ginger, and slice thin.
2. Place the ginger and cinnamon sticks inside the inner pot, and fill with water as shown in the table
below. Cook for 8 to 10 hours in SLOW mode.
3. Add brown sugar to taste, and allow the mixture to cool. Garnish with persimmons and pine nuts
depending on your taste.
※ Marinate the dried persimmons until tender.
Fruit Punch
Cook in SLOW Mode
Cook in STEAM Mode
● Ingredients: 800g of pork, 1 large green onion, 1 ginger, and 5 cloves of garlic
● Directions
1. Trim fat off the pork and place inside the inner pot along with the spring onion, ginger, and garlic. Add 3
cups of water.
2. Select STEAM menu, and press the MIN button to set the cooking duration to 50 minutes. Then, start
cooking.
※ Cut large chunks of meat into appropriate sizes before adding.
※ The end result may take on a yellowish tinge (due to juices from the meat and salt content).
Adding water in excess of the standard may cause the water to spew out during steam ventilation.
Boiled Beef
Servings 6 to 7 Servings 10 Servings
Amount of water 6 Serving-Mark of Plain Pressure Scale 8 Serving-Mark of Plain Pressure Scale
WHA-VE0601GD Series ENG-0308.indd 16 2013-03-19 �� 1:12:55

17
Operating Instructions
● Ingredients: 1kg of peeled pumpkin, 3/4 to 1 cup of sticky rice powder, white sugar, and fine salt
● Directions
1 Dice the pumpkin into cubes and add to the inner pot along with the sticky rice powder. Add water (2 1/2
to 3 measuring cups for 6- to 7-serving pots and fill to the 8-serving level if using a 10-serving pot).
Cook in SLOW mode for five hours.
2 Strain and mash the pumpkin, or use a blender to grind it.
3 Add the salt and sugar depending on your taste.
Pumpkin Porridge
Cook in SLOW Mode
● Ingredients: 50g of onions and potatoes, 40g of carrots, 40g of champignon mushrooms, 100g of beef sirloin,
160g of cream soup powder, olive oil, and 8 cups of water
● Directions
1. Slice the onions, potatoes, carrots, and beef sirloin thin, and cut champignon mushrooms.
2. Sauté the ingredients in a small amount of olive oil. Add 1/2 tablespoon of salt. (Sautéing is optional.)
3. Fill the inner pot with water, and add the soup powder. Add the rest of the ingredients, and cook for five
hours in SLOW mode.
Vegetable Soup
Cook in SLOW Mode
Cook in STEAM Mode
● Ingredients: 600g of beef short ribs, 1/2 of a carrot, 1/2 of an onion, 10 chestnuts, 10 gingko nuts, 1/4 of a
pear, (for marinade) 7 tablespoons of aged soy sauce, 1 tablespoon of salt with parched sesame, 1
tablespoon of minced garlic, 1 teaspoon of pepper, 1 teaspoon of sesame oil, 2 tablespoons of minced spring
onions, 2 tablespoons of starch syrup, 2 tablespoons of cooking wine, and 2 tablespoons of sugar
● Directions
1. Remove fat and tendons from chopped short ribs and soak in cold water for 2 hours to draw out the
blood.
2. Take out the ribs, pat dry, and score. Marinate in a mixture of the sugar and cooking wine for 30 minutes
to tenderize.
3. Lightly sauté the gingko nuts with a small amount of salt. Dice the carrots into chestnut sizes. Puree the
onion and pear after grinding.
4. Mix all prepared ingredients with the soy sauce. Marinate the ribs with the mixture for more than an
hour, and then place them inside the pot. (Water does not need to be added.)
5. Select STEAM mode, and set cooking duration to 45 minutes. Then, start cooking.
6. Plate the short ribs, and garnish with yellow and white egg cuisine and dropwort.
※ The ingredients cook in their own juices and the marinade and do not require additional water.
Adding more water can cause it to spew out through the steam vent.
Braised Short Ribs
WHA-VE0601GD Series ENG-0308.indd 17 2013-03-19 �� 1:12:55

18
Preset
Using PRESET (PLAIN Mode for 9:50am)

Check to see if the clock setting is correct.
For instructions on setting the time, see p.10.
If the current clock setting is incorrect, the preset time will not be accurate.

Press the PRESSURE/QUICK button.
●
The cooker will display the amount of time remaining, along with
the preset timer indicator.
●
The preset timer setting is the time when you want the cooking to
be finished.
●
In PRESET mode, the actual completion time may vary by 30
minutes or so, depending on the amount of rice being cooked and
the selected cooking mode.
Setting the Preset Time
Example) Current time is 8:00pm and you wish to have the rice ready
by 9:50am the next day.
①Check to see if the clock displays 8:00pm.
②Use the HOUR/MENU button to set the hour setting to 9 and the
MIN/MENU button to set the minute setting to 50.
The HOUR/MENU button adjusts the time in 1-hour increments
and the MIN/MENU button adjusts the time in 10-minute
increments.

●
Rice can quickly turn sour in the summer months. Therefore, the preset timer should not be set to more than 10 hours.
●
Cooking old (seal broken long ago) or dried out rice can produce an overcooked or unevenly cooked result.
●
If the rice is undercooked, add more water than usual (about half a scale more).
●
Starting Preset Timer cooking while the inner pot is still hot or warm from the previous cooking will cause the rice to turn sour. Allow the inner pot to cool down
sufficiently before using the Preset Timer feature.
●
Certain ingredients, depending on factors such as the ambient temperature and types and state of the ingredients, may spoil. Avoid using long preset timer
settings if possible.
Menus that can be Preset
PLAIN and NURUNGJI
MIXED
BROWN and BARLEY
STEAM and SLOW
Available Timer Range
36 minutes to 13 hours
45 minutes to 13 hours
55 minutes to 13 hours
(Current Time+1 minute) to 13 hours

Turn the Lock Lid to the Lock position and press the PRESET
button. Use the HOUR/MENU and MIN/MENU buttons to select
the desired mode and press OK button.
Preset mode will be disabled if the handle is not in the Lock position and you press the
PRESET button.
Available Timer Range in Each Menu ※If you set the timer to more than 13 hours, the cooker override the setting and set it to 13 hours.
Precautions for Preset Mode
●
The preset timer setting will remain in memory.
Thus, the next time you wish to use the Preset option with the
same settings, simply press the PRESET and PRESSURE/
QUICK buttons in sequence.
※To check the current time while the preset timer is counting down,
press and hold the HOUR/MENU or MIN/MENU button for three
seconds.
※It’s possible for the cooking to finish before the preset time.
WHA-VE0601GD Series ENG-0308.indd 18 2013-03-19 �� 1:12:57

19
Cooking and Preset in STEAM and SLOW Modes
Instructions for Cooking (40 minutes of STEAM)
Preset (STEAM for 50 minutes at 4:30pm)


Use the HOUR/MENU or MIN/MENU button and select STEAM or
SLOW. Press OK button to confirm.
After pressing the PRESET button, use the HOUR/MENU or MIN/
MENU button to select STEAM or SLOW and then press OK button
to confirm.
Configure the desired cooking completion time using the HOUR/
MENU and MIN/MENU buttons and press OK or PRESSURE
button.
If 25 seconds go by without any input from the user, the cooker uses the last settings and
activates the timer.



Configure the cooking duration using the HOUR/MENU and MIN/
MENU buttons and press PRESSURE button.
Configure the cooking duration using the HOUR/MENU and MIN/
MENU buttons and press OK button.
- Configure the cooking duration using the HOUR/MENU and MIN/MENU buttons and
press OK button.
STEAM
Decrease by 5 minutes.
Increase by 5 minutes.
Hour
Minute
SLOW
Increase by 1 hour.
Increase by 10 minutes.
STEAM
10 minutes to 90 minutes
Decrease by 5 minutes.
Increase by 5 minutes.
Time Setting
Hour
Minute
SLOW
1 hour to 12 hours 50 minutes
Increase by 1 hour.
Increase by 10 minutes.
WHA-VE0601GD Series ENG-0308.indd 19 2013-03-19 �� 1:12:59

20
Voice Adjustment/Auto Clean
Voice Control
Auto Clean/Sterilizing

Press the SET button four times.

Adjust the volume using the HOUR/MENU and MIN/MENU buttons and press OK button.
Volume can be set to OFF to 4.
※ The volume can be adjusted from OFF to Level 4. Setting the volume to OFF effectively turns off the voice navigation feature and
turns off the voice navigation icon.

Add water using the measuring cup, close the lid, and
turn the Lid Lock to the Lock position.
●
Auto Clean: Fill to the Auto Clean scale inside the inner pot.
●
Sterilizing: Fill to the 3-serving line of the inner pot’s plain scale.

Press AUTO CLEAN button once to start Auto Clean
and press the button twice to start Sterilizing.
●
Auto Clean: Cleans the inner pot and the steam vent.
●
Sterilizing: Destroys odor-causing bacillus subtilis and harmful salmonella by
sterilizing the inner pot and cooker at 120°C for fifteen minutes.
※AUTO CLEAN mode helps keep the rice cooker clean.
This feature removes debris and odor and prevents germs from spreading.
▶Auto Clean Precautions
Extremely hot and highly pressurized air will be discharged from the steam vent.
Use water only. Do not use detergent, soap, or any other chemical product.
Four
Times
Once
Twice
WHA-VE0601GD Series ENG-0308.indd 20 2013-03-19 �� 1:13:00
