ASSEMBLY INSTRUCTIONS
14
Gas Tank Assembly
• You must provide propane gas and propane cylinder.
• Use a standard 1.02 lb. propane cylinder only.
• Can be used with a 20 lb. propane tank for longer performance. This
requires a tank conversion hose, sold separately (LP Adapter Hose
SKU QG-012B). Place the conversion hose through one of the bottom
back holes, keeping the unit level on the surface. Make sure to place the
tank and hose away from any well-traveled paths.
• Storage of an appliance indoors is permissible only if the cylinder is
disconnected and removed from the appliance. A cylinder must be
stored outdoors in a well-ventilated area out of the reach of children. A
disconnected cylinder must have dust caps tightly installed and must not
be stored in a building, garage or any other enclosed area.
• The pressure regulator supplied with the appliance must be used.
• Only a cylinder marked “propane” can be used.
• Certain materials or items, when stored under the heater, will be subjected to radiant
heat and could be seriouslydamaged.
• The installation must conform with local codes, or in the absence of local codes,with National Fuel Gas Code,
ANSI Z223.1/NFPA54, Natural Gas and Propane Installation Code, CSA B149.1, or Propane Storage and Handling
Code, B149.2.
• A dented, rusted or damaged propane cylinder may be hazardous and should be checked by your cylinder
supplier. Never use a propane cylinder with a damaged valve connection.
• The propane cylinder must be constructed and marked in accordance with the specifications for LP gas
cylinders of the U.S. Department of Transportation (DOT). or the Standard for Cylinders, Spheres and Tubes for
Transportation of Dangerous Goods and Commission, CAN/CSA-B339.
• Provided with a listed overfilling prevention device.
• Provided with a cylinder connection device compatible with the connection for the appliance.
• The cylinder used must include a collar to protect the cylinder valve.
• Never connect an unregulated propane cylinder to the heater.
• Turn off the control knob of the burner. Fix the 1.02 lb. propane cylinder to the regulator(rotate the propane
cylinder clockwise toward the regulator connecting until tighten it).
• The cylinder be disconnected when the appliance is not use.
• Replacement pressure regulator must be that specified by the appliance manufacturer.The pressure regulator and
hose assembly supplied with the appliance must be used.
• Storage of an appliance indoors is permissible only if the cylinder is disconnected and removed from the
appliance.
• An appliance may be installed with shelter no more inclusive than:
(a) With walls on all sides,but with no overhead cover.
(b) Within a partial enclosure which includes an overhead cover and no more than two side walls. These side walls
may be parallet, as in a breezeway, or at right angles to each other.
(c) Within a partial enclosure which includes an overhead cover and three side walls, as long as 30 percent or more
of the horizontal periphery of the enclosure is permanently open.
(a) Do not store a spare LP-gas cylinder under or near this appliance;
(b) Never fill the cylinder beyond 80 percent full
