CULITEK TEKRB-24-NG User manual

Gas Radiant
Standard Charbroilers
A Professional Line of Commercial Cooking Equipment
Instruction Manual
CHARBROILERS
MODELS: TEKRB-24-NG/LP, TEKRB-36-NG/LP
TEKRB-48-NG/LP
This manual contains important information regarding your Culitek unit. Please read this manual
thoroughly prior to equipment set-up, operation and maintenance. Failure to comply with regular
maintenance guidelines outlined in this manual may void the warranty.

- 1 -
Dear customers and users:
Thank you for purchasing our products. In order to be able to better use
this product, please read these instructions carefully before any operation,
and follow the guide, to avoid any unnecessary trouble during using.
Please keep this instruction manual in a safe place for convenient
reference and operation.
This instruction manual is subject to any change without further notice,
and the manufacturer reserves the right of final interpretation.
The appliance is designed for commercial purposes, not for household
use.
A statement instructing the purchaser to post in a prominent location
instructions to be followed in the event the user smells gas. This
information shall be obtained by consulting the local gas supplier
Gas Radiant Charbroilers
A Professional Line of Commercial Cooking Equipment

- 2 -
Gas Radiant Countertop Charbroilers
Installation, Operation and Maintenance Guide
Contents
1. Safety Protection ……………………………………………………3
2. Brief Introduction……………………………………………………3
3. Manufacturer's Authority and Responsibility …………………3
4. Parameter Specifications……………………………………………4
5. Transport and Storage ………………………………………………6
6. Installation and Debugging…………………………………………6
7. Safety Notices and Precautions……………………………………8
8. Operating Instructions………………………………………………9
9. Cleaning and Maintenance……………………………………………12
10. Troubleshooting ……………………………………………………14
11. Spare Parts……………………………………………………………15
12. Accessories List……………………………………………………18
Gas Radiant Charbroilers
A Professional Line of Commercial Cooking Equipment

- 3 -
1. Safety Protection
Please make sure that the operator is an authorized and licensed technician
before you allow him/her to install and operate the products. Be sure to
strictly follow this instruction guide during installation and using. The
manufacturer is not responsible for any dangers or accidents caused by
improper operation or maintenance.
Do not store flammable or explosive objects around the product. Keep all
flammable and explosive objects at a safe distance away from the product
for normal use.
Place the product in a reasonable position. Regarding related matters of
gas, customer should execute the requirements of local gas supply sector;
If you smell a gas leak, turn off the gas valves immediately and call the
gas company;
The product should not be operated by those under 18 years of age, or those
with physical or mental disorders, or disabilities that lack the necessary
knowledge or experience unless with appropriate instructions and sufficient
safety.
2. Brief Introduction
The product is a series of gas char broilers in our company production,
which is novel designed, reasonable structured, convenient operated, durable
used, and convenient maintained. It's equipped with a high efficiency
stainless steel tubular burner and a pilot light, and convenient to ignite
the main fire burner. This is hotel, supermarket, western restaurant, noshery
and food industry's ideal barbecue product equipment.
3. Manufacturer's Authority and Responsibility
Banning of all or partial transformation to the products without the
manufacturer's explicit authorization.
The Manufacturer refuses to undertake responsibility to third parties
for the following reasons:
Not follow the instruction guide and take caution in using and testing;
Not comply with the requirements of technical parameters using this product;
Incorrectly or irrationally using the product by untrained personnel;
Not obey the local law using this product;
Be repaired or changed by unauthorized technicians;
Use the spare parts or accessories provided by non-manufacturer;
Gas Radiant Charbroilers
A Professional Line of Commercial Cooking Equipment

- 4 -
Accidents caused by force majeure;
Not strictly comply with related guide of instruction by any reason.
4. Parameter Specifications
4.1、Outline Dimensions(inch)*
TEKRB-24
TEKRB-36

- 5 -
4.2、Gas Supply and Burner Information
The minimum supplied gas pressure regulator is factory set at 4”Natural
Gas W.C, and 10”L.P. Gas W.C. The external thread of product’s intake-tube
is 3/4 inches.
<Table 1>
Model
#of burners
and control
method
Gas
Species
Intake-tube
pressure
（in.W.C.）
Per BTU
B.T.U./h
Total BTU
B.T.U./h
Nozzle
No.
TEKRB-24
2 pieces
Independent
control
Natural
Gas
4
35,000
70,000
#36
L.P. Gas
10
35,000
70,000
#50
TEKRB-36
3 pieces
Independent
control
Natural
Gas
4
35,000
105,000
#36
L.P. Gas
10
35,000
105,000
#50
TEKRB-48
4 pieces
Independent
control
Natural
Gas
4
35,000
140,000
#36
L.P. Gas
10
35,000
140,000
#50
5. Transport and Storage
TEKRB-48

- 6 -
In the process of transportation, handle carefully and keep upright to
prevent damage to the product packing. Wrapped equipment should not be
long-term open storage, and shall be placed in a well-ventilated and
non-corrosive gases warehouse. When equipment needs temporary storage,
rainproof measures should be taken.
6. Installation and Debugging
Any erroneous installation, adjustment, refit, overhaul or maintenance may
cause property damage or personal injury. All this work shall be completed
by authorized and licensed technicians, otherwise the manufacturer has the
right not to provide warranty service;
Only be installed in accordance with the local code. If no similar standard,
you should conform to the National Fuel Gas Code, ANSI Z223.1/NFPA 54, the
National Gas Installation Code, CSA-B149.1, or the L.P. Gas Installation
Code, CSA-B149.2 as applicable;
The appliance individual shutoff valve must be disconnected from the gas
supply piping system during any pressure testing of that system at test
pressures in excess of 1/2psi (3.45kPa).
6.1、Unpacking and Installation
Please dispose of all packaging materials and residues after unpacking;
Check the equipment. If it is damaged, please keep wrappers and receipts,
which must be signed by the carrier representative (Driver), and contact the
carriers to pursue a claim within 15 days after receiving;
Check all accessories complete. Refer to P17 table 5;
Be sure to install supporting legs before using, and do not tear up any label
or logo before the normal using;
Please read these instructions carefully before installation and operation.
Please contact your local agent if you have any questions;
The charbroiled shall be installed on a level, solid, non-skid and
incombustible surface, and placed in a well-lighted work area with waterproof,
and away from children and customers;
The installation position is a well-ventilated place in accordance with the
local regulations;
The charbroiled must be installed under the matched cooking fume exhauster
according to the local regulations;

- 7 -
Important: Installation and ventilation laws, and codes are very different,
you should state and comply with all codes of the National Fire Protection
Association Inc when it comes to requirements for installation of equipment;
Screw 4 adjustable stainless steel legs in the tapping hole with four corners
of the char broiler bottom, ensure sufficient space for ventilation;
Adjustable stainless steel legs to make the equipment level, and get the same
level with other series of the same stove; Please lift the equipment rather
than drag if you need to move it;
Open the grate, and take out the support under it, and reinstall grate after
you make sure the thermal radiation plate is unmoved, and dispose the support;
Supplied gas pressure regulator is factory set at 4”Natural Gas W.C, and
10”L.P. Gas W.C;
The equipment can only be placed on the nonflammable counter top, and keep
a distance of at least 6 inches(152mm) to equipment’s both sides and back,
and keep a distance of at least 4 inches(102mm) to the bottom;
Do not put anything around the equipment, and on the counter top and bottom,
in order to avoid influencing combustion and air circulation;
Leave enough distance in front of the equipment to take apart the control
panel. All major parts, in addition to the burner remove from the front
intake-tube;
It may be necessary to adjust the balance of air input by authorized and
licensed technicians;
Pipe threading compound must be resistant to the action of liquefied
petroleum gases.
Warning! Use soap water or testing instrument to test whether piping joint
leaks before use, and forbidden to use an open flame to test!
After installing, you should check gas supply pressure. Use a pressure gauge
which is equipped with liquid (such as U-type pressure gauge, the minimum
value is 0.1mbar) or a digital pressure gauge to test. Steps as following:
●Remove counter top plate, and needle type pressure joint screw arbor
(Fig.1), then slip rubber tube of pressure gauge over needle type
pressure joint;
●Start the equipment in accordance with the
instructions, measuring gas supply
pressure (dynamic pressure) in the work
state;
●Access to the equipment if measured data
within the limits of table 1, otherwise,

- 8 -
you will need to adjust gas pressure regulating valve or contact gas
supplier to bargain;
●Unplug pressure gauge after you accomplish pressure testing, then
install needle type pressure joint screw arbor. Important: must screw
joint screw arbor to prevent Fig.1
gas escape!
6.2、Debugging
It’s very important to debug the new stove. Through the comprehensive
system test of equipment, we can ensure product’s function and safety
performance. Discovering any potential problems before use (such as
equipment’s placement, ventilation, operation, etc), can avoid costly
losses.
7. Safety Notices and Precautions
Warning! For your safety, do not place petrol and other flammables nearby.
Please keep clean and free of flammables surroundings. (Read ANSI Z83.14B,
1991 for reference)
Warning! Any erroneous installation, adjustment and refit may cause property
damage or personal injury and maintenance failure. Read the instructions
carefully before installation and using.
Warning! Operation instruction must be placed in a conspicuous location.
When customers smell gas in the process of using, should take safety
precautions immediately. Immediately turn off the main gas valve, extinguish
all heat and flames, and call 911. Safety information can be obtained from
your local gas suppliers.
When using this equipment, safety precautions should always
be followed, including the following:
The char broilers burners, grates and outside surfaces may become hot after
useing, so you must be careful to touch;
During operation, do not directly touch burners and grates;
Turn off the equipment as not in using, cleaning, servicing or adjusting any
parts or attachments.
If the equipment has any problems of equipment damage, gas piping leaks,
igniter or valves damage, or lose product accessories, do not operate by
yourself and call customer service immediately;

- 9 -
The use of attachments not recommended or sold by the manufacturer may cause
fire, personal injury, even death;
Do not use out of doors;
The equipment is used for barbecue, not available for any other use;
The equipment does not contain any user-serviceable parts. Dealers or
technicians will repair it. Do not take apart any spare parts without
authorization;
Never change any other parts without authorization to this equipment,
otherwise, may cause hazards, and the manufacturer has the right not to
provide warranty service;
Steel cutting producers used to manufacture with sharp edges. The
manufacturer has dealt with these sharp edges during production, however,
we insist the operator take care when in contact with this piece of equipment;
Always keep hands, hair and clothing away from heating source.
Waiting until the unit cools down before you clean. Because the unit is too
hot to handle after using.
8. Operating Instructions
Before operating, make sure place the unit horizontally by adjusting bottom
adjustable legs, and place the catch tray properly.
The pilot light has been set at the factory. Each burner has a pilot light.
8.1、Lighting the pilot light
Turn the control valve at the position of “0”(Fig.2), make sure all
knobs are in the close state. Light and hold an ignition source at the pilots.
The pilot light may not be lighted immediately, for existing gas in the pipe.
Wait a minute, the pilot light will be lighted after the gas extinguished.
Tips: You can use a screwdriver to adjust the height of the flame (Fig.3).
8.2、Lighting the main burner
Revolve the main fire control valve knob counterclockwise after lighting
the pilot light, then the main fire burner is lighted by the pilot light.
The power of burner increases as revolving angel increases. When knob reaches
to " ", burner is in the maximum power(Fig.4).

- 10 -
Fig.2 Fig.3 Fig.4
Make sure air circulation at the bottom of equipment;
Do not use fan or air-conditioning blowing at the flame, in order to avoid
extinguishing flame, and cause safety accidents;
Install the matched cooking fume exhauster according to the local regulations
over the char broiler;
Make sure to keep natural air circulation in the kitchen.
8.3、Turn off the valve
Revolve the control valve knob clockwise to "0" (Fig.1), so that
extinguish flame of the main burner, but the pilot light still works.
After turning off the equipment, the main fire should be stop more than
5 minutes before next using.
8.4、Stove Operation
Before using the stove for the first time, please use a mild detergent
to wipe it clean. Do not use corrosive or abrasives detergent.
Turn the burners on about 15-20 minutes before broiling for preheating,
according to the cooking requirement to adjust the flame size.
Notice: When first preheating, the furnace will smoke rise. This is
because of protective lipids on the grates and other parts are heated, it
is normal, and it will be eliminated after the power up to the maximum for
burning an hour.
One side of grate with grease trough (Fig.5), and on the other side of
grate is flat (Fig.6), users can choose a side according to demand, users
also can adjust grate’s gradient according to demand (Fig.7). The side of
grate with grease trough up if roasting food with more oil, and oil will drop
into grease trough, then flow to catch tray.

- 11 -
Fig.5 Fig.6 Fig.7
8.5、Exchange main fire nozzle to switch gas source
Remove control panel, grate and heat storage plate, remove the pilot
light head, and bottom tightening screw of the end of burner (arc), then
remove main fire nozzle with proper open spanner, exchange nozzle of another
gas source, then screw it (Fig.8). Reinstall burner, the pilot light head,
cooking grates and control panel in proper place.
Caution: Each main fire nozzle of the burner has been installed before
delivery, normal use without adjustment but only switching gas. Adjust only
by authorized and licensed technicians. When you converse the gas source,
exchange the corresponding pressure maintaining valve which installed on
air intake. See 2 in P18.
8.6、Adjust air input
Remove control panel, unscrew damper solid screw(Fig.9), revolve damper
left to right (Fig.10), meanwhile, observe flame and adjust an appropriate
opening degree. Then screw damper solid screw, make sure the equipment will
not get loose in the process of moving and translation. Reinstall control
panel.
Caution: Each burner damper has been adjusted before delivery (once air
input), normal use without adjustment but only switching gas. Adjust only
by authorized and licensed technicians.
Fig.8 Fig.9 Fig.10

- 12 -
9. Cleaning and Maintenance
Do not use any abrasive or flammable detergent to wipe;
Do not hose down, immerse or pressure wash any part of the char broiler,
excluding the catch tray;
Do not use abrasive cleaning matters to wash, even not use corrosive
detergent!
Warning: Before cleaning, all control valves must be turned off.
Strictly follow the lighting instructions to work again after
cleaning!
Warning: Wait for the equipment cool down before your cleaning!
Cut off the gas source as not in using;
If the equipment is not used for a long time, clean the surface by wiping
it with a soft cloth and place it in a well-ventilated area;
Comprehensively check the equipment at least once every year by authorized
and licensed technicians;
The product is made of 90% metals, and can not be disposed anywhere. Deal
with it in accordance with the local codes.
Instructions to clean appliance regularly with recommended cleaning agents,
if necessary.
Recommended cleaning methods
<Table 2>
Item
Method
Time
Body
Wipe it with a soft cloth and mild
detergent
daily
Control panel
Turn off the valves when not in
use;
Wipe panel and control valve knob
with mild detergent.
daily

- 13 -
Grates & Radiants
Caution: Wear insulated gloves when
handling grates or radiants, in
order to prevent possible burns!
1.Take out grates and radiants;
2.Clean up grease and other
impurity on grates with a wire
brush;
3.Clean grid slot with a scraper;
4. Grates coated with food grade
lubricants. Reinstall radiant and
grate in proper order, open char
broiler to evaporate for 45
minutes, then close it.
Warning: Do not cover grates in the
process of evaporation!
daily/as need
Char Grate
Back Support
Brace
Remove grate until the equipment
cools down. Take off char grate back
support brace, clean grease and
other crumbs. Then daub lubricants.
Reinstall after cleaning.
daily/as need
Catch tray
Pull out catch tray from front body
until the equipment cools down.
Clean grease and other crumbs.
Reinstall after cleaning and
daubing lubricants.
Warning: if the catch tray is
permitted to fill too high, should
be cleaned!
Per use

- 14 -
10. Troubleshooting
<Table 3>
Problems
Possible causes
Problem solving
Not lighting
1.Insufficient gas pressure
in pipe
1.Contact the local
gas supply dept.
2.Nozzle occlusion
2.Dredge nozzle
Ignite the
pilot light
but not the
main fire
1.Insufficient gas pressure
in pipe
1.Contact the local
gas supply dept.
2.The main fire nozzle
occlusion
2.Dredge nozzle
3.Gas control valves have
problems
3.Change gas
control valves
4.The pilot light and the main
fire’s distance is too far
4.Adjust the
distance of them
5.Flame is too low
5.Adjust the height
of the pilot light
Close gas and
heard a sound
of fire
1.Insufficient gas pressure
in pipe
1.Contact the local
gas supply dept.
2.Not match nozzle aperture with
gas resources
2.Adjust nozzle
diameter
3.Flow of connection pipe is
not enough
3.Increase pipe’s
allowable flow
4.Damper opening degree is
too large
4.Adjust damper
Yellow flame
and black
smoke
1.Use bottom gas
1.Change gas
2.Not match nozzle aperture with
gas resources
2.Adjust nozzle
diameter
3.Not enough air to ignite
3.Increase damper
opening degree
4.In the peak of using gas,
sources of gas float heavy
4.Turn down valves
flow. Turn it up
after the peak
The problems mentioned above are only for reference. If any fault occurs,
please stop using, and contact technicians to check and repair. Safety first,
turn off the power and gas supply before maintenance.

- 15 -
11. Spare Parts
The use of parts provided by other companies, our company has the right not
to provide warranty service;
Order replacement parts from authorized representatives and after-sale
service agency.
Provide the model number, serial number and description when you order
components.
1234567
89
10
11
12
13
14
15
16
17 18
19
20
21
22
23
24
34
Fig.11

- 16 -
<Table 4>
No.
Matters
Code
Component
name
Qty
Dimensions
(mm)/Model
Remark
1
301110001
Adjustable
steel leg
4
φ41.5*100
TEKRB-24\36\48
2
21105001001
Catch tray
1
507*620*26.5
TEKRB-24
21105002001
807*620*26.5
TEKRB-36
21105003001
1107*620*26.5
TEKRB-48
3
301080002
Galvanized
flange face nut
6
M6
TEKRB-24
9
TEKRB-36
11
TEKRB-48
4
301082001
Galvanized
flat grommet
4
φ6*φ10
TEKRB-24
6
TEKRB-36
7
TEKRB-48
5
301081006
Galvanized
American
outside six
corner with pad
tapping
24
ST4.8*12.5
TEKRB-24\36\48
6
21105001002
Control panel
1
605*185
TEKRB-24
21105002002
905*185
TEKRB-36
21105002002
1205*185
TEKRB-48
7
301140001
Kirsite knob
2
TEKRB-24
3
TEKRB-36
4
TEKRB-48
8
301060001
Needle type
pressure joint
1
1/8"-27NPT
TEKRB-24\36\48
9
301060002
Needle type
pressure joint
screw arbor
1
M5*23
TEKRB-24\36\48
10
301030002
A18 stopcock
2
A18-318
TEKRB-24
3
TEKRB-36
4
TEKRB-48

- 17 -
11
301040006(NG)
301040007(LP)
A18 nozzle (NG)
A18 nozzle(LP)
2
NG36
LP50
TEKRB-24
3
TEKRB-36
4
TEKRB-48
12
301030001
Pilot light
valve-single
unit
2
AP7-1
TEKRB-24
3
TEKRB-36
4
TEKRB-48
13
301070013
Air input pipe
2
φ4.7*0.6
L=400
TEKRB-24
3
TEKRB-36
4
TEKRB-48
14
301170015
Pilot light
head stator
2
TEKRB-24
3
TEKRB-36
4
TEKRB-48
15
301060003
Pilot light
head
2
A73007/TiPφ4.7
TEKRB-24
3
TEKRB-36
4
TEKRB-48
16
21205001001
countertop
1
610*700*218
TEKRB-24
21205002001
910*700*218
TEKRB-36
21205003001
1210*700*218
TEKRB-48
17
301020003
grates
4
150*525*22
TEKRB-24
6
TEKRB-36
8
TEKRB-48
18
21205001003
Char grate back
support brace
1
L=600
TEKRB-24
21205002003
L=900
TEKRB-36
21205003003
L=1200
TEKRB-48
19
301170002
Radiants
(short)
2
92*103
TEKRB-24
3
TEKRB-36
4
TEKRB-48
20
301170001
Radiants
(long)
4
L=451
TEKRB-24
6
TEKRB-36
8
TEKRB-48
21
301010007
U-type burner
2
TEKRB-24
3
TEKRB-36
4
TEKRB-48

- 18 -
22
301030014
pressure
maintaining
valve
1
4”-10”
TEKRB-24\36\48
23
301070001
24”countertop
char broiler
intake-tube
1
Φ26-503*648
TEKRB-24
301070002
36”countertop
char broiler
intake-tube
Φ26-803*648
TEKRB-36
301070003
48”countertop
char broiler
intake-tube
Φ26-1113*648
TEKRB-48
24
21205001002
surround
1
600*640*203
TEKRB-24
21205002002
900*640*203
TEKRB-36
21205003002
1200*640*203
TEKRB-48
12. Accessories List
<Table 5>
TEKRB-24 TEKRB-36 TEKRB-48
Adjustable
steel legs
4 pieces
4 pieces
4 pieces
Catch tray
1 piece
1 piece
1 piece
pressure
maintaining
valve
1 piece
1 piece
1 piece
A18 Orifice
2 pieces
3 pieces
4 pieces
instructions
1 piece
1 piece
1 piece
Notice:
1、Pressure maintaining valve connects with air intake, must be installed by
authorized and licensed technicians, to assure interface tightness.
2、Screw the hex nut (Fig.12) before connect air intake, ensure gas mark (Fig.13)
on the plastic core whether match with connected gas source, if not, then pull
Model
Qty
Name

- 19 -
out the plastic core and change another head, insert it again. The same as
exchanging gas source.
3、When exchange gas source, use the A18 orifice (Fig.14) in the accessories.
Follow rules of 8.5.
Fig.12 Fig.13 Fig.14
