Assembly Instructions (see Diagram 1)
If your CURRENT COASTER was purchased pre-assembled, we strongly recommend that you review these assembly instructions and check to ensure that it was assembled
properly
Tip: If assembling over a hard surface, consider laying out a blanket, towel or cardboard to protect from scratching.
Step 1: Assemble front fender
Turn the fork so that the dropouts are angled forward. Afx the fender stay with provided screw, washer and nut to the inside of the front fender. Note that the open ends of the
axle loops should be facing down.
Step 2: Connect front fender and brake to the fork
Insert the caliper brake rod into the front of the fork. From behind the fork, connect the fender stay tab, as shown. Tighten the caliper brake lock nut securely.
Step 3: Assemble the wheels
For the front wheel, remove the capped nuts and insert the axle fully into the fork dropouts. Slide on each wheel retaining clip. Place the looped ends of the fender stays over
the axles and securely replace the capped nuts.
Tip:Inatethetiresafterthefrontwheelhasbeenattachedtothefork.Thiswillmakeiteasiertopassthefronttirebetween
thebrakepads.Inateuptothemaximumpressureshownonthetirewalls.
Tip: (For Kenda Kwickroller tires only) Though the front and rear wheels are interchangeable, it’s important that the arrow printed on each tire
sidewall points forward when at the top of each wheel.
Step 4: Connect the handlebar stem to the steerer
Loosen the center stem bolt enough so that the wedge and stem can slide into the fork steerer tube. Lower the stem until the minimum insertion mark is no longer visible. Once
the handlebar is set to the desired height, lightly tighten the stem bolt with a 6 mm Allen wrench so that the handlebar can be aligned perpendicular to the forks. Once aligned,
ensure that the stem bolt is tightened and that the headset locknuts are secure.
Tip:Forsafety,thestemmusttsnuglyintotheforksteerer.Thetighttolerancemaycausemarringofthehandlebarstempaint.
Therefore, we recommend setting the handlebar high to test, and lower as desired.
CAUTION: Be sure the quill is inserted beyond the stem minimum insertion mark - it must not be visible above the top of the headset. If the
stem is raised above this mark, the stem could pull free, causing loss of control and injury!
Step 5: Connect the deck to the frame
Being careful not to scratch the paint, insert the rear of the deck into position, then the front. Screw each bolt securely into the deck with a 4 mm Allen wrench.
