SPIDER HNSC07900 User manual

WARNING:To reduce
the risk of serious injury, read these
warnings before using the scooter.
1. Read and follow all instructions.
2. It is the owner’s responsibility to
ensure that all users of the scooter
are adequately informed of all
warnings and instructions.
3. Inspect the scooter and tighten or
replace any loose or missing parts
before each use. In addition, make
sure that the handles and the stem
are securely locked in position, the
wheels rotate freely, the brake is in
working order and free of all
debris, and the wheel bolts are
secure.
4. The scooter should not be used by
children under the age of eight. A
responsible adult must always
supervise young riders.
5. Always wear protective equipment,
including a helmet, knee pads, wrist
guards, elbow pads, and closed-toed
shoes, when using the scooter.
6. Never ride on streets, roadways, or
driveways that enter vehicle traffic
routes. Never ride on wet or uneven
surfaces, at night, or when visibility
is poor.
7. Never tow a rider with a bicycle,
motorcycle, or vehicle.
8. Locate the warning decals on the
scooter, and read the warnings
before using the scooter.
9. Save this User’s Manual for future
reference.
10. This scooter should not be used by
persons weighing more than 200
pounds.
11. Braking from high speeds or pro-
longed braking on inclines can cause
excessive wear of the rear wheel and
brake. Exercise caution when select-
ing your area of use.
12. To prevent burns, avoid touching
the brake after prolonged use.
User’s Manual
Model No. HNSC07900

Setup
1. Firmly press the thumb tab and pivot the upright up until it
locks in a nearly vertical position.
2. Insert the handles into the stem until the lock pins are visi-
ble in the holes in the stem.
3. Open the quick-release lever. Depress the lock pin on the
stem, and slide the stem up until the lock pin is visible in
one of the three holes in the upright. When the stem is at
the desired height, close the quick-release lever so it is snug
against the upright. If the quick release is not snug, see
ADJUSTING THE QUICK RELEASE on the back of this
manual.
Before using the scooter, make sure that the scooter is set up
as described and that all parts are securely tightened.
The decal shown at the right has been placed on the scooter.
If the decal is missing or illegible, please call our Customer
Service Department toll-free at 1-800-999-3756, Monday
through Friday, 6 a.m. until 6 p.m. Mountain Time, to order
a free replacement decal. Apply the replacement decal in the
location shown.
Storage
1. Open the quick-release lever. Depress the lock pin on the
stem and slide the stem down into the upright. Close the
quick-release lever.
2. Depress the lock pins and remove the handles from the
stem. Press the handles into the storage clip on the upright.
3. Pull the thumb tab and pivot the upright down until it locks
in the horizontal position.
Thumb Tab
Thumb Tab
Storage Clip
Hand
Brake
Stem
Quick Release
Handle
HandleUpright
Hand Brake and Cable are not shown.
Lock Pins
Lock Pin
Upright
Front
Left Side
Right Side
Groove

No. Qty. Description
1 1 Deck
2 1 Head Tube
3 1 Fork
4 1 Upright
5 1 Stem
6 2 Handle
7 2 Foam Pad
8 2 Handle Cap
9 3 Lock Pin
10 1 Handle Cord
11 1 Quick Release
12 1 Upright Clamp
13 1 Bearing Nut
14 1 Bearing Cap
15 2 Bearing
16 2 Bearing Race
17 2 Bushing
18 1 Pivot Union Bolt Set
19 1 Front Union Bolt Set
20 2 Rear Union Bolt Set
21 2 Wheel
22 2 Rear Wheel Spacer
23 1 Brake Spring
24 1 Brake
25 1 Head Tube Spring
26 1 Storage Clip
27 2 Front Wheel Spacer
28 1 Lock Pin
29 1 Deck Mount
30 1 Deck Cushion
31 1 Frame
32 4 Deck Screw
33 1 Cable Clip
34 2 Tek Screw
35 2 Brake Spacer
36 1 Mount Union Bolt Set
37 1 Hand Brake
38 1 Brake Bracket
39 1 Cable Bracket
40 1 Brake Cable
41 2 Flange Nut
42 4 Wheel Bearing
43 2 Frame Nut
44 1 Upright Nut
45 1 Upright Bolt
* 1 User’s Manual
*The user’s manual is not shown. Note: Specifications are subject to change without notice.
Part List/Exploded Drawing Model No. HNSC07900 R0101A
8
7
6
9
5
9
6
7
84
910
11
26
12
13
14
15
16
2
16
17
18
18
3
19 19
25
17
28
27 21
27
20
20
36
36
1
22
21
22
23 24
15
29
30
31
32
32
34
35
32
35
34
38
39
40
41
41
37
33
42
43
43
44
45
46
46
46
46
Ordering Replacement Parts
To order replacement parts, call toll-free 1-800-999-3756, Monday through Friday, 6 a.m. until 6 p.m. Mountain Time (excluding
holidays). When ordering parts, please mention the model number (HNSC07900) and the number and description of the parts
needed.

Part No. 168689 R0101A Printed in China © 2001 ICON Health & Fitness, Inc.
Adjusting the Quick Release
If the quick release doesn’t hold the stem snug in place, you
will need to adjust it.
Open the quick-release lever. Turn the adjustment nut clockwise
one half turn while keeping the lever from turning. Close the
lever. Repeat this procedure until the stem is held snug in place.
If the quick release is too snug to close, you will need to adjust it.
While the quick-release lever is open, turn the adjustment nut
counterclockwise one quarter turn while keeping the lever from
turning. Close the lever. Repeat this procedure until the stem is
held snug in place and the quick release is closed.
Adjustment
Nut
Open
Close
Lever
Quick
Release
Hand Brake Maintenance
Refer to inset drawing 1. Locate the adjustment barrel (B) and
the lock nut (A) on the hand brake. Turn the lock nut (A) coun-
terclockwise to loosen it. Next, turn the adjustment barrel (B)
counterclockwise a few turns. Then, turn the lock nut (2) clock-
wise to retighten it. Repeat until the hand brake is properly
adjusted.
If the movement of the hand brake needs to be further adjusted,
the lower end of the brake cable can be adjusted. Using an allen
wrench, remove the indicated union bolt set (36). Next, remove
the rear deck screw (32) and lift off the deck (1).
Refer to inset drawing 2. Locate the adjustment barrel (C) and
the lock nuts (D and E) near the end of the brake cable. Using a
small open-end wrench, turn the outer lock nut (E) counter-
clockwise to loosen it. Next, turn the adjustment barrel (C)
counterclockwise a few turns. Then, turn the inner lock nut (D)
clockwise to tighten it.
Reattach the deck (1) with the rear deck screw (32) and the
union bolt set (36).
A
1
2
B
32
1
36
36
CD
E
