Current Prime Tower 2645 User manual

EMAIL:[e-mail]
WWW.CURRENT-USA.COM
Inline Chiller
Instructions for Models
#2645,2646
Warning and Safety Instructions ....... Page 2
Chiller Installation ....... Page 3
Temperature Controller Programming ....... Page 5
Warranty ....... Page 6
Prime Tower™
JEE 07/05

WWW.CURRENT-USA.COM
2
WARNING
To guard against injury, basic safety precautions should be observed, including the following:
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
DANGER
To avoid possible electric shock, special care should be taken since water is employed in the use of
aquarium equipment. For each of the following situations, do not attempt repairs by yourself. Return
the appliance to your retailer or discard the appliance.
• If the appliance falls into the water, or water drips onto the unit, DON’T reach for it! First
unplug it and then retrieve it. If electrical components of the appliance get wet, unplug the
appliance immediately.
• Always unplug appliance from an outlet when not in use, before putting on or taking off
parts, and before cleaning. Never yank cord to pull plug from outlet. Grasp the plug fully
and pull out to disconnect.
• Carefully examine the appliance after replacement. It should not be plugged in if there is
water on parts not intended to be wet.
• Do not operate any appliance if it has a damaged cord or plug, or if it is malfunctioning or
has been dropped or damaged in any manner.
• Do not use the Prime Tower Chiller for anything other then its intended use. The use of
attachments not recommended or sold by Current USA may cause unsafe conditions.
• Exposing chiller/power cords to water may cause electrical short and fire.
• Do not allow water or salt to come in contact with thermostat or power cords.
• Do not operate chiller without water flow to the unit. This may cause the evaporator housing
to freeze up and result in damage to the unit.
SAVE THESE INSTRUCTIONS
GROUND FAULT CIRCUIT INTERRUPTER PROTECTION
To comply with the National Electrical Code (NFPA 70), and to provide additional protection from the
risk of shock, this unit MUST be connected to a ground fault circuit interrupter (GFCI) outlet at all times.
Do not use extension cords. WARNING – To reduce the risk of electrocution, keep all connections dry
and off the ground. Do not touch plug with wet hands.
Safety Instructions

WWW.CURRENT-USA.COM
3
1. Before removing your Prime Chiller from the box, please note any exterior shipping damage
to the box. It is strongly recommended to keep the box and packaging material in the
unlikely event there is shipping damage or service is required.
2. Remove the chiller and controller from the box and inspect thoroughly for any signs of
damage, even if the box does not show damage. If you notice any damage (cracked or bent
cover, damaged condenser, fins, etc...) please stop and contact your dealer immediately.
3. Make sure the chiller is placed on a firm, level surface in a location that has plenty of ventilation
and will not be exposed to salt or saltwater. Do not use an extension cord for the chiller or
the thermostat.
The requirements for ventilation are:
a) Back/Front: Condenser (radiator) requires at least 18” clearance to allow air into the chiller.
b) Sides: Requires at least 6” clearance to allow for proper air flow.
c) Chiller must not be placed in a closed closet or cabinet. If placing chiller under a cabinet, the
cabinet MUST have a back opening at least 30" wide x 30" high for adequate ventilation.
d) The warm air from the chiller must be completely evacuated from the chiller location. A fan
may be necessary to draw warm air away from the chiller. The maximum operating temperature
is 95 F.
Installation:
4. The chiller includes both ¾" and 5/8" hose barb fittings. Insert desired hose connector into
compression cap.
5. Place barb fitting onto inlet or outlet and tighten compression cap. Ensure that the gasket
fits snug between the barb fitting and chiller.
6. Slide hose clamps onto hose. Attach hose to inlet/outlet barb fitting and tighten hose
clamp.
7. Before turning on chiller, ensure the following:
a) The chiller must have adequate water flow for proper operation.
Model HP Min/Max Flow
2645 ¼ 5-10 gpm
2646 1/3 6-12 gpm
b) Make sure the pump will operate normally without any blockage.
c) Make sure the chiller is plugged into a GFCI protected 110V power outlet.
7. Turn on water pump and check for leaks. IMPORTANT: Do Not Run Chiller without water
flow. Doing so may damage evaporator.
8. Set the temperature controller to the desired temperature as instructed in Programming
Chiller installation

WWW.CURRENT-USA.COM
4
NOTE:
If Chiller is installed underneath a stand or cabinet, the furniture must have an
opening in the back for proper ventilation. a minimum opening of 30"L x 30"w is
recommended.
If chiller is installed next to or near a wall, allow a minimum space of 18" from
the front and back of chiller for proper air ventilation.
Proper ventilation is key for optimum performance and efficiency.
Chiller installation
Digital Temperature
Controller
Maintenance:
Warning: always disconnect chiller before cleaning or performing any
maintenance
Monthly:
Vacuum any dirt or debris from front cover. Remove air filter and vacuum rinse with cold water. Air dry
and replace.
Clean any salt creep that may build up on unit with freshwater.
Removable Air
Filter

WWW.CURRENT-USA.COM
5
Prime Chiller Temperature Controller
The electronic temperature controller is designed to provide on/off control of cooling. It is equipped
with an easy to read Liquid Crystal Display (LCD) that displays a constant readout of actual temperature,
control settings, relay status and system diagnostics. The simple keypad allows programming of set
point temperature and temperature differential.
Displaying current temperature and previous setting
1. Press the SET button. The indicator light will appear and the display will automatically show the
previous set temperature.
2. Press the SET button again, the indicator light will turn off and the current water temperature will
be displayed.
Changing the temperature setting
1. Press the SET button for three (3) seconds. The previous set temperature will be displayed.
2. Press Up "<" button to increase temperature or press Down ">"button to decrease temperature. The
temperature must be set between 60-85 degrees F.
3. Confirm set temperature by pressing SET button again or waiting for 8 seconds. The current aquarium
temperature will then be displayed when chiller begins to operate in normal mode.
Please Note: The chiller has a built-in protection mode that can delay the cooling mode operation for
up to three (3) minutes.
temperature differential
The temperature differential is automatically set to two (2) degrees F as an default.
trouble shooting
P1 Error - Indicates sensor needs replaced or that water has come in contact with controller. Unplug
unit and allow it to try completely before re-starting up. If P1 error continues, contact your dealer for
a replacement temperature sensor.
Temperature Error - if the digital display reads an unusual temperature reading (like 122 F), it indicated
a temperature sensor malfunction. Contact your dealer or Current-USA for a replacement temperature
sensor.
Registering your product
Product registration can be found on the web at www.current-usa.com.
Temperature Controller
specifications/Installation

WWW.CURRENT-USA.COM
6
Current USA, Inc. One-Year Limited Warranty
Current USA, Inc. warrants this product against defects in materials and workmanship for a period of
ONE (1) YEAR from the date of original retail purchase. Light Bulbs carry a 3 month warranty.
Note: Current-USA, Inc. One-Year Limited Warranty does not cover damage caused by the following:
Improper installation, saltwater corrosion, and electrical surges.
Warranty on all Products, including Aquariums, is limited to replacement of the product and does not
cover fish loss, personal injury, property loss or direct, incidental or consequential damage arising to
the use of this product.
If you discover a defect, Current USA, Inc. will, at it’s option, repair or replace the product at no charge
to you, provided you return it during the warranty period. It is required that you present this warranty
card and a copy of the bill of sale as proof of original purchase date, in the event the product needs
repairs, within the warranty period. Please see your dealer for return options. This warranty applies
only to products by or for Current USA, Inc. that can be identified by trade name, or logo affixed to
them. Current-USA, Inc. does not warrant any products that are not Current-USA, Inc. products. This
warranty does not apply if the product has been damaged by accident, abuse, misuse or misapplication
or if the product has been modified without the written permission of Current-USA, Inc.; or if any
Current-USA, Inc. logos have been removed or defaced.
THE WARRANTY AND REMEDIES SET FORTH ABOVE ARE EXCLUSIVE AND IN LIEU OF ALL
OTHERS, WHETHER ORAL OR WRITTEN, EXPRESS OR IMPLIED. Current USA, Inc. SPECIFICALLY
DISCLAIMS ANY AND ALL IMPLIED WARRANTIES, INCLUDING BUT NOT LIMITED TO LOST PROFITS,
DOWNTIME, GOODWILL, DAMAGE TO OR REPLACEMENT OF EQUIPMENT AND PROPERTY, AND
ANY COSTS OF RECOVERING ANIMALS, PLANTS, TANKS OR OTHER AQUARIUM RELATED ITEMS
AND/OR EQUIPMENT. Current USA, Inc. IS NOT RESPONSIBLE FOR SPECIAL, INCIDENTAL, OR
CONSEQUENTIAL DAMAGES RESULTING FROM ANY BREACH OF WARRANTY, OR REPLACEMENT OF
EQUIPMENT OR PROPERTY, OR ANY COSTS OF RECOVERING OR REPRODUCING ANY EQUIPMENT,
ANIMALS OR PLANTS USED OR GROWN WITH Current USA, Inc. PRODUCTS.
Some jurisdictions do not allow the exclusion or limitation of incidental or consequential damages or
exclusions of implied warranties, so the above limitations or exclusions may not apply to you. This
warranty gives you specific legal rights, and you may also have other rights that vary form jurisdiction
to jurisdiction.
