Current COMPASS CELS User manual

WARNING – This product contains chemicals known to the State of California to cause cancer, birth
defects and/or other reproductive harm. Thoroughly wash hands after installing, handling, cleaning,
or otherwise touching this product.
Surface Mount LED Emergency Exit
CELS
IMPORTANT SAFEGUARDS
When using electrical equipment, basic safety precautions should
always be followed including the following:
READ AND FOLLOW ALL SAFETY
INSTRUCTIONS
1. Do not use outdoors.
2. Do not let power supply cords touch hot surfaces.
3. Do not mount near gas or electric heaters.
4. Equipment should be mounted in locations and at heights where it will not readily be subject
to tampering by unauthorized personnel.
5. The use of accessory equipment not authorized by the manufacturer may cause an unsafe
condition.
6. Do not use this equipment for other than its intended purpose.
7. Servicing of this equipment should be performed by qualified service personnel.
8. Test cycling: the Life Safety Code (NFPA 101) requires testing of emergency lighting units once
a month for a minimum of 30 seconds, and once a year for a minimum of 90 minutes.
INSTALLER:
•SEE UNIT LABEL FOR ADDITIONAL MODEL SPECIFICATIONS
•SAVE THESE INSTRUCTIONS FOR USE BY OWNER/OCCUPANT
RECYCLING INFORMATION
All steel, aluminum and thermoplastic parts are recyclable.
NOTICE: Emergency units contain rechargeable batteries which must
be recycled or disposed of properly.
PACKAGE CONTENTS
Part Description Quantity
1 LED Edge-Lit EXIT Sign 1
2 Canopy 1
3 Hardware Bag 1
ELECTRICAL CONNECTIONS
1. Make the proper supply wire connections.
2. If using 120 VAC, connect the black and white wires to the building utility.
3. If using 277 VAC, connect the orange and white wires to the building utility.
4. Cap o unused wire. In all cases, use standard wire nuts in connection to wires.
WIRING DIAGRAM
Hubbell Lighting, Inc.
WARNING – This product contains chemicals known to the State of California to cause cancer, birth
defects and/or other reproductive harm. Thoroughly wash hands after installing, handling, cleaning,
or otherwise touching this product.
Surface Mount LED Emergency Exit
CELS
IMPORTANT SAFEGUARDS
When using electrical equipment, basic safety precautions should
always be followed including the following.
READ AND FOLLOW ALL SAFETY
INSTRUCTIONS
1. Do not use outdoors.
2. Do not let power supply cords touch hot surfaces.
3. Do not mount near gas or electric heaters.
4. Equipment should be mounted in locations and at heights where it will not readily be subject
to tampering by unauthorized personnel.
5. The use of accessory equipment not authorized by the manufacturer may cause an
unsafe condition.
6. Do not use this equipment for other than its intended purpose.
7. Servicing of this equipment should be performed by qualified service personnel.
8. Test cycling: the Life Safety Code (NFPA 101) requires testing of emergency lighting units once a month for a
minimum of 30 seconds, and once a year for a minimum of 90 minutes.
INSTALLER:
•SEE UNIT LABEL FOR ADDITIONAL MODEL SPECIFICATIONS
•SAVE THESE INSTRUCTIONS FOR USE BY OWNER/OCCUPANT
RECYCLING INFORMATION
All steel, aluminum and thermoplastic parts are recyclable.
NOTICE: Emergency units contain rechargeable batteries which
must be recycled or disposed of properly.
Hubbell Lighting, Inc. Life Safety Products • www.dual-lite.com
Copyright© Hubbell Lighting, Inc., All Rights Reserved • Specifications subject to change without notice. • Printed in U.S.A.
COMP0002_INST_SHT 09/12
PACKAGE CONTENTS
Part Description Quantity
1 LED Edge-Lit EXIT Sign 1
2 Canopy 1
3 Hardware Bag 1
ELECTRICAL CONNECTIONS
1. Make the proper supply wire connections.
2. If using 120 VAC, connect the black and white wires to the building utility.
3. If using 277 VAC, connect the orange and white wires to the building utility.
4. Cap off unused wire. In all cases, use standard wire nuts in connection to wires.
WIRING DIAGRAM
COMP0002
Rev 06/08/22
comp_cels_instsht_R01
currentlighting.com/compass
© 2022 HLI Solutions, Inc. All rights reserved. Information and specifications subject to change
without notice. All values are design or typical values when measured under laboratory conditions.
Current Lighting Solutions, LLC
701 Millennium Blvd.
Greenville, SC 29607

INSTALLATION INSTALLATION
1. Attach crossbar to junction box,
using screws if needed
(screws are not provided)
2. Use screwdriver to open front cover
to connect battery connector.
6. Peel o protective film from both sides of EXIT panel
Insert EXIT panel into main body assembly gently. If EXIT panel is for single
face, make sure EXIT letter direction is correct.
3. Feed AC supply wires through canopy
center hole.
4. Assemble canopy onto main
body assembly with (2) PM4*15
screws (supplied) and make wire
connections.
(See ELECTRICAL CONNECTIONS)
5. Use (2) PM4-40 screws (supplied)
tighten canopy to crossbar.
7. Determine direction for
chevron placement.
(See DETERMINE DIRECTION)
8. The unit can be installed on any
surface. You may rotate the EXIT
panel in any angle from 0° to 180°.
Ceiling mounting rotate 90°
become wall mounting.
NOTE: FIRST TURN OFF ELECTRICITY
SURFACE CEILING & WALL MOUNTING
SURFACE END MOUNTING
1. Attach crossbar to junction box,
using screws if needed.
(Screws are not provided)
2. Use screwdriver open front cover
to connect battery connector.
3. Remove the hole plug from
mounting end cap.
4. Pull out all AC supply wires and
feed wires thru the center hole of
mounting end cap and then canopy.
5. Reference 4-7 step in surface
ceiling and wall mounting above
for surface end mounting.
6. The unit can be installed on any
surface, you may rotate the EXIT
panel in any angle from 0° to 180°.
ASSEMBLY DRAWING
DETERMINE DIRECTIONS
1. If indicator chevron is required,
maintain chevron and remove
locator template.
2. If indicator chevron is not required,
remove both the chevron and
locator template.
