Currys Essentials CUL50W12 User manual

6 fue£011 MN6--t- ~ Mo~cL- No CUL5ow l L.
curi)tS essentials
SOCM UNDERCOUNTER LARDER
INSTRUCTION MANUAL
CULSOW12

Contents
Unpacking....................................................................................................................................4
Installation ...................................................................................................................................5
Location ..................................................................................................................................................................... 5
Reversing
the DoorSwing ................................................................................................................................... 5
Levelling
the Unit ................................................................................................................................................... 7
Cleaning Before
Use· .............................................................................................................................................. 7
Before Using Your
Unit .......................................................................................................................................... 7
InteriorAccessories
................................................................................................................................................ 7
Product Overview ........................................................................................................................8
Operation .....................................................................................................................................9
Switching On Your Unit ........................................................................................................................................ 9
Adjusting
the Temperature ................................................................................................................................. 9
Noises Inside
the Unit! .......................................................................................................................................... 9
Shopping
for Chilled Foods .............................................................................................................................. 10
Tips
for Keeping Food in the Unit ................................................................................................................... 10
Cleaning ..................................................................................................................................... 11
Defrosting ............................................................................................................................................................... 11
Cleaning the Interiorand the Exterior of the Unit .................................................................................... 11
CleaningTips .......................................................................................................................................................... 11
Maintenance .............................................................................................................................. 12
Changing the Internal Light ............................................................................................................................. 12
Care When Handling I MovingYour Unit ..................................................................................................... 12
Servicing .................................................................................................................................................................. 12
Switching Off for Long Periods ofTime ........................................................................................................ 12
Disposal...................................................................................................................................... 12
Specifications.............................................................................................................................13
SafetyWarnings.........................................................................................................................
14

Thank you for purchasing your newCurrys Essentials Larder.
We recommend that you spend some time reading this instruction manual
in order
that you fully understand all the operational features it offers.
Read all the safety instructions carefully before use and keep this
instruction manual
for future reference.
Unpacking
Remove all packaging from the unit. Retain the packaging. If you dispose of it please do so
according to local regulations.
The following items are included:
The Main Unit
Adjustable
Glass Shelfx 2
P.N.:
1098935
Upper Door Shelfx 2
P.N.:
1110359
\tZJ
?·~;,.
:.. . :;~
·' ·-
Salad Bin
P.N.: 1096010 _
Salad
Bin Cover
P.N.: 1
098933
Lower Door Shelf
P.N.:
1110358
currys essentials
Instruction Manual
P.N.: DSGCUL50W12-002
If items are missing or damaged please contact Partmaster (UK only).
Tel: [phone] for assistance.
4

INSTALLATION
Location
When selecting a position for your unit you should make sure the floor is flat and firm, and
the room is well ventilated with an average room temperature of between 16°C and 38°C.
Avoid locating your unit near a heat source, e.g. cooker, boiler or radiator. Also avoid direct
sunlight
as it may increase the electrical consumption. Extreme cold ambient temperatures
may also cause
the unit not to perform properly.This unit is not designed for use in a garage
or
outdoor installation. Do not drape the unit with any covering.
When installing
the unit, ensure that 40 mm of free space is left at both sides, 20 mm at
the rear and 40 mm at the top of the unit.The door can be opened to the right or the left,
depending on
what better suits the location. Please ensure there is adequate space for the
door to fully open.
~~==================================~
• If you want to have the door swing reversed, we recommend that you contact a
qualified technician.
You should only try to reverse the door yourself if you believe
that you are qualified to do so.
• All parts removed must be saved to do the reinstallation of the door. You should
rest
the unit on something solid so that it will not slip during the door change
process. Do
not lay the unit flat as this may damage the coolant system. Ensure the
unit is unplugged and empty.
Reversing the Door Swing
Tools required: Phillips style screwdriver I Flat bladed screwdriver I Hexagonal spanner
• Ensure the unit is unplugged and empty.
• Adjust
the two levelling feet to their highest position.
•
To take the door off it is necessary to tilt the unit backwards. You should rest the
unit on something solid so that it will not slip during the door reversing process.
• All parts removed must be saved
to do the reinstallation of the door.
• Do
not lay the unit flat as this may damage the coolant system.
•
We recommend that 2 people handle the unit during assembly.
1. Tilt the unit slightly towards the rear and
prop
it securely. Two people are required
to tilt the unit during the door reversal
process.
5

•i
~· INSTALLATION
~:
!
2. Remove the upper hinge cap (1).
3. Remove
the two upper screws and hinge bracket (2) from the unit top.
4.
Carefully lift the door up and remove it from the unit. Place door on a padded surface to
prevent from scratching.
5.
Remove the plug (3) and shaft sleeve (6) from the door and reattach them to the
corresponding position on the opposite side of the door. Press the both firmly into the
hole.
6. Remove the two lower screws, hinge bracket and levelling leg (4) from the unit bottom.
7. Remove the screw-type levelling front leg (5) from the unit bottom and transfer it to the
corresponding position on the opposite side of the unit bottom.
8. Reattach the two lower screws, hinge bracket and levelling front leg (4) to the opposite
side of the unit bottom. Secure.
9. Carefully set the door back into place, sliding it onto the bottom hinge.
10. Securely reattach
the two upper screws and hinge bracket (2) to the unit top on the
opposite the side from which it was removed. Ensure that the hinge pin is properly
positioned in the bushing (hole) at the top of unit door.
11. Reattach
the hinge cap (1) over the top hinge bracket.
5~
12. With the door closed, check that the
door is aligned horizontally and vertically
and
that the seals are closed on all sides
before finally
tightening the bottom
hinge. Re-adjust the levelling feet as
needed.
~1
~--@----;
' I '
'i '
' '
:~:-2
I Q Q I
[ __ -
0
- __ o _j
Upper hinge cap
2
Upper screws
&
upper hinge
bracket
3 Plug
4 Lower screws,
levelling
front leg
&
lower hinge
bracket
5 Levelling
front leg
6 Shaft Sleeve
&~~~~~~
*All images are for reference
only; please refer
to your
individual unit for actual item.

INSTALLATION
Levelling the Unit
To do this adjust the two levelling feet at the
front of the unit.
If the unit is not level, the door and magnetic
seal alignments will not be covered properly.
Cleaning Before Use
BB
Wipe the inside of the unit with a weak solution of bicarbonate soda. Then rinse with warm
water using a
'wrung-out' sponge or cloth. Wash the shelves and salad bin in warm soapy
water and
dry completely before replacing in the unit. Clean the exterior of the unit with a
damp cloth.
If you require more information refer to the Cleaning section.
• Before Plugging in
YOU MUST
Check
that you have a socket which is compatible with the plug supplied with the
unit.
• Before Turning On!
Do
not turn on until two hours after moving the unit.The coolant fluid needs time
to settle.
Before Using Your Unit
Before placing any food in your unit, turn it on and wait for 24 hours, to make sure it is
li working properly and to allow it time to fall to the correct temperature. Your unit should not
be overfilled.
Interior Accessories
Various glass or plastic storage shelves are included with your appliance- different models
have different combinations.
You should always slide one of the full size glass storage shelves into the lowest set of
guides, above the fruit and vegetable containers, and keep it in this position. To do this, pull
the storage shelfforward until it can be swivelled upwards or downwards and removed.
Please
do the same in reverse to insert the shelf at a different height.
In order
to make the most of the volume of the fresh food storage compartment, the
user can removed one or more shelves, drawers, out of the appliance, according to
your daily use.
7

Product Overview
Glass Shelves
8
.--------- Internal Light and
Thermostat Control Dial
Levelling Feet
Door
Shelves

Operation
Switching On Your Unit
1. Before connecting the unit to the mains supply
make sure
that the thermostat control dial is set
at position 0.This is located on the right side of
the cabinet. Connect the mains cable to the mains
socket.
2. Adjust the thermostat control dial to the desired
position, bear in
mind that the higher the number,
the lower the temperature. Position 2 or 3 or 4
recommended setting when operating
at normal
room
temperature (between 16°C and 38°C).
3. The unit may not operate at the correct
temperature ifit is in a particularly hot or a
particularly cold room,
or if you open the door
often.
4. To ensure that the unit is cool enough to sufficiently
chill
your food, wait 24 hours before filling it with
food.
5. If you are concerned that your unit is not being kept
cold enough and wish to check the temperature,
you will need a special fridge/freezer thermometer.
These are available
from most supermarkets and
hardware shops.
Place
the thermometer in the centre of the unit,
where
it can be read easily. Leave overnight, the
temperature in the unit should be soc or lower.
Adjusting the Temperature
The internal temperature of the unit is controlled by a thermostat.The recommended position
is between 1 to 4 for colder working environments (i.e. during winter) and between 5 to 6 for
hotter environments. Please adjustaccording to the environment.
Noises Inside the Unit!
You may notice that your unit makes some unusual noises. Most of these are perfectly normal,
but you should be aware of them!
These noises are caused by the circulation of the refrigerant liquid in the cooling system. It has
become more pronounced since the introduction of CFC free gases. This is not a fault and will
not affect the performance of your unit.This is the compressor motor working, as it pumps the
refrigerant around the system.
9

,,
Shopping for Chilled Foods
• Take a quick look at the chilled food package and make sure it is in perfect condition.
•
Try to keep chilled food together whilst shopping and on the journey home as this will help
to keep the food cold.
Don't buy chilled food unless you can chill
it straight away. Specially insulated bags can be
bought from most supermarkets and hardware shops.These bags can keep chilled food cold
for longer while transporting.
Food
that has been left in a car or at room temperature for a prolonged period of time could
raise
the food temperature to a dangerous level, which allows harmful bacteria to grow.
Always unpack
and place chilled food in the unit before storing dry food.
Tips for Keeping Food in the Unit
Cooked meats/fishes should always be stored on a shelf above raw meats/fishes to avoid
bacterial transfer. Keep raw meats/fishes
in a container which is large enough to collect
juices
and cover it properly. Place the container on the lowest shelf.
Leave
space around yourfood, to allow air to circulate inside the unit. Ensure all parts of the
unit are kept cool.
To prevent transfer offlavours and drying out, pack or cover the food separately. Fruit and
vegetables do not need to be wrapped.
Always let pre-cooked food cool down before you
put in the unit. This will help to maintain
the internal temperature of the unit.
•
To prevent cold air escaping from the unit, try to limit the number of times you open the
door. We recommend that you only open the door when you need to put food in or take
food out.
10

Cleaning
Defrosting
Frost may accumulate on the inner rear surface of the
appliance which will automatically defrost during the off
cycle of the compressor.
Water
is channelled via the drain hole to the collection tray
above
the compressor where it will evaporate.
Please ensure
the drain hole is checked and cleaned on a
regular basis
so water can exit the storage compartment.
Cleaning the Interiorand the Exterior ofthe Unit
Remove all the shelves and the salad bin. To remove the salad bin first remove the lower
door shelf.
Wipe
the inside of the unit with a weak solution of bicarbonate soda and then rinse with
warm water using a 'wrung-out' sponge or cloth. Wipe completely dry before replacing the
shelves and salad bin.
Use a damp cloth to clean the exterior, and then wipe with a standard furniture polish. Make
sure
that the door is closed to avoid the polish getting on the magnetic door seal or inside
the unit.
The grille
of the condenser at the back of the unit and the adjacent components can be
vacuumed using a
soft brush attachment.
Cleaning Tips
Condensation may appear on the outside of the unit.This may be due to a change in room
temperature. Wipe
off any moisture residue. If the problem continues, please contact a qualified
technician
for assistance.
11

Maintenance
Changing the Internal Light
1. Before carrying out the bulb replacement always
adjust
the thermostat control dial to Position 0, then
disconnect
the mains supply.
2. To change the light bulb (220-240, max. 15W), undo the
screw.
3. Press the light bulb cover as shown and slide it
backwards.
4. Change the defective light bulb.
5. Refit the light bulb cover and the screw.
6. Put the refrigerator back into operation.
Care When Handling I Moving Your Unit
Hold the unit around its sides or base when moving it. Under no circumstances should it be
lifted
by holding the edges of the top surface.
Servicing
The unit should be serviced by an authorised engineer and only genuine spare parts should be
used. Under no circumstances should you attempt to repair the unit yourself. Repairs carried
out by inexperienced persons may cause injury or serious malfunction. Contact a qualified
technician.
Switching Offfor Long Periods ofTime
When the unit is not in use for a long period of time, disconnect it from the mains supply, empty
all food and clean the appliance, leaving the door ajar to prevent unpleasant smells.
Disposal
Old units still have some residual value. An environmentally friendly method of disposal will
ensure
that valuable raw materials can be recovered and used again.The refrigerant used in
your unit and insulation materials require special disposal procedures. Ensure that none of the
pipes on the back of the unit are damaged prior to disposal.
Up
to date information concerning options of disposing of your old unit and packaging from
the new one can be obtained from your local council office.
When disposing
of an old unit break off any old locks or latches and remove the door as a
safeguard.
12

Specifications
CULSOW12
102L
0- soc, average:.,; 4°C
0.326kWh I 24h
Category 1 (Refrigerator)
A+
N/A
Auto Defrost
N/ST
43dB
220V-240V
O.SA
494 x 494 x 839 mm
Features and specifications are subject to change without prior notice.
13

SafetyWarnings
For your continued safety and to reduce the risk of injury or electric shock, please follow all the
safety precautions listed below.
Read all instructions carefully before using the unit and keep them for future reference.
Retain
the manual. If you pass the unit onto a third party, make sure to include this manual.
Keep ventilation openings in
the appliance enclosure clear of obstructions.
Do
not use mechanical devices or other means to accelerate the defrosting process, other
than those recommended by
the manufacturer.
Do
not use electrical appliances inside the food storage compartments of the unit, unless
they are
of the type recommended by the manufacturer.
If the mains cable is damaged, it must be replaced by the manufacturer, its service agent or a
qualified technician in order
to avoid a hazard.
Choose a location
for your unit away from heat sources such as radiators or fires as
refrigerant and vesicant are burnable.
Young children should be supervised
to ensure that they do not play with the unit.
Do
not damage the refrigerant circuit (applicable only for appliances with refrigeration
circuits which are accessible
to the user).
o The unit must be maneuvered by a minimum of 2 persons.
o This unit is not intended for use by persons (including children) with reduced sensory or
mental capabilities, or lack of experience and knowledge unless they have been given
supervision or instructions concerning
the use of the unit by a person responsible for their
safety.
If your unit is fitted with a lock to prevent children being trapped inside, keep the key out of
reach and not in the vicinity of the unit.
Do
not store volatile or flammable substances in the unit.
WARNING
IT IS HAZARDOUS FOR ANYONE OTHER THAN AUTHORISED SERVICE PERSONNEL TO
CARRY OUT SERVICING OF REPAIRS WHICH INVOLVE THE REMOVAL OF COVERS.
A TO AVOID THE RISK OF AN ELECTRICAL SHOCK DO NOT ATIEMPT REPAIRS YOURSELF.
14

Installation site
In a ventilated room.
Protected from direct sunlight.
Not situated near
to a heatsource
(radiator, oven).
Where
the ideal ambient room
temperature is approx 20°C.
Only open the doors when
necessary
and for as short a time
as possible.
Store food
ih an organised way.
Allow hot food and drinks to cool
down before placing.
them in the ·.
unit.
co ideas
15

NOTE: If you require a replacement for any of the items listed below, please quote their
corresponding part numbers:
Adjustable Glass Shelf 1098935
Salad Bin Cover 1098933
Salad Bin 1096010
Upper Door Shelf 1110359
Lower
Door Shelf 1110358
Visit Partmaster.co.uk
today for the easiest way to
buy electrical spares and accessories. With over
[
Partmaster )
. _______ co.uk . 1
million spares and accessories available we can
deliver
direct to your door the very next day. Visit www.partmaster.co.uk or call
0844 800 3456
(UK customers only). Calls charged at National Rate.
This symbol on
the product or in the instructions means that
your electrical and electronic equipment should be disposed at
the end of its life separately from your household waste. There
are separate collection systems
for recycling in the EU.
For more information, please contact the local authority or
your retailer where you purchased the product.
DSG Retail Ltd • Maylands Avenue· Hemel Hempstead
Herts •
HP2 7TG • England
(P.N.: DSGCUL50W12-002)
