Currys ESSENTIALS CIL60W14 User manual

INSTRUCTION MANUAL
BUILT-IN 60CM WHITE UNDER-
COUNTER LARDER
CIL60W14
CIL60W14_IB_RC_151204_grace.indd 1 4/12/15 1:59 pm

CIL60W14_IB_RC_151204_grace.indd 2 4/12/15 1:59 pm

Contents
Safety Warnings........................................................................................................................... 4
Unpacking.................................................................................................................................... 6
Location ..................................................................................................................................................................... 7
Levelling the Unit ................................................................................................................................................... 7
Free Space Requirements ................................................................................................................................... 7
Reversing the Door Swing................................................................................................................................... 8
Height Regulation................................................................................................................................................10
Installation of the Unit Under the Worktop ................................................................................................10
Fastening the Unit Under the Worktop ........................................................................................................11
Mounting the Kitchen Cabinet Door.............................................................................................................11
Cleaning Before Use ............................................................................................................................................13
Before Using Your Unit........................................................................................................................................13
Product Overview...................................................................................................................... 14
Main Unit.................................................................................................................................................................14
Operation ................................................................................................................................... 15
Switching On Your Unit ......................................................................................................................................15
Adjusting the Temperature...............................................................................................................................15
Noises Inside the Unit!........................................................................................................................................15
Tips for Keeping Food in the Unit...................................................................................................................16
Cleaning ..................................................................................................................................... 17
Defrosting ...............................................................................................................................................................17
Cleaning the Interior and the Exterior of the Unit....................................................................................17
Maintenance .............................................................................................................................. 18
Changing the Internal Light .............................................................................................................................18
Care When Handling / Moving Your Unit.....................................................................................................18
Servicing..................................................................................................................................................................18
Switching O for Long Periods of Time........................................................................................................18
Condensation.........................................................................................................................................................18
Disposal...................................................................................................................................... 18
Specications............................................................................................................................. 19
CIL60W14_IB_RC_151204_grace.indd 3 4/12/15 1:59 pm

4
Safety Warnings
For your continued safety and to reduce the risk of injury or electric shock,
please follow all the safety precautions listed below.
• Read all instructions carefully before using the unit and keep them for
future reference.
• Retain the manual. If you pass the unit onto a third party, make sure to
include this manual.
• This appliance is intended for indoor household use and similar
applications such as:
- farm houses and by clients in hotels, motels and other residential type
environment;
- bed and breakfast type environment;
- catering and similar non-retail applications.
• Ensure that the plug is easily accessible to enable disconnection from
the mains supply.
• If the mains cable is damaged, it must be replaced by the manufacturer,
its service agent or a qualied technician in order to avoid a hazard.
• Choose a location for your unit away from heat sources such as radiators
or res as refrigerant and vesicant are burnable.
• The unit must be manoeuvred by a minimum of 2 persons.
• This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been given supervision
or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall not be made by
children without supervision.
• Children should be supervised to ensure that they do not play with the
unit.
• If your unit is tted with a lock to prevent children being trapped inside,
keep the key out of reach and not in the vicinity of the unit.
• Do not store explosive substances such as aerosol cans with a
ammable propellant in this appliance.
CIL60W14_IB_RC_151204_grace.indd 4 4/12/15 1:59 pm

5
• Do not store bottles or glass containers in the freezer compartment.
Contents can expand when frozen (zzy drinks) which may break the
bottle and damage your freezer compartment. (If applicable)
WARNING
• Keep ventilation openings in the unit enclosure or in the built-in
structure clear of obstructions.
• Do not use mechanical devices or other means to accelerate
the defrosting process, other than those recommended by the
manufacturer.
• Do not use electrical appliances inside the food storage
compartments of the unit, unless they are of the type
recommended by the manufacturer.
• Do not damage the refrigerant circuit (The refrigerant is a very
environmental-friendly gas but is also combustible. Take care when
transporting or moving the unit to ensure that the refrigeration
circuit is not damaged. In the event of damage avoid naked ames
or ignition sources and ventilate the room in which the unit is
placed for a few minutes.)
WARNING
IT IS HAZARDOUS FOR ANYONE OTHER THAN AUTHORISED
SERVICE PERSONNEL TO CARRY OUT SERVICING OF REPAIRS WHICH
INVOLVE THE REMOVAL OF COVERS.
TO AVOID THE RISK OF AN ELECTRICAL SHOCK DO NOT ATTEMPT
REPAIRS YOURSELF.
CIL60W14_IB_RC_151204_grace.indd 5 4/12/15 1:59 pm

6
Upper Fridge Door
Balcony
Upper Fridge Door
Balcony Cover
Unpacking
Remove all items from the packaging. Retain the packaging. If you dispose of it please do so
according to local regulations.
The following items are included:
Thank you for purchasing your new Currys Essentials Larder.
You must spend some time reading this instruction manual in order that
you fully understand all the operational features it offers.
Read all the safety instructions carefully before use and keep this
instruction manual for future reference.
If items are missing or damaged please contact Partmaster (UK only).
Tel: [phone] for assistance.
Shelf x 2 Salad Bin Cover Salad BinMain Unit
Upper Connecting
Block x 2
Lower Connecting
Block x 2
Egg Tray x 2 ST4.2 x 13 Screw x 7
Double Threaded Bolt x 2Bolt x 2 Domed Headed
Nut x 2
Instruction / Installation
Manual x 1
Instruction
Manual
Lower Fridge Door Balcony Bottom Wire Rack
CIL60W14_IB_RC_151204_grace.indd 6 4/12/15 1:59 pm

7
INSTALLATION
Location
When selecting a position for your unit you should make sure the floor is flat and firm, and
the room is well ventilated with an average room temperature of between 16°C and 38°C.
Avoid locating your unit near a heat source, e.g. cooker, boiler or radiator. Also avoid direct
sunlight as it may increase the electrical consumption. Extreme cold ambient temperatures
may also cause the unit not to perform properly. This unit is not designed for use in a garage
or outdoor installation. Do not drape the unit with any covering.
Levelling the Unit
To do this adjust the two levelling feet at the front of the unit.
If the unit is not level, the doors and magnetic seal alignments
will not be covered properly.
Free Space Requirements
When installing the unit, ensure that 25 mm
of free space is left at both sides, 50 mm at
the rear of the unit and 25 mm at the top
of the unit. The door can be opened to the
right or the left, depending on which best
suits the location.
Please ensure there is more than twice the
width and depth distance space of the unit
to fully open the door to a maximum angle
of 160°.
Max. 160°
Y mm
X mm
CIL60W14_IB_RC_151204_grace.indd 7 4/12/15 1:59 pm

8
INSTALLATION
Reversing the Door Swing
Tools required: Philips style screwdriver / Flat bladed screwdriver / Hexagonal spanner
• Ensure the unit is unplugged and empty.
• To take the door off it is necessary to tilt the unit backwards. You should rest the
unit on something solid, e.g. a chair just below the top panel.
• All parts removed must be saved to do the reinstallation of the door.
• Do not lay the unit flat as this may damage the coolant system.
• We recommend that 2 people handle the unit during assembly.
• If you want to have the door swing reversed, we recommend that you contact a
qualified technician. You should only try to reverse the door yourself if you believe
that you are qualified to do so.
1. Remove the 4 blanking plates from the
outside of the fridge door.
2. With the door closed, remove the screws
on the outside of the hinges. Start with
the top hinge.
3. Open the hinges away from the door.
CIL60W14_IB_RC_151204_grace.indd 8 4/12/15 1:59 pm

9
INSTALLATION
4. Remove the door while supporting the
bottom of the door. Be careful with the
hinges.
5. With the hinges open, undo the screws
holding them to the cabinet. Be careful
with the hinges, use a long shafted
screwdriver if you have one.
6. Remove the 4 blanking plates from the
fridge cabinet.
7. Turn the hinges over and place them
diagonally on the opposite corner of
the cabinet. Screw them back in place.
Replace all the blanking plates on the
opposite side of both the cabinet and the
fridge door.
CIL60W14_IB_RC_151204_grace.indd 9 4/12/15 1:59 pm

10
INSTALLATION
8. With the door closed, check that the
door is aligned horizontally and vertically
and that the seals are closed on all sides
before finally tightening the bottom
hinge. Re-adjust the levelling feet as
needed.
Height Regulation
Installation of the Unit Under the Worktop
825 = 100 - 170
25 - 80
825 - 870
min 580
600
870 = 180 - 250
