Curtis Kubota ZD1211 Operating instructions

1 of 30
INSTALLATION & OWNER’S MANUAL
Kubota ZD1211
(p/n: 1KUBZD1211PR)
Cab with A/C
(fits both 60” and 72” mowers.
Does not fit with bagger system)
Rev. E, 11/10/2021
p/n: IM-1KUBZD1211PR
While this cab kit was designed to fit on the vehicle listed above, manufacturing tolerances and vehicle
assembly may affect cab fitment. It is the responsibility of the cab installer to check all vehicle pedals and
levers for full functionality and, as required, adjust the cab fitment to prevent any interference of the cab
components with the travel of pedals or levers.
(*=Not including accessories)
Available Options:
1. Side View Mirrors (P/N: 9PM5)
2. Switch Panel (P/N: 1KUBZD1211CK) (req’d for following 2 items)
3. Front LED Work Lights (P/N: 1KUBZD1211LK)
4. Front Wiper/Washer Kit (P/N: 1KUBZD1211WK)
Approximate Installation Time *
Experienced Dealer Technician – 4 Hours
Average Dealer Technician – 6 Hours
Do-It-Yourself – 6-8 Hours
Approximate Product Specifications
Floorboard to Roof Height: 60 inches
Weight: 240 lbs.
Cab Width: 54 inches
The contents of this envelope are the property of the owner. Leave with the owner when installation is complete.
Register your new product quickly online at
Curtiscab.com/product-registration/
Download a digital copy of your installation
instructions online at Curtiscab.com/literature/
Curtis encourages all customers to register their
Curtis products. However, failure to do so will not
diminish right to warranty. Curtis Industries does not
sell or share your information with anyone else.
Curtis strives to continuously improve our products,
technical documentation, etc. Therefore, the
installation manual for this product may have been
updated after your product was packaged. The
latest revision of the installation manual can always
be found at the website above.
Premium Cab Shown with Options

2 of 30
TABLE OF CONTENTS
WARNINGS, TIPS, & REQUIRED TOOLS.......................................................3
CAB INSTALLATION ...................................................................................4-21
CAB FEATURES & OPERATION ...................................................................22
CARE AND MAINTENANCE ..........................................................................23
SERVICE PARTS .....................................................................................24-29
BOLT TORQUE SPECIFICATIONS................................................................30

3 of 30
Curtis cabs feature an assembly of parts designed for your vehicle which require adjustment
and alignment of components to accommodate vehicle variations and provide proper weather
protection. For accurate installation, proper operation, and years of satisfaction, please read
and understand the installation and owner’s manual fully prior to installing the cab.
From all of us at Curtis, we thank you for choosing our product.
HELPFUL HINTS:
•Refer to parts diagram found in the service parts section of this manual to help identify parts
during the assembly process.
•To assist with the cab installation, leave all fasteners loose for later adjustment unless
otherwise specified.
•Read and understand all instructions before beginning.
•Apply a silicone sealant to seal any minor gaps that may occur due to vehicle variations.
•Use caution to avoid damaging the factory installed threaded inserts or weld nuts. Begin the
thread engagement by hand to avoid or correct potential cross threading.
•Make sure the areas where the supplied self-adhesive hook Velcro will be applied are clean
and dry and at room temperature for best adhesion.
driver and passenger.
Curtis accessory weights are listed in product
add additional weight to the base vehicle. All
Curtis Cabs, blades and general accessories
ADDED
WEIGHT
brochures. Deduct the accessory's total weight
from the vehicle's rated capacity and never
exceed the vehicle's rated capacity including
Exposure to Carbon Monoxide
can Cause illness, serious injury or
death. Never operate vehicle if suspicious of Carbon Monox-
ide. Inspect exhaust system for leaks monthly. Leaks can
result from loose connections, corrosion, cracks or other
damage to the exhaust manifold. If leaks are found, repair or
replace exhaust system. Do not use vehicle until repair or
replacement is complete.
•Set of Standard and Metric Sockets (3/8” + 1/2” Drive)
•3/8” + 1/2” Drive Ratchets and Long Drive Extension
•Set of Standard and Metric Open-End Wrenches
•Set of Standard and Metric Allen Wrenches
•#1, #2, and #3 Phillips Head Screwdrivers
•Torque Wrench (1/2” Drive)
•Rubber Mallet or Plastic Dead Blow Hammer
•Bungee Cord or Twine
•Hoisting Strap
•Drill/Driver
•9/32” Drill Bit
•#2 and #3 Phillips Head Bit
•Utility Knife
•Pair of Scissors
•Shears
•Grease
•Black Silicone Sealant
•Steel Straight Edge
WARNINGS, TIPS, & REQUIRED TOOLS
TOOLS REQUIRED:
GENERAL INFORMATION BEFORE YOU START
California Health and Safety Proposition 65 Warning: This product may contain chemi-
cals known to the state of California to cause cancer and birth defects or other reproductive harm.

CAB INSTALLATION
4 of 30
Step 1: (Vehicle Prep)
1.1 Park vehicle in a location accessible by an
overhead hoist.
1.2 Disconnect the negative battery terminal.
1.3 Remove the bolt from the battery clamp and
replace with a longer one from the supplied
hardware kit and re-use the nut, but do not re-
connect the battery.
Hardware Used Qty
5/16x1-1/4 Square Head Bolt 1
1.4 Remove the plastic cover around both the left and
right control sticks. (Note: the nut on the lower
screw can be loosened slightly and the panel can
then be removed. It does not need to be fully
removed from the screw.)
1.5 Install the supplied bulb rubber to the bottom
flange of the covers. The rubber should be joined
where shown.
1.6 Re-install only the left plastic cover ensuring that
the bulb on the rubber is not causing interference
with the controls or switch. The right cover will be
re-installed in a later step.
1.7 Disconnect the wires from the stud on the starter
as well as the wire plugged into the connector on
the starter.
1.8 Remove and discard three bolts from the left side
of the engine as shown.
Fig. 1.5 (Install Rubber (Left shown))
Seam
Fig. 1.3 (Replace Negative Battery Bolt)
Replace
Fig. 1.4 (Remove Covers)
Fig. 1.7 (Remove Components)
Remove
Remove
Disconnect
Remove
Loosen

CAB INSTALLATION
5 of 30
Step 2: (Dynamo Installation)
2.1 Remove and save the OEM dynamo. Discard the
mounting hardware.
2.2 Remove and discard the nut and washers from the
OEM dynamo shaft.
2.3 Remove and discard the shaft from the OEM
dynamo, but keep the dynamo together when
removing to ensure spacer stays in its proper
location. If the rotor is separated from the stator
and the spacer comes loose, re-install with the
smooth convex side of spacer inwards against the
bearing.
2.4 Install the OEM dynamo onto the shaft of the
secondary dynamo provided in the kit. A rubber or
plastic mallet may be required to tap the shaft
through the bearings. Secure with the following
hardware and torque to 39.2 to 44.1 Nm (28.9 to
32.5 lbf-ft). Ensure that the flat washer is centered
over the shaft when tightening.
Hardware Used Qty
M12x24 Steel Flat Washer 1
M10x18 Split Lock Washer 1
M10x1.25 Nut 1
2.5 Position the supplied steel spacer and the thickest
shim washer from the hardware kit that will fit
between the top dynamo ears. Rotating the
dynamo shaft may allow a thicker shim to fit.
The fastening bolt should pass through the
smooth hole of the secondary dynamo, through
the spacer, shim, and then thread into the OEM
dynamo ear. Tighten fully and back off 1/2 turn.
Note: There are two of each thickness shim
washers in the kit. The exact same thickness
shim must be used between the lower pivot mount
and secondary dynamo in step 2.7.
Hardware Used Qty
Steel Spacer .75 OD x 1.145 L 1
M8x1.25x80mm Hex Head Bolt 1
M8x16 Steel Flat Washer 1
13/16 x 11/32 SS Shim x
.015”, .030”, .048” or .062” Thick 1
Fig. 2.2 (Remove OEM Dynamo Shaft)
Remove
Fig. 2.1 (Remove Dynamo)
Fig. 2.5 (Install Spacer)
Fig. 2.4 (Install OEM Dynamo onto Shaft)
Install +
Torque
OEM
Dynamo
Remove
OEM
Dynamo
Spacer
Spacer
Shim

CAB INSTALLATION
6 of 30
2.6 Hang the double dynamo setup onto the vehicle
with the OEM dynamo back into its original
location with the threads on the previously
installed bolt protruding through the upper dynamo
adjustment slot. Install a nut onto the end of the
bolt, but do not tighten.
Hardware Used Qty
M8x1.25 Flange Locknut 1
2.7 Install the same thickness shim washer as was
used on the upper ears (step 2.5) between the
lower pivot mount and secondary dynamo. The
dynamo shaft may need to be rotated to allow the
shim to fit.
Install the lower pivot bolt from the front side of the
OEM dynamo. With a lock washer and then a flat
washer under the head of the bolt, pass through
the smooth hole in the OEM dynamo, through the
ear on the engine, through the appropriate
thickness stainless steel shim washer, and thread
into the secondary dynamo ear. Tighten the bolt
and then back off 1/2 turn.
Hardware Used Qty
M8x1.25x65mm Hex Head Bolt 1
M8x16 Steel Flat Washer 1
M8x14 Split Lock Washer 1
13/16 x 11/32 SS Shim x
.015”, .030”, .048” or .062” Thick 1
2.8 Tighten the upper dynamo bolt only, at this time.
Do not tighten the upper dynamo nut.
2.9 Re-install the OEM belt onto the OEM dynamo
and tension. Tighten nut on the upper dynamo
bolt first then the lower pivot bolt. Note: hold the
head of the upper bolt while tightening the nut.
Fig. 2.6 (Hang Dynamo’s, Install Locknut)
Fig. 2.7 (Install Pivot Bolt and Washer)
Fig. 2.8 (Tighten Upper Bolt)
Stainless
Shim
Locknut
Tighten
Upper Bolt
Fig. 2.9 (Re-Install Belt)
Tighten
Nut
Tighten
Bolt
Hold Bolt
Head

CAB INSTALLATION
7 of 30
Step 3: (Install ROPS Mounts)
3.1 Remove the left and right hand tension screws
and clips on the ROPS and discard.
3.2 Remove the ROPS pin and bolt from the left side
and discard. Leave the right side installed at this
time.
3.3 Remove the upper bolt on the cross hose
protector as shown and discard.
3.4 Install the left ROPS mount using the following
hardware. The large bolt in the pivot hole should
be tightened just enough so that the ROPS can
still tilt without damaging the paint. The large bolt
in the hole where the pin was removed should be
installed through the bracket, but no nut installed
at this time. Tighten the smaller M8 bolt at this
time.
Hardware Used Qty
M16x2x80mm Hex Head Bolt 2
M16x30 Steel Flat Washer 3
M16x2 Locknut 1
M8x1.25x30mm Flange Bolt 1
3.5 Repeat steps 3.2, 3.3, and 3.4 for the right side.
3.6 Remove the lower M16 bolts from the previous
steps and tilt the ROPS back and re-use the bolts
to pin in the tilted position. Be careful not to
damage the engine hood if it is in the open
position. The nuts on the lower bolts will be
installed in a later step.
Fig. 3.6 (Tilt the ROPS)
Fig. 3.1 (Remove hand screws and ROPS Bolt)
Fig. 3.3 (Remove upper bolt)
Fig. 3.4 (Install Left ROPS Mount)
Remove
Remove
Remove
Bolt Only ROPS
Mount

CAB INSTALLATION
8 of 30
Step 4: (Vehicle Prep)
4.1 Remove and discard the four floorboard bolts
shown in Figure 4.1. If the mower is a 60”,
remove two additional bolts in the location shown.
4.2 Cut the rubber tabs on the floormat at the bolt
locations as shown so that the hole is clearly
accessible.
4.3 Remove the pine tree clips from the floormat at
the 12 locations shown.
4.4 If installing on a 60” mower, remove and save the
tilting front cover at the front of the machine.
4.5 Install the pedal seal panel on top of the floormat
as shown. Secure to the floorpan using the
following hardware. The floorpan may need to be
lifted slightly in the front on a 60” mower to access
the center screw.
Hardware Used Qty
#10-32x3/4” Phillips Head Screw 6
#10-32 Flange Nut 6
Fig. 4.5 (Install Sealing Brushes)
Fig. 4.1 (Remove Bolts)
Fig. 4.2 (Cut Floormat)
Fig. 4.3 (Remove Pine Tree Clips)
60” Only
Cut Tabs

CAB INSTALLATION
9 of 30
4.6 Install self-adhesive seal around the edge of the
floorpan as shown and cut to length. Refer to
Figure 4.6a for 60” and 4.6b for 72”.
Note: placement on the 72” machine. Seal should
follow along the white line shown.
4.7 Insert spacer bushings into the depressions where
the floorboard bolts were removed. (72” uses 4
bushings, 60” uses 6 bushings/spacers)
Hardware Used Qty
1/2” Long Spacer 4 or 6
4.8 Remove and discard the two screws securing the
voltage regulator to the frame.
4.9 Install the supplied secondary voltage regulator in
front of the OEM regulator with the following
hardware.
Hardware Used Qty
M6x1.0x70mm Hex Head Bolt 2
M6x12 Steel Flat Washer 2
1.25” Long Aluminum Spacer 2
Fig. 4.6a (Seal location on 60”)
Fig. 4.6b (Seal location on 72”)
Fig. 4.7 (Install Spacers)
Spacers
60” Only
Fig. 4.9 (Install Secondary Regulator)
Secondary
Regulator

CAB INSTALLATION
10 of 30
4.10 Flip the seat forward and install the supplied
adhesive Velcro as shown. Be sure to wipe down
the surfaces where the Velcro will be adhered and
that the surfaces are at room temperature.
Apply between round seat bumpers
Apply along horizontal edge of fenders
Apply 3 sections underneath front seat support
frame member as indicated by dotted line. Velcro
must be on the underside.
Step 5: (Cabin Installation)
5.1 Lower the seat and slide the seat all the way
forward and use the knob on the seat to tilt the
seatback forward as much as possible.
5.2 Remove the doors from the cabin and set aside
carefully to prevent scratching the panels.
5.3 Remove the 3 bolts securing the compressor
bracket to the base of the shipping mount and cut
any zip ties holding the hoses and wire harness to
the shipping mount. Support the compressor
using a bungee cord or rope. Do not ever use the
hoses to support the compressor or damage may
occur.
5.4 Position a lifting strap where shown so that it sits
roughly 2” in front of the b-pillar.
Fig. 5.4 (Position lifting strap)
Fig. 4.10 (Install Velcro)
Fig. 5.1 (Move Seat forward, Rotate seatback)
Fig. 5.3 (Unbolt Compressor)

CAB INSTALLATION
11 of 30
5.5 Put tension on the lifting strap with the overhead
hoist. Remove and discard the 4 bolts holding the
rear of the cab down to the shipping bracket
(located inside the cab) as well as the 4 lag
screws holding the floorboards to the pallet.
5.6 With assistance, lift the cabin and position over the
vehicle. Be sure to support the A/C compressor
so that it never hangs from the hoses.
5.7 Lower the cabin slowly onto the vehicle being
careful to not scratch the fenders with the rear
edge of the floorboard. The A/C compressor
should pass to the inside of the ROPS and end up
on the left side of the engine.
5.8 Fasten the rear of the cabin to the ROPS mounts
using the following hardware. Leave loose at this
time.
Hardware Used Qty
5/16-18 x 1-3/4 Hex Head Bolt 4
5/16-18 Flange Nut 4
5.9 Fasten the cab to the floor of the tractor using the
following hardware. Note: On 60” tractors, use 6
M8 bolts. On 72” tractors, only install 4 M8 bolts
and leave additional slot open.
Hardware Used Qty
M8x1.25x40mm Button Head Bolt 4 or 6
5/16x1-1/4” Steel Fender Washers 4 or 6
1/4-20x1” Button Head Bolt 6
1/4x1” Steel Fender Washers 6
1/4-20 Flange Nut 6
5.10 Tighten all floorboard bolts and rear cabin bolts at
this time
Fig. 5.5a (Remove Rear Bolts)
Fig. 5.5b (Remove Lag Screws)
Fig. 5.8 (Install Rear Bolts)
Remove
Inside Cab
Install
Install
Fig. 5.9 (Install Floorboard Bolts)
M8
M8 on
60”

CAB INSTALLATION
12 of 30
5.11 Raise ROPS bar and loosely re-install M16 bolts
used to pin it.
5.12 Loosen the 4 factory installed 5/16” bolts securing
the upper ROPS mount so that the mount can
slide up against the underside of the ROPS.
5.13 Install the upper ROPS clamp plate to the top side
of the ROPS and secure with the following
hardware. Bolts can be tightened at this time.
Hand tighten only. Do not over-tighten or plate will
deform.
Hardware Used Qty
5/16-18x2-1/2” Flange Bolts 4
5/16x1” Steel Fender Washers 8
5/16-18 Flange Nut 4
5.14 Re-tighten the bolts loosened in step 5.12.
5.15 Install the washer and nuts onto the M16 ROPS
bolts and tighten at this time. Note: The tightening
torque is different for the upper and lower bolt.
Torque the upper bolt to 167 to 196 Nm (123 to
144 lbf-ft)
Torque the lower bolt to 78 to 90 Nm (58 to 66 lbf-
ft)
Hardware Used Qty
M16x30 Steel Flat Washer 1
M16x2 Locknut 1
5.16 If installed on a 72” mower, drill 9/32” holes
through the tractor floorboard centered on the
open slots in the cab floorboards. Do not drill too
deep to avoid damaging any items on the
underside of the floorboard.
5.17 Dab the raw edge of the holes in the steel
floorboard with some paint to prevent corrosion.
5.18 Install the following hardware into the newly drilled
holes and tighten.
Hardware Used Qty
1/4-20x1” Button Head Bolt 2
1/4x1” Steel Fender Washers 2
1/4-20 Flange Nut 2
Fig. 5.12 (Loosen Upper ROPS Mount)
Fig. 5.13 (Install Upper ROPS Clamp Plate)
Fig. 5.15 (Tighten ROPS Bolts)
Loosen
Install Clamp
Plate
Torque
Fig. 5.16 (Drill Hole on 72” Mowers)
Drill
on 72”

CAB INSTALLATION
13 of 30
Step 6: (Compressor Installation)
6.1 Loosen the lower and upper pivot bolts that are
securing the compressor to its mounts.
6.2 Move compressor into location on the left side of
the engine and secure the bracket with the
hardware listed below as shown in figures 6.2a
and 6.2b.
Hardware Used Qty
M10x1.25x30mm Flange Bolt 3
6.3 Align the pulley on the compressor with the pulley
on the dynamo using a steel straight edge and
tighten the three mounting bolts installed in step
6.2.
6.4 With the compressor tilted all the way out in its
adjustment slot, re-connect the two ring terminals
to the stud on the starter and re-install the
additional wire into the connector on the starter.
Torque the stud to 5.9 to 11.8 Nm (4.3 to 8.7 lbf-ft)
Note: Be sure that none of the wires or terminals
are touching the steel compressor bracket after
tightening the starter nut! Ensure protective boot
is re-installed.
6.5 Install the supplied belt and tension. Tighten all
compressor pivot bolts at this time.
Fig. 6.2a (Secure Compressor with 2 Bolts in Rear)
Fig. 6.2b (Secure Compressor with 1 Bolt in Front)
Fig. 6.4 (Re-Attach Starter Wires)
M10
Bolts
M10
Bolt
Ensure
Clearance
Fig. 6.5 (Install Belt and Tension)
Belt

CAB INSTALLATION
14 of 30
6.6 Install two p-clamps to the lower ROPS brackets
as shown to secure the larger A/C hose to the
ROPS bracket. Twist clamps and adjust hose
position so that hose does not contact sharp
edges of ROPS bracket.
Hardware Used Qty
1/4-20x1” Button Head Bolt 2
1/4-20 Flange Nut 2
3/4” P-Clamp 2
6.7 Secure both hoses to the vehicle frame using a
cable tie as shown. Ensure that the hoses will not
contact any sharp edges.
Hardware Used Qty
Cable Tie 1
Step 7: (Wiring)
7.1 Cut the cable ties securing the wiring harness and
attach the harness to the lower ROPS brackets
with p-clamps as shown.
Hardware Used Qty
1/4-20x1” Button Head Bolt 2
1/4-20 Flange Nut 2
3/4” P-Clamp 2
7.2 Secure the wire harness to the vehicle frame
using a cable tie as shown. Ensure that the
harness will not contact any sharp edges.
Hardware Used Qty
Cable Tie 1
Fig. 6.6 (P-Clamp Hoses to ROPS Bracket)
Fig. 6.7 (Cable Tie Hoses)
Fig. 7.1 (P-Clamp Wire Harness to ROPS Bracket)
P-Clamps
Cable
Tie
P-Clamps
Fig. 7.2 (Secure Wire Harness to Vehicle)
Cable
Tie

CAB INSTALLATION
15 of 30
7.3 Install the ring terminals on the red wires onto the
stud on the positive battery clamp (outboard of the
existing battery clamp nut) and secure with the
following hardware.
Hardware Used Qty
M6x1.0 Nut 1
7.4 Locate the portion of the wire harness with two
ring terminals crimped on the ends of black and
gray wires. Route the ring terminals forward over
the ROPS tube in front of the battery next to the
existing wiring and up along the right side of the
vehicle to right hand control.
Note: Wires must be routed above the ROPS, but
below the flat area that the hood seals on when it
is closed.
Avoid any moving parts.
7.5 Route the wires up behind the right control stick
and connect to the supplied switch as shown. The
gray wire should go to the center screw (NO, #3)
and the black wire should be connected to the
COM, #1 screw.
It is recommended to do the assembly over the
floor of the tractor to prevent losing any screws.
7.6 Remove the bolt shown in figure 7.6 and re-install
with the switch bracket so that the spring loaded
switch rod will be contacted by the throttle control
lever. Adjust the bracket and switch so that when
the throttle control lever is beyond 3/4 throttle the
switch is engaged. The switch can be rotated on
the bracket and the bracket can also be rotated
where it mounts to the vehicle.
Fig. 7.6 (Install Switch Bracket)
Bolt
Fig. 7.3 (Attach Red Wires to Battery)
Fig. 7.4 (Route Harness to Right Control Sick)
Fig. 7.5 (Connect Wires to Switch)
Take Image During Pilot Install
M6 Nut

CAB INSTALLATION
16 of 30
7.7 If installing the optional seal kit, do so at this time.
Otherwise, re-install the plastic cover (removed in
step 1.4) over the right hand control stick.
7.8 Route the remaining section of the harness with
the white connector on the end forward from the
battery area over the ROPS and up under the
seat. The harness should run across the top of
the transmission along the existing OEM harness
and end on the left side of the vehicle.
Note: Wires must be routed above the ROPS, but
below the flat area that the hood seals on when it
is closed.
7.9 Connect the white connector on the harness to the
mating connector on the secondary regulator.
7.10 Cut the blue tape on the OEM vehicle wire
harness under the seat to expose a male and
female bullet terminal. Connect the male bullet
terminal at the end of the yellow wire on the A/C
wire harness to the female bullet terminal on the
OEM harness.
Fig. 7.10 (Locate OEM Signal Wire)
Signal
Wire
Fig. 7.7 (Re-Install Cover)
Fig. 7.8 (Route Wiring)
Fig. 7.9 (Connect Regulator)

CAB INSTALLATION
17 of 30
7.11 Route the two remaining sections of wires on the
A/C harness out the rear of the left side of the
vehicle so that they pass above the ROPS tube
and end near the compressor.
7.12 Re-connect the OEM dynamo wires to the vehicle
wire harness. Connect the blue wires with the two
bullet terminals from the A/C harness to the bullet
terminals on the secondary dynamo.
7.13 Connect the female bullet terminal on the end of
the blue wire to the male bullet terminal on the
compressor.
7.14 Remove the bolt shown in figure 7.13 and install
the 3/8” ring terminal from the A/C harness onto
the bolt so that it is contacting the ear of the
compressor.
7.15 Use cable ties to secure the wire harness going to
the compressor to the hoses.
7.16 Re-install the negative terminal back onto the
battery post and tighten.
7.17 Install the 4 ring terminals on the black ground
wires to the battery bolt and secure with an
additional nut.
Hardware Used Qty
5/16-18 Serrated Nut 1
Fig. 7.12 (Connect Dynamo Wiring)
Fig. 7.13 (Connect Dynamo Wiring)
Fig. 7.17 (Connect Ground Wires)
Install Ring
Terminal

CAB INSTALLATION
18 of 30
Step 8: (Functionality Testing)
8.1 Ensure that all wires and hoses are securely
fastened with cable ties to prevent any rubbing or
chaffing on sharp or hot objects.
8.2 Turn the vehicle on and check to make sure that
belts and components are not vibrating
excessively.
8.3 Bring engine to full throttle, turn on A/C blower,
and move thermostat to cold.
8.4 Check to make sure A/C is blowing cold air.
8.5 Turn engine off and allow to cool.
Step 9: (Shroud Installation)
9.1 Remove the two OEM bolts shown in Figure 9.1,
install the rear shroud bracket, and re-install the
bolts.
9.2 Install the front shroud bracket oriented as shown
so that the bolts for the shroud can be installed
from the front. Secure to the pre-existing hole in
the vehicle frame.
Hardware Used Qty
M6x1.0x20mm Flange Bolt 1
M6x1.0 Nylock Nut 1
9.3 Assemble the front shroud panel to the front side
of the bracket installed in step 9.2. Leave bolts
finger tight.
Hardware Used Qty
1/4-20x3/4” Flange Bolts 2
Fig. 9.2 (Install Front Shroud Bracket)
Fig. 9.3 (Install Front Shroud Panel)
Fig. 9.1 (Install Rear Shroud Bracket)
Remove
Bolts
M6 Bolt
Front
Shroud

CAB INSTALLATION
19 of 30
9.4 Assemble the rear shroud panel and cover
together as shown. Leave the bolts loose at this
time.
Hardware Used Qty
1/4-20x3/4” Flange Bolts 3
9.5 Assemble the rear shroud panel to the vehicle.
Tighten all shroud bolts at this time.
Hardware Used Qty
1/4-20x3/4” Flange Bolts 6
Step 10: (Filler Installation)
10.1 Raise the seat and install the rubber underseat
filler panel as shown. Start by aligning the panel
over the round rubber bumpers that the seat rests
on and work around the perimeter to attach to the
pre-installed Velcro.
10.2 Install Velcro around the perimeter of the
underseat filler in the areas where Velcro was not
pre-installed using the filler as the locating
template for the Velcro. Be sure to wipe down the
surfaces where the Velcro will be adhered and
that the surfaces are at room temperature.
10.3 Lower the seat, slide the seat completely forward,
tilt seat back forward, and install adhesive Velcro
to the seat base so that it is located up against the
stamped rib as shown.
Fig. 9.4 (Assemble Cover Panel)
Fig. 9.5 (Install Shroud over Compressor)
Fig. 10.1 (Install Underseat Filler)
Fig. 10.3 (Install Velcro)
1/4”
Bolts
1/4”
Bolts
Align
Back of Seat
Velcro

CAB INSTALLATION
20 of 30
10.4 Install the upper portion of the rubber filler along
the bottom edge of the rear panel to locate it and
then secure under the seat and along the sides.
10.5 The back ends of the rubber filler should be pulled
out under the cab so that they can be velcroed to
the fenders behind the cab.
10.6 Use the rubber filler as a guide and apply
adhesive Velcro to the tractor fenders behind the
cab.
Step 11: (Final Installation)
11.1 Re-install doors and install gas shocks. The end
with the red tab should be attached to the
sideframe of the vehicle.
11.2 Re-install the front hinged cover if working on a
60” mower.
11.3 If working on a 72” mower, inspect along the
floormat across the entire front of the vehicle and
apply a bead of black silicone to fill any gaps that
may occur.
11.4 Re-install battery cover.
Fig. 11.1 (Attach Gas Shock)
Fig. 10.4 (Filler Location)
Rubber Filler
Fig. 10.5 (Filler Location)
Rubber
Extends out
