Cabrio Terrace Assembly
Follow instructions from Steps 1 through 6 in the
Cabrio installation guide for assembly of the beams
and roof framework. Note that the supplied long
beam replaces two smaller beams.
Install the two dummy posts at the
location shown in the adjacent diagrams. See Step
7 in the Cabrio installation guide for instructions
how to install the corner posts.
[EX.SCT.20-A]
[EX.P.04-A2]
This annex provides supplementary instructions to the
Cabrio installation guide for the assembly of the Cabrio
Terrace configuration. Please refer to the Cabrio installation
guide when necessary. The struts and gutter system
installation instructions are covered in separate annexes.
View A-A
Cabrio Terrace
(2x1 Shelter Configuration)
Top View Alternate Arrangement
Pivot
Hinge
(4 places) Pivot
Hinge
(4 places)
Roof
Lever Arm
(2 places)
Roof
Lever Arm
(2 places)
View A-A
(Top View)
Assembled Roof Framework
Strut
Gutter System
Long Beam
Long Beam
Long Beam
Remove the
cover door
to install
Stub Post
Assembly
Stub Post Assembly
Stub Post Assembly
2 x
1 x
EX.SCT.20-A
EX.SCT.20-A
EX.P.04-A2
EX.P.04-A2
Instructions
1
EX.P.04-A2

www.cuscini-design.com
Supp.
Cabrio Terrace Assembly
Attach the corner posts to each corner of the structure
using the provided hardware. This step may require a
second person or a ladder to lift the roof assembly
during installation of the corner posts. See Step 7 in
the Cabrio installation guide for further assembly
instructions.
Joining more than one Terrace assembly
together allows for various configuration
arrangements. See adjacent diagrams for
some of the possible arrangements.
2
Top View
Top View
Cabrio Terrace
(2x2 Shelter Configuration)
Cabrio Terrace
(4x1 Shelter Configuration)
Corner
Post
Corner
Post
Other Terrace Configurations
