SERVICE MANUAL

MCR33xx

Magnetic/IC card Reader/Writer

Technical characteristics are subject to change without notice

This document may not be reproduced, adapted or translated without prior written authorization.

may not be held liable for direct, indirect, accidental, consequential or other

damages relating to the provision and use of this information.

Edition: September 1999

Code: MAN 1129

Previous issue Subjects covered in the new issue New pages

introduced or amended

This manual is meant for technicians servicing the MCR33xx card reader/recorder.

NOTE:

The machine must be used solely for the purposes for which it was designed. Any intervention

modifying its original operating configuration must be authorized and certified beforehand by the

manufacturer.

Custom is not liable for any damages caused by the use of non-original spare

parts.

FOREWORD

FOREWORD....................... 3

INTRODUCTION AND FUNCTIONAL DESCRIPTION ....... 5

MCR33xx IN THE SYSTEM ................... 6

GENERAL CHARACTERISTICS ................. 7

FUNCTIONAL ASSEMBLIES .................. 8

EXTERNAL CONTROLS AND INDICATORS ............. 9

BLOCK DIAGRAM ......................10

INSTALLATION AND USE..................11

MCR33xx POWER SUPPLY...................11

MCR33xx Power Supply (desktop version) ..............11

MCR33xx Power Supply (Open Frame version) ............11

SERIAL CONNECTION RS 232 .................12

COMMUNICATION PROTOCOL DESCRIPTIONS ...........15

COMMAND LIST ......................16

COMMANDS ........................20

Software Diagnostics & DEMO of MCR33XX ..........31

CONTROL ELECTRONICS .................41

MECHANICAL ADJUSTMENTS ...............44

SHUTTER ADJUSTMENT ...................45

Checking the shutter opening mechanism ..............45

Shutter opening electromagnet adjustment..............45

Shutter position microswitch adjustment...............46

Checking the shutter opening mechanism ..............46

Card presence microswitch adjustment ...............47

ADJUSTING THE POSITIVE DRIVE BELT..............48

Adjusting the belt ......................48

ADJUSTING THE CONTRAST ROLLERS ..............49

Checking Contrast Roller Adjustment................50

READ/WRITE HEAD ADJUSTMENT................51

CHIP CARD ELECTROMAGNET ADJUSTMENT ...........52

GENERAL FEATURES ...................53

The MCR33xx card reader/writer is a compact, versatile peripheral, suitable for the most widely

disparate applications, even in the hardest environmental conditions.

In accordance with ISO standards, the MCR33xx can record both low and high coercivity cards,

by means of a simple software-driven selection.

Available in different versions depending on the installed options, the MCR33xx can be used

manually (in desktop configuration), or in self-service applications (open frame configuration).

The desktop version is available with the external 110/230 Volt power supply unit.

Connection with the system is through an RS-232 serial interface.

INTRODUCTION AND FUNCTIONAL

DESCRIPTION

MCR33xx IN THE SYSTEM

MCR33xx

GENERAL CHARACTERISTICS

Fully controlled function by software with autotests, FW download, no jumper or setting. Specific

software and driver to test, demo, work and troubleshoot.

Shutter

The shutter (installed only in the self service configuration) is activated by an electromagnet; its

open or shut position is detected by a microswitch located on the right side of the electromagnet.

On the left side of the inlet is installed a microswitch that detects the presence of the card, while a

reading head positioned on the lower side checks the incoming card for the presence of written

magnetic tracks, to prevent objects other than written magnetic cards from being inserted into the

peripheral.

Card Transport

Astepped motor controls the transport of the card inside the MCR33xx.Three conveyor rollers,

moved by three positive drive belts, move the card over the read/write head.

Card Reading/Writing

High and/or low coercivity head mounted on a special support fastened by means of a leaf spring.

The head can read and write the tracks through a software selection; there are no jumpers or dip

switches.

High precision mechanics let the card slide over special bearings.

Power Supply

Only the desktop version is equipped with an external power supply

unit. The self service version is fitted with a 4-way connector, whose

specifications are described in the figure that follows.

1 - DC +24V

2 - gnd

3 - gnd

4 - DC +24V (aux)

To power down detect circuit

Diode Power

+24Vdc 1

GND 2

External capacitor (opt.)

Diode

150 ohm/2W

Electronic

Board

Power supply

MOLEX

Connector

FUNCTIONAL ASSEMBLIES

1 - Shutter position microswitch

2 - Stepper motor

3 - Chip card contact activation electromagnet

4 - Chip card contacts

5 - Electronic board

6 - Shutter opening electromagnet

7 - Card presence microswitch

8 - Reading head to detect incoming written magnetic band

9 - Inlet photo two (standard)

10 - Reading/writing photo

11- - Reading/writing head

12 - End of path photo

13 - Inlet photo one (installed only on the version without the shutter)

14 - Chip card photo

12 3

right side

14 5 4 6

11 10 913

left side

EXTERNAL CONTROLS AND INDICATORS

1 - ON/OFF switch (only on DESKTOP version)

2 - LED

3 - RS232 serial connection (male - db9)

BLOCK DIAGRAM

Shutter solenoid

driver

Card detect sensor

Card in read/write

position sensor

Card at the end

of path sensor

FLASH eprom

Mag-stripe

read/write circuit

Motor driver

IC contact driver

Automatic Card feeder

Motor

Automatic Card feeder

Sensor

Card detect circuit

Pre - head (#2, #3)

Shutter solenoid

Inlet photosensor

ransport stepper motor

IC contact solenoid

(Optional)

HOST serial

Connection

Power supply

Aux

DC +24V

TXD

RXD

RTS

CTS

DTR

DSR

SNG

Dati TX/RX (download)

Mother

Board

Card detect SW

Reading/writing photo

Endofpathphoto

Shutter open detect

Read/write #1#2#3

Flat cable

(Optional)

INSTALLATION AND USE

POWER SUPPLY

The MCR33xx is normally factory programmed to the Customer’sorders. Any modifications to its

programming must be performed by specially qualified personnel.

Power Supply (desktop version)

·Check the power supply transformer to ensure it corresponds to the mains voltage and power

supply voltage of the MCR33xx.

·Connect the transformer to a wall outlet.

Connect the transformer cable to the MCR33xx plug.

·Connect the serial cable RS232

Power Supply (Open Frame version)

Power with +24V direct current between pins 1and 2on the 4-way connector mounted on the

electronic board (see the diagram on page 7).

fastening

Tofix the MCR33xx use the bench mark described in the picture below

PLEASE NOTE:

TheMCR33xx has been designed to be installed horizontally,as shown in the picture. To

install the MCR33xx in adifferent way please contact the manufacturer first.

39.5mm

14.5mm

76mm

91.5mm

101.5mm

188.5mm

IC card interface cable

Pin No Signal name I/O Function

1 C8 -- IC Contact C8

2 C4 -- IC Contact C4

3 C3 -- IC Contact C3

4 G (NC) -- Connect to the signal ground

5 C7 -- IC Contact C7

6 C6 -- IC Contact C6

7 G (NC) -- Connect to the signal ground

8 C2 -- IC Contact C2

9 C1 -- IC Contact C1

10 C5 -- IC Contact C5

IC card interface cable

(FCC cable)

for lower position contacts

#10

IC card interface cable

(FCC cable)

for upper position contacts

#10

IC contact connection

Upper position contacts and lower position contacts are being located in serial as shown in the

figure below.

Upper position

Lower position

Upper position

Lower position

SERIAL CONNECTION RS 232

Pin No. Signal Name I/O Function

1NC-

2 RXD(RD) I Receive Data

3 TXD(SD) O Transmit Data

4 DTR(ER) O Data Terminal Ready

5 SGN - Signal Ground (0V)

6 DSR(DR) I Data Set Ready

7 RTS(RS) O Request To Send

8 CTS(CS) I Clear To Send

9NC-

Transmission And Control Specification

1. Synchronous method : Asynchronous

2. Transmission method : Half duplex

3. Baud rate: 4800 Bps or 19200 Bps (autodetected)

4. Data length : 7 bit + 1 parity

5. Stop bit ; 1 bit

6. Character Code : ASCII

7. Parity check method : Even

TXD

RXD

RTS

CTS

DTR

DSR

SGN

TXD

RXD

RTS

CTS

DTR

DSR

SGN

HOST RW

RS232C

Transmission Control Method

MCR33xx executes particular operation according to text (command) received from HOST,then

reports result of execution to HOST.

NOTE:

BBC & CR are omissible according to initialize command.

STX (02H) Indicate start of text.

ETX (03H) Indicate end of text.

ENQ (05H) Request to send response.

ACK (06H) Send positive response.

NAK (15H) Send negative response.

DLE, EOT (10H) (04H) Clear the line and Reset MCR33xx

CR (0DH) Carriage return.

Control Characters

16 l

STX TEXT ETX BCC CR

BCC range

DLE EOT CRENQ CRNAK CRACK CR

Comunication Timing Chart

·Ordinary Operation.

·Irregular Operation.

HOST

EXECUTION

COMMAND ENQ

ACK RESPONSE

HOST

EXECUTION

COMMAND

ENQ

ACK

RESPONSE

COMMAND

20msec Timeout

HOST

EXECUTION

COMMAND

ENQ

ACK

RESPONSE

COMMAND

NAK

Error

HOST

EXECUTION

COMMAND ENQ

ACK

RESPONSE

ACK

Error

COMMAND

ENQ

20msec Timeout (Except Entry command)

HOST

EXECUTION

COMMAND

ENQ

RESPONSE

RW ACK

ENQ

RESPONSE

Error

HOST

EXECUTION

COMMAND ENQ

ACK

RESPONSE

COMMAND

ACK

Error

COMMUNICATION PROTOCOL DESCRIPTIONS

Command Text Format

“C” cm pm Data

The first character shall be “C”(=43H).

cm : Command code

pm : Parameters

Positive Response Format

“P” cm pm st1 st0 Data

The first character shall be “P”(=50H).

cm : Command code

pm : Parameters

St1, St0 : Status code

Negative Response Format

“N” cm pm e1 e0

The first character shall be “N”(=4EH).

cm : Command code

pm : Parameters

e1, e0 : Error code

COMMAND LIST

Cm : Command code pm: Parameters

Command cm Function pm Details of operation

30H If the card is inside MCR33xx, eject card

31H If card is inside MCR33xx, capture card

INITIALIZE 30H Initialize MCR33xx

32H If card is inside MCR33xx, retain card inside of

MCR33xx

30H Report presence of card & its positionSTATUS

REQUEST 31H Inquire status 31H Report precence of sensor status in detail

30H Does not refer to Pre-Head

ENTRY 32H Card entry 31H Pre-Head detects ISO Tr. 2 or Tr. 3 (only

desktop)

Eject 30H Move card to Gate from inside MCR33xx

31H Capture card to rear back of MCR33xx

EJECT 33H Capture 32H Card in read/write position

RETRIVE 34H Retrive 30H Retrive card which is in Gate position

Move card 30H Only card movement

MS#1 read 31H ISO #1 Track reads Transmit read data

MS#2 read 32H ISO #2 Track reads Transmit read data

MS#3 read 33H ISO #3 Track reads Transmit read data

All track read 35H Transmit All channels data

READ 36H

Clear memory 36H Clear out all the stored data for reading and

writing

Command cm Function pm Details of operation

WRITE 37H Write data

31H ISO #1 Track writes received data

32H ISO #2 Track writes received data

33H ISO #3 Track writes received data

ENB/DIS 3AH

Cleaning card 30H Accepts cleaning card

Disable 31H Disable

Enable 32H Enable with referring pre-head (only desktop)

DIAGNOSTIC 3DH

30H Test motor /solenoid

31H Read sensor and photo

32H Read buffer acquisition tracks

33H Read counter

CHIP

CONTACT 40H CHIP contact set

30H Move card to CHIP CARD contact position

32H Reset CHIP contact

IDENTIFY 41H Revision 30H Release PROM revision (firmware)

31H Release (download)

COERCIVITY 45H

LOW 30H Low coercivity

HIGH 31H High coercivity

DISABLE

RETRY

46H 30H Only for diagnostic - disable retries on R/W tracks

Status Code

St1, st0 : ICRW status code

ICRW status Meaning

“00” No card detected(including card gate)

“01” Card locates at card Gate

“02” Card locates inside(Transport)

Table of contents

Custom Audio Electronics MCR33 Series User manual

Popular Card Reader manuals by other brands
