CyberHome LDV 1010B User manual

CH-LDV 1010B
DVD
Progressive
Player
Operation Guide
Scan
Portable
TM
with
TMTM
/
+
-

The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and servicing instructions in the literature
accompanying the appliance.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE THE COVER (OR BACK). NO USER-SERVICEABLE PARTS
INSIDE. REFER TO QUALIFIED SERVICE PERSONNEL FOR SERVICING.
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the presence
of not isolated dangerous voltage within the inside of the
product that may be sufficient magnitude to constitute a risk of
electric shock to persons.
WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR
ANNOYING INTERFERENCE, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR
MOISTURE AND ONLY USE THE RECOMMENDED ACCESSORIES.
Read these instructions - When using this unit, basic precautions

outlined in this section should always be followed.
Keep these instructions - Retain this user manual for future

reference.
Heed all warnings - Follow all warning labels on the product, and

the safety instructions in this manual.
Follow all instructions - Adhere to the instructions outlined in this

manual and on the unit.
Clean only with a dry cloth - Unplug the unit before cleaning. Do

not use any liquid or detergents for cleaning.
Do not block any ventilation opening. Install in accordance with

the manufacture's instructions.
Do not install near any heat sources such as radiators, heat

registers, stoves, or other apparatus (including amplifiers) that
produce heat.
Do not defect the safety purpose of the polarized plug. A polarized

plug has two blades with one wider than the other. The wide blade
is provided for your safety. If the provided plug does not fit into
your outlet, consult an electrician for replacement of the obsolete
outlet.
Protect the power cord from being walked on or pinched

particularly at plugs, convenience receptacles, and the point where
they exit from the apparatus.
Only use attachments / accessories specified by the manufacturer.

The apparatus shall not be exposed to dripping or splashing and no

objects filled with liquids, such as vases, shall be placed on the
apparatus.
Use only with the cart, stand, tripod, bracket, or

table specified by the manufacturer, or sold with
the apparatus. When a cart is used, use caution
when moving the cart / apparatus combination to
avoid injury from tip-over.
Unplug this apparatus during lightning storms or

when unused for long periods of time.
Refer all servicing to qualified service personnel. Servicing is

required when the apparatus has been damaged in any way, such
as when the power-supply cord or plug is damaged, liquid has
been spilled, objects have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, or when the unit does not
operate normally, or has been dropped.
Power cord protection - To avoid any malfunctions of the unit

and to protect against electric shock, fire or personal injury,
please observe the following:
a) Hold the plug firmly when connecting or disconnecting the
AC power cord to this unit.
b) Do not connect or disconnect the AC power cord with wet
hands.
c) Keep the AC power cord away from heating appliances.
d) Never put any heavy object on the AC power cord.
e) Do not attempt to repair or reconstruct the AC power cord in
any way.
Remove dust, dirt, etc. on the plug at regular intervals.

If the unit has been dropped or otherwise damaged, turn off the

power and disconnect the AC power cord.
If smoke, odors or noises are emitted from the unit, turn off the

power and disconnect the AC power cord.
Placement - Avoid placing the unit in areas of direct sunlight,

heating radiators, closed automobiles, high temperature (over 35°
C (95° F)), high humidity (over 90%), excessive dust, vibration,
impact or where the surface is tilted, as the internal parts may be
seriously damaged.
Non-use periods - When the unit is not used, turn the power off.

When the unit is unused for a long period of time, the unit should

be unplugged from the household AC outlet.
No fingers or other objects inside - Touching internal parts of this

unit is dangerous and may cause serious damage to the unit. Do
not attempt to disassemble the unit.
Do not put any foreign object on the disc tray.

Keep away from water and magnets.

Keep the unit away from flower vases, tubs, sinks, etc. If liquids

are spilled into the unit, serious damage could occur.
Keep magnetic objects, such as speakers, distant from the player.

Stacking - Place the unit in a horizontal position and do not place

anything heavy on it.
Do not place the unit on amplifiers or other equipment which

may become hot.
Condensation - Moisture may form on the lens in the following

cases: a) immediately after a heater has been turned on b) in a
steamy or very humid room c) the unit is moved from a cold
environment to a warm one.
If moisture forms inside this unit, it may not operate properly. In

this case, turn off the power and wait about one hour for the
moisture to evaporate.
Noise interference while a broadcast is being received -

depending on the reception condition of the TV, interference may
appear on the TV screen while you are watching a TV broadcast,
if the unit is switched on. This is not a malfunction of the unit or
the TV. To watch a TV broadcast, turn off this unit.
Caution - Use of controls or adjustments or performance of

procedures other than those specified herein may result in
hazardous radiation exposure.
SAVE THESE INSTRUCTIONS
SAFETY INSTRUCTIONS
Explanation of warning symbols
Read the following instructions carefully
2

IMPORTANT BATTERY SAFETY PRECAUTIONS
Charging
Read these instructions carefully before using the battery.
•Do not disassemble the cells and battery.
•Do not use a damaged battery.
•Do not expose the battery to fire, or throw the battery into a fire. This may cause the battery to explode.
•Use the specified charger only.
•Do not touch the battery terminals with metal objects.
•Keep out of reach of children.
•If any electrolyte contacts with your hands or clothes, wash it off thoroughly with water.
•The battery may present a risk of fire or chemical burn if misused.
•Charging shall be less than specified 8.4 V.
•The battery should be charged within the specified temperature of 0~45° C.
Discharging
•In order to prevent over-discharging, the battery should discharge between 7.2 to 7.8 V.
•The battery should be discharged within the temperature -20~60° C.
Storage
•The battery should be stored within the temperature range of -20~60° C.
•Keep the battery terminals clean while storing.
Others
3

CONTENTS
4
INTRODUCTION
DISPLAYING JPG IMAGES ON YOUR TV
Features.................................5
ViewingaJPGslideshow..................32
Optical disc compatibility . . . . . . . . . . . . . . . . . . . 5
Slideshowoptions........................32
Caringforopticaldiscs.....................5
Advanced JPG functions . . . . . . . . . . . . . . . . 32-33
GETTING STARTED
THE DVD PLAYER SETUP MENU
Checking the package contents . . . . . . . . . . . . . . . 6
Usingthesetupmenu .....................34
Usingtheremotecontrol....................7
Languagesetuppage......................35
Replacing the remote control battery. . . . . . . . . . . 7
Videosetuppage.........................35
Operating the remote control. . . . . . . . . . . . . . . . . 7
Audiosetuppage......................36-37
FUNCTIONAL OVERVIEW Passwordsetuppage......................37
Remote control functions. . . . . . . . . . . . . . . . . . . . 8 Generalsetuppage........................38
Frontpanelfunctions.......................9
Usingthefunctionmenu...................10 TROUBLESHOOTING
External battery pack operation . . . . . . . . . . . . . . 11 .......................................40
Detaching external battery pack . . . . . . . . . . . . . 12 SPECIFICATIONS
Internal battery pack operation (optional) . . . . . . 13 .......................................41
Detaching internal battery pack. . . . . . . . . . . . . . 14 INDEX
.......................................42
CONNECTIONS TO TELEVISION
DVD player connections . . . . . . . . . . . . . . . . . . 15
Using DVD player connections. . . . . . . . . . . . . . 16
Composite video/stereo connections . . . . . . . . . . 17
S-Videoconnections ......................18
Component connections . . . . . . . . . . . . . . . . . 18-19
Audio output connections . . . . . . . . . . . . . . . . . . 20
Connecting external AV source . . . . . . . . . . . . . . 21
GETTING STARTED
Poweringontheunit......................22
Insertingadisc...........................22
DVD PLAYER OPERATION
Usingadisc-rootmenu...................23
Basicdiscplayback.......................23
Fastforwardandreverse...................24
Slowmotionplayback.....................24
GOTOMenu............................24
Zoomfunction...........................25
Multi-anglefunction ......................26
Usingsubtitles...........................26
Changing the audio track. . . . . . . . . . . . . . . . . . . 26
Displaying playback information . . . . . . . . . . . . 26
Bookmarkfunction.......................28
Programfunction.........................28
Displaymodes-LCD.....................29
Adjustingbrightness......................29
PLAYING MP3 MUSIC FILES
UsingtheMP3navigator...................30
Settingrepeatoptions .....................30
Creating a custom playlist . . . . . . . . . . . . . . . . . . 31
Notes on copyright
This product incorporates copyright protection technology
that is protected by method claims of certain U.S. Patents
and other intellectual property rights owned by Macrovision
Corporation and other rights owners.
Use of this copyright protection technology must be
authorized by Macrovision Corporation, and is intended for
home and other limited viewing uses only unless otherwise
authorized by Macrovision Corporation. Reverse
engineering or disassembly is prohibited.
Manufactured under license from Dolby Laboratories.
“Dolby”, “Pro Logic” and the double-D symbol are
trademarks of Dolby Laboratories. Confidential
Unpublished Works.
1992-1997 Dolby Laboratories, Inc. All rights reserved.

Labels
Tapes
Labeling Side
Surface
Optical disc compatibility
This unit plays DVDs recorded for a particular region.

The region mark on the back of the player must
correspond to that on any DVD discs you wish to play.
Units sold in North America are coded for Region 1,
and marked as shown:
This unit supports CD-R/RW discs recorded with MP3

or JPG files, and VCD format.
MP3 files must be named with the extension “.MP3”

JPG files must be named with the extension “.JPG”

JPG images must be saved with “standard” encoding,

rather than “progressive” encoding.
Discs created with personal computers may have

problems playing due to differences in recording
software settings, disc formats and other factors.
Hold a disc by the rim or with an index finger in the

central hole. Never touch the signal surface.
Finger prints or stains on the surface of the disc may

cause signal loss.
Use a soft cloth and wipe in a radiating manner from

the center of the disc to the outer rims when cleaning
the disc surface.
Never add labels or adhesive tapes on the discs and be

careful not to scratch or damage the disc surface.
To prevent discs from becoming bent or deformed,

they should be vertically kept in the disc storage case.
To prevent damage, avoid leaving discs in your car,
where they may be subject to direct sunlight and high
temperature.
Do not use any disc accessory to improve the audio

quality, disc protective solutions or lens cleaner. These
products may damage the disc surface.
Caring for Optical Discs
DISC COMPATIBILITY / CARE
5
FEATURES
Progressive Scan Video with 3:2 pulldown.

Plays DVD, VCD, CD-ROM, MP3, JPG and other

disc types.
Component Video, S-Video and Composite Video

Outputs.
Stereo Audio out and Optical digital outputs.

Advanced playback functions: Slow playback, repeat

playback, parental control, MP3 player, JPG player,
screen saver, Zoom In/Out, track selection, on-screen
display and more.
JPG
TM
The CH-LDV 1010B is a Portable DVD Player with a large 10 inch LCD screen. It can play your favorite MP3 files
or view JPG files from your digital camera. It’s got everything you need to take it out on the open road and when you
come back home, become a part of your home theater system. Now you can start enjoying today’s hottest DVD
movies with superb video quality. Welcome to the digital revolution!
Labels
Tapes
Labeling Side
Surface

GETTING STARTED
Make sure the package contents are complete
In addition to the DVD player, your package should contain the following accessories. Check the contents of the package carefully, as
some items may be located under the packing foam.
6
Composite / S - Video
Video cable
Stereo Audio Cable
(Analog Stereo)
Remote control Remote Control Battery
Power cord
This operation manual
and warranty card
AC Power Converter
TMTM
/
+
-
Earphones Car Adapter External battery

If the remote control functions better when it is closer to

the unit, the battery may be running low.
In case of any leakage from the battery, dispose of the

battery right away and avoid touching the chemical
discharge. Make sure to clean the remote control’s battery
compartment before installing a new battery.
Operating the remote control
When using the remote control, be sure to stay within a 30
degree angle of the sensor on the receiver. Keep in mind that
any obstructions between the remote control and the receiver
will affect performance.
GETTING STARTED
Notes on battery
2
Place the battery into the holder as pictured below
with the POSITIVE SIDE (marked on Battery as “ +”)
facing upwards and insert into the remote control to
complete the battery installation.
30 30
2
7
2
+
Battery
+
To use the remote control
To replace the remote control’s battery, the battery holder must
be removed. Be sure to take note of the polarity marking on the
battery. The " + " side must face the bottom of the remote (the
side without any buttons).
To access the Battery, remove the Battery Holder
from the remote control. To remove the battery
holder, use your thumbnail to squeeze the Release
Clip in toward the center, while simultaneously
pulling the Handle out with your index fingernail, as
depicted below:
1
6
Replacing the remote control battery
The DVD player comes complete with a remote control. Just
pull the plastic tab in the remote control to activate the battery.
The plastic tab - which covers the battery terminals - extends
the life of the battery. *Please note that some models will not
include this plastic tab. If so please refer to the next section for
battery installation. Remote Control
Plastic Tab
Pull
Remote Control
Handle
Release Clip
Battery Holder
TMTM
/
+
-

REMOTE CONTROL FUNCTIONS
SETUP
Accesses the on-screen Setup Menu
for settings adjustment.
DISPLAY
Shows the elapsed time and other
information during playback of a
disc.
GOTO
Press to navigate to a specific
chapter. Follow with corresponding
number key.
PROGRAM
Create a custom play list of selected
tracks and sequence.
SUBTITLE
Selects available subtitles on DVD.
BRIGHTNESS
Use to adjust the brightness level.
FAST FORWARD
Scan in fast forward on DVD's and
other discs.
PLAY/PAUSE
Use to play a disc, chapter or track.
Press to pause audio track play or
video to a still frame. Press again to
advance frame by frame ( DVD ) or
resume playback ( Audio CD ).
STOP
Press once to stop current disc play
but holds resume location. Press
again to completely stop play - also
required for some setup functions.
SKIP NEXT
Press to skip to the next chapter or
track.
SLOW
Press to advance slow.
ZOOM
Press to magnify and shrink the
screen with DVD discs.
AUDIO
Selects an audio track on DVD or
VCD discs.
MUTE
To turn off sound. Press again to turn
sound back on.
VOLUME
Press the “ + “ key to increase the
volume level and “- “ key to
decrease.
1POWER
Turns the DVD player on or off.
LCD
Press to cycle through and select the
display mode you wish, includes full,
zoom, wide, normal or off.
TITLE
Accesses Menus on DVD Discs.
MENU / PBC
Accesses the Title menu on DVD
Discs. With VCD discs, turns the
PBC function On/Off.
BOOKMARK
Press to store the current point on the
disc as a bookmark that can be
accessed quickly without searching.
ANGLE
Selects between the multiple angle
views on supported DVD's.
FAST REVERSE
Scan in fast reverse on DVD's and
other discs.
ARROWS
Use to navigate disc menus, on-screen
setup menu, etc.
ENTER
Selects options in menus.
SKIP PREVIOUS
Press to skip to the previous chapter or
track.
RETURN
Returns to the previous menu
accessed in DVD mode.
REPEAT 1/ALL, A-B
Used with DVD discs, 1/ALL repeats
a chapter, title or disc. A-B sets the
beginning and ending of a time
segment to repeat.
NUMBER KEYS
Use to enter numeric values when
using GOTO and more.
CLEAR
Clears input when entering values.
MONITOR
Use to switch between selectable video
input / output. Includes regular unit
viewing, unit to external monitor and
composite input from external device.
2
3
4
5
6
7
8
9
10
11
12
13
14
15
19
20
21
22
23
24
25
28
26
27
29
30
17
18
TMTM
POWER
0C
9
6
5
4
3
ENTER
PBC
LCD
8
7
GOTO
2
1
A-B
1/ALL
MUTE
AUDIO
ZOOM
RETURN REPEAT SLOW
STOP
PLAY/PAUSE
BRIGHTNESS
PROGRAM
BOOKMARK SUBTITLE
ANGLE
DISPLAY
MENU
TITLE
MONITOR
SETUP
11
1
2
3
4
5
6
7
8
11
9
10
12
12
14
15 21
16
20
19
18
17
21
22
23
24
25
26
27
28
29
30
16
VOLUME
13
8

FRONT PANEL FUNCTIONS
9
LCD SCREEN PLAY / PAUSE / ON
The DVD Player’s LCD Screen. Multifunction button controls the play, pause
and power ON function of the unit.
DISC DOOR
Open disc door to insert discs for playback. NEXT / FAST FORWARD
With optical discs, press to advance to the
DISC DOOR BUTTON next chapter or track.
Push to open the disc door.
PREVIOUS / FAST REVERSE
LCD BUTTON With optical discs, press to return to the
Closing the LCD screen activates the button previous chapter or track.
to turn off the LCD display.
VOLUME
MONITOR Use the “ + “ or “ - “ buttons to control the
Change the Audio Video Input / Output volume level during playback.
mode.
ENTER
MENU / PBC Use to select options in menus.
Accesses the root menu on discs.
ARROW BUTTONS
FUNCTION Use to navigate disc menus, on-screen setup
Press to enter the Function Menu. menu, etc.
OFF
Use this button to power OFF the unit.
1
2
3
4
5
8
9
10
13
12
6
7
11
14
2
1
4
6
5
7
8
9
10
11
12
14
13
3

10
Using the function menu
The Function key - located on the front panel of the unit -
allows you to access various functions including the Setup
Menu and battery status among others.
Press the Function Key on the front panel of the unit
to access the on-screen Function Menu. The
Function menu will automatically disappear from the
screen after 10 seconds of inactivity.
1
FUNCTION
Use the Arrow Keys on the front panel of the unit or
the remote control to navigate the Function Menu.
The available options include ;
2
Function Menu
- Battery status
- Setup Menu
- Brightness Level Adjustment
- Display Menu
FRONT PANEL FUNCTIONS
- LCD Monitor Mode

EXTERNAL BATTERY PACK
11
Preparing the external battery pack for use
The DVD player comes complete with an external battery pack
to allow playback without any AC power source.
Before using the battery pack the first time, you must
first charge it. Connect the battery pack to the AC
adapter as shown below. The LED will turn green
when fully charged.
1
Using the battery pack
Attaching the battery pack to the DVD player is an easy few
steps.
Turn the unit upside down. Align the battery pack’s
guides to the unit’s slots.
1
To secure the battery pack to the unit, ensure the
battery pack locks onto the unit. To lock the battery
pack into place, gently slide the battery pack toward
the front on the unit until there is an audible click.
2
Plug the battery pack’s power plug firmly into the
unit’s ‘DC IN 9V’ power jack as shown below.
3
Fully Charged
Three Fourth Charge Reminding
Almost out of Power
Remaining Charge is getting low
100%
70%
50%
20%
DC IN 9V BATTERY Press the Display key on the remote control to check
the battery pack status.
4
POWER LCD
GOTO
PROGRAM
BOOKMARK SUBTITLE
ANGLE
DISPLAY
MENU
TITLE
MONITOR
SETUP
OR
FUNCTION MENU
Press the RIGHT ARROW button, then press the ENTER
button to confirm the BATTERY Menu selection from
the FUNCTION Menu. Use the table below as a guide to
the current battery pack status. If the front panel power
indicator is blinking, the battery pack has less than 10
minutes of charge remaining.
DVD PLAYER
SLOTS
BATTERY PACK
POWER CORD
If the remote control is not handy, press the FUNCTION
button on the front panel of the player to bring up the
FUNCTION MENU.
UNPLUG
CORD
BEFORE
CHARGING
PACK
LED
!
Do not recharge the battery pack when connected to the

DVD Player at any time.
Unplug the battery pack’s power connector to the unit

BEFORE recharging.
!
Important

PHU
S
Detaching the external battery pack
Detach the battery pack from the DVD player if you will be storing the unit for an extended period of time. The unit will continue to
consume power while the battery pack is attached and turned off. Over discharge of the battery pack will lead to reduced service life
time. Ensure the unit is turned off before detaching the battery pack.
Slide the latch toward the front of the unit. Hold the
tab in this position.
1Gently slide the battery pack towards the back of the
unit. Lift the battery pack from your unit.
2
EXTERNAL BATTERY PACK
12
Lift battery pack
upwards and away
from the unit.
!
Recharge your battery pack when the battery status is

less than 25%.
Do not charge the battery pack when connected to the

DVD Player unit.
Unnecessary charging will reduce the battery pack

service lifetime.
When the battery pack is being charged, the LED will

glow red.
After successfully charging the battery pack, the LED will

glow green.
The time to charge the battery pack is normally 3 to 4

hours. Do not charge for more than 8 hours.
!
Important
1
2
2

INTERNAL BATTERY PACK (OPTIONAL)
Preparing the internal battery
The optional Internal Battery Pack extends the playing time by
over an hour. The optional internal battery pack must be
charged with the charger before use.
Before using the battery pack the first time, you must
first charge it. Connect the AC adapter to the internal
battery charger as shown below. The POWER LED
indicator is illuminated red.
1
Insert the charged battery pack into the unit’s battery
bay. Slide the battery pack towards the back of the
unit. Gently press the back end of the battery pack
downwards.
2
Installing the Internal battery pack
This battery must be charged before installation.
Turn the DVD player upside down as shown below. To
remove the battery door, press down and slide
downwards on the tab to disengage the lock. Slide the
battery door downward.
11
Insert the internal battery into the charger as shown
below. The CHARGING LED will glow red indicating that
charging has begun. When the CHARGING FINISHED
LED turns green, the charging cycle has been
completed.
12
Power Charging Charging
Finished
13
To p
Insert the battery
pack as shown.
The battery
contacts - gold in
color - must be
oriented as
shown. Replace
the cover in the
reverse order as
shown above.
Slide
Down
1
2
Top

14
Detaching the internal battery pack
Removal of the battery pack from your unit for recharging is
the reverse of installation.
Turn the DVD player upside down as shown below. To
remove the battery door, press the tab to disengage the
lock. Slide the battery door downward and off.
11
Gently lift up the back end of the battery pack.
Remove the battery pack from your unit. Replace the
battery compartment cover back onto the unit.
2
INTERNAL BATTERY PACK
!
Recharge your battery pack when the battery status is

less than 25%.
Unnecessary charging will reduce the battery pack

service lifetime.
!
Important
Lift End
Pull Out
2
Upwards
To p 1

DVD PLAYER CONNECTIONS
15
Right Side
Rear Panel
34
1
67
Front Panel
5
EARPHONE JACK POWER SWITCH
Connect to the included earphones for a private listening Main power to the unit. Must be ‘ON’ to power on the unit
environment. from the top panel or remote control.
POWER CORD SOCKET - DC IN 9V LCD SCREEN RELEASE LATCH
Main power socket for the unit. Connect to the car adapter Slide release hatch in the direction of the arrow to release the
or AC power adapter. LCD screen locking mechanism.
AUDIO IN / OUT - OPTICAL DIGITAL IN / OUT REMOTE CONTROL RECEIVER
Use the provided analog stereo INPUT / OUTPUT cable to The remote control receiver for the unit. Keep the receiver
make a connection between the unit and an audio output free from obstructions to allow for proper operation.
device. The most common connection made is to a TV. You STATUS LED
can also use a mini - optical cable (not included), to connect The Status LED will change colors when selecting the various
to a receiver or other device with a 5.1 channel decoder. video modes.
This is a coded digital signal.
VIDEO IN / OUT
Able to support Component, S-Video or Composite video
INPUT / OUTPUT for TVs with matching input. Use the
provided video cables for this connection.
1
2
3
4
5
6
7
2
8

USING DVD PLAYER CONNECTIONS
16
Using the car adapter
The DVD player comes complete with a car adapter to connect
to your car’s power receptacle.
To use the car adapter in your vehicle, simply plug in
the car adapter into the car’s power receptacle as
depicted below and the other end into the unit’s ‘DC
IN 9V’ connector.
1
!
Do not operate the unit or view the video output while

operating a motor vehicle.
Place the unit in a secure position before operating the

vehicle.
Do not use the car adapter to charge the battery pack.

The car adapter can only be used during playback of

discs.
Important
Using the power adapter
The DVD player comes complete with a power adapter to
charge the battery pack or to power the unit when attached to
an AC wall outlet.
To use the power adapter, simply connect the
appropriate end into an electrical wall outlet as
depicted below and the other end into the unit’s “DC
IN 9V’ connector.
1
!
Once power is applied, with the POWER button set to ON,

the unit will be in STANDBY Mode.
Do not charge battery pack and play disc concurrently.

Disconnect AC power adapter from wall when not in use.

!
Important
Using the earphones
The DVD player comes complete with earphones when you
prefer a private listening environment.
Insert the earphones into the earphone jack on the
right side of the unit. Adjust the volume level with
the volume “+” or “-” keys on the remote control or
front panel to a low output level. Place the earphone
buds into your ear. Increase the volume to your
desired volume level.
1
Excessive loud

usage of
headphones
could cause
damage to your
hearing.
Turn down the

volume before
connecting to
the unit, then
raise the
volume level to
your comfort
level.
No sound will

come out from
the unit’s
speakers once
the headphones
are connected.
!
!
Important
OROR

Connecting the video output to your TV
In order to use this DVD player with your TV, a few cable connections are necessary. The capabilities of your TV will determine the
connections you can use. There are 3 possible connection types:
Composite Video - The most widely used connection.

S-Video - A higher quality connection that requires the provided S-Video connector and an S-Video capable TV.

Component Video - The highest quality video connection. Supported on high-end televisions.

Composite Video
Input Jack
Composite Video (Typical connection)
Use the Composite / S - Video and Stereo Audio cable for connection to TVs with a standard video input as shown below. This is the
most widely used type of connection on TV’s. The composite connector is colored yellow, and is normally accompanied by stereo
audio inputs, colored red and white for stereo channels right and left, respectively.
Composite / S - Video Cable
First, use the supplied Composite / S - Video cable to
connect to the composite video input jack on your TV.
This is normally a yellow-colored connector as pictured
below.
2If you wish to hear sound through the TV, connect the
included red and white analog stereo cable.
1
4On your TV, select the video input. This is normally done
by selecting “Video 1” or “Video Input” with the remote
control. On some TVs, this is done by selecting a
particular channel.
6You should now see the DVD players' splash screen on
the TV.
V
TV with
Composite
Video Input
(Typical
Connection)
VIDEO INPUT
R
STEREO AUDIO IN
L
!
If your TV does not have a composite video-in jack like that pictured above, you cannot connect this
unit directly. If this is the case, check to make sure your TV has at least a coaxial connector (used for
antenna/cable TV/VCR/etc.) such as that pictured to the right. If this is the case, you can use an RF
Modulator to convert this unit’s video out to the coaxial connection on your TV. RF Modulators are
available at major electronics retailers.
Antenna/cable TV
coaxial connector
on older TVs
RF Modulator
Important note for older TV models
Older TV with
coaxial
antenna/cable
connector
DVD Player
11
10
AUDIO / VIDEO CONNECTIONS
17
Analog Stereo Cable Stereo Audio
Input Jacks
1
11
12
3Turn on the TV and DVD Player.
5Press the “Monitor” key on the front panel of the DVD
player one time to change the video output mode.
Rear Panel
VIDEO OUTPUT
11
12

AUDIO / VIDEO CONNECTIONS
S-Video
Input Jack
S-Video
This is a higher quality connection than standard composite video. The S-Video connector is distinguishable by its 4 pins, as shown
below. If your TV has an S-Video input, it’s recommended that you use this type of connection for better picture quality.
Component Video & Progressive Scan
The highest quality video connection, component video, requires the Component Video Cable, with separate connectors for the Y,
Pb/Cb, and Pr/Cr signals. To use the progressive scan option on this unit, you’ll need to use the component video output. Using the
component video output requires these steps:
Connect the optional Component Video cable to the
unit’s Video Output connection. Connect the opposite
end to your television’s Component Video input
connection.
4Press the MONITOR key on the remote control or front
panel to change the Video Output to your TV. The unit’s
splash screen will now appear.
1
S-Video Cable
Connect the Composite / S-Video cable to the unit’s
Video Out connector and the black S-Video connector
to the corresponding S-Video input on your TV.
2Turn on the DVD Player.
1
3On your TV, select the S-Video input. This is normally
done by selecting “Video 2” or “AV2” with the remote
control. On some TVs, this is done by selecting a
particular channel.
4Press the “Monitor” key on the front panel of the DVD
player once to change the video output selection.
TV with
S-Video Input
5
S
VIDEO
INPUT
1
You should now see the DVD players' splash screen on
the TV.
POWER LCD
GOTO
PROGRAM
BOOKMARK SUBTITLE
ANGLE
DISPLAY
MENU
TITLE
MONITOR
SETUP
Component
Video Cable
(not included)
Component Video
Input Jacks
Y Pb/Cb Pr/Cr
2Power on your TV and the DVD player.
3On your TV, select the Component Video input. This is
normally done by selecting “Video 2” or “AV2” with the
remote control. On some TVs, this is done by selecting a
particular channel.
TV with
Component
Video Input /
Progressive Scan
capability. VIDEO
INPUT
Y Pb Pr 1

AUDIO / VIDEO CONNECTIONS
If you are using a Progressive Scan TV, change the
VIDEO MODE to P-SCAN. At this time you will be
prompted twice to confirm this change in settings. In
each case, press the LEFT ARROW key once and to
confirm each new selection, press ENTER each time.
47
Video Setup Page
.. ..
Set the video mode
Video Setup Page
.. ..
TV Display
TV Type
Video Output
Video Mode
P-Scan Mode
Video Quality
Wide
NTSC
YUV
Auto
Interlaced
P - Scan
19
!
If the VIDEO MODE setting in the setup is set to P-SCAN
but you are not using a progressive scan-capable TV,
you will loose video. If this happens, reset the video to
the default Interlaced mode, which is used by most TVs.
To reset the TV MODE, press “DISPLAY - 1 - 2 - 3” on the
remote control.
Resetting the video output
5Press SETUP and change the VIDEO OUTPUT setting
(Submenu of VIDEO SETTINGS) to YUV. At this time you
will be prompted to confirm this change. Press the LEFT
ARROW key once to select ‘Enter’, and then press the
ENTER key on the remote control to confirm.
18
Video Setup Page
.. ..
Video Setup Page
.. ..
Incorrectly setting this item can
corrupt the picture. If the picture
becomes distorted or unusable, wait
a few seconds and the setting will be
restored to its previous value.
Press ‘Enter’ to continue
Enter Cancel
YUV Warning
Video Setup Page
.. ..
Video Setup Page
.. ..
This setting has been changed.
Do you want to keep the new setting ?
Yes No
YUV Warning
You will be prompted a second time to confirm your
selection. Press the LEFT ARROW key once to select
‘Yes’ then press the ENTER key on the remote control to
confirm your selection. You must respond within 4
seconds to this prompt otherwise it will disappear from
the screen. If this occurs, please return to step 5 and
restart these steps.
Video Setup Page
.. ..
Set the video output
Video Setup Page
.. ..
TV Display
TV Type
Video Output
Video Mode
P-Scan Mode
Video Quality
Wide
NTSC
YUV
Auto
46
POWER LCD
GOTO
PROGRAM
BOOKMARK SUBTITLE
ANGLE
DISPLAY
MENU
TITLE
MONITOR
SETUP

Audio Output Connections
AUDIO / VIDEO CONNECTIONS
Receiver with Digital
Audio Input
The DVD player features a variety of audio line outputs for connection to a TV or receiver.
Use the included Audio cable to connect the stereo analog audio outputs for connection to a TV or recording equipment.

Or you can use the digital optical audio output to send an encoded digital bit stream to a receiver, suitable for receivers with

Dolby Digital decoding capability. This output requires a special mini optical digital cable, not included *.
OPTICAL DIGITAL AUDIO IN
R
STEREO AUDIO IN TV, receiver
or recording
equipment
with stereo
audio in
L
20
* EXAMPLE OF AN
OPTICAL DIGITAL CABLE WITH
A MINI OPTICAL ADAPTER
(NOT INCLUDED)
OROR
* EXAMPLE OF AN
OPTICAL DIGITAL
CONNECTOR
ON A STEREO RECEIVER
(NOT INCLUDED)
