CyberResearch CPPC CEL-20-X User manual

®
CPPC Series
PICMG Single Board Computers
CPPC CEL-20-X: 2.0GHz Celeron CPU
CPPC CEL-28-X: 2.8GHz Celeron CPU
CPPC P4-24-X:2.4GHz Pentium 4 CPU
CPPC P4-32-X: 3.2GHz Pentium 4 CPU
CPU Cards
USER’S MANUAL
VER. A1 • DEC 2004
No part of this manual may be reproduced without permission
CyberResearch®, Inc.
www.cyberresearch.com
25 Business Park Dr., Branford, CT 06405 USA
203-483-8815 (9am to 5pm EST) FAX: [phone]

CyberResearch®CPU Cards CPPC Series
©Copyright 2005
All Rights Reserved.
December 1, 2004
The information in this document is subject to change without prior notice
in order to improve reliability, design, and function and does not represent
a commitment on the part of CyberResearch, Inc.
In no event will CyberResearch, Inc. be liable for direct, indirect, special,
incidental, or consequential damages arising out of the use of or inability
to use the product or documentation, even if advised of the possibility of
such damages.
This document contains proprietary information protected by copyright.
All rights are reserved. No part of this manual may be reproduced by any
mechanical, electronic, or other means in any form without prior written
permission of CyberResearch, Inc.
Trademarks
“CyberResearch,” and “CPPC Series,” are trademarks of CyberResearch,
Inc. Other product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of
their respective companies.
• NOTICE •
CyberResearch, Inc. does not authorize any CyberResearch product for
use in life support systems, medical equipment, and/or medical devices
without the written approval of the President of CyberResearch, Inc. Life
support devices and systems are devices or systems which are intended
for surgical implantation into the body, or to support or sustain life and
whose failure to perform can be reasonably expected to result in injury.
Other medical equipment includes devices used for monitoring, data
acquisition, modification, or notification purposes in relation to life
support, life sustaining, or vital statistic recording. CyberResearch
products are not designed with the components required, are not subject
to the testing required, and are not submitted to the certification required
to ensure a level of reliability appropriate for the treatment and diagnosis of
humans.
CyberResearch, Inc.iii
25 Business Park Drive P: [phone]; F: [phone]
Branford, CT USA www.cyberresearch.com

CPPC Series CyberResearch®CPU Cards
Intentionally Blank
iv ©Copyright 2004 CyberResearch, Inc.

CPPC Series CyberResearch®CPU Cards
CyberResearch, Inc.v
25 Business Park Drive P: [phone]; F: [phone]
Branford, CT USA www.cyberresearch.com
Introduction ........................................... 1
1.1 Unpacking CPPC Series..........................1
1.2 Description ..........................................3
1.3 Features .............................................3
1.3.1 Hardware Monitoring ..................................4
1.3.2 I/O Shield Connector..................................4
1.3.3 CPPC Series Overview ................................4
1.3.4 System Block Diagram ...............................5
1.4 Specifications.......................................6
Installation ............................................. 8
2.1 System Installation...............................8
2.1.1 CPU Installation.........................................8
2.1.2 Heat Sink & Retention Module Installation .....9
2.1.3 Memory Module Installation....................... 10
2.1.4 Setting Jumpers ...................................... 11
2.2 Board Layout ..................................... 12
2.3 Jumper Settings ................................. 13
2.4 Connector Description ......................... 14
2.5 Optional CPP AUDIO Audio Card ........... 28
AWARD BIOS SETUP ................................. 30
3.1 BIOS Instructions ............................... 30
3.2 Main Menu......................................... 31
3.3 Standard CMOS Features..................... 33
3.4 IDE Adapters ..................................... 36
3.5 Advanced BIOS Features ..................... 38
3.6 Advanced Chipset Features .................. 44
3.7 Integrated Peripherals......................... 47
3.8 Power Management Setup ................... 53
3.9 PnP/PCI Configurations ....................... 57
3.10 PC Health Status ................................ 59
3.11 Frequency/Voltage Control................... 61
3.12 Load Fail-Safe Defaults ....................... 62
3.13 Load Optimized Defaults...................... 62
3.14 Supervisor/User Password Setting ........ 63

CyberResearch®CPU Cards CPPC Series
vi ©Copyright 2004 CyberResearch, Inc.
3.15 Exit Selecting .......................................... 65

CPPC Series CyberResearch®CPU Cards
CyberResearch, Inc.vii
25 Business Park Drive P: [phone]; F: [phone]
Branford, CT USA www.cyberresearch.com

CyberResearch®CPU Cards CPPC Series
viii ©Copyright 2004 CyberResearch, Inc.

CPPC Series CyberResearch®CPU Cards
CyberResearch, Inc.1
Introduction
1.1 Unpacking CPPC Series
1. Remove the CPPC series unit from the box, check that the CPU card is
properly packaged in the plastic bag.
2. Check the contents of the carton box:
¡Single Board Computer ¡Installation Guide
¡Floppy ribbon cable ¡ATA-66/100 HDD ribbon cable
¡CD Driver ¡Printer & COM1 ribbon cable
25 Business Park Drive P: [phone]; F: [phone]
Branford, CT USA www.cyberresearch.com

CyberResearch®CPU Cards CPPC Series
2©Copyright 2004 CyberResearch, Inc.
¡K/B & M/S Y type cable ¡K/B extend to BP cable
(5-pins to 6-pins)
¡ATX power control cable ¡USB 2.0 cable (1 Set)
(4-pins to 4-pins)
¡S-ATA & Power cable
3. Optional Audio Card / Cable
¡CPP AUDIO Audio Card ¡Audio 9-pin round cable

CPPC Series CyberResearch®CPU Cards
CyberResearch, Inc.3
25 Business Park Drive P: [phone]; F: [phone]
Branford, CT USA www.cyberresearch.com
1.2 Description
The CPPC Series single board computer is optimized for socket 478
FC-PGA processor, supporting 800/533MHz Front Side Bus, and up to 2GB
DDR333/400 SDRAM. This board is based on the Intel®865G chipset and is
fully designed for a harsh industrial environment. The CPPC series is
800MHz FSB with chipset (GMCH) on-die enhanced Intel®Extreme
Graphics 2 and one 10/100/1000 Mbps Gigabit Ethernet controller. It is for
CTI and high-performance applications.
The other I/O function include two SATA ports, two serial ports, one
parallel port, two ATA100 IDE interface, one FDC interface, four USB 2.0
ports, Watchdog Timer and PS/2 Keyboard & Mouse.
The key components of this board were chosen with long-term
availability in mind.
1.3 Features
¡
Intel®Pentium®4 / Celeron®processor
¡
Intel®865G + ICH5 AGPset
¡
Supports 2GB DDR333/400 SDRAM (Max.) Memory
¡
Front Side Bus Frequency: 533 / 800 MHz
¡
Chipset integrated AGP8X graphic function
¡
Single 10/100/1000 Mbps Gigabit Ethernet using Intel®82547GI chip
¡
Software programmable watchdog timer
¡
Hardware Monitoring
¡
AC97 Audio pin-header (Optional CPP AUDIO audio card)

CyberResearch®CPU Cards CPPC Series
4©Copyright 2004 CyberResearch, Inc.
1.3.1 Hardware Monitoring
Hardware monitoring allows you to monitor various aspects of your
systems operations and status. The features include CPU temperature,
voltage and RPM of fan.
1.3.2 I/O Shield Connector
The SBC is equipped with an I/O bracket. Please use the appropriate
I/O shield (figure 1).
CPPC Series
KB
MS
Figure 1: I/O bracket layout
1.3.3 CPPC Series Overview
Function / Model CPPC
¡
Chipset i865G
¡
SCSI function /
¡
LCD function /
¡
VGA function (i865G)
¡
Gigabit Ethernet function 
¡
AC97 Audio Pin-header (Optional CPP AUDIO Audio Card)
¡
Two EIDE interface 
¡
Two SATA interface 
¡
One Floppy interface 
¡
Two Serial, One Parallel 
¡
Four USB 2.0 ports 

CPPC Series CyberResearch®CPU Cards
CyberResearch, Inc.5
1.3.4 System Block Diagram
P4 Socket 478-pins ClockVRM
DATACTRLADDR
GMCH (865G)
932 FC-BGA
ICH5
460 uBGA
DDR333/400 X1
CRT
Super I/O
W83627HF
ATA100
USB
IDE Primary
IDE Secondary
USB Port 0/1
USB Port 2/3
SATA Port1
SATA Port2
FWH
Keyboard
Mouse
COM Port
LPT Port
Floppy
iTE Bridge
IT8888F
ISA BUS
PCI BUS
PICMG SLOT
10/100/1000
Base-TX
82547GI
CSA
DDR333/400 X1
AGP 8X
SATA
Figure 2: System Block Diagram
25 Business Park Drive P: [phone]; F: [phone]
Branford, CT USA www.cyberresearch.com

CyberResearch®CPU Cards CPPC Series
6©Copyright 2004 CyberResearch, Inc.
1.4 Specifications
CPPC:
¡
Processor:
-Socket 478 processors, for Intel®Pentium®4/ Celeron®processor
CPPC CEL-20-X: 2.0GHz Celeron
CPPC CEL-28-X: 2.8GHz Celeron
CPPC P4-24-X: 2.4GHz Pentium 4
CPPC P4-32-X: 3.2GHz Pentium 4
¡
Chipset:
- Intel®865G + ICH5 AGPset
¡
Front Side Bus:
- 400 / 533 / 800 MHz
¡
DRAM Module:
- 2 x 184pins DIMM for DDR SDRAM up to 2GB (max.)
- Support DDR 266 / 333 / 400 SDRAM
¡
VGA Function:
- Intel®865G chipset integrated graphic function
¡
Gigabit Ethernet Function:
-Intel®82547GI Gigabit Ethernet controller
- For 10 / 100 / 1000 Base-TX Ethernet
¡
Audio Function: (Optional)
-AC97 audio interface, by option audio card --- CPP AUDIO
-Onboard 9-pins (pin-header) interface
¡
SATA Function:
- Two S-ATA ports, support data transfer rates up to 150MB/s
¡
Onboard I/O:
- On-Chip I/O integrated with K/B, Mouse, FDD, Parallel and Serial
controller

CPPC Series CyberResearch®CPU Cards
CyberResearch, Inc.7
25 Business Park Drive P: [phone]; F: [phone]
Branford, CT USA www.cyberresearch.com
¡
Onboard PCI / IDE:
- Intel®ICH5 South Bridge controller
- PCI Rev2.2 Compliant
- ACPI Compliant Power Management
- PCI Bus IDE Port with PIO /ATA-100 x 2 (Up to 4 Devices)
¡
Bracket I/O Connectors:
- D-Sub Serial port (COM1)
-Single RJ-45 connector
-15-pins D-Sub VGA connector
- PS/2 style Mouse or Keyboard connector
¡
USB 2.0 Ports:
- 4 x USB 2.0 ports (pin-header)
¡
BIOS:
- Award Plug & Play BIOS
¡
Extended Function:
- Hardware monitoring function
-IrDA by pin-header
¡
Form Factor:
- 13.3” x 4.8” (338 x 122mm)
¡
Weight:
- 0.93lb (420g) --- CPPC

CyberResearch®CPU Cards CPPC Series
8©Copyright 2004 CyberResearch, Inc.
Installation
2.1 System Installation
2.1.1 CPU Installation
Carefully follow the steps below to install the CPU:
1. Check and confirm you are installing the correct CPU type and pin
numbers (figure 3).
2. Lift the releasing lever of the Socket 478.
3. Align the pins of the CPU against the pinholes of the Socket 478. Be
sure to pay attention to the orientation of the CPU.
Figure 3: CPU Socket
4. Push down the CPU into the Socket 478.
5. Push down the release lever and lock it against the key hook.
6. Hook the hole in ZIF clip for the CPU cooling fan onto the notch on the
socket 478.
7. Place the CPU cooling fan atop the CPU surface.
8. Push down the opposite side of the ZIF clip and hook it.
9. Slide the head of the clip to left and lock it.
10. Connect the cooling fan cable to the socket. Be careful not to place the
cable on the CPU cooling fan.

CPPC Series CyberResearch®CPU Cards
CyberResearch, Inc.9
Removing a CPU:
1. Before removing the CPU, turn off the CPPC Series power; then wait for
about 3 minutes until the heatsink and the CPU cool down.
2. To remove the CPU, lift the releasing lever of the Socket 478.
Note: The CPU and the heat heatsink are hot; they may cause
burns.
To remove the CPU, reverse the installation steps.
2.1.2 Heat Sink & Retention Module Installation
It is highly recommended that only CPPC Heat Sink + Fan (figure 4),
designed for use in the chassis be used -- the use of other heat sinks,
including those boxed with CPUs, may result in damage to the CPPC SBC.
Make sure that good contact is made between the processors and the
heat sinks. Insufficient contact, incorrect types of heat sinks, fans, or thermal
compound used or improper amount of thermal compound applied on the
CPU die can cause the processors to overheat, which may crash the system.
The Retention Module can prevent the board to crooked, so user must
add the Retention Module to hold up the weight of Heat Sink & Fan.
Heat Sink & Fan
(For P4 processor only)
InstallationRetention Module
(For P4 Heat Sink & Fan)
Figure 4: Heat Sink Installation
25 Business Park Drive P: [phone]; F: [phone]
Branford, CT USA www.cyberresearch.com

CyberResearch®CPU Cards CPPC Series
10 ©Copyright 2004 CyberResearch, Inc.
2.1.3 Memory Module Installation
Figure 5 display the notch marks and what they should look like on your
DIMM memory module.
DIMMs have184-pins and two notches that match with the onboard
DIMM socket. DIMM modules are installed by placing the chip firmly into the
socket at a 90-degree angle and pressing straight down (figure 6) until it fits
tightly into the DIMM socket.
Figure 5: DIMM Memory and 184-pins Socket
Figure 6: Memory Installation
Carefully follow the steps below in order to install the DIMMs:
1. To avoid generating static electricity and damaging the DIMM, ground
yourself by touching a grounded metal surface or using a ground scrap
before you touch the DIMM.
2. Do not touch the connector of the DIMM. Dirt residue may cause a
malfunction.
3. Hold the DIMM with its notch to the front side of the CPPC Series and
insert it completely into the socket. A DIMM should be inserted into the
inner socket first. Guiding the hole at each end of the DIMM over the
retaining post at each end of the DIMM socket.
4. If you install two DIMMs, install the second DIMM using the same
procedure as above.
