CycleSafe BS2-S2P User manual

RELEASE DATE: BY:
REVISION DATE: REV
PRODUCT NAME:
PRODUCT NUMBER:
ASSEMBLY INSTRUCTIONS
SCOPE:
This installation instruction will describe how to assemble a two-top shelter and
secure it to a solid base.
Tools Needed
Carpenter's Level 3/16" Hex Wrench 3/8" Concrete Drill
Carpenter's Square 7/32" Hex Wrench Concrete Epoxy (optional)
Power Drill Motor 1/2" Socket or Wrench Hammer Drill Motor
Button Head Carriage Hex Head Flanged Anchor
Cap Screw Bolt Screw Lock Nut Bolt
Washer
14-Oct-11
ALWAYS OBSERVE POSTED SAFETY GUIDELINES
WHEN ASSEMBLING THIS PRODUCT. ALWAYS WEAR SAFETY GLASSES
Geri Mohr
A
Basic Starter Shelter
17005 (BS2-S2P)
Lock
WI4.9.044-A Shelter (17005) Installation Instructions.xlsx
Printed: 10/19/2011
CONTROLLED DOCUMENT
Page 1 of 6
FM4.5.002
Rev -

RELEASE DATE: BY:
REVISION DATE: REV
PRODUCT NAME:
PRODUCT NUMBER:
ASSEMBLY INSTRUCTIONS
14-Oct-11
Geri Mohr
A
Basic Starter Shelter
17005 (BS2-S2P)
WI4.9.044-A Shelter (17005) Installation Instructions.xlsx
Printed: 10/19/2011
CONTROLLED DOCUMENT
Page 2 of 6
FM4.5.002
Rev -

RELEASE DATE: BY:
REVISION DATE: REV
PRODUCT NAME:
PRODUCT NUMBER:
ASSEMBLY INSTRUCTIONS
14-Oct-11
Geri Mohr
A
Basic Starter Shelter
17005 (BS2-S2P)
1 Mount (2) pair of LH (17149) and
RH (17150) panel brackets to the
stringers (17123) using 3/8" screws (17111)
and lock washer (17041).
2 Separate the four legs from the packaging.
There are (4) common legs (17128).
Top holes on the legs need to face outward.
3 Using the 3/8" screw (17111) and
lock washer (17041) locate and fasten
the stringer (17123) to the front/rear legs sets at
Step - 2 the "U" shaped saddle on top of the legs
4 Locate and mount the Cross Brace (17105)
to one set of Leg/Stringers using
3/8" screws (17111) and lock washer (17041).
Stand up one set of Legs/Cross Brace and
mount to the remaining set of Legs/Stringer
Fasten together using the 3/8" screws (17111)
and lock washers (17041).
The framework should stand by itself
SQUARE THE LEGS AND STRINGERS BEFORE TIGHTENING
5 Adjust the leg spacing so they are all on the same
outside dimension, including corner to corner
ALWAYS OBSERVE POSTED SAFETY GUIDELINES
WHEN ASSEMBLING THIS PRODUCT. ALWAYS WEAR SAFETY GLASSES
Step - 3
Step - 4
Step - 1
Step - 5
WI4.9.044-A Shelter (17005) Installation Instructions.xlsx
Printed: 10/19/2011
CONTROLLED DOCUMENT
Page 3 of 6
FM4.5.002
Rev -

RELEASE DATE: BY:
REVISION DATE: REV
PRODUCT NAME:
PRODUCT NUMBER:
ASSEMBLY INSTRUCTIONS
14-Oct-11
Geri Mohr
A
Basic Starter Shelter
17005 (BS2-S2P)
6 Locate (2) Right Hand Corner Braces (17161) and
(2) Left Hand Corner Braces (17160).
Using 3/8" screws (17111) and lock washers (17041)
fasten the Corner Braces to the framework.
Left Corner Brace
ALWAYS OBSERVE POSTED SAFETY GUIDELINES
WHEN ASSEMBLING THIS PRODUCT. ALWAYS WEAR SAFETY GLASSES
Left Corner Brace
Right Corner Brace
Right Corner Brace
Step - 6
WI4.9.044-A Shelter (17005) Installation Instructions.xlsx
Printed: 10/19/2011
CONTROLLED DOCUMENT
Page 4 of 6
FM4.5.002
Rev -

RELEASE DATE: BY:
REVISION DATE: REV
PRODUCT NAME:
PRODUCT NUMBER:
ASSEMBLY INSTRUCTIONS
14-Oct-11
Geri Mohr
A
Basic Starter Shelter
17005 (BS2-S2P)
7 Locate the Horizontal Frame (10202) down
the middle of the leg framework using the
LH and RH brackets. Fasten with
5/16" Carriage Bolts (10208) and
Flange Nuts (10304).
DO NOT overtighten the fasteners to the SMC plastic
parts. They should only be wrench snug!
8 Locate the Fascia Assembly (17109) along the
outside of each leg framework. Using the 5/16" Carriage Bolts (10208)
and Flange Nuts (10304) attach to the LH and RH brackets.
WHEN ASSEMBLING THIS PRODUCT. ALWAYS WEAR SAFETY GLASSES
ALWAYS OBSERVE POSTED SAFETY GUIDELINES
Step - 7
Step - 8
WI4.9.044-A Shelter (17005) Installation Instructions.xlsx
Printed: 10/19/2011
CONTROLLED DOCUMENT
Page 5 of 6
FM4.5.002
Rev -

RELEASE DATE: BY:
REVISION DATE: REV
PRODUCT NAME:
PRODUCT NUMBER:
ASSEMBLY INSTRUCTIONS
14-Oct-11
Geri Mohr
A
Basic Starter Shelter
17005 (BS2-S2P)
9 Assemble the Top Panels (10301) to the
Horizontal Frame (10202) and the Fascia
Assembly (17109) using the 5/16" Hex
Screws (10222).
DO NOT overtighten the fasteners to the SMC plastic
parts. They should only be wrench snug!
10 Locate and mount both Side Walls (17118)
to the legs using the 3/8" screws (17111) and
lock washers (17041).
11 Layout anchor bolt pattern using assembled
shelter. Drill 3/8" diameter X 2" deep hole
through the base plates and insert the anchors
into holes (use the concrete epoxy for
additional holding strength). Bolt through
base plates into anchors.
12 Insert Nutsert Plugs (17156) into all open nutserts.
Step - 12
WHEN ASSEMBLING THIS PRODUCT. ALWAYS WEAR SAFETY GLASSES
ALWAYS OBSERVE POSTED SAFETY GUIDELINES
Step - 9
Step - 10
Step - 11
WI4.9.044-A Shelter (17005) Installation Instructions.xlsx
Printed: 10/19/2011
CONTROLLED DOCUMENT
Page 6 of 6
FM4.5.002
Rev -
