cycliq Fly6 CE601 User manual

Fly6 CE601 Instruction Manual
CE601

FLY6 CE601 – User Manual
2
What you get
Features
3
What’s in the box
23
Video resolution
4
Functions
23
Electronic image stabilisation
5
Changing your Fly6 CE settings
24
Looping function
6
Registering your Fly6 CE
25
Incident protection function
27
HomeSafe™ function
Read this before your set-up your Fly6 CE601
27
Bike Alarm
6
Disclaimer
27
Idle Mode
6
Warning against copyright infringement
28
Charging on the fly
7
Safety, operating and care information
28
Cycliq Quick Release System™
7
Caution
28
Nanotechnology
8
Fly6 CE layout
29
Master reset
Setting up your Fly6 CE601
Using your footage
13
Charging the battery
30
Accessing your footage
14
Battery level indicator
30
Video segment length
15
Formatting your microSD card
30
Editing footage
15
Inserting and removing microSD Card
31
The CycliqPlus mobile app
16
Mounting your Fly6 CE601
34
Join the Cycliq community
35
Technical data
Using your Fly6 CE
36
FCC compliance statement
20
Turning on your Fly6 CE
37
IC compliance statement
20
Turning off your Fly6 CE
38
Regulatory information
20
Light mode settings
21
Visual and audible alerts summary
22
Audio settings
22
Airplane mode
22
Garmin Connect IQ app – CycliqPlus Connect

FLY6 CE601 – User Manual
3
What you get
What’s in the box
1 x Fly6 CE601
1 x Narrow aero adapter
1 x Seat post mount
1 x Wide aero adapter
1 x Standard Velcro seat post strap
1 x Quick start guide
1 x Aero Velcro seat post strap
1 x Safety information and warranty sheet
1 x 7.5° Rubber spacer
1 x USB to USB-C cable
1 x 0° Rubber spacer
1 x Safety tether

FLY6 CE601 – User Manual
4
Functions
Full HD video and audio recording
Multiple light modes
Looping recording for set and forget use
Incident protection technology
6-axis image stabilisation
HomeSafe™ mode
Bike alarm
Idle mode
Audio recording
Ultra-wide viewing angle
Audible status alerts
Bluetooth and ANT+ connectivity

FLY6 CE601 – User Manual
5
Changing your Fly6 CE settings
Most of the primary functions of the Fly6 CE can be controlled using the buttons on the back of the device.
Summary
1. On the Fly6 CE device
All primary functions can be accessed using the two buttons on the device.
2. On the CycliqPlus mobile app
There are other settings and features that are only accessible via the CycliqPlus mobile app (iOS and
Android). Please download this from App Store or Google Play.
3. On your PC or Mac
This option offers similar functionality to the CycliqPlus mobile app. It is accessible on your PC or Mac
when you plug your Fly6 CE into your computer using the supplied USB cable. Alternatively insert your
microSD card into your computer’s microSD card reader.
Attention: Garmin users, an important note.
You can use your compatible Garmin bike computer to adjust some functions of the Fly6 CE. Our CycliqPlus
Connect app (different from the CyclicPlus mobile app) will allow you to change light modes, flashing sequences,
check the battery level of your Fly6 CE and turn the device on and off from your Garmin bike computer. See Garmin
Connect IQ on page 21.
To download our CycliqPlus Connect app, go to apps.garmin.com or visit Connect IQ via your Garmin device.

FLY6 CE601 – User Manual
6
Registering your Fly6 CE
We strongly advise that you register your Fly6 CE with Cycliq. Once registered, you’ll receive any notifications of
new software or firmware updates, new features and user tips. Registration also speeds up the process should you
require assistance with technical support or warranty queries.
To register your device, either visit cycliq.com/register, or use the CycliqPlus mobile app.
Read this before you set-up your Fly6 CE601
Disclaimer
Fly6 CE601 is designed specifically to be used as a rear ‘tail’ light with video and audio recording
capabilities for bicycles. While every effort has been made to ensure it will fit most bicycles on the
market, it may not fit all bicycles, depending on how the set up.
Please note that Cycliq, its subsidiaries and affiliates, and its distributors are not liable for any
consequential damages
arising from any malfunction of the device, including memory cards.
Warning against copyright infringement
The images recorded with this camera are intended for personal use. Do not record images that infringe
upon copyright laws without the prior permission of the copyright holder. Please be advised that in
certain cases the copying of images from performances, exhibitions, or commercial properties by means
of a camera or other device may contravene copyright or other legal rights even if the image was shot for
personal use.

FLY6 CE601 – User Manual
7
Safety, operating and care information
Following is important information which relates to the safe operation and care of your Fly6 CE. For
more information, please read your ‘Safety Information & Limited Warranty Guide’ contained in your
accessory box or visit cycliq.com for more information.
Caution
• Warning! No modification of this device is allowed.
• The Fly6 CE is not a toy: children should not play with the device.
• Do not look directly at the LED lights when operating.
• Do not immerse the Fly6 CE in water or any other liquid.
• Avoid dropping or knocking the Fly6 CE in any way.
• Pay attention and care when closing the waterproof port door.Please ensure it is closed completely prior
to operation.
• No liability can be accepted for any damage caused by non-compliance with these instructions or any
other improper use or mishandling.
• The Fly6 CE has a lithium ion battery. When disposing of this, it should be done in compliance with the laws,
rules and regulations of your relevant local authorities.

FLY6 CE601 – User Manual
8
Fly6 CE Layout – Front

FLY6 CE601 – User Manual
9
Fly6 CE Layout - Back

FLY6 CE601 – User Manual
10
Fly6 CE Layout – Side

FLY6 CE601 – User Manual
11
Fly6 CE Layout – Side

FLY6 CE601 – User Manual
12
Fly6 CE Layout – Top (flap closed)
Fly6 CE Layout – Top (flap open)

FLY6 CE601 – User Manual
13
Setting up your Fly6 CE601
Charging the battery
Your Fly6 CE comes partially charged. Before using it for the first time, please charge the device fully.
To charge:
1. Connect your device to a USB wall charger (not supplied) using the supplied USB cable.
2. The charge indicating light will illuminate showing that the device is charging.
3. When the device is fully charged the LED will illuminate green.
You can charge your Fly6 CE using the USB cable provided and your computer, however this will significantly
reduce the rate of charge. For the quickest charge, use a wall USB charger with a capacity of 10w 5V 2.0A.
Note
Fly6 CE601 is ‘Fast Charge’ compatible and accepts up to 2.1 amps. Accordingly, the time to charge from flat to fully charged varies
from 2 to 6 hours depending on the method of charging, i.e. mains power USB at 2.1 amps (not supplied) or computer USB (at as
little as 0.5A). For maximum battery life, fully discharge the battery before re-charging. Battery life will diminish over time and charge
cycles.

FLY6 CE601 – User Manual
14
Battery Level Indicator
When turning on your Fly6 CE, an audible battery status will sound, alerting you to the current battery level. This
will indicate whether you have enough power for your next ride. See below for audible notification guide:
4 Beeps
75% to <100% charged
3 Beeps
50% to <75% charged
2 Beeps
25% to <50% charged
1 Beeps
12% to <25% charged
3 Loud Long Beeps, then beeps every 60 seconds
<12% Charged
Feature: Cycliq HomeSafe™ function
Should your battery deplete to beneath 12% capacity during your ride, 3 long beeps will sound. This indicates the
camera on Fly6 CE has turned off (saving power), however the light will continue to function for a further 1.5
hours (approximately). See Cycliq HomeSafe™ function on page 26.

FLY6 CE601 – User Manual
15
Formatting your microSD card
Before you use a microSD card for the first time, you will need to format the card. We recommend doing this
through the CycliqPlus mobile app. It can also be done on PC or Mac.
To watch a video on how to format a microSD card on PC or Mac, visit cycliq.com/sdcard.
Inserting and removing microSD card
Your Fly6 CE is unable to record without a compatible microSD card installed. Insert a compatible microSD card
into the microSD card slot of your Fly6 CE device and press in gently until locked in place.
To remove your microSD card, gently press down on the SD card until it releases from the microSD card slot.
NOTE: MicroSD is not included with the Fly6 CE. Find out recommended microSD cards at cycliq.com/sdcard .

FLY6 CE601 – User Manual
16
Mounting your Fly6 CE
Your Fly6 CE comes with a seat post mount that features the Cycliq Quick Release System™. The seat post mount is
a strong, secure and reliable mounting mechanism. It is attached to the seat post using one of two different Velcro
seat post straps that allow for its use on traditional, or aero seat post configurations.
1. Insert either the standard or aero length Velcro seat post strap and pull all the way through until the clasp meets
the seat post mount, ensuring silicon-coated surface is facing outwards to grip your seat post.

FLY6 CE601 – User Manual
17
2. Select the appropriate spacer or adapter for your bike if required (0oor 7.5ospacers, and narrow or wide
aero adapters). Place the spacer or adapter between the Fly6 CE seat post mount and the seat post. Choose
the spacer or adapter that makes the Fly6 CE sit as vertical as possible for the best field of view.
3. While holding the seat post mount against your seat post, wrap the Velcro seat post strap around the seat
post and pull through the slot at the other end of the Fly6 CE.

FLY6 CE601 – User Manual
18
4. Pull Velcro strap tight, checking the seat post mount is secure.
5. Insert Fly6 CE into the mounting unit at a 45° angle, and complete a 1/8th turn until the device clicks into an
upright position. A distinctive ‘click’ sound confirms the unit has been locked in place.
You can easily remove Fly6 CE from your bike by removing it from the seat post mount with a 1/8th turn. You can
leave the mount on your bike for next use.

FLY6 CE601 – User Manual
19
Applying the safety tether to your Fly6 CE
On the back of the Fly6 CE are two rubber plugs covering the holes for the safety tether. Push a pin or end of a
paper clip through the open holes to loosen the plug, and remove.
Thread the thinner part of the tether through the hole, then thread the other end through the loop to secure the
tether. Then place the rubber plug back into the hole.

FLY6 CE601 – User Manual
20
Using your Fly6 CE
Turning on your Fly6 CE
Press and hold the power button for approximately 1 second until the rotating LED bezel illuminates and the ‘power
on’ chime is heard – then release. Power level ‘beeps’ will sound, signalling the battery status (see page 14 for Batter
Level Indicator).
Turning off your Fly6 CE
Press and hold the power button until the power off chime is heard. Power level ‘beeps’ will sound, indicating the
battery status (see page 14 for Batter Level Indicator).
Light mode settings
There are three light modes and three light dimming options:
• Light modes: Constant, Flash, Pulse and OFF. Toggle these using the power button.
• Dimming options: High, Medium, Low and OFF. Toggle these using the Q button.
Light modes can be accessed and customised via the CycliqPlus mobile app or via your PC or Mac.
Note:
There is also a ‘Light Off’ mode so you do not have to always have a light on. This is the default mode at power on out of the box. To
maximise battery life, select a dimmer flashing setting and turn off your Fly6 CE when not in use. Your light settings will be remembered
when the device is turned OFF/ON. Consider bicycle light regulations in your area when setting your light functions.
