CYCLOPS CarCam User manual

1. What’s in the Box
2. Installation
3. Before your journey
4. Safety
5. Protection on your journey
6. Protection you can trust
7. In the event of an accident
8. Problems?
9. Extras
10. Additional information

1. What’s in the box

2. Installation
Position the Cyclops CarCam on a firm surface to attach the CarCam
mounting accessories.
Choose either the suction cups or the stick-on plastic mount (semi-
permanent)….
Plug in the Car Charger….
Connect the opposite end of the Car Charger to the Cyclops CarCam….
Clean the windscreen and position the Cyclops CarCam in a suitable location
on that does NOT obscure driving vision.…
Check to see the RED RECORD light is flashing and the GREEN GPS
light is on (please SEE section 3)….

3. Before your journey
Install your Cyclops CarCam by following the installation instructions in section 2.
To switch ON your Cyclops CarCam connect the car charger as described in the installation section. When you
connect the Cyclops CarCam to the car charger, the four CLEAR lights situated at the front of the Cyclops CarCam
will illuminate for approximately 10 seconds.
Position and fix the Cyclops CarCam to the windscreen in your preferred driving position.
Installation is NOW complete!
Under normal operating conditions the RED RECORDING light will flash and the GREEN GPS light will illuminate.
The first time you start your Cyclops CarCam, the device may need a few minutes to determine your current position.
Whilst locating your position the GREEN GPS positioning light will continue to flash. Once located the GREEN GPS
positioning light will remain illuminated. Subsequently, your position will be found faster, normally within a minute.
To ensure good GPS reception, you should use your device outdoors in a vehicle. Sometimes, large objects such as
tall buildings can interfere with reception. In the event of location issues, drive to a clear area to install the device.
If you continue to experience problems please see section 8.
Never leave your Cyclops CarCam or accessories on view when you leave the car - they may be targeted by thieves.
It is important to take care of your device.
The Cyclops CarCam is not designed for use in extreme temperatures and any such exposure may
cause permanent damage
Opening the casing of the Cyclops CarCam will invalidate the warranty
To switch OFF your Cyclops CarCam, disconnect the car charger and place in a safe place e.g. Glove box.

4. Safety
Consider carefully where to attach the Cyclops CarCam in your car. The device should not block or interfere with any
of the following:
Your view of the road
Any of the controls in your car
Any of your mirrors
The vehicle airbag
When your Cyclops CarCam is installed, you should be able to reach the device without leaning or stretching.
You can attach the Cyclops CarCam to the windscreen or dashboard. A dashboard install kit and other approved
mounting solutions are available directly.
For further details, please SEE section 9 or visit our website.
.

5. Protection on your journey
The first time you start your Cyclops CarCam, the device may need a few minutes to locate your current position.
Subsequently, your position will be found faster, usually within a minute.
Under normal operating conditions the RED RECORD light will flash slowly and the GREEN GPS light stay on.
The Cyclops CarCam is a passive device that starts functioning shortly after switching on. During your journey the
following information is being captured:
Front driving view
Rear driving view
Interior view
Sound
Longitude Position
Latitude Position
Time
Date
Speed
G-force
The Cyclops CarCam is fitted with special parts to allow NORMAL operation even in the dark.

6. Protection you can TRUST
The Cyclops CarCam is designed to capture important driving events. The device captures all information as detailed
in section 5 and records that information to the pre-installed SD memory card.
When the SD memory card capacity is full the Cyclops CarCam begins to record over the first events captured. This is
sometimes described as a recording loop.
However, the Cyclops CarCam is designed NOT to record over accident events. These events are captured and
archived, ready for future retrieval.
Accidents
Serious jolt
Pressing the FORCE button
RED light FLASHING SLOWLY indicates the Cyclops CarCam is recording.
RED light FLASHING QUICKLY indicates the Cyclops CarCam is recording in EMERGENCY mode.
GREEN light FLASHING indicates the Cyclops CarCam is searching for the GPS signal.
GREEN light STAYING ON indicates the Cyclops CarCam has found the GPS signal.

7. In the event of an accident
The Cyclops CarCam is designed to capture important driving events. This information can be used to:
Protect your No Claims Bonus
Provides strong evidence in the event of a traffic accident
Helps to reduce the time taken to settle an insurance claim
Modifies driver behaviour
Reduces motoring costs by improving driver skills
The Cyclops CarCam captures all information as detailed in the previous chapter and records that information to the
pre-installed SD memory card.
In the event of an accident, we STRONGLY RECOMMEND that the SD memory card is REMOVED and REPLACED
with a spare (see Extras) SD memory card; this will preserve important recordings. The recorded information will
need to be examined and forwarded to the relevant authorities.
In the event of an accident please CALL 01633 535 535 to arrange for the SD memory card to be picked up,
OR
Remove the SD memory card and send too:
Europe Home Security Limited
Unit 16, Leeway
Leeway Industrial Estate
NEWPORT
GWENT
NP19 4SL
UNITED KINGDOM

8. Problems?
The GPS antenna is built into the top left of the Cyclops CarCam. Therefore, avoid covering this area of the CarCam
with any objects that may cause a reduction in reception. We advise that any cables e.g. Power, Video, are routed to
avoid covering this area of the Cyclops CarCam.
The Cyclops CarCam will continue to record in the event that there is NO GPS reception. However, certain information
will not be recorded e.g. Longitude Position, Latitude Position, Speed.
Do not leave your Cyclops CarCam or Cyclops CarCam accessories on view when you leave your car –both, are an
easy target for thieves. Also, we recommend the following:
Do not plug in more than ONE micro-USB terminal
Take care of your Cyclops CarCam device and clean the lenses carefully
Use a soft cloth to wipe the camera lenses of your device; do not use any liquid cleaners
If your device gets wet, dry it with a soft cloth
Do not open the casing of your device; doing so will invalidate your warranty
Do not use the supplied Micro SD memory card with any other devices; this may cause damage
Do not expose your device to high or low temperatures, which can cause permanent damage. E.g. do
not leave Cyclops CarCam in the car on a hot summer days or a cold winter nights

9. Extras
For further details, please visit our website.

10. Additional information
Specification:
Chipset: H.264 image compression chip
Front: VGA CMOS Sensor, viewing angle 120 degrees, 640x480, Max 30fps (NTSC), 25fps (PAL)
Back: VGA CMOS Sensor, viewing angle 170 degrees, 640x480, Max 15fps (NTSC), 15fps (PAL)
Power: 5V ±5%, 1A Cigarette lighter adapter (4.7v minimum).
Operational Temperate: -15 to +65 degrees Centigrade (inside the vehicle).
Storage Device: Micro SD Card MAX 32GB, Silicon Power & Transcend recommend, Min. Class 6
A. FRONT
B. REAR
CE Marking
This equipment complies with the requirements for CE marking when used in a residential, commercial, vehicular or light
industrial environment.
R&TTE directive
Hereby, Europe Home Security Limited declares that the Cyclops CarCam device is in compliance with the essential requirements
and other relevant provisions of the EU Directive 1999/5/EC.
WEEE directive
This symbol on the product or its packaging indicates that this product shall not be treated as household waste. In line with EU
Directive 2002/96/EC for waste electrical and electronic equipment (WEEE), this electrical product must not be disposed of as
unsorted municipal waste. Please dispose of this product by returning it to the point of sale or to your local municipal collection
point for recycling.
This Document
Great care was taken in preparing this manual. Constant product development may mean that some information is not
completely up to date. The information in this document is subject to change without notice. Europe Home Security Limited
shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential damages
resulting from the performance or use of this material.
This document contains information protected by copyright.
No part of this manual may be photocopied or reproduced in any form without notice from Europe Home Security Limited.
