NESA NRC-80DLM Installation and operating instructions
NRC-80DLM
USER MANUAL & INSTALLATION GUIDE
Universal Reversing Camera
with Dynamic Guidelines
1
CONTENTS
1.0 INTRODUCTION.............................................................................2
1.1 Component List .....................................................................2
1.2 Technical Specications: .......................................................3
2.0 WIRING DIAGRAM .........................................................................3
3.0 DYNAMIC REVERSING GUIDELINES...........................................4
4.0 TESTING.........................................................................................4
4.1 How to test ............................................................................4
5.0 TROUBLESHOOTING ....................................................................4
6.0 CARE AND MAINTENANCE ..........................................................4
7.0 WARRANTY TERMS & CONDITIONS ...........................................5
8.0 NOTES .......................................................................................... 10
32
1.0 INTRODUCTION
Thank you for purchasing Nesa’s NRC-80DLM camera. We are
certain that our product will give you trouble-free operation while
providing you with safety features that enhance your driving
experience.
DISCLAIMER
Our products are to assist and aid the driver, not to replace the
manual function of the person operating the vehicle.
Although the NRC-80DLM is a visual aid and will allow you to view
what is behind the vehicle, it does not remove the responsibility
of driving the vehicle from the driver. Legal responsibility and
safe driving practise remains with the driver at all times.You have
purchased this product with the understanding that its use is as
an aid only. We highly recommend that you have this product
professionally installed to ensure that it will provide the functions it
is set out to perform.
CAUTION
• Ensure you are using your rear camera within your countries’
road laws. Please make sure you are familiar with your local
road legislation before use.
1.1 COMPONENT LIST
• Universal reverse camera
• 6m extention cable
• 3M double sided tape
• Installation guide and user manual
IMPORTANT NOTICE
• Please read this manual carefully before using the product.
• Wire connection points should always be insulated.
• Wiring should always be installed away from heat sources and
electrical components.
• Please perform tests after nishing installation to ensure
camera is working correctly.
• This camera is intended for use as an aid when reversing
your vehicle. Drivers must always use extreme caution when
operating a vehicle.
• Specications are subject to change without notice.
WARNING
• Do not disassemble the camera or cut the camera cable
as this voids the warranty. Disassembling the camera will
compromise the waterproof seal.
1.2 TECHNICAL SPECIFICATIONS:
Signal System: NTSC
Horizontal Resolution: 800 TVL
Minimum Illumination: 0.1 – 0.5Lux
Diagonal Angle: 170°
Waterproof Rating: IP69K
Nominal Voltage: 12V/24V
Working Temperature: -30°C to 85°C
2.0 WIRING DIAGRAM
Front view option: NRC-80DLM functions as a rear view camera
as standard. For front view application, please cut the thin WHITE
wire near the camera lead and restart power to see the image
reversed.
RED to Reversing Light +
BLACK to Ground
Switching Wire
Monitor Video Input video extension cable
54
3.0 DYNAMIC REVERSING GUIDELINES
Inbuilt G sensor moves the guidelines in accordance with the
vehicles' movement, this helps the driver to avoid obstacles while
reverse parking.
Guideline option: NRC-80DLM has parking guide-lines as a
default. To remove guide-lines, cut the thin GREEN wire near the
camera lead and the guide-lines will now be removed.
4.0 TESTING
4.1 HOW TO TEST
1. Apply the parking brakes. (Safety Precaution)
2. Turn ignition on. (DO NOT TURN ON VEHICLE)
3. Shift into reverse gear.
4. Image should appear on the monitor.
5.0 TROUBLESHOOTING
6.0 CARE AND MAINTENANCE
