Cyetus KCB Series User manual

Series Coffee Maker
Model：KC5020DA

Before using the electrical appliance, the following basic precautions should
always be followed including the following:
- 1 -
IMPORTANT SAFEGUARDS
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
(9)
(10)
(11)
(12)
(13)
(14)
(15)
Read all instruction.
Before using check that the voltage of wall outlet corresponds to rated voltage
marked on the rating plate.
This appliance has been incorporated with a polarized plug.
To protect against fire, electric shock and injury to persons do not immerse
cord, plug, in water or other liquid.
Remove plug from wall outlet before cleaning and when not in use. Allow
appliance cool down completely before taking off, attaching components or
before cleaning.
Do not operate any appliance with a damaged cord or plug or after the
appliance malfunctions, or is dropped or damaged in any manner. Return
appliance to the nearest authorized service facility for examination, repair or
electrical or mechanical adjustment.
The use of accessory attachments not recommended by the appliance manu-
facturer may result in fire, electric shock or injury to persons.
Place appliance on flat surface or table, do not hang power cord over the
edge of table or counter.
Ensure the power cord do not touch hot surface of appliance.
Do not place the coffee maker on hot surface or beside fire in order to avoid
to be damaged.
To disconnect, tum any control to"off, " then remove plug from wall outlet.
Always hold the plug. But never pull the cord.
Do not use appliance for other than intended use and place it in a dry
environment.
Close supervision is necessary when your appliance is being used by or near
children.
Be careful not to get burned by the steam.
Do not touch the hot surface of appliance(such as steam wand, and the steel

- 2 -
SAVE THESE INSTRUCTIONS
(16)
(17)
(18)
(19)
(20)
(21)
(22)
(23)
(24)
(25)
(26)
(27)
mesh just boiling). Use handle or knobs.
Do not let the coffee maker operate without water.
Scalding may occur if the water tank is removed during the brewing cycles.
Do not remove the metal funnel when appliance in brewing coffee or when
steam and hot water escape from metal funnel and ensure to release the
pressure in water tank before removing metal funnel.
Connect plug to wall outlet before using and turn any switch off before plug is
removed from wall outlet.
Relief pressure through steam wand before removing tank cover or metal
funnel.
This appliance is not intended for used by persons(including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliances by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the
appliance.
This appliance is intended to be household use only.
This appliance is intended to be used in household and similar applications
such as:
– Staff kitchen areas in shops, offices and other working environments;
– Farm houses;
– By clients in hotels, motels and other residential type environments;
– Bed and breakfast type environments.
Do not use outdoors.
Do not place on or near a hot gas or electric bumer, or in a heated oven.
WARNING: To avoid the risk of injury, do not open the brew chamber during
the brew process.
a) A short power-supply cord (or detachable power-supply cord) is provided
to reduce the risk resulting from becoming entangled in or tripping over a
NOTE OF CORD:

WARNINGS:
a. Pressure
In order to prevent hot steam and hot water from scalding the body or caus-
ing other personal injuries as well as prevent damage to this product, do not
remove the water tank or portafilter when the machine brews coffee or makes
froth. Before you remove the portafilter to brew another cup of coffee, make
sure that the coffee machine is in standby mode. If you want to add more
water into the water tank, please turn off the machine by pressing the
ON/OFF button “ ”, at that time, only the indicator of ON/OFF button
“” lights weekly while other indicators turn off. When extracting
coffee, make sure that the portafilter is turned to the specified position to
avoid it getting loose due to the pressure during use, which may easily cause
human injury.
b. High temperature
When the machine is working, do not extend your hands and other parts of
your body into the bottom of the portafilter or steam tube to prevent burns.
It is not allowed to touch the steam tube with your hands or other parts of
your body at any time. You can only turn the steam tube by touching the
silicone sleeve that wraps the steam tube.
- 3 -
The marked electrical rating of the cord set or extension cord should
be at least as great as the electrical rating of the appliance;
The cord should be arranged so that it will not drape over the counter-
top or tabletop where it can be pulled on by children or tripped over
unintentionally;
If the appliance is of the grounded type, the cord set or extension cord
should be a grounding-type 3-wire cord.
b)
c)
longer cord.
Longer detachable power-supply cords or extension cords are available
and may be used if care is exercised in their use.
If a longer detachable power-supply cord or extension cord is used:
•
•
•

CONTROL PANEL
- 4 -
KNOW YOUR COFFEE MACHINE

STEAM/HOT WATER ILLUSTRATION
BEFORE THE FIRST USE
•After water stops dispensing, empty the water in drip tray or in the cup.
•Thoroughly clean the detachable parts of the whole machine with warm water.
NOTE:
Do not extend any parts of your body closed to portafilter and steam tube
to avoid scald during brewing hot water.
Before the first use or the machine has not been used for a long time, you should
follow below steps to rinse and warm up the internal pipes of the machine.
•
•
•
•
•
•
Check and ensure that all accessories are complete and not damaged.
Fill the water tank with clean water, and water level should not exceed the MAX
position.
Align the portafilter with portafilter bracket (no coffee powder is placed at this
moment), and rotate the portafilter counterclockwise to lock it tightly (place a
single-cup or double-cup filter as needed).
Put a cup on the drip plate, plug in the appliance, press “ ” button and the
appliance enters into the preheating condition, after finish preheating, the
appliance will enter into the standby mode.
Turn the knob to “ ”, after a while, some steam will flow out of the steam
tube. The steam tube shall align with the drip tray or a cup can be used for
collecting the steam or hot water.
Press “ ” or “ ” button to clean the pipes in the machine, use a cup to
collect the water to avoid any scald.
- 5 -

Choose the right coffee powder
- 6 -
Coffee powder
The coffee should be freshly ground and subjected to deep roasting. You may need
to use French or espresso roasted coffee powder for espresso coffee. Pre-ground
coffee powder can only keep the aroma for 7 to 8 days unless it is stored in a sealed
container, and place it in a cool place. Do not store coffee in the refrigerator or
freezer. In general, it is not recommended to use pre-ground coffee powder. The
coffee beans freshly ground are more easily to retain the aroma of the coffee and
obtain higher coffee quality.
Grind
If you are making coffee, this step is a key step in the espresso making process and
requires more practice.
•
•
•
•
•
•
In order to obtain a uniform and consistent coffee powder, be sure to adjust
the grinding setting according to the type and quality of coffee beans to obtain
a cup of high-quality coffee.
The correct powder should look like salt.
If the powder is too finely ground, it may cause the coffee to flow intermittently
or fail to brew coffee.
If the powder is too coarse, the water will flow through the coffee too quickly,
which will affect aroma and taste of the extracted coffee.
You can adjust the thickness of the ground coffee powder by adjusting the coffee
bean box, which will vary depending on the type and quality of the coffee beans
you use, so you need to make appropriate adjustments to achieve the best
results.
For the freshly-roasted coffee beans (within 1 month), the grinding position
should be set between 5-10, the double-cup (Grind) setting can produce about
19g of powder and the single-cup (Grind) setting can produce about 13g, this will
bring relatively good coffee extraction effect.
In order to prevent the coffee beans from getting wet and affecting the grinding
effect and the final coffee taste, please do not put too much coffee beans in the
bean box.

•
•
Preheat:
Press the “ ” once, the whole machine enters into preheating mode, the power
indicator “ ” flashes in the form of breathing light, and “ ”、“” lights
up at the same time.
Standby mode:
The appliance will enter into the standby mode after the preheating is finished. At
that time, all the indicators except “ ” and “ ” light solidly, and the coffee
machine can be used normally.
Brew single-cup of coffee:
In the standby mode, install the single-cup filter into the portafilter, load about 13
grams of coffee powder, use the coffee tamper and press the coffee powder with a
force of about 12.5Kg, then align the portafilter to the portafilter bracket, turn the
portafilter counterclockwise to lock it. Put a coffee cup on the drip plate, press “ ”
button, the indicator of “ ” button flashes and “ ”、“” indicators turn
off, and the machine starts to brew single-cup of coffee. When the set coffee dose is
reached (about 30ML), the machine will stop working automatically, all the indicators
except “ ” and “ ” will light solidly, and the appliance will enter into the
standby mode.
Fill the water tank with drinking water, the water level should not exceed the
"MAX" position.
Plug in the power and press the ON/OFF button “ ” (make sure the knob is
at “ ” position), then the machine enters into the preheating mode. The specif-
ic operation is as follows:
There are three functional indicators: Coffee brewing, hot water and steam
function cannot work at the same time, only one function can work in one time.
Indicators in different states show various working modes of the machine. Hot
water and steam function cannot work at the same time.
OPERATION INSTRUCTION
I. Brew coffee, hot water and steam
- 7 -

Steam preheating and steam function:
In standby mode, turn the knob to steam position “ ”. The machine enters into
steam mode.at this time, Steam/hot water indicator light will flash, and“ ” 、
“” 、“” indicators turn off, other indicator lights are unchanged.
Brew double-cup of coffee:
In the standby mode, install the double-cup filter into the portafilter, load about 19
grams of coffee powder, use the coffee tamper and press the coffee powder with a
force of about 12.5Kg, then align the portafilter to the portafilter bracket, turn the
portafilter counterclockwise to lock it. Put a coffee cup on the drip plate, press “ ”
button, the indicator of “ ” button flashes and “ ”、“ ” indicators turn
off, and the machine starts to brew double-cup of coffee. When the set coffee dose
is reached (about 60ML), the machine will stop working automatically, all the indica-
tors except “ ” and “ ” will light solidly, and the appliance will enter into
the standby mode.
Boil hot water:
In standby mode, turn the knob to hot water position “ ”, the machine enter into
hot water mode, at this time, Steam/hot water indicator light will flash, and “ ”
indicators turn off, other indicator lights are unchanged. Turn the knob to “ ”
position , the machine stops brewing hot water. The machine enters into standby
mode.
- 8 -
NOTE:
The maximum water output of hot water function is 190-240ml, it’s important
to use big enough container to collect the hot water or there must be some-
one to guard it when in use. After hot water function is finished, please turn
the knob to the twelve o'clock position in time; if not, the hot water indicator
will flash as an alarm.
The steam function will generate high temperature steam, please pay
attention to avoid scalding when using it;
•
NOTE:

Coffee dose of single-cup and double-cup, you can adjust the specific coffee
dose according to your needs, operation is as follows:
Hold and press the Single-cup button “ ” or Double-cup button “ ”, and
its corresponding indicator and “ ” flashes, the indicator of “ ” lights solid-
ly and other indicators unchanged, the coffee starts to dispense. When the
desired coffee amount is reached, release the Single-cup button “ ” or
Double-cup button “ ”, the coffee stops dispensing, the buzzer sounds, and
the machine will record the coffee dose and enter into the standby mode. When
you brew coffee next time, the machine will brew the coffee amount as per your
setting ( adjustable coffee amount MAX about 125ml for single-cup or 250ml for
double cup).
Factory reset:
Under the standby mode, simultaneously hold and press Single-cup button “ ”
or Double-cup button “ ”and Program button “ ”, at that time, the indica-
tors of Single-cup button “ ” or Double-cup button “ ” and Program
button “ ” start to flash, the buzzer sounds for once time, then release the
Single-cup button “ ” or Double-cup button “ ” and Program button
“”, and the coffee dose of single-cup coffee or double-cup coffee will be
recovered, then the appliance will go back to the standby mode.
Customized setting:
a.
b.
Sleep state:
The machine will automatically enter into sleep mode after 15 minutes of no opera-
tion. You can activate the machine again by pressing ON/OFF button, the machine
will re-enter into warm-up state.
- 9 -
To ensure good foaming effect of milk, wait the steam runs for 3-5 seconds,
and then turn the knob to the twelve o'clock position, extend the steam
tube into the milk, and turn the knob to steam indicator to froth the milk.
The maximum milk frothing time is 5 minutes;
After milk frothing, please turn the knob to the twelve o'clock position in
time. If it is not turned back, the steam indicator light will flash as an alarm.
•
•
•

Sleep state:
The machine will automatically enter into the sleep mode after 15 minutes of no
operation during the standby mode.You can activate the machine again by pressing
any button or turning the knob to make it enter into the preheat condition again.
The steam function will generate high-temperature steam, please pay
attention to avoid scald when using it.
To ensure a good frothing effect, make the steam run for 3-5 seconds,
and then turn the knob to the “ ” position, extend the steam tube
into the milk, and turn the knob to the steam position for frothing the milk.
After finish making steam, please turn the knob to the “ ” position in
time.
•
•
•
Steam function:
Under the standby mode, turn the knob to “ ”, the machine enters into
steam-making mode, at that time, the “ ” flashes and the appliance starts to
make steam. Turn the knob to “ ”position , the machine stops making steam and
enters into the standby mode.
- 10 -
When extracting coffee, make sure that the portafilter is turned counterclockwise
into the correct position as shown in the Figures below.
NOTE:

Ⅱ. Grind Coffee Beans
This product has a function of grinding coffee bean, before using this function, please
make sure that all parts are installed in accordance with the requirements. The
details are as follows:
Suggestion:
We suggest that you can preheat the appliance, including the portafilter, filters and
cup before brewing coffee, so that the coffee will not be affected by the coldness of
appliance. The specific operation is as below: Put the filter into the portafilter and
then install the portafilter onto the portafilter bracket, put a cup well in position and
press Single-cup button “ ” or Double-cup button “ ” to make the appliance
work. After the appliance stops working, the coffee-brewing can be activated.
Special note:
The functions of Steam and Coffee cannot be operated at the same time. Please pay
attention to the selected function to avoid the personal injury due to misoperation.
- 11 -
1
2
Fig. 1: Install the cutter head (2) and
tighten it clockwise, then install the
bean box (1) and screw it as shown in
Fig. 2.
Fig. 2: Align the positions in red
circles in the Figure, and press it
down, rotate it clockwise and install
it into the machine.

Maker sure the bean box is installed in place. When the indicator of “ ” and
“” turns to illuminate in white solidly from red, the grinder is ready for
use.
Add appropriate amount of coffee beans in the bean box. To prevent the coffee
beans from getting wet and affecting the grinding effect and the final coffee
taste, please do not put too many coffee beans in the bean box.
As shown in Fig. 5, put the portafilter with single-cup filter or double-cup filter
into the powder receiving bracket,
as shown in Fig. 5.
a.
b.
c.
There are markings to show the coffee coarseness on bean box, see Fig. 3. To adjust
the grind setting, make sure the coffee grind setting you want on the bean box is
aligned with the mark position on the top cover (as shown in Fig. 4).
Fig. 3: From 0 to 30, coffee power is from
fine to coarse. Bigger number for coarser
coffee powder.
Fig. 4
Fig. 5
- 12 -

Remove the portafilter, tap the portafilter on the desktop, and add the coffee
powder in the filter.
Use the coffee tamper and apply it with a force of about 12.5kg to compact the
coffee powder by following the steps as below.
f.
g.
Single-cup(Grind) button “ ”
Press the Single-cup (Grind) button“ ” , its corresponding indicator flashes
and “ ”、“” indicators turn off, the grinder starts to run. And the grinder
will stop running automatically after the set ground coffee amount is reached,
and you can press the Single-cup (Grind) button “ ” once to make the appli-
ance stop running during working process.
d.
Double-cup (Grind) “ ”
Press the Double-cup (Grind) button“ ” , its corresponding indicator flashes
and “ ”、“” indicators turn off, the grinder starts to run. And the grinder
will stop running automatically after the set ground coffee amount is reached,
and you can press the Double-cup (Grind) button “ ” once to make the appli-
ance stop running during working process.
e.
- 13 -
NOTE:
The default grinding time required for Single-cup dose is about 9 seconds.
And the grinder will produce about 13g of powder at the grinding settings of
5-10, which has a relatively good coffee extraction effect (The parameters
may need to be adjusted slightly, depending on the baking degree and fresh-
ness of coffee beans).
NOTE:
The default grinding time required for Double-cup dose is about 14 seconds.
And the grinder will produce about 19g of powder at the grinding settings of
5-10, which has a relatively good coffee extraction effect (The parameters
may need to be adjusted slightly, depending on the baking degree and fresh-
ness of coffee beans).

Tamp the coffee powder down-
wards.
When the edge of tamper aligns to edge
of portafilter, the powder amount is
appropriate.
When the bean box is not installed, the indicators of Single-cup(Grind)
button “ ” and Double-cup (Grind) button “ ” will illuminate in red
solidly and three beeps can be heard.
When the grinding function cannot be used normally, the indicators of
Single-cup (Grind) button “ ” and Double-cup (Grind) button “ ”
will flash in red and three beeps can be heard.
When the grinder works continuously for 3 minutes and the intermediate
rest time is less than 6 minutes, the machine will limit the use of grinding
function in order to protect the grinding system. After the rest time reach-
es 6 minutes, the machine will automatically release the limitation and the
grinder can resume to work again.
When the grinding system is limited to use, press the Single-cup (Grind)
button “ ” or Double-cup (Grind) button “ ”, the buzzer will sound
three times, and the indicators of Single-cup (Grind) button “ ” and
Double-cup (Grind) button “ ” will flash in red.
•
•
•
•
- 14 -
Turn the portafilter counterclockwise into the portafilter bracket, and select the
corresponding Single-cup button (Coffee) “ ” or Double-cup button (Coffee)
“ ” according to the filter size.
h.
NOTE:

Single-cup (Grind)
Follow the operation as below to make factory reset for the grinding time of
Single-cup (Grind) “ ” under the standby mode: Simultaneously hold and
press Single-cup (Grind) button “ ” and Program button “ ”, and their
corresponding indicators start to flash, release the buttons after one beep are
heard, then the appliance goes back to the standby mode.
Double-cup (Grind)
Follow the operation as below to make factory reset for the grinding time of
Double-cup (Grind) “ ” under the standby mode: Simultaneously hold and
press Double-cup (Grind) button “ ” and Program button “ ”, and their
corresponding indicators start to flash, release the buttons after one beep are
Factory reset for grinding time
a.
b.
Adjustment for grinding time of Single-cup (Grind) button “ ” :
You can set the grinding time as per your need by following the operation as below:
Hold and press the Single-cup (Grind) button “ ”, its corresponding indicator and
“” will flash, and “ ”indicators turn off, while other indicators are unchanged,
and the grinder will start working. When the set ground coffee amount is reached,
release the Single-cup (Grind) button “ ” , the appliance will stop, the buzzer
sounds, and the machine will record the grinding time and enter into the standby
mode. When you grind next time, the machine will grind the same time as per your
setting (adjustable time between about 6~13 seconds).
Adjustment for grinding time of Double-cup (Grind) button “ ” :
You can set the grinding time as per your need by following the operation as below:
Hold and press the Double-cup (Grind) button “ ”, its corresponding indicator
and “ ” will flash, and “ ”indicators turn off, while other indicators are
unchanged, and the grinder will start working. When the set ground coffee amount
is reached, release the Double-cup (Grind) button “ ”, the appliance will stop,
the buzzer sounds, and the machine will record the grinding time and enter into the
standby mode. When you grind next time, the machine will grind the same time as
per your setting (adjustable time between about 10~18 seconds).
- 15 -

Press the Single-cup (Grind) button “ ” and adjust the coffee-extracting
temperature to be 90℃, the indicator of Program button “ ” flashes, the
indicator of Single-cup (Grind) button “ ” lights solidly, while other indicators
turn off.
Press the Double-cup (Grind) button “ ” and adjust the coffee-extracting
temperature to be 92℃, the indicator of Program button “ ” flashes, the
indicator of Double-cup (Grind) button “ ” lights solidly, while other indica-
a.
b.
III. Customized setting for coffee-extracting temperature
This machine has a PID control function, which can monitor the heating block for
heating water, so that the coffee can be extracted at a temperature of 92°C.
You can adjust the coffee-extracting temperature, and the adjustable temperature
ranges between 90-96°C. 2℃ can be changed each time, which can meet different
taste requirements.
- The bitterness will be increased and the acidity will be decreased when the
temperature temperature is higher.
- The bitterness will be decreased and the acidity will be increased when the
temperature is lower.
heard, then the appliance goes back to the standby mode.
Special notes:
•
•
•
The appliance is equipped with two single-layer filters and two double-layer
filters.
The single-layer filters are applicable for finer coffee powder, and it is recom-
mended that the grinding setting shall range between 0 and 15.
The double-layer filters are applicable for coarser coffee powder, and it is
recommended that the grinding setting shall range between 15 and 30.
To enter the mode for setting the coffee-extracting temperature
Hold and press the Program button “ ” for 3 seconds, the machine will beep and
the indicator of Program button “ ” will start to flash.
- 16 -

NOTE:
After setting the above temperatures, press the Program button “ ” again,
the appliance will beep and go back to the standby condition.
tors turn off.
Press the Single-cup (Coffee) button “ ” and adjust the coffee-extracting
temperature to be 94℃, the indicator of Program button “ ” flashes, the
indicator of Single-cup (Coffee) button “ ” lights solidly, while other indica-
tors turn off.
Press the Double-cup (Coffee) button “ ” and adjust the coffee-extracting
temperature to be 96℃, the indicator of Program button “ ” flashes, the
indicator of Double-cup (Coffee) button “ ” lights solidly, while other indica-
tors turn off.
c.
d.
Ⅳ. Restore to factory settings
In the case of wrong settings, the user can hold and press the ON/OFF button “ ”
and Program button “ ” at the same time.The machine will beep and all the
indicators will flash for 2 times together. Then the machine will return to the factory
settings.
V. Tool box and cleaning accessories
The machine is equipped with a tool box which is used for storing cleaning pin and
cleaning brush.
- 17 -
After entering the customized setting mode, the appliance will exit from
the mode and return to the standby state if no button is pressed within 1
minute.
To exit from the setting mode, press any button during operation.
•
•
IMPORTANT:

Fig. 7
Clean the steam tube with thicker pin
Fig. 8
Clean the filters with thinner pin
Single-cup filter and double-cup filter can be stored in the tool box as well. The tool
box is placed at the left lower part of appliance, where you can pull it out when you
remove drip tray from the machine (Fig. 6).
Fig. 6
- 18 -
Cleaning pin
The cleaning pin is used for cleaning steam spout and filters. The thicker pin is for
cleaning steam tube (Fig. 7), and thinner one is for filters (Fig. 8).

Cleaning brush
The cleaning brush is used for cleaning the grinding system. Following the section
of “Clean the grinder”, after removing the bean box and grinding wheel, you can
use the cleaning brush to clean the chamber of grinder and the powder channel.
Clean the anti-static device and coffee
power outlet
(If coffee powder coming out slower than
usual or coffee powder floats, clean the
anti-static device and the coffee powder
outlet with attached cleaning brush as
Fig. 8)
Clean the chamber of grinder and
the powder channel with attached
cleaning brush as Fig. 9.
The rear end of cleaning brush could be
used to detach filter from portafilter as
Fig. 10
- 19 -
