Cyrus CDi-XR User manual

Cyrus CDi-XR User guide for rmware version V1.0.1
An updated user guide may be available from
www.cyrusaudio.com for newer rmware revisions

Cyrus CDi-XR User Instrucons
IMPORTANT! READ BEFORE OPERATING THIS EQUIPMENT! ...1
Laser product.............................................................................2
Power supply .............................................................................2
Servicing ....................................................................................2
Product service centre ...............................................................2
FCC NOTICE* ..............................................................................3
WELCOME TO THE WORLD OF CYRUS! .......................................4
Preparaons for Installaon ......................................................4
INSTALLATION ...............................................................................4
Key to the rear panel drawing ...................................................4
Important – read before making any connecons ....................5
Connecng to the System Amplier ..........................................5
Connecng a Digital amplier or D/A converter .......................5
Connecng with a cable ............................................................5
Connecng with opcal interconnect .......................................5
External Power Supply - PSU-XR ................................................5
How it works ..............................................................................5
MC-BUS System Connecon (Oponal).....................................5
Connecng to the AC Mains Supply ..........................................5
OPERATION ...................................................................................6
Key to the front panel drawing ..................................................6
Touch pad controls ....................................................................7
Switching On..............................................................................7
Mains power..............................................................................7
Standby......................................................................................7
Auto-standby .............................................................................7
Loading a Disc ............................................................................7
Playing a Disc .............................................................................7
Pausing .....................................................................................7
Previous/Next Track Selecon ...................................................7
Fast Forward/Reverse ................................................................7
Repeat .......................................................................................7
Stop/Eject ..................................................................................7
Program Memory Storage .........................................................8
REMOTE CONTROL OPERATION ..................................................9
Remote control introducon .....................................................9
Remote control backlight ..........................................................9
Fing baeries to the remote control ......................................9
Sending commands to Cyrus components ................................9
Switching on Cyrus source components ....................................9
Cyrus amplier commands ......................................................10
Cyrus CD player commands .....................................................11
Cyrus audio streamer commands ............................................12
Cyrus Phono Signature commands ..........................................13
Learning TV and Satellite commands ......................................14
Preparaon for learning ..........................................................14
Learning commands ................................................................14
Checking programmed commands ..........................................15
Problems with learning ...........................................................15
Sending TV or SAT commands .................................................15
SETUP MENUS .............................................................................16
Setup opons ..........................................................................16
Navigang the menu ...............................................................16
Menu map ...............................................................................17
FIRMWARE UPDATES ..................................................................18
TROUBLESHOOTING GUIDE .......................................................19
SPECIFICATIONS ..........................................................................19
Power Supply ...........................................................................19
Enclosure .................................................................................19
WARRANTY ..................................................................................20
WEEE ............................................................................................20
CONTENTS

Cyrus CDi-XR User Instrucons
1
WARNING: To reduce the risk of electrical shock do not
remove any unit covers or panels. There are no user
serviceable parts in this product.
WARNING: To reduce the risk of electric shock, do not
expose this equipment to rain or moisture.
HEED WARNINGS: All warnings on the product and in the
operang instrucons should be adhered to.
READ ALL THE INSTRUCTIONS: All the safety and operang
instrucons should be read before the product is operated.
RETAIN INSTRUCTIONS: The safety and operang
instrucons should be retained for future reference.
FOLLOW INSTRUCTIONS: All operang and use instrucons
should be followed.
CLEANING: Unplug this product from the mains before
cleaning. Do not use liquid or aerosol cleaners. Use a damp
cloth for cleaning.
WATER AND MOISTURE: Do not use this product near
water - for example, near a bath tub, wash bowl, kitchen
sink, or laundry tub, in a wet basement; or near a
swimming pool and the like. The product must not be
exposed to dripping or splashing and no objects lled with
liquids, such as vases, shall be placed on the product.
HEAT: The product should be situated away from heat
sources such as radiators, stoves, or any other products
(including ampliers) that produce heat.
VENTILATION: Slots and openings in the cabinet are
provided for venlaon, to ensure reliable operaon of
the product and to protect it from overheang and these
openings must not be blocked or covered. The openings
should never be blocked by placing the product on a bed,
sofa, rug or similar surface. This product should not be
placed in a built-in installaon such as a bookcase or rack
unless proper venlaon is provided or the manufacturer’s
instrucons have been adhered to.
OBJECT OR LIQUID ENTRY: Never push objects of any kind
into this product through openings as they may touch
dangerous voltage points or short-out parts that could
result in a re or electric shock.
ACCESSORIES: Do not place this product on an unstable
cart, stand, tripod, bracket, or table. The product may
fall, causing serious injury to a child or adult, and serious
damage to the product. Use only with a cart, stand, tripod,
bracket or table recommended by the manufacturer, or
sold with the product. Any mounng of the product should
follow the manufacturer’s instrucons, and should use a
mounng accessory recommended by the manufacturer.
IMPORTANT! Read before operang this equipment!
CAUTION: The exclamaon mark is to draw your
aenon to important instrucons and safety
procedures in this manual.
ATTENTION: The lightning ash warns you of the
risk of electrical shock presented by components
inside this product. Unauthorised personnel
must not open this unit.
MOVING THE PRODUCT: A product and cart
combinaon should be moved with care.
Sudden stops, excessive force, and uneven
surfaces may cause the product and cart to
overturn.
POWER SOURCES: This product should be operated
only from the type of power source indicated on the
marking label. If you are not sure of the type of power
supply to your home, consult your product dealer or local
power company. For products intended to operate from
baery power, or other sources, refer to the operang
instrucons.
OVERLOADING: Never overload wall outlets, extension
cords, or integral convenience receptacles. This can result
in an increased risk of re or electric shock.
POWER CORD PROTECTION: Power supply cords should
be routed so that they are not likely to be walked on or
pinched by items placed upon or against them, paying
parcular aenon to cords at plugs, convenience
receptacles, and the point where they exit from the
product.
NAKED FLAMES: No naked ame sources, such as candles,
must be placed on this product.
LIGHTNING: For added protecon for this product during
a lightning storm, or when it is le unaended or unused
for long periods of me, unplug it from the wall outlet and
disconnect the antenna or cable system. This will prevent
damage to the product due to lightning and power-line
surges.
BATTERIES: Warning : Baeries shall not be exposed to
excessive heat such as sunshine, re or the like.
CAUTION! POLARISED CONNECTOR (CANADA and USA):
To prevent electrical shock, match wide blade of plug to
wide slot, fully insert. Do not alter or remove this plug if
it does not t your mains power socket. Have a suitable
socket installed by a competent electrician.
ACCESS TO THE MAINS PLUG: The means to disconnect
this product from the mains supply is the mains plug.
Ensure that the mains plug is accessible at all mes.
ATTACHMENTS: Do not use aachments not recommended
by the product manufacturer as they may cause hazards.

Cyrus CDi-XR User Instrucons
2
Laser product Servicing
Do not aempt to service this product yourself as opening
or removing covers may expose you to dangerous voltage
or other hazards. Refer all servicing to qualied service
personnel.
CONDITIONS REQUIRING SERVICE: Unplug this product
from the wall outlet and refer servicing to qualied service
personnel when:
• When the power supply cord or plug is damaged.
• If liquid has been spilled, or objects have fallen into the
product.
• If the product has been exposed to rain or water.
• If the product has been dropped or damaged in any
way.
• If the product does not operate normally by following
the operang instrucons. (Adjust only those controls
that are covered by the operang instrucons.
Improper adjustment of other controls may result
in damage requiring extensive work by a qualied
technician to restore the product to its normal
operaon).
• When the product exhibits a disnct change in
performance.
REPLACEMENT PARTS When replacement parts are
required, be sure the service technician has used
replacements specied by the manufacturer or have the
same characteriscs as the original part. Unauthorised
substuons may result in re, electric shock, or other
hazards.
SAFETY CHECK Upon compleon of any service or repairs
to this product, ask the service technician to perform
safety checks to determine that the product is in proper
operang condion.
Product service centre
For product service or technical advice, contact only
authorised Cyrus service centres. Contact details for Cyrus
distributors may be found on the Cyrus website at www.
cyrusaudio.com.
This label on the rear panel
tells you that the unit contains
a Laser component. Opening
this unit will expose the user to
radiaon from the laser beam.
Power supply
The moulded IEC connector of the AC cord supplied plugs
into the power inlet on the rear of the unit.
The mains supply requirement is marked on a label on the
rear panel. Before connecng, check that this voltage is the
same as your mains supply.
220-230V Products: Voltage Range 220V-240V
115V Products: Voltage Range 110V-120V
If you move to an area with a dierent mains voltage,
contact your local Cyrus distributor to have your product
converted.
There are no user replaceable fuses in this unit.

Cyrus CDi-XR User Instrucons
3
FCC NOTICE*
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed
to provide reasonable protecon against harmful interference in a residenal
installaon. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instrucons, may cause
harmful interference to radio communicaons. However, there is no guarantee that
interference will not occur in a parcular installaon. If this equipment does cause
harmful interference to radio or television recepon, which can be determined by
turning the equipment o and on, the user is encouraged to try and correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separaon between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Any changes or modicaons not expressly approved by the manufacturer could void
the user’s authority to operate the equipment.
*115V products

Cyrus CDi-XR User Instrucons
4
Welcome to the world of Cyrus!
Congratulaons on your choice of Cyrus Hi- products. Our
state-of-the-art design technology and outstanding quality
of manufacture has won countless awards around the
world. We are condent that you will derive great pleasure
from owning a product from one of the most recognised
and respected manufacturers of hi- equipment.
Now is a good me to register your new Cyrus product. To
register, visit www.cyrusaudio.com/support and click the
‘Register your product’ link.
Please read these instrucons carefully before commencing
installaon. They provide full guidance to help you install
your CD player safely and correctly.
Preparaons for Installaon
Before installing the CDi-XR check that the following items
are included in the accessory box.
• AC Mains Cable
• Remote Control Handset
• 2 x Phono leads for MC-BUS connecon
Aer removing these items, please retain the packaging.
Install the CDi-XR in a well venlated locaon away from
sources of high temperature, dust or humidity. Never stand
it under another unit or on any surface likely to hamper its
cooling or venlaon.
Installaon
Key to the rear panel drawing
1. Audio outputs
2. Opcal Output
3. Digital Output
4. MC-BUS connecon
5. Servo upgrade port
6. PSU-XR connecon
7. UI upgrade port
8. Power Inlet
R
MADE IN ENGLAND
MC BUS
OUT
IN
L
OUT 1 OUT 2
DIGITAL OUTPUT
SERVO UPGRADEUI UPGRADE
efg
bc d
h
a

Cyrus CDi-XR User Instrucons
5
Connecng to the System Amplier
• Connect a suitable stereo RCA phono interconnect
between the OUT1 or OUT2 sockets and the
corresponding input of the amplier or receiver.
Amplier inputs suitable for this purpose are line inputs.
Dual outputs are provided for convenient connecon
to mulroom units or for direct connecon to tape/disc
recorders etc.
DO NOT connect the CDi-XR to the PHONO input of the
amplier, as this could damage your amplier or speakers.
Connecng a Digital amplier or D/A converter
The CDi-XR provides two digital outputs to connect to a
digital amplier or D/A converter.
Connecng with a cable
• Connect a single, digital interconnect between the
DIGITAL OUTPUT coaxial socket and a digital input of an
amplier or D/A converter.
Connecng with opcal interconnect
• Connect a Toslink opcal interconnect between the
DIGITAL OUTPUT opcal port and an opcal input of an
amplier or D/A converter.
The cable connecon is recommended for the best quality
where this connecon is available.
NOTE: The digital output of the CDi-XR is only compable
with digital inputs. It is not suitable for connecon to an
analogue amplier.
External Power Supply - PSU-XR
The PSU-XR is a unique DC power supply that will upgrade
the sonic performance of compable products in the Cyrus
range.
• To connect a PSU-XR, disconnect both components from
the mains.
• Plug the mul-pin interconnect from the PSU-XR into
the PSU-XR socket on the back panel.
CAUTION: Use only the interconnect supplied with the PSU-
XR. Other interconnects may damage the PSU-XR and the
amplier.
• Connect a mains supply to both units.
NOTE: Connecon of a PSU-XR is detected automacally, so
no internal adjustments are required.
How it works
The PSU-XR contains ve separate power supplies. When
a PSU-XR is connected to a Cyrus product, the power from
the PSU-XR is applied to specic parts of the connected
product.
The twin main power supply of the versale PSU-XR can
be congured to increase the power reserve available for
power amplicaon and servo circuitry or provide ultra-
smooth, low noise power for sensive circuits such as
analogue preampliers.
Three addional regulated power supplies can be
simultaneously applied to other sensive preamplier or
control circuits as required.
Connecon of a PSU-XR will also bring a secondary benet
by signicantly reducing the load placed on internal
power supplies and therefore reducing any power supply
related noise artefacts that may appear within the internal
circuitry.
MC-BUS System Connecon (Oponal)
By using the MC-BUS connecon, a highly funconal
integrated system with full remote control may be set up.
This feature is usable if you own a Cyrus amplier. Refer
to the relevant product handbook for MC-BUS wiring
instrucons.
Connecng to the AC Mains Supply
• Connect the socket on the AC Power cable to the AC
Power inlet the back panel.
• Now connect the cable to a suitable AC power point.
There is no mains power switch. To switch o the mains
supply remove the plug from the wall outlet. For this
reason, ensure that the plug is easily accessible when
installing the unit.
To avoid possible damage to your audio system, it
is essenal to disconnect all system components
from the mains supply before connecng or
disconnecng audio interconnects.
Important – read before making any connecons

Cyrus CDi-XR User Instrucons
6
1. Standby and indicator
2. Remote eye
3. Display window
4. CD Loading slot
5. Stop/Eject
6. Repeat
Operaon
7. Search forward
8. Search reverse
9. Next track
10. Previous track
11. Play/Pause
Key to the front panel drawing
CDi-XR
abc
e
fghi1)1!
d

Cyrus CDi-XR User Instrucons
7
Touch pad controls
The front panel controls are touch sensive. There is no
need to press the controls, just lightly touch or hold a
nger on the touchpad to select a funcon.
Switching On
Mains power
In regular use mains power can be le connected
permanently.
When unaended for a long period (holidays etc) mains
power should be disconnected.
Standby
When mains power is connected, the Standby touchpad
() is used for power control.
• Touch and hold briey to switch the unit on or set to
Standby.
The touchpad will be red when in Standby and white
when the amplier is operang.
When set to Standby, all sengs in use are retained.
Auto-standby
To save energy Standby will set automacally aer 20
minutes if le in pause or stop modes.
Loading a Disc
Before loading a disc, check that the display reads ‘No Disc’,
indicang that a disc is not already loaded.
• Hold the disc label side upwards and place it gently into
the CD Loading Slot.
Once a third of the disc is loaded, the disc will be
automacally loaded through the front panel. The
display will show ‘Reading’ while checking the contents
of the disc.
Playing a Disc
• Touch .
Playback will commence from track 1 unless otherwise
selected.
Pausing
• Touch to pause the current track.
The disc will be held at the precise point of interrupon
and the PAUSE symbol will show on the display.
• Touch again to resume playing the disc.
Previous/Next Track Selecon
• Touching or to select the next or previous
track on the CD.
Track indicaons appear on the display.
Fast Forward/Reverse
• Touch and hold or to locate a specic point
within a track.
The search will commence inially at a slow speed
increasing aer a few seconds if the key is held down.
The Search keys will also search through next or
previous tracks if held down long enough.
Repeat
Touch to set repeat and replay the enre disc or
programmed tracks.
When repeat is selected, its symbol shows on the
display.
• Touch a second me to clear Repeat.
If a program selecon has been stored, repeat will allow
connuous play of this program sequence.
Stop/Eject
When a disc is playing -
• Touch to stop the disc immediately.
If the disc is already staonary -
• Touch to eject the CD.

Cyrus CDi-XR User Instrucons
8
Program Memory Storage
There are two program modes – Program and Exclude.
Storing a program sequence will play the sequence of
tracks you like.
Storing an exclude sequence will skip the tracks you don’t
like.
To program or exclude a selecon of tracks, follow this
sequence-
• Load a disc.
• Press the STORE key on the remote control once to set
program mode (the display will read ‘Enter Tracks’) or
twice to set exclude mode (the display will read ‘Skip
Tracks’).
• Enter the sequence of tracks to be stored (or skipped)
with the remote control numeric keypad.
A maximum of 30 tracks may be stored in the program
memory. If an error is made in the programming
sequence, press on the remote control or touch
to cancel the last entry.
• When all the tracks have been stored, press the STORE
key again on the remote control (the display will now
read ‘Program Ready’.
• Set the player to play the disc.
The tracks will play in the programmed sequence.
NOTE:
1. ‘Memory full’ indicaon will show on the display when
the program stored exceeds 30 tracks or a stored
program me of 100 minutes or greater.
2. If disc playback is stopped while a program is stored,
an extra stop command is needed to clear the memory.
Thus:
• One stop command will stop the disc.
• A second stop command will clear the memory.
• A third stop command will eject the CD.
• One connuous press will accomplish all operaons.

Cyrus CDi-XR User Instrucons
9
Remote control operaon
Remote control introducon
The iR14 remote control will send commands to Cyrus
ampliers, CD players and Audio streamers*.
The remote control can also be programmed with the
commands from two other remote control handsets. These
will normally be for your TV and a Satellite or terrestrial
TV set-top box, programmed to the TV and SAT buons,
but could also be other audio components such as a Cyrus
tuner or DVD player etc.
*NOTE: It may be necessary to upgrade the rmware in
an Audio streamer to enable Infra-red remote control
operaon.
Remote control backlight
The remote control keypad includes a back-light. The back-
light will switch on automacally when moved or when a
command is sent.
Fing baeries to the remote control
The baery compartment is on the back of the remote
control.
123
45
79
6
8
0/10
SATTV
STORE
MENU
ENTER
SELECT
LIST
CH
SETUP
abc def
ghi jkl mno
pqrs tuv wxyz
GUIDE
INFO
TEXT
TV/AV
CONTROL
SOURCE
Switching on Cyrus source components
123
45
79
6
8
0/10
SATTV
STORE
MENU
ENTER
SELECT
LIST
CH
SETUP
abc def
ghi jkl mno
pqrs tuv wxyz
GUIDE
INFO
TEXT
TV/AV
CONTROL
SOURCE
123
45
79
6
8
0/10
SATTV
STORE
MENU
ENTER
SELECT
LIST
CH
SETUP
abc def
ghi jkl mno
pqrs tuv wxyz
GUIDE
INFO
TEXT
TV/AV
CONTROL
SOURCE
Sending commands to Cyrus components
AAA
AAA
a
b
1. Press the catch on the
baery cover and li o
the cover.
2. Slide a AAA baery
under the retaining hook
in the upper half of the
baery compartment as
shown.
3. Fit a second AAA baery
into the remaining space.
4. Replace the baery
cove r.
Replace the handset baeries only with AAA baeries of
the same voltage and type.
Discard used baeries in accordance with recycling
regulaons in force in your area.
• Press the CYRUS
key to switch on
a Cyrus amplier.
The remote
control will now
send commands
to a Cyrus
amplier.
• Press the key
to switch on a
Cyrus Audio CD
player and send
commands to the
CD player and an
amplier.
NOTE: If an amplier input has been named CD, the
amplier will switch on, set to the correct input.
• Press the key
to switch on
a Cyrus Audio
streamer and
send commands
to the streamer
and an amplier.

Cyrus CDi-XR User Instrucons
10
Cyrus amplier commands
• Press the CYRUS key to set the remote control to Cyrus
amplier mode.
You can now control a Cyrus amplier. The CYRUS key
will ash red when commands are being sent in Amplier
mode.
NOTE: Commands marked * are for Cyrus XR series
ampliers only, other Cyrus ampliers will not respond to
these commands.
Amplier mode commands available are listed below –
1. Set Cyrus ampliers, CD players and Audio streamers to
Standby.
2. Set the handset to send commands to Cyrus
components.
3. Send commands to a Satellite receiver (or other device
programmed to use this key).
4. Set the handset to send commands to an amplier and
CD player. Select an input named CD.
5. Step to the next amplier input.
6. No command for an amplier.
7. No command for an amplier.
8. Jump to the About menu*.
9. Step up menu opons*.
10. Step down menu opons*.
11. Step down menu opons*.
12. Open menu/Select menu opon*.
13. Amplier mute.
14. Step to the next amplier input*.
15. Step to the previous amplier input*.
16. Open menu/Select menu opon*.
17. No command for an amplier.
18. No command for an amplier.
19. No command for an amplier.
20. No command for an amplier.
21. No command for an amplier.
22. Setup key for programming TV/SAT keys.
23. No command for an amplier.
24. No command for an amplier.
25. No command for an amplier.
26. No command for an amplier.
27. No command for an amplier.
28. Volume down.
29. Volume up.
30. Balance.
31. Step back in menu tree*.
32. Step up menu opons*.
33. Open menu/Select menu opon*.
34. Menu home page*.
35. Display o.
36. No command for an amplier.
37. Step to the previous input.
38. Set the handset to send commands to an amplier and
Audio streamer.
39. Send commands to a TV (or other device programmed
to use this key).
123
45
79
6
8
0/10
SATTV
STORE
MENU
ENTER
SELECT
LIST
CH
SETUP
abc def
ghi jkl mno
pqrs tuv wxyz
GUIDE
INFO
TEXT
TV/AV
CONTROL
SOURCE
a
b
c
d
e
f
g
h
i
1)
1!
1@
1#
1$
1%
1^
1&
1*
1(
2)
2!
2@
2#
2$
2%
2&
2^
2*
2(
3)
3!
3@
3#
3$
3%
3^
3&
3*
3(

Cyrus CDi-XR User Instrucons
11
Cyrus CD player commands
• Press the CYRUS key
• Press the key to set the remote control to CD
mode.
The key will light red. You can now control both a Cyrus
CD player and amplier. The key will ash red when
commands are being sent in CD mode.
NOTE: Commands marked * are for Cyrus XR series CD
players only, other Cyrus CD players will not respond to
these commands.
The CD mode commands available are listed below –
1. Set Cyrus ampliers, CD players and Audio streamers to
Standby.
2. Set the handset to send commands to an amplier.
3. Send commands to a Satellite receiver (or other device
programmed to use this key).
4. Set the handset to send commands to an amplier and
CD player. Select an input named CD.
5. Step to the next amplier input.
6. No command for a CD player.
7. CD player repeat.
8. Jump to the About menu*.
9. CD player next track/Step up menu opons*.
10. CD player search forwards/Step down menu opons*.
11. CD player previous track/Step down menu opons.
12. Open menu/Select menu opon*.
13. Amplier mute.
14. No command for a CD player.
15. No command for a CD player.
16. CD player audio phase.
Changes in phase are subtle and are best established from
the listening posion. When the phase seng is changed,
the display text area will show the message ‘Phase Normal’
or ‘Phase Invert’. The performance of the CD player is
unaected whether the signal is in normal or phase
inverted mode.
17. CD player stop.
18. CD player search forwards.
19. No command for a CD player.
20. CD player next track.
21. CD player numeric keypad.
Enter a one or two digit track number to jump to a specic
track.
22. Setup key for programming TV/SAT keys.
23. CD player memory store.
24. CD player previous track.
25. CD player pause.
26. CD player search back.
27. CD player play/pause.
28. Amplier volume down.
29. Amplier volume up.
30. Amplier balance.
31. Step back in menu tree*.
32. Step up menu opons*.
33. No command for a CD player.
34. Menu home page*.
35. CD player display o.
36. CD player display mode.
Choose track elapsed me or disc remaining me.
37. Step to the previous amplier input.
38. Set the handset to send commands to an amplier and
Audio streamer.
39. Send commands to a TV (or other device programmed
to use this key).
123
45
79
6
8
0/10
SATTV
STORE
MENU
ENTER
SELECT
LIST
CH
SETUP
abc def
ghi jkl mno
pqrs tuv wxyz
GUIDE
INFO
TEXT
TV/AV
CONTROL
SOURCE
a
b
c
d
e
f
g
h
i
1)
1!
1@
1#
1$
1%
1^
1&
1*
1(
2)
2!
2@
2#
2$
2%
2&
2^
2*
2(
3)
3!
3@
3#
3$
3%
3^
3&
3*
3(

Cyrus CDi-XR User Instrucons
12
Cyrus audio streamer commands
• Press the CYRUS key
• Press the key to set the remote control to Audio
streamer mode.
The key will light red. You can now control both a Cyrus
Audio streamer and amplier or an Audio streamer that
includes an amplier. The key will ash red when
commands are being sent in Audio streamer mode.
The Audio streamer mode commands available are listed
below –
1. Set Cyrus ampliers, CD players and Audio streamers to
Standby.
2. Set the handset to send commands to a Cyrus amplier.
3. Send commands to a Satellite receiver (or other device
programmed to use this key).
4. Set the handset to send commands to an amplier and
CD player. Select an input named CD.
5. Step to the next amplier input.
6. No command for an audio streamer.
7. Audio streamer repeat.
8. Audio streamer display informaon.
9. Audio streamer cursor up.
10. Audio streamer cursor right.
11. Audio streamer cursor down.
12. No command for an audio streamer.
13. Amplier mute.
14. No command for an audio streamer.
15. No command for an audio streamer.
16. No command for an audio streamer.
17. Audio streamer stop.
18. No command for an audio streamer.
19. No command for an audio streamer.
20. Audio streamer next track.
21. Audio streamer alpha-numeric keypad.
22. Setup key for programming TV/SAT keys.
23. No command for an Audio streamer.
24. Audio streamer previous track.
25. Audio streamer pause.
26. No command for an audio streamer.
27. Audio streamer play/pause.
28. Amplier volume down.
29. Amplier volume up.
30. Amplier balance.
31. Audio streamer back.
32. Audio streamer cursor le.
33. Audio streamer select.
34. Audio streamer home.
35. Audio streamer display o.
36. No command for an Audio streamer.
37. Step to the previous amplier input.
38. Set the handset to send commands to an amplier and
Audio streamer.
39. Send commands to a TV (or other device programmed
to use this key).
123
45
79
6
8
0/10
SATTV
STORE
MENU
ENTER
SELECT
LIST
CH
SETUP
abc def
ghi jkl mno
pqrs tuv wxyz
GUIDE
INFO
TEXT
TV/AV
CONTROL
SOURCE
a
b
c
d
e
f
g
h
i
1)
1!
1@
1#
1$
1%
1^
1&
1*
1(
2)
2!
2@
2#
2$
2%
2&
2^
2*
2(
3)
3!
3@
3#
3$
3%
3^
3&
3*
3(

Cyrus CDi-XR User Instrucons
13
Cyrus Phono Signature commands
Commands are sent to the Phono Signature via keys
reserved from the amplier control system.
The remote control operates in the same way as the front
panel controls - press a key to select a funcon, change
that seng with the CURSOR keys, conrm the seng with
ENTER/SELECT.
This page lists commands that will control the Phono
Signature.
• Press the CYRUS key to set the remote control to Cyrus
mode.
You can now control both a Cyrus amplier and the Phono
Signature. The CYRUS key will ash red when commands
are being sent in this mode.
123
45
79
6
8
0/10
SATTV
STORE
MENU
ENTER
SELECT
LIST
CH
SETUP
abc def
ghi jkl mno
pqrs tuv wxyz
GUIDE
INFO
TEXT
TV/AV
CONTROL
SOURCE
Standby
Select
Step le Step right
Input select
Warp lter
MM/MC
Gain select
Resistance
Capacitance
Store
Display o

Cyrus CDi-XR User Instrucons
14
Learning TV and Satellite commands
In addion to controlling Cyrus components, the remote
control can learn the commands from two other remote
control handsets. These will normally be a TV and a
Satellite or terrestrial TV set-top box, programmed to
the TV and SAT buons, but could also be other audio
components including a Cyrus tuner or DVD player etc.
All keys may be programmed with the excepon of the
groups marked CONTROL and SOURCE and the SETUP key.
Preparaon for learning
Check the following points before aempng to learn any
commands -
• Check that both remote controls have fresh baeries.
• Choose a locaon on a tabletop that is not brightly lit.
Subdued light is beer, away from bright natural or
indoor lighng.
• Check that you have enough me to spare to complete
the learning process for all the keys you want to use.
Learning commands
In this example, the Cyrus remote control will be learning
commands from a ‘reference’ Satellite receiver remote
control.
1. Set the two remote controls up facing each other,
spaced by about 5cm.
123
45
79
6
8
0/10
SATTV
STORE
MENU
ENTER
SELECT
LIST
CH
SETUP
abc def
ghi jkl mno
pqrs tuv wxyz
GUIDE
INFO
TEXT
TV/AV
CONTROL
SOURCE
123
45
79
6
8
0/10
SATTV
STORE
MENU
ENTER
SELECT
LIST
CH
SETUP
abc def
ghi jkl mno
pqrs tuv wxyz
GUIDE
INFO
TEXT
TV/AV
CONTROL
SOURCE
The keypad will light and the key you selected will be red.
2. Press the TV or
SAT key to select
the mode that
you want to
program.
3. Press and hold the
SETUP key.
123
45
79
6
8
0/10
SATTV
STORE
MENU
ENTER
SELECT
LIST
CH
SETUP
abc def
ghi jkl mno
pqrs tuv wxyz
GUIDE
INFO
TEXT
TV/AV
CONTROL
SOURCE
123
65
4
789
0
AUDIO SUB
TTX GUIDE FAV
INFO TV/R
OK
LIST EXIT
AD
ZOOM
MENU
VOL CH
5cm
The mode key will change to white. Aer about three
seconds, the mode key will light red again. This indicates
that the remote control is ready to learn codes.
4. Release the SETUP key.
The remote control is now waing to learn commands. The
keypad will light connually and the mode key will light
pale red.
5. On the reference remote control, press and hold the
rst key you want to learn (for example, volume up)
unl the mode key ashes red.
This indicates that the command has been received.
6. Release the key on the reference remote control.
7. Press a key on the Cyrus remote control (volume up
in this example) to select where you want to save that
command.
The mode key will stop ashing. This indicates that the
command has been saved successfully.
If the learning process was successful, the remote control
will be ready to learn the next command.
8. Repeat steps 5 to 7 for each command you want to
learn.
When you have completed learning all commands -
• Press the SETUP key.
The mode key will change to white. Aer a few seconds the
backlight will switch o.

Cyrus CDi-XR User Instrucons
15
Checking programmed commands
• Select the mode that you just programmed and check
that the commands were learned successfully.
NOTE: The TV or SAT mode key should ash red when
sending a command. If the mode key is not ashing, then
the command has not learned correctly.
• Make a note of any commands that have not
programmed correctly and repeat the learning process
to add these in.
NOTE: When you start the learning process it does not
erase any programmed keys so you can re-program
individual keys if required.
Problems with learning
If none of the commands have learned correctly, try re-
starng the learning process again. Test a few keys rst
to ensure that your handset is compable for learning. If
the test works then connue to program the rest of the
commands you need.
If you sll have problems, check carefully that the mode
light is ashing correctly as you send a command to learn.
If not, it may be that the baeries need replacement in
the reference handset or that the spacing between the
handsets is not ideal. Try adjusng the spacing between
the handsets and repeang the learning process.
If you connue to have problems, it may be that your
handset is incompable with the learning process. This
could happen with an older design of handset or one that
has an unusual code-set.
Sending TV or SAT commands
Once you have programmed all the keys with the
commands you want, you can use the remote control to
send commands to your TV or Satellite receiver etc.
• Press the TV or SAT key to select the mode you want.
• Press the command key.
The mode key will ash red when sending a programmed
command.

Cyrus CDi-XR User Instrucons
16
Setup menus
Setup menus enable extensive customisaon of the user
interface.
Setup opons
The next page shows a map of the menu opons available.
Navigang the menu
• Press to open the menu home page.
• Press or to step through the available opons.
• Press to select an opon.
• Press to step back through the menu without making
any changes.
SATTV
ENTER
SELECT
GUIDE
INFO
CONTROL
SOURCE
Menu home
page
Step down
opons
Step back
through
menu
Quick access to
About menu
Step up
opons
Select an
opon

Cyrus CDi-XR User Instrucons
17
General
Setup
Display polarity
Display contrast
LED brightness
Sets the display polarity to positive (dark characters on a light background) or negative (light characters on a dark
background).
Display brightness
Sets the contrast of the display in the range -30 to +30. Factory default setting is -4.
Sets the brightness of the display in the range Level 1 to Level 5. Factory default setting is Level 5.
Sets the brightness of the standby indicator in the range Level 1 to Level 5. Factory default setting is Level 5.
System
Aesthetic
Language
Factory reset
Select an language from the list
This option changes the language for the display.
NOTE: Avoid changing the language to a language you can’t read. It will be difficult to reset to your local language
if you can’t read the display.
This option will return all user settings to the factory defaults. After selecting this option you will need to confirm
you want to go ahead by selecting ‘Yes’ from the sub-menu. Factory reset cannot be undone.
About
This option displays information about the firmware of the unit including model name, firmware version and
release date.
Standby Sensitivity
The sensitivity of the front panel touchpads is adjustable to compensate for changes in the local environment. Low,
Medium and High settings are available. The default ‘Medium’setting is normally suitable for most systems.
Setting to ‘High’ will increase touchpad sensitivity if these are unresponsive or ‘Low’ if there are occasional false
responses. After setting the sensitivity, operate the Standby touchpad once to complete the setup.
NOTE: It is necessary to hold the Standby touchpad briefly to operate it.
Menu map

Cyrus CDi-XR User Instrucons
18
Firmware updates
The operaonal rmware may be upgraded from me to
me to add new features and to x operaonal issues.
New rmware versions will be available from the ‘Support’
pages of the Cyrus website www.cyrusaudio.com.
If new rmware is available, this will be packaged with
other documents including -
• Firmware version change log.
• Latest rmware update procedure.
• Revised handbook (if required).
