Cytech UCM Series User manual

19
Installing the USB Driver
.....................................
19
System Requirements
.......................................
19
USB Connector
..............................................
19
LED Indicators on Daughter Board
............................
19
Parts Supplied
...............................................
18
UCM/USB
.....................................................
17
Comfigurator Network Connection
............................
15
Device Explorer Software
....................................
13
DS Manager Settings
........................................
11
DS Manager
.................................................
11
Connect UCM/ETH02
........................................
10
Ethernet LED Indicators
.....................................
10
SW101
.....................................................
10
Jumper Settings
.............................................
10
Ethernet Connector
..........................................
10
ETH02 Specifications
.........................................
9
UCM/ETH02
....................................................
8
Connectors (Common to all UCMs)
.............................
8
Physical
......................................................
8
J4 Select EEPROM
............................................
8
Other Settings (SW8)
........................................
7
ICs
..........................................................
7
Buttons on UCM Board
........................................
7
LED Indications
...............................................
6
Comfigurator > Modules Tab
..................................
6
ID Setting using COPY Switch (from UCM 6.080)
................
5
Set UCM ID using SW7
........................................
5
Connections
..................................................
5
Getting Started
.................................................
5
Section 2 UCM Settings
...................................
3
UCM submodules
.............................................
3
UCM/232F
...................................................
3
UCM/USB
....................................................
3
UCM/ETH02
..................................................
3
Section 1 Types of UCM
..................................
Universal Communications Module
1

38
Manual Revision History
......................................
37
Section 6 Firmware and Vocab Upgrading
.............
35
Problems with Learned IR Codes
...............................
35
Infrared Learning Errors
.......................................
29
Operation
...................................................
29
Limitations and Disclaimer
...................................
29
Specification
................................................
29
Definitions
..................................................
29
Installation
..................................................
29
Infrared Learning
............................................
29
Section 5 Infrared Learning
.............................
28
LED Status Indications
.........................................
27
“Unable to Communicate with UCM”
...........................
27
Common Problems
.............................................
27
Section 4 Troubleshooting
...............................
25
Compare Button
.............................................
25
Copy/ID Button
.............................................
25
Test Button
.................................................
25
Download Button
............................................
25
Upload Button
...............................................
25
The U2 EEPROM
............................................
25
Section 3 UCM Button Operation
........................
24
RS232 Connector
............................................
22
UCM/232
......................................................
20
Comfigurator Setup
..........................................
Universal Communications Module
2

SECTION 1 TYPES OF UCM
The Universal Communications Modules allows Comfort to connect via RS232
interface, USB or Local Area network to a computer or external equipment. The
types of UCM include;
UCM/ETH02
The UCM/ETH02 has a RJ45 jack for connection to an Ethernet Local Area
Network (LAN) using the TCP/IP protocol. The UCM/ETH02 is a new model
which replaces the UCM/Ethernet. UCM Firmware 5.228 and above is required
for UCM/ETH02.
UCM/USB
The UCM/USB has a USB interface for connection to the USB port of a PC. The
UCM/USB is supported by Comfigurator 3.0.0 onwards.
The term UCM is used when describing functions common to all the above UCM
modules which have identical functions.
UCM/232F
The UCM/232F provides RS232 serial interface to Comfort. UCM/232F is not
usually used for Comfigurator since computers normally do not have serial
ports.
UCM submodules
1 UCM06 is the baseboard to which RS232/F, R232/M USB01, ETH01
daughterboards can be added to make up UCM/232, UCM/USB and
UCM/ETH02 respectively. The UCM06 allows the flexibility of using different
interfaces by plugging in the appropriate daughterboard.
2 USB01 daughterboard. Plugs onto UCM06 to make UCM/USB.
3 ETH02 daughterboard. Plugs onto UCM06 to make UCM/ETH02.
4 RS232/M and RS232/F daughterboard with Male and Female RS232
connectors respectively. Plugs onto UCM06 to make UCM/232M and
UCM/232F.
This manual describes the UCMs with firmware 6.080 and above. For
UCMs with firmware < 6.080, the old manual 3.66 can be downloaded
from http://www.cytech.biz/product_details.php?item_id=159
The UCM/USB, /ETH02 and /232 have the following common functions:
1 It allows configuration on the U2 EEPROM on the UCM to be transferred to
Comfort. This is a useful tool when programming, testing or troubleshooting
Comfort installations.
2 The Comfigurator software requires the UCM to read and write the
configuration file to Comfort.
3 It allows a PC or other controller to communicate with Comfort allowing
third party products or software (e.g. Wizcomfort) to work with Comfort .
The Comfort command protocol can be requested from [email protected]
for the purpose of development of third party interfaces or software.
4 It also allows Infrared signals to be learned and saved as .ifr files which can
be assigned to Comfort IR codes via Comfigurator.
Universal Communications Module
3

5 Allows other Flash-based Comfort and UCM firmware to be upgraded using
Comfigurator Firmware Upgrade.
6 Comfort Voice/Vocabulary (new version of language) can be written to
Comfort using Comfigurator.
There are also application-specific UCMs which interface to specific third party
systems for example, UCM/CBUS for Clipsal’s CBUS, UCM/KNX for the KNX Bus,
UCM/Ulti for Ulti lighting swtches, UCM/Zwave, UCM/GSM for GSM/SMS
Interface, etc. These UCMs cannot be used for programming Comfort. They are
described in their individual manuals. All user and installation manuals are
available from the Cytech website http://www.cytech.biz/manuals.html
Universal Communications Module
4

SECTION 2 UCM SETTINGS
Getting Started
This section is common to UCM/232, UCM/ETH02 and UCM/USB
Connections
Connect the UCM to Comfort using the supplied white cable with 4-way
connector on both ends. It plugs into JP2 or JP2A on the UCM and “RS485”
4-pin header (J6) connector on Comfort II. This supplied cable can be used for
short runs (about 30 centimeter). If the UCM is located further from the
Comfort panel, up to 100 meters, use a cable with 3 twisted pairs. 12V/GND,
KA/KB are to be paired with one pair as spare. Shielding is not necessary. The
UCM may also be connected from the SEM modules. Ensure that polarity is
correct as this is a common cause of problems with communications.
It is not necessary to switch off power to Comfort before plugging in the UCM
connections. The UCM is often connected in order to transfer a configuration file
using Comfigurator.
The firmware programming cable is used only when upgrading
firmware on Comfort or other modules. It should not be connected to
Comfort in normal operations as it will disable Comfort.
Set UCM ID using SW7
SW7 (RS485 ID) 4 way DIP switch should normally be set to 1 according to the
table below (positions A,B,C, D ON) if this UCM is used for programming
Comfort using Comfigurator, because when this UCM ID is disconnected,
Comfort does not report “Communications Failure”, while with UCM IDs 2 to 8,
communications failure will be reported.
Comfort is able to support up to 8 UCMs. SW7 is a 4-way DIP switch which
determines the UCM ID, according to the table below.
Off
Off
Off
Off
COPY Button
On
Off
Off
Off
8
On
Off
Off
On
7
On
Off
On
Off
6
On
Off
On
On
5
On
On
Off
Off
4
On
On
Off
On
3
On
On
On
Off
2
On
On
On
On
1
SW7-D
SW7-C
SW7-B
SW7-A
ID
Table 2.1 - RS485 ID Settings (SW7)
Other UCMs or types of UCM may be connected for interfacing to C-Bus, KNX,
Velbus or others. These other UCMs should be set to higher-numbered IDs, up
to 8. UCM IDs should be sequential, i.e. there should not be any missing ID
numbers, i.e. 1,2,3,4 and not 1, 3, 4, 5
If the ID is changed while power is on, RESET the UCM by pressing the RESET
switch SW1 on the UCM.
Universal Communications Module
5

Make sure that only 1 UCM has ID=1 in the system, otherwise there
will be an addressing conflict which will prevent proper
communication.
ID Setting using COPY Switch (from UCM 6.080)
From UCM Firmware 6.080, the UCM ID can be changed by use of the COPY
switch. If SW7 A to D are all OFF, then the UCM ID is determined by the
saved setting in the U2 EEPROM. Pressing the COPY button momentarily will
show the ID on its leds as shown below (in binary code)
On
On
On
On
Unassigned
Off
Off
Off
On
8
On
On
On
Off
7
Off
On
On
Off
6
On
Off
On
Off
5
Off
Off
On
Off
4
On
On
Off
Off
3
Off
On
Off
Off
2
On
Off
Off
Off
1
RDY (D1)
BUSY1 (D2)
BUSY2 (D3)
ERR (D4)
ID
To change the UCM ID assignment, press and hold the COPY button for at least
2 seconds. The UCM ID will be incremented to the next higher number up to 8.
Press and release the COPY button to increment the ID until the desired ID is
seen. If the COPY button is not pressed for 4 seconds, the ID is confirmed and
the UCM is reset causing all the LEDs to momentarily turn on.This setting
only works if the U2 EEPROM is present and the SW7 DIP switches are
all open.
If the ID is unassigned, all leds are ON.
Comfigurator > Modules Tab
The UCMs in the system are shown in Comfigurator >> Modules Tab
Right Click UCMs and select Scan for UCMs or Scan for All Modules to discover
all UCMs in the system provided the UCMs have been set so that each UCM has
a unique ID.
Universal Communications Module
6

After Scanning for modules, do a Transfer > Write to Comfort to write
the number of modules to Comfort.
LED Indications
Once the UCM is connected with the ID setting set correctly, the LEDs D10
(green) and D9 (red) will flash continuously, and the D1 RDY green LED should
stay on. The RDY LED indicates that the power is on. D10 green led blinking
indicates RS485 data is being received from Comfort, and D9 Red led blinking
indicates the UCM is replying to Comfort. The BUSY1, BUSY2, and ERROR LEDs
should be off. If the LED states are not as described, see the Comments column
or the Troubleshooting section
Blinks send data to USB/RS232/Ethernet
Off
D12 (Red)
Blinks when receive data from USB/RS232/Ethernet
Off
D11 (Green)
Off means ID is incorrect or not polled by Comfort
Blinking (Send RS485)
D9 (Red)
Off means RS485 not connected to Comfort
Blinking (Receive RS485)
D10 (Green)
ON if Error or Operation Failure
Off
D4/ERR (Red)
OFF
D3/BUSY2 (Red)
Blinks if Busy (operation in progress)
OFF
D2/BUSY1 (Red)
Off means no power or module faulty
Steady ON
D1/RDY (Green)
Comments
Idle Behavior
LEDs
Table 2.2 - LEDs states on UCM board in idle mode
If the RDY LED is not on, press the RESET button on the UCM. This may happen
when connecting the UCM 4-way cable to Comfort without turning off power.
RESET on the UCM usually starts the UCM to operate correctly.
Table 2.3 has been removed
Buttons on UCM Board
See UCM Button Operation in the next Section for an explanation
SW1 - RESET
SW2 - UPLOAD Comfort to U2
SW3 - DOWNLOAD U2 to Comfort
SW4 - TEST
SW5 - COPY /ID button
SW6 - COMPARE (NOT USED)
ICs
U1 - Microcontroller IC with Firmware marked “UCM 5.xxx”.
U2 - Backup EEPROM
U5 - RS485 transceiver for Comfort Bus.
Universal Communications Module
7

U8, U9 are Infrared LED receivers for learning IR signals.
Other Settings (SW8)
Not Used
Not Used
H
Not Used
Not Used
G
UCM/ETH02
UCM/ETHf01
F
Not Used
Not Used
A to E
Off - Open
On - Short
SW8
Table 2-4 - SW8 Settings
SW8-F shunt should be inserted for UCM/ETH01 and left out for
UCM/ETH02 or if the UCM is not an Ethernet Module. SEE NOTE below
SW8 - H shunt. Not used. Hardware handshake is disabled in UCM 5.228
firmware. SEE NOTE below
Note that for UCM firmware 5.228 and above, SW8-H for hardware
Flow control is ignored, i.e. no flow control, and SW8-H need not be
inserted
J4 Select EEPROM
J4 - selects U2 or U3 EEPROM socket for reading/writing operations (Found on
earlier UCMs). Always set J4 to U2 position where the EEPROM is
inserted. Note that later UCM hardware will NOT have the J4 shunt and there
will be no IC socket for U2.
Physical
PCB size: 108 x 88 mm
Mounting Holes: 103 x 83 mm (M3 holes 5 mm from corners)
Connectors (Common to all UCMs)
JP2, JP2A - 4 way headers (12V/COM/KA/KB).
JP3 - 12V/COM.
JP4 - KA/KB.
PP1 and PP3 - for Firmware Upgrading of other modules, DO NOT
CONNECT THE FIRMWARE PROGRAMMING CABLE IN NORMAL
OPERATION
Universal Communications Module
8

UCM/ETH02
Figure 2.3 UCM/ETH02
The UCM/ETH02 module allows the Comfort system to be connected to a Local
Area Network. This module converts the serial data of the UCM to the
industry-standard TCP/IP protocol over the Ethernet. This allows the
Comfigurator software to read and write Comfort configuration and allows
Wizcomfort which is a stand-alone user software to access Comfort, over the
LAN instead of using a serial port on the PC. It also allows the Comfort iPhone
App to connect to Comfort, see http://www.cytech.biz/iphone_app_1.html
The UCM/ETH02 can be located in or next to the Comfort panel, and far from
the PCs on the network (up to 100 meters away).
The Comfort serial protocol can be used by third party developers to develop
customized applications for Comfort over the network or Internet.
Figure 2.4 Removed
Universal Communications Module
9

Figure 2.5 ETH02 Daughterboard
The UCM/ETH02 is equivalent to a UCM06 Baseboard with ETH02 daughter
board plugged in.
ETH02 Specifications
Ethernet Interface: 10/100BaseT
Network Protocols: TCP, UDP, HTTP
Serial Interface baud rate: 9600 bits per second
Current Consumption: 80 mA (typical) from Comfort 12V auxiliary output.
Ethernet Connector
MJ101 - RJ45 connector for Ethernet Local Area Network.
Jumper Settings
SW8-F (Ethernet) inserted for ETH01 and open for ETH02.
SW101
Pushbutton switch for reinitializing ETH02 to programming modein case
firmware is corrupted. DO NOT use in normal operations.
Power off UCM/ETH02.
Press and hold SW101 switch.
Power on UCM/ETH02.
Release the SW101 switch after at least 7 seconds upon powered on.
The Green LED on RJ45 connector will turn steady on and D101 red LED will
be flashing when the Ethernet cable is plugged in.
Run Device Explorer software and refer to Device Explorer Software section
on firmware upgrade instruction.
Ethernet LED Indicators
D101 - Link Status LED (Red) - This turns on when ‘active’ Ethernet cable is
plugged into the Ethernet port and blinks whenever an Ethernet packet is
received.
RJ45 connector LEDs (Green and Amber) - dual-function Ethernet status
LEDs. The Green LED should be on when connection is established to its IP
address/port, and blinks twice and repeats while there is no connection.
Universal Communications Module
10

The Amber LED should be off in normal operation and on as error indication
or has a buffer overflow condition.
Connect UCM/ETH02
Connect the Ethernet port MJ101 to the Local Area Network (LAN) by means of
a hub or switch using a parallel CAT 5 cable.
Plug in the 4-way cable from JP2 or JP2A on the UCM to “RS485” (J6) on
Comfort II, and press the RESET button on the UCM. The RDY LED on the UCM
should turn on steady and the LEDs D10 and D9 should be flashing
continuously.
The D101 (Red) should turn on and the two LEDs (Green and Amber) on RJ45
connector should flash 3 times initially. After that, the Green LED will blink
twice every few seconds and D101 (R) will be flashing. When there is no
Ethernet cable plugged in, D101(R) will stay off and the blinking of Green LED
on RJ45 connector will be dimmer.
DS Manager
To set up the IP address and the other network and serial port settings for
UCM/ETH, use DS Manager Software which is included in Comfigurator. The
instructions here assume Comfigurator 3.6.x
In Comfigurator go to Options > Settings > UCM Connection. Select UCM
Interface as Network (Local). The DS Manager Link is seen on the bottom right.
Figure 2.6 - DS Manager in Comfigurator 3.5
Universal Communications Module
11

Click DS Manager. The DS Manager opening screen is shown below;
Figure 2.7 - DS Manager Screen
The barrel icon on the left is gray if it is not on the same network. The icon
channges to blue if it is on the same network. If there is a connection, there will
be blue arrows to the left of the icon. If there is a buffer overflow, the arrow
will be in red dotted lines. To reset the buffer overflow condition, double click
on settings button and press OK to confirm the settings.
The IP address of the UCM/Ethernet is found by the auto-discovery process.
The default IP address as shipped will range from 10.0.0.51 to 10.0.0.60. The
IP address must be changed to one which resides on the same Subnet as the
computers which will be accessing the UCM/Ethernet through the network. For
example, if one of the computers on the network has an address like 10.0.0.1
and the Subnet mask 255.255.255.0, the IP address of the UCM/Ethernet can
be set to any address in the range 10.0.0.2 to 10.0.0.254, making sure that it
does not conflict with any assigned IP address on the network. Click on the
“ChangeIP” button. Enter the new IP address of the UCM/Ethernet. This is not
necessary if the DHCP feature is enabled in the Network Settings page.
On the DS Manager screen, the new IP address should be shown.
The UPGRADE button is used to upgrade the firmware over the network. on
the ETH01 only not ETH02. The Ethernet firmware is for the Ethernet functions
and is not the same as the UCM Firmware. To upgrade, press the Upgrade
button and select the name of the firmware file. The current firmware for
ETH01 is CYTEM334.BIN. Upgrading takes only a few seconds. Upgrading
ETH02 firmware is done by another software, the DS Explorer
described in a later section.
Universal Communications Module
12

The INITIALIZE button initializes all settings back to factory default, except for
the IP address. Do this is any error is shown for the UCM/Ethernet IP address
after refresh.
The BUZZ button causes the RED and GREEN Status LEDs to blink for a few
seconds so that the UCM/ETH02 module which is being accessed can be
identified. This is useful if you have several UCM/ETH02 modules connected
(Comfort can be connected to 8 UCMs of various types)
The ROUTING STATUS button shows the status of Routing buffers, Network
Connection and Serial Port, useful for debugging
Figure 2.8 has been removed
DS Manager Settings
Select the IP address in DS Manager and click on the Settings button. The
General Tab screen is shown below;
Figure 2.9 Device Server General Settings
Owner Name and Device Name are for description only.
DHCP if enabled, it allows the device to be automatically assigned an IP
address if there is a DHCP server in the network. It is recommended that a
fixed IP address be assigned to the device so that Comfigurator or the
iPhone Application and other software can find it.
IP-address is the current IP address of the device.
Next click the Channel1 tab
Universal Communications Module
13

Figure 2.10 Device Server Channel1 Settings
Connection timeout (min): This is the time in minutes (0 to 255) for which
the TCP connection will remain open if there is no data in either direction. A
value of 0 means the connection will never time-out.
It is recommended that 2 minute connection time-out is used when
there may be more than 1 application trying to use the connection at
the same time, eg for iPhone application. The UCM/Eth02 only allows
one connection at a time.
Transport protocol: Choose TCP.
Inband commands: should be disabled.
Routing Mode: should be 0- Server (Slave).
Accept connection from: 0 - Any IP address, or 1 to specify an IP address
to accept connection from.
Port: is the network port through which the data is sent and received from
the UCM. By default, the port is set to 1001.
Notification destination: select 0 - Last port.
Serial interface: 0 - Full-duplex (RS232).
RTS/CTS flow control: 0 disables Flow control. RTS/CTS flow control should
be disabled.
DTR mode: 0 - Idle or remote.
Power-up DTR state: 0 - Low.
Universal Communications Module
14

Baud rate: 3 - 9600bps.
Parity: 0 - None.
Data bits: 1 - 8 bits.
Soft entry into Serial programming mode: 0 - Disabled.
On-the-Fly commands: 1 - Enabled.
Password for on-the-Fly commands: 0 - Disabled.
Notification bitmask: 0
Notification destination: select 0 - Last port.
The TAB called ALL displays the same settings as the General and Channel1
Settings screens combined. The use of this screen is thus not needed, but it
may be used for future expansion of settings.
The button SAVE at the bottom saves the profile under a file name that you
specify with the extension .ds. The button LOAD allows you to load a previously
saved profile.
The PASSWORD button is not used. Ignore it
Device Explorer Software
To upgrade the Ethernet module ETH02 firmware (DOES NOT apply to
UCM/ETH01), install the Device Explorer Software. This is available from Cytech
website at http://www.cytech.biz/device_explorer.html Unzip the file
tdevexplore-2-50-11.zip (the current version at the time of writing) and install
the software.
After Installation, run Device Explorer.
The Device Explorer opening screen is shown below;
Figure 2.15 - Device Explorer Screen
Universal Communications Module
15

The IP address of the UCM/ETH02 is found by the auto-discovery process. The
IP address can also be changed using the DS Manager software.
There will be two display lines shown for the same unit. One is shown with a
blue icon (“programmable TiOS Device” on the status bar) and another is
hammer icon (a “fixed firmware Device Server” on the status bar). Both show
the same MAC address and IP address.
The BUZZ button causes the RED and GREEN Status LEDs to blink for a few
seconds so that the UCM/ETH02 module which is being accessed can be
identified. This is useful if you have several UCM/ETH02 modules connected
The CHANGE MAC button is used to change the physical Ethernet Address of
the module. This should not be changed.
Upgrading Firmware on ETH02 Submodule
The ETH02 firmware is NOT the same as the UCM firmware of the baseboard.
The ETH02 firmware runs on the Ethernet module and not the UCM.
The UPLOAD button is used to upgrade the ETH02 firmware on the submodule
over the network. Select the “programmable TiOS Device” shown with a
hammer icon NOT the blue icon
and not the blue icon. Firmware upgrades are available from the Cytech
Technology website at http://www.cytech.biz/eth02_firmware.html . To
upgrade, press the Upload button, select “Load Firmware Through the
Network”, NOT “Load Application”. Select the firmware file. The current ETH02
firmware is cytech_nowifi_3.11.bin at the time of writing.
The message “The Firmware you have chosen may not be compatible
with the selected device. Do you still want to proceed?” Enter Yes.
Figure 2.16 Upload Firmware for ETH02
Universal Communications Module
16

Firmware Upgrading takes only a few seconds. The Network Upload progress
window is seen as shown below;
Figure 2.17 - Network Upload Progress
If the Network Upload window does not show any progress after a few
seconds, this is usually due to a firewall. Disable the firewalls on your
PC eg Zone Alarm before upgrading the firmware.
After upgrading the ETH02 firmware go back to DS Manager. If there
an error message on DS Manager, press the Initialise button to
initialise the module. This defaults all settings except the IP Address.
Enter the parameters as shown above if necessary.
Features of ETH02 Firmware cytech_3.13.bin
Presets DS Manager settings like baud rate, enable Inband commands,
Connection Time-out 2 minutes. These settings are the default settings after
the Initialise Button is pressed in DS Manager
Comfigurator Network Connection
Figure 2.18 Comfigurator Network Connection
To use Comfigurator to connect to Comfort over the network, select Menu
Options > Settings.
Universal Communications Module
17

In UCM Interface, select Network. In IP Address or Host Name, enter the IP
Address and the Port number which was set for the UCM/ETH02 and click OK.
UCM/USB
Figure 2.19 UCM/USB
The UCM/USB module provides a USB interface to Comfort. It has the same
functionality as the UCM/232 which has a serial (RS232) interface. The
UCM/USB uses the same firmware as a UCM/232.
Universal Communications Module
18

Figure 2.20 USB01
The UCM/USB is equivalent to a UCM06 Baseboard with a USB01 daughter
board plugged in.
Parts Supplied
UCM/USB Firmware 5.228 and above
USB Cable A to A
RS485 4-way cable
6-way programming cable
LED Indicators on Daughter Board
D1 (Red) – Receive from PC.
D2 (Green) – Transmit to PC.
USB Connector
P2 - USB connector for USB interface.
System Requirements
UCM 5.178 and above.
Comfigurator version 3.0.0 and above.
Windows XP/Vista/7
Installing the USB Driver
The USB drivers can be found in the folder "C:\Program
Files\Cytech\Comfigurator\USB Drivers" depending on your Comfigurator
installation folder. The latest version of the driver if needed can be downloaded
from http://www.ftdichip.com/Drivers/D2XX.htm This driver should be of
version 2.06.00 or above.
If a device of the same type has already been installed on your
machine and the drivers that are about to be installed are different
from those installed already, this may prevent the UCM/USB from
communicating the original drivers need to be uninstalled before
installing the new driver. Delete the driver by going to My Computer >
Control Panel > System> Hardware Tab > Device Manager. Look for
USB Serial Bus Controller > USB to serial converter. Right Click and
select Delete Driver.
Universal Communications Module
19

Connect the device to a spare USB port on your PC. If there is an available
Internet connection, Windows will silently connect to the Windows Update
website and install any suitable driver it finds for the device. If the automatic
installation takes place there is no need to continue with the procedure outlined
below.
For Windows XP
If there is no available Internet connection or Windows XP SP 2 is
configured to ask before connecting to Windows Update, the “Found New
Hardware” screen appears. displayed. Select "No, not this time" from the
options available and then click "Next" to proceed with the installation.
Select "Install from a list or specific location (Advanced)" and then click
"Next".
Select "Search for the best driver in these locations" and browse to the
folder Program Files\Cytech\Comfigurator\USB Drivers. Click next to
proceed.
If the message dialogue that “the software has not passed Windows Logo
Testing” appears, click on "Continue Anyway" to continue with the
installation.
The Wizard will install the necessary driver files and show when the
installation has been completed. Click Finish to complete the installation.
For Windows 7
If no suitable driver is automatically found then the following procedure
should be followed.
Press the Windows start button to bring up the start menu and select
“Control Panel”.
From the Control Panel window select Hardware and Sound. At the next
screen select Device Manager
In the Device Manager window there will be a device under Other Devices
with a yellow warning symbol to indicate a problem i.e. no driver installed.
The text next to this device will depend on the device attached. In this
example the device was a TTL232R device. Right click on the other device
(TTL232R in this example) to bring up a menu as shown below. From the
displayed menu select “Update Driver Software…”
This then displays the option for an automatic search or a manual search.
Select the second option to browse manually. In the address box put the
exact location where the drivers have been saved to.
After entering the address select “NEXT” to start the installation. When the
installation has finished a completion screen is displayed.
Comfigurator Setup
The UCM/USB is supported by Comfigurator 3.0.0 and above. Switch on
Comfort with the UCM/USB and connect the USB cable to the computer. The
new hardware should be detected and installed automatically by the computer.
In Comfigurator, go to Options > Settings > UCM Interface. Select USB from
Universal Communications Module
20
