D-Link Air DWL-120 User manual

DWL-120
11 Mbps Wireless USB Adapter
Quick Install GuideQuick Install Guide
11 Installing the DriversInstalling the Drivers
With the computer turned ON, insert the
driver CD for the DWL-120 Wireless
USB adapter into the CD-ROM.
Note: Please do not connect the DWL-120 wireless USB
adapter until advised to do so.
The driver CD will automatically load.
Click on “Install Drivers.”
This screen will appear for just a
moment.
Windows will recognize the DWL-120 Wireless USB adapter.
When the following “Welcome” screen
is displayed,
Click Next.
Rev:dwl-120.01-22-01.10am
for Windows 2000for Windows 2000

11 Installing the DriversInstalling the Drivers continuedcontinued
Finishing InstallationFinishing Installation
Windows will prompt for the destina-
tion folder.
Click Next to accept the selected fold-
er.
Otherwise, click “Browse,”
and select an alternate folder.
Click Next, on the following screen.
When the following screen is displayed,
Click Next.
Windows will finish loading system files.
Rev:dwl-120.01-22-01.10am
22
Insert the DWL-120 Wireless USB adapter into an available USB port.
Windows will recognize
the new hardware.

22 Finishing InstallationFinishing Installation continuedcontinued
The driver files will be found on the CD, as shown
in the following screen.
Note: If Windows is unable to find the drivers,
refer to Appendix A for browsing the CD-ROM
drive.
Click Next.
In the following dialog box, make sure that
“Search for a suitable driver for my device”
is selected.
Click Next.
On the next screen, make sure that the
“CD-ROM drive” box is selected in the
location box.
Click Next.
Rev:dwl-120.01-22-01.10am
The “Add New Hardware Wizard” screen will
appear.
Click Next.

22 Finishing InstallationFinishing Installation continuedcontinued
To check that the adapter is working, click on the configura
-
tion utility icon in the task bar. Make sure that there is a wire
-
less connection under the “status tab.”
At the next window,
Click Finish.
Restart the computer to complete the installation.
The following screen will appear only during the
initial installation.
Click Yes to continue.

For instructions on configuration, please see your User’s Manual.
AA
APPENDIXAPPENDIX Providing Driver FilesProviding Driver Files
If prompted for the driver files, insert the driver CD.
Click Browse.
Click OK.
Select the CD-ROM drive.
Windows will copy the necessary files.
