Düren tools 321275 User manual

PLEASE KEEP THIS MANUAL SAFE FOR FUTURE REFERENCE
www.duren.co.uk
Part Code: 625627
625624_Product Instructions 27/03/2014 08:30 Page 1
Air operated 10mm Belt Sander
Instruction Manual
Part Code: 321275

Tool Use
This Air Operated Dual Action Sander is
designed for the purpose of sanding a
variety of coatings from steel, wood,
plastics, etc.
Usefull Links
625627
Instrucon Manual
Duren Tools
T: 01582 484875 E: [e-mail]
www.duren.co.uk
IMPORTANT
Please read through this Manual carefully before using the 625627.
This tool must only be used for sanding and within the parameters
outlined in this manual. All users of the equipment should be trained in
any risks associated with the products they are sanding or using as
finishing aids.
Specification
Pad Diameter 3”/75mm
Pad Thread Size M6
Free Speed 15,000RPM
Minimum Disc Speed 18,000RPM
Operating Pressure 90Psi/6.3BAR
Air Consumption 4CFM
Air Inlet 1/4” BSP
Vibration Level 6.56m/s2
Noise Level 86aD(A)
Weight 690g
Length 170mm
Safety Instructions
These instructions are intended as a guide to the correct use of this equipment. The process or
materials being sanded may have risk characteristics requiring additional safety measures and
these must be identified by the user. All users of this sander must be thoroughly acquainted with
this manual.
Before Use and Before Using Tool for the First Time
- Make sure you have the relevant Personal Protection Equipment (PPE).
Hand Protection
The pad revolves at high speed and may cause damage if bought into contact with
exposed flesh. The workpiece and the pad may also get hot after prolonged use. Hand
protection must be strong enough to protect the skin and be a good fit and have no loose
parts that may get caught in rotating parts.
Determination of the test results includes consideration of measurement
uncertainty from the test equipment and methods.
www.duren.co.uk Product
Information
625624_Product Instructions 27/03/2014 08:30 Page 2
Tool Use
This Air Operated Dual Action Sander is
designed for the purpose of sanding a
variety of coatings from steel, wood,
plastics, etc.
Usefull Links
625627
Instrucon Manual
Duren Tools
T: 01582 484875 E: [email protected]
www.duren.co.uk
IMPORTANT
Please read through this Manual carefully before using the 625627.
This tool must only be used for sanding and within the parameters
outlined in this manual. All users of the equipment should be trained in
any risks associated with the products they are sanding or using as
finishing aids.
Specification
Pad Diameter 3”/75mm
Pad Thread Size M6
Free Speed 15,000RPM
Minimum Disc Speed 18,000RPM
Operating Pressure 90Psi/6.3BAR
Air Consumption 4CFM
Air Inlet 1/4” BSP
Vibration Level 6.56m/s2
Noise Level 86aD(A)
Weight 690g
Length 170mm
Safety Instructions
These instructions are intended as a guide to the correct use of this equipment. The process or
materials being sanded may have risk characteristics requiring additional safety measures and
these must be identified by the user. All users of this sander must be thoroughly acquainted with
this manual.
Before Use and Before Using Tool for the First Time
- Make sure you have the relevant Personal Protection Equipment (PPE).
Hand Protection
The pad revolves at high speed and may cause damage if bought into contact with
exposed flesh. The workpiece and the pad may also get hot after prolonged use. Hand
protection must be strong enough to protect the skin and be a good fit and have no loose
parts that may get caught in rotating parts.
Determination of the test results includes consideration of measurement
uncertainty from the test equipment and methods.
www.duren.co.uk Product
Information
625624_Product Instructions 27/03/2014 08:30 Page 2
Specication
Free speed 16,000 RPM
Air Consumption 3.5 CFM
Air Pressure 90PSI/6.3BAR
Air Inlet 1/4BSP
Net Weight 0.8Kg
Belt Size 10x330mm
Noise Level Lpa:89; Lwa:10
Vibration Level 0.9m/s² Max
Tool Use
This Air Operated Dual Action Sander is
designed for the purpose of sanding a
variety of coatings from steel, wood,
plastics, etc.
Usefull Links
625627
Instrucon Manual
Duren Tools
T: 01582 484875 E: [e-mail]
www.duren.co.uk
IMPORTANT
Please read through this Manual carefully before using the 625627.
This tool must only be used for sanding and within the parameters
outlined in this manual. All users of the equipment should be trained in
any risks associated with the products they are sanding or using as
finishing aids.
Specification
Pad Diameter 3”/75mm
Pad Thread Size M6
Free Speed 15,000RPM
Minimum Disc Speed 18,000RPM
Operating Pressure 90Psi/6.3BAR
Air Consumption 4CFM
Air Inlet 1/4” BSP
Vibration Level 6.56m/s2
Noise Level 86aD(A)
Weight 690g
Length 170mm
Safety Instructions
These instructions are intended as a guide to the correct use of this equipment. The process or
materials being sanded may have risk characteristics requiring additional safety measures and
these must be identified by the user. All users of this sander must be thoroughly acquainted with
this manual.
Before Use and Before Using Tool for the First Time
- Make sure you have the relevant Personal Protection Equipment (PPE).
Hand Protection
The pad revolves at high speed and may cause damage if bought into contact with
exposed flesh. The workpiece and the pad may also get hot after prolonged use. Hand
protection must be strong enough to protect the skin and be a good fit and have no loose
parts that may get caught in rotating parts.
Determination of the test results includes consideration of measurement
uncertainty from the test equipment and methods.
www.duren.co.uk Product
Information
625624_Product Instructions 27/03/2014 08:30 Page 2
Tool Use
This Air Operated Dual Action Sander is
designed for the purpose of sanding a
variety of coatings from steel, wood,
plastics, etc.
Usefull Links
625627
Instrucon Manual
Duren Tools
T: 01582 484875 E: [e-mail]
www.duren.co.uk
IMPORTANT
Please read through this Manual carefully before using the 625627.
This tool must only be used for sanding and within the parameters
outlined in this manual. All users of the equipment should be trained in
any risks associated with the products they are sanding or using as
finishing aids.
Specification
Pad Diameter 3”/75mm
Pad Thread Size M6
Free Speed 15,000RPM
Minimum Disc Speed 18,000RPM
Operating Pressure 90Psi/6.3BAR
Air Consumption 4CFM
Air Inlet 1/4” BSP
Vibration Level 6.56m/s2
Noise Level 86aD(A)
Weight 690g
Length 170mm
Safety Instructions
These instructions are intended as a guide to the correct use of this equipment. The process or
materials being sanded may have risk characteristics requiring additional safety measures and
these must be identified by the user. All users of this sander must be thoroughly acquainted with
this manual.
Before Use and Before Using Tool for the First Time
- Make sure you have the relevant Personal Protection Equipment (PPE).
Hand Protection
The pad revolves at high speed and may cause damage if bought into contact with
exposed flesh. The workpiece and the pad may also get hot after prolonged use. Hand
protection must be strong enough to protect the skin and be a good fit and have no loose
parts that may get caught in rotating parts.
Determination of the test results includes consideration of measurement
uncertainty from the test equipment and methods.
www.duren.co.uk Product
Information
625624_Product Instructions 27/03/2014 08:30 Page 2
321275
321275.
Tool Use
This Air Operated Belt Sander is designed
for the purpose of sanding a variety of coat-
ings from steel, wood, plastics, etc.

Eye and Breathing Protection
The sanding process will create dust and other airborne particles. There is no dust
extraction function on this machine so it is essential that approved eye and breathing
protection is worn.
Noise and Ear Protection
Depending on the material being worked on and the type of sanding disc used, noise
levels may cause hearing damage including temporary or even permanent hearing loss.
It is recommended that Ear Protection is worn at all times when using the sander.
Repetitive Strain Injury (RSI)
All products of this nature can cause RSI if used for long period, particulary in an
awkward operating position. Adequate rest periods and working conditions should be
considered for prolonged use.
General Safety Information
1 Ensure the sanding pad is equal to or greater than 120% of the stated RPM of the
sander.
2 Keep the workplace clean and tidy.
3 Use the tool in a well ventilated area.
4 Air hoses can present a trip hazard, always keep hoses in a way that minimises trip
hazards.
5 DO NOT hold the workpiece by hand, always make sure the workpiece is clamped
securely.
6 Keep all flammable and combustible materials away from the work area.
7 Children and other unauthorised persons should be kept away from the work area.
8 NEVER use the sander whilst the floor underfoot is wet or slippery.
9 NEVER use the sander when standing on an unstable surface.
10 Keep the sander out of reach of children.
11 Analyse the material you are sanding. Be aware of the dangers of sanding lead based
paints. Historically, paint contained lead and sanding such paint will cause toxic dust. If
you suspect that lead could be in the paint the following actions must be observed;
- Alert any other persons in the nearby and keep them away from the working
area.
- Use specific air fed respirator, PE coated coveralls and latex gloves.
- Dispose of any dust and paint waste correctly and thoroughly clean the
workpiece and working area after the sanding has finished.
12 NEVER attempt to sand materials containing asbestos.
13 VIBRATION. Hand held air tools may produce vibration. Vibration from sanders can
cause disease. The use of gloves will help reduce the risk and can help prevent injury.
14 Disconnect the air supply before changing disc or pad.
15 Ensure the sander has stopped rotating before putting it down or handling the pad or
disc.
16 NEVER carry the sander by the air hose.
17 NEVER point the sander at other persons.
18 NEVER operate the sander whilst under the influence or drugs, alcohol or intoxicating
medication.
19 Check you have no loose clothing, hair, jewellery or any other items of a personal nature
that might become entangled with the rotating parts.
20 Check you have a maximum inlet air pressure of 90PSI/6.3BAR.
PLEASE KEEP THIS MANUAL SAFE FOR FUTURE REFERENCE
Duren Tools
T: 01582 484875 E: [e-mail]
www.duren.co.uk
625624_Product Instructions 27/03/2014 08:30 Page 3
Eye and Breathing Protection
The sanding process will create dust and other airborne particles. There is no dust
extraction function on this machine so it is essential that approved eye and breathing
protection is worn.
Noise and Ear Protection
Depending on the material being worked on and the type of sanding disc used, noise
levels may cause hearing damage including temporary or even permanent hearing loss.
It is recommended that Ear Protection is worn at all times when using the sander.
Repetitive Strain Injury (RSI)
All products of this nature can cause RSI if used for long period, particulary in an
awkward operating position. Adequate rest periods and working conditions should be
considered for prolonged use.
General Safety Information
1 Ensure the sanding pad is equal to or greater than 120% of the stated RPM of the
sander.
2 Keep the workplace clean and tidy.
3 Use the tool in a well ventilated area.
4 Air hoses can present a trip hazard, always keep hoses in a way that minimises trip
hazards.
5 DO NOT hold the workpiece by hand, always make sure the workpiece is clamped
securely.
6 Keep all flammable and combustible materials away from the work area.
7 Children and other unauthorised persons should be kept away from the work area.
8 NEVER use the sander whilst the floor underfoot is wet or slippery.
9 NEVER use the sander when standing on an unstable surface.
10 Keep the sander out of reach of children.
11 Analyse the material you are sanding. Be aware of the dangers of sanding lead based
paints. Historically, paint contained lead and sanding such paint will cause toxic dust. If
you suspect that lead could be in the paint the following actions must be observed;
- Alert any other persons in the nearby and keep them away from the working
area.
- Use specific air fed respirator, PE coated coveralls and latex gloves.
- Dispose of any dust and paint waste correctly and thoroughly clean the
workpiece and working area after the sanding has finished.
12 NEVER attempt to sand materials containing asbestos.
13 VIBRATION. Hand held air tools may produce vibration. Vibration from sanders can
cause disease. The use of gloves will help reduce the risk and can help prevent injury.
14 Disconnect the air supply before changing disc or pad.
15 Ensure the sander has stopped rotating before putting it down or handling the pad or
disc.
16 NEVER carry the sander by the air hose.
17 NEVER point the sander at other persons.
18 NEVER operate the sander whilst under the influence or drugs, alcohol or intoxicating
medication.
19 Check you have no loose clothing, hair, jewellery or any other items of a personal nature
that might become entangled with the rotating parts.
20 Check you have a maximum inlet air pressure of 90PSI/6.3BAR.
PLEASE KEEP THIS MANUAL SAFE FOR FUTURE REFERENCE
Duren Tools
T: 01582 484875 E: [e-mail]
www.duren.co.uk
625624_Product Instructions 27/03/2014 08:30 Page 3
PLEASE KEEP THIS MANUAL SAFE FOR FUTURE REFERENCE
Duren Tools
T: 01582 484875 E: [email protected]
www.duren.co.uk
4 It is strongly advised that you always use a Whip Hose/Leader Hose in combination with
Quick Release Couplings. See Fig. 2 for recommended setup.
5 Water in the air supply will cause the internal bearing of the tool to rust and eventually
seize.
6 Make sure that your airline is free from water at all times.
7 Always select the correct sanding disc grit for the job.
Tools Included with your Sander
1 x High Flow Male Air Fitting
Maintenance
1 If the air supply is not lubricated sufficiently it will be necessary to lubricate the tool
directly. This can be done by disconnecting the air hose and pouring in 5ml of air tool oil
into the Air Inlet. Read safety data sheet or instructions on use of oil to ensure safe
usage. These can be obtained from your supplier.
2 Replace worn or damaged parts using genuine parts only.
3 Store tool in a dry area, do not allow tool to be immerse in water or used/stored in wet
conditions.
625624_Product Instructions 27/03/2014 08:30 Page 5
PLEASE KEEP THIS MANUAL SAFE FOR FUTURE REFERENCE
Duren Tools
T: 01582 484875 E: [e-mail]
www.duren.co.uk
4 It is strongly advised that you always use a Whip Hose/Leader Hose in combination with
Quick Release Couplings. See Fig. 2 for recommended setup.
5 Water in the air supply will cause the internal bearing of the tool to rust and eventually
seize.
6 Make sure that your airline is free from water at all times.
7 Always select the correct sanding disc grit for the job.
Tools Included with your Sander
1 x High Flow Male Air Fitting
Maintenance
1 If the air supply is not lubricated sufficiently it will be necessary to lubricate the tool
directly. This can be done by disconnecting the air hose and pouring in 5ml of air tool oil
into the Air Inlet. Read safety data sheet or instructions on use of oil to ensure safe
usage. These can be obtained from your supplier.
2 Replace worn or damaged parts using genuine parts only.
3 Store tool in a dry area, do not allow tool to be immerse in water or used/stored in wet
conditions.
625624_Product Instructions 27/03/2014 08:30 Page 5
PLEASE KEEP THIS MANUAL SAFE FOR FUTURE REFERENCE
Duren Tools
T: 01582 484875 E: [e-mail]
www.duren.co.uk
4 It is strongly advised that you always use a Whip Hose/Leader Hose in combination with
Quick Release Couplings. See Fig. 2 for recommended setup.
5 Water in the air supply will cause the internal bearing of the tool to rust and eventually
seize.
6 Make sure that your airline is free from water at all times.
7 Always select the correct sanding disc grit for the job.
Tools Included with your Sander
1 x High Flow Male Air Fitting
Maintenance
1 If the air supply is not lubricated sufficiently it will be necessary to lubricate the tool
directly. This can be done by disconnecting the air hose and pouring in 5ml of air tool oil
into the Air Inlet. Read safety data sheet or instructions on use of oil to ensure safe
usage. These can be obtained from your supplier.
2 Replace worn or damaged parts using genuine parts only.
3 Store tool in a dry area, do not allow tool to be immerse in water or used/stored in wet
conditions.
625624_Product Instructions 27/03/2014 08:30 Page 5

Entanglement Hazards
Choking, scalping and/or lacerations can occur if loose clothing,
personal jewellery, neck wear, hair or gloves are not kept away
from the tool and its accessories.
Operating Hazards
a Use of the tool can expose the operator’s hands to hazards,
including cuts, abrasions and heat.
b) Wear suitable gloves to protect hands.
c) Operators and maintenance personnel should be physically able
to handle the bulk weight and power of the tool.
d) Hold the tool correctly; be ready to counter act normal or sudden
movements: and have both hands available.
e) Maintain a balanced body position and secure footing.
f) Release the start and stop device in the case of an interruption of
the energy supply.
g) Use only lubricants recommended by the manufacturer.
h) Personal protective safety glasses should be used; suitable gloves
and protective clothing are recommended.
I) Avoid direct contact with moving parts In order to prevent pinching
or cutting of hands or other body parts.
j) There is a risk of electrostatic discharge if used on plastic and
other non-conductlve materials.
Repetitive Motion Hazards
a When using this tool to perform work-related activities, the
operator can experience discomfort in the hands, arms, shoulders,
neck or other parts of the body.
b) While using this tool the operator should adopt a comfortable
position maintaining secure footing and avoiding awkward or
off-balance postures. The operator should change posture during
extended tasks; this can help avoid discomfort and fatigue.
c) If the operator experiences symptoms such as persistent or
recurring discomfort, pain, throbbing, aching, tingling, numbness,
burning sensations or stiffness, these warning signs should not be
ignored. The operator should inform the employer and consult a
qualied health professional.
Accessory Hazards
a) Disconnect the tool from the energy supply before tting or
changing the inserted tool or accessory.
b) Avoid direct contact with the inserted tool during and after use, as
it can be hot or sharp.
c) Use only sizes and types of accessories and consumables that
are recommended by the manufacturer of this tool; do not use
other types or sizes of accessories or consumables
Workplace Hazards
a) Slips, trips and falls are major causes of workplace Injury. Be
aware of slippery surfaces caused by use of the tool and also of
trip hazards caused by the air line or hydraulic hose.
b) This tool is not intended for use In potentially explosive
atmospheres and is not insulated against contact with electric
power.
Dust & Fume Hazards
a) Dust and fumes generated when using this tool can cause
ill health (for example cancer, birth defects, asthma and/or
dermatitis); risk assessment and implementation of appropriate
controls for these hazards are essential.
b) Risk assessment should include dust created by the use of the
tool and the potential for disturbing existing dust.
c) Direct the exhaust so as to minimise disturbance of dust in a dust-
lled environment.
d) Where dust or fumes are created, the priority should be to control
them at the point of emission.
e) Select, maintain and replace the consumable inserted tool
as recommended in the instruction handbook, to prevent an
unnecessary increase In dust or fumes.
f) Use respiratory protection in accordance with employer’s
instructions and as required by occupational health and safety
regulations.
Noise Hazards
a) Exposure to high noise levels can cause permanent disabling
hearing loss and other problems, such tinnitus (ringing, buzzing,
whistling or humming in the ears). Therefore, risk assessment
and implementation of appropriate controls for these hazards are
essential.
b) Appropriate controls to reduce the risk can include actions such as
damping material to prevent work pieces from ‘ringing’
c) Use hearing protection In accordance with employer’s Instructions
and as required by occupational health and safety regulations.
d) Operate and maintain this tool as recommended in the instruction
handbook, to prevent an unnecessary increase in the noise level.
e) Select, maintain and replace the consumable inserted tool
as recommended in the instruction handbook, to prevent an
unnecessary increase in noise.
f) If the tool has a silencer, always ensure it is in place and in good
working order when the tool is being operated.
Vibration Hazards
a) Exposure to vibration can cause disabling damage to the nerves
and blood supply of the hands and arms.
b) Wear warm clothing when working in cold conditions and keep
your hands warm and dry.
c) If you experience numbness, tingling, pain or whitening of the
skin in your ngers or hands, stop using the machine, inform your
employer and consult a physician.
d) Operate and maintain the sander or polisher as recommended in
the instruction handbook, to prevent an unnecessary increase in
vibration levels.
e) Hold the tool with a light but safe grip, taking account of the
required hand reaction forces, because the risk from vibration is
generally greater when the grip force is higher.
Additional Safety Instructions for
Pneumatic Power Tools
Air under pressure can cause severe injury:
• Always shut off air supply, drain hose of air pressure and
disconnect tool from air supply when not in use, before changing
accessories or when making repairs.
• Never direct air at yourself or anyone else.
• Whipping hoses can cause severe injury. Always check for
damaged or loose hoses and ttings.
• Whenever universal twist couplings (claw couplings) are used,
lock pins should be installed and whip check safety cables should
be used to safeguard against possible hose-to-tool or hose-to-
hose connection failure.
• Do not exceed the maximum air pressure stated on the tool.
• Never carry an air tool by the hose.
Sanding Tool Safety WARNING!
• Use clamps or another practical way to secure the work piece
to a stable platform. Holding the work piece by hand or against
the body makes it unstable and may lead to a loss of control.
a. ALWAYS wear appropriate protective equipment, Including a
dust mask with a minimum FFP2 rating, eye protection and
ear defenders.
b. Ensure all people In the vicinity of the work area are also
equipped with suitable personal protective equipment.
c. Take special care when sanding some work (such as beech,
oak. mahogany and teak) as the dust produced is toxic and can
cause extreme reactions.
d. NEVER use to process any materials containing asbestos.
Consult a qualied professional, if you are uncertain whether an
object contains asbestos.
e. DO NOT sand magnesium or alloys containing a high
percentage of magnesium.
f. Be aware of paint nishes or treatments that may have been
applied to the material that is being sanded. Many treatments
can create dust that is toxic or otherwise harmful. If working
on a building constructed prior to 1960, there is an increased
chance of encountering lead-based paints.
g. The dust produced when sanding lead based paints is
particularly hazardous to children, pregnant women and
people with high blood pressure. DO NOT allow these people
near lo the work area, even if wearing appropriate personal
protective equipment.
h. Whenever possible, use a vacuum dust extraction system to
control dust and waste
i. Be especially careful when using a machine for both wood
and metal sanding. Sparks from metal can easily ignite wood
dust. ALWAYS clean your machine thoroughly to reduce the risk
of re.
j. Empty the dust bag or container (where applicable )frequently
during use, before taking breaks and after completion of
sanding. Dust may be an explosion hazard. DO NOT throw
sanding dust into an open re. Spontaneous combustion may
occur when oil or water particles come Into contact with dust
particles. Dispose of waste materials carefully and in accordance
with local laws and regulations.
k. Work surfaces and sandpaper can become very hot during
use, If there is evidence of burning (smoke or ash), from the
work surface, stop and allow the material to cool. DO NOT
touch work surface or sandpaper until they have had time to cool.
l. DO NOT touch the moving sandpaper
m. ALWAYS switch off before you put the sander down.
n. DO NOT use for wet sanding. Liquids entering the motor
housing can cause severe electric shocks.
o. ALWAYS unplug the sander from the mains power supply
before changing or replacing sandpaper.
p. Even when this tool is used as prescribed it is not possible to
eliminate all residual risk factors. If you are in any doubt as to
safe use of this tool, do not use it.

PLEASE KEEP THIS MANUAL SAFE FOR FUTURE REFERENCE
Duren Tools
T: 01582 484875 E: [email protected]
www.duren.co.uk
4 It is strongly advised that you always use a Whip Hose/Leader Hose in combination with
Quick Release Couplings. See Fig. 2 for recommended setup.
5 Water in the air supply will cause the internal bearing of the tool to rust and eventually
seize.
6 Make sure that your airline is free from water at all times.
7 Always select the correct sanding disc grit for the job.
Tools Included with your Sander
1 x High Flow Male Air Fitting
Maintenance
1 If the air supply is not lubricated sufficiently it will be necessary to lubricate the tool
directly. This can be done by disconnecting the air hose and pouring in 5ml of air tool oil
into the Air Inlet. Read safety data sheet or instructions on use of oil to ensure safe
usage. These can be obtained from your supplier.
2 Replace worn or damaged parts using genuine parts only.
3 Store tool in a dry area, do not allow tool to be immerse in water or used/stored in wet
conditions.
625624_Product Instructions 27/03/2014 08:30 Page 5
Parts Diagram
Tensioning
Arm
Accessories (Not Shown):
2 x Sanding Belt (60 grit)
Hex Key
Tensioning
Pulley
Tensioning Lever
Extension Arm
Angle
Adjustment
Screw
Handle
Air Inlet
Exhaust
Quick
Connector
Sanding Belt

PLEASE KEEP THIS MANUAL SAFE FOR FUTURE REFERENCE
Duren Tools
T: 01582 484875 E: [e-mail]
www.duren.co.uk
Warranty
We hope that you will be very happy with your purchase. If you do have a problem with your tool,
you have the added peace of mind of a 12 month warranty, which comes into date from the date of
purchase (proof of purchase required).
Scope of Warranty
- The warranty will cover you from all faults caused by defective components or poor workmanship.
- Tools sent outside the EU are not covered by this warranty.
- Product must be returned to us, the warranty does not cover cost of carriage.
- If the product is no longer in manufacture, it will be replaced with a tool of equivalent or higher
specification.
What is not covered
- Normal wear and tear caused by use in accordance with the operating instructions.
- Replacement of any provided accessories, such as Backing Pads, Airline Connections, Air
Fittings, Blades, Spanners, etc.
- Accidental damage, faults caused by negligent use or care, neglect, misuse or careless operation,
handling and storage of the product.
- Modification of, or change of, any part of this product in any way.
- Faults caused by use of non compatible accessories.
- Tool seizure caused by insufficient oiling.
- Faults caused by incorrect installation.
- Repairs or alterations carried out by non-approved parties.
- Traces of water or rust inside tool - this shows that a properly working air filter has not been used.
Validity
- This warranty is valid for 12 months after date of purchase.
- Warranty is rendered invalid if;
- Tool is taken apart for any reason without our consent.
- Tool is not oiled daily.
- Air supply line is not used with a properly working air filter.
- A warranty claim will not be accepted without an official proof of purchase from your supplier.
625624_Product Instructions 27/03/2014 08:30 Page 7
PLEASE KEEP THIS MANUAL SAFE FOR FUTURE REFERENCE
Duren Tools
T: 01582 484875 E: [email protected]
www.duren.co.uk
4 It is strongly advised that you always use a Whip Hose/Leader Hose in combination with
Quick Release Couplings. See Fig. 2 for recommended setup.
5 Water in the air supply will cause the internal bearing of the tool to rust and eventually
seize.
6 Make sure that your airline is free from water at all times.
7 Always select the correct sanding disc grit for the job.
Tools Included with your Sander
1 x High Flow Male Air Fitting
Maintenance
1 If the air supply is not lubricated sufficiently it will be necessary to lubricate the tool
directly. This can be done by disconnecting the air hose and pouring in 5ml of air tool oil
into the Air Inlet. Read safety data sheet or instructions on use of oil to ensure safe
usage. These can be obtained from your supplier.
2 Replace worn or damaged parts using genuine parts only.
3 Store tool in a dry area, do not allow tool to be immerse in water or used/stored in wet
conditions.
625624_Product Instructions 27/03/2014 08:30 Page 5

625627
Instrucon Manual
Duren Tools
T: 01582 484875 E: [e-mail]
www.duren.co.uk
Declaration of Conformity
We declare that the equipment detail below, to the best of our knowledge and
ability, complies with the following Directive.
Machinery Directive - 2006/42/EC and amending Directives
Equipment Description 75mm Palm Sander
Part Code 625627
Distributed in the EU by Fast Mover Tools Ltd
Address Unit 1 Frenchs Avenue
Dunstable
Bedfordshire
LU6 1BH
United Kingdom
The following Transposed Harmonised Standards have been applied in the
design and construction of this equipment:
The manufacturer and the distributor, stated above, hold the Technical Construction File for this
equipment.
Signed on behalf of the distributor
(the responsible person) …………………………………………
Name: Brian Moffitt
Position: Director
Date and Place: 01/03/16, Dunstable, UK
Please look after the environment, dispose of all packaging in a responsible way.
Always dispose of tools in accordance with local authority guidelines.
© 2016 Fast Mover Tools Ltd. This document is copyright and is not to be copied, circulated, distributed or shown
to anyone other than the intended recipient without the express permission of Fast Mover Tools.
625624_Product Instructions 27/03/2014 08:30 Page 8
EN ISO 11148-8:2011 Part 8: Hand held non – electrical power tools- safety requirements –
sanders and polishers
10mm Belt Sander
321275
30/11/17, Dunstable, UK
321275
PLEASE KEEP THIS MANUAL SAFE FOR FUTURE REFERENCE
Duren Tools
T: 01582 484875 E: [email protected]
www.duren.co.uk
4 It is strongly advised that you always use a Whip Hose/Leader Hose in combination with
Quick Release Couplings. See Fig. 2 for recommended setup.
5 Water in the air supply will cause the internal bearing of the tool to rust and eventually
seize.
6 Make sure that your airline is free from water at all times.
7 Always select the correct sanding disc grit for the job.
Tools Included with your Sander
1 x High Flow Male Air Fitting
Maintenance
1 If the air supply is not lubricated sufficiently it will be necessary to lubricate the tool
directly. This can be done by disconnecting the air hose and pouring in 5ml of air tool oil
into the Air Inlet. Read safety data sheet or instructions on use of oil to ensure safe
usage. These can be obtained from your supplier.
2 Replace worn or damaged parts using genuine parts only.
3 Store tool in a dry area, do not allow tool to be immerse in water or used/stored in wet
conditions.
625624_Product Instructions 27/03/2014 08:30 Page 5
