Dacor PMOR0321 Technical manual

PLANNING
GUIDE
Web: http://www.Dacor.com
Corporate Phone: [phone]
Specifications are subject to change without notice.
See installation instructions for additional details. 12.3
Over the Range Microwave Oven
PMOR3021
Recommended
Utility Location
18” (457mm) Min.
Both Sides
"A"
30”
(762mm)
UPPER CABINET DIMENSIONS
(Upper Cabinets 13” (330mm) Maximum Depth)
“A” - From Top of PMOR3021 to Finished Countertop
34” (864mm) Minimum with deector for a maximum
cooktop surface BTU rating of 44,000 BTU’s.
36” (914mm) Minimum without deector for a maximum
cooktop surface BTU rating of 44,000 BTU’s.
36” (914mm) Minimum with deector for a maximum
cooktop surface BTU rating of 60,000 BTU’s.
Model No. Dedicated Circuit Required Total Connected Load
Approximate
Shipping Weight
PMOR3021 120VAC, 60Hz, 15A
(Breaker) 1.45kW (12A) 60 lbs.
NOTES:
1. 30” electric cooktops or ranges can be installed at
34” (864mm) with deflector or 36” (914mm) without
deflector for a maximum cooktop surface rating of
10,000 watts.
2. Microwave is supplied with a 48” (1219mm) power
cord, with a three prong grounded plug.
Deflector
15 9/16"
(395mm)
29 15/16"
(761mm)
17"
(432mm)
OVERALL DIMENSIONS
c
L
c
L
Equal Equal
3 1/4" x 10"
(89mm x 254mm)
Direct Connection
4"
(102mm)
MICROWAVE TOP VIEW
EXHAUST LOCATION
1/1092105
