Dacor ER30D Technical manual

PLANNING
GUIDE
Web: http://www.Dacor.com
Corporate Phone: [phone]
Specifications are subject to change without notice.
See installation instructions for additional details. 5.10
Epicure™ Ranges
ER30D
ElEctrical rEquirEmEnts
It is the owner’s responsibility to ensure that the electrical
connection of this appliance is performed by a qualified electrician.
The electrical installation, including minimum supply wire size
and grounding, must be in accordance with the National Electric
code ANSI/NFPA 70-1993* (or latest revision) and local codes and
ordinances. A copy of this standard may be obtained from:
National Fire Protection Association
1 Batterymarch Park
Quincy, Massachusetts 02269-9101
The correct voltage, frequency, and amperage must be
supplied to the appliance from a separate, grounded, circuit
that is protected by a properly sized circuit breaker or time
delay fuse. Refer to the chart below for requirements.
A 4-wire connection (not provided) is required to connect the
range to the junction box. The minimum wire gauge suggested
by Dacor
®is 10 AWG. Consult local building codes for the
type and minimum wire gauge to use.
Suggested wiring color code: Black, white, red, and green.
The wiring needs to be long enough to allow the range to be pulled
out from the wall for service, while remaining connected.
◊
◊
◊
Gas supply rEquirEmEnts
Check your local building codes for the proper method of
installation. In the absence of local codes, this appliance
should be installed in accordance with the National Fuel Gas
Code ANSI Z223.1.
Be certain that the appliance being installed is correct for the
gas service being provided (natural gas or LP gas). Also, if
operating the range at an altitude above 4000 ft. (1219 m)
make sure it is equipped for high altitude operation. Refer to
the range data plate and the table on page 3 to determine the
correct model.
See the table below for gas supply pressure requirements.
The regulator inlet accommodates a 3/4” gas line. The range
ships with a 1/2” to 3/4” adapter connected to the regulator.
◊
◊
◊
◊
1/2
071707
GAS SUPPLY PRESSURE REQUIREMENTS
Gas Type Manifold Pressure Minimum Gas
Supply Pressure
Natural Gas 5” Water Column 6” Water Column
Liquid Petroleum
(LP) 10” Water Column 11” Water Column
ELECTRIC CIRCUIT REQUIREMENTS
Range Model Circuit Required Total Connected
Load
ER30D 240VAC,
60Hz, 30A 5.6kW (23A)
GAS - ELECTRICAL ACCESS DIMENSIONS
“A” “B” “C” “D” “E”
4 7/8” 21 3/4” 9 1/16” 10 1/2” 7/8”
B
A
C
D
Gas Inlet
E Conduit Connection
Hole in Bottom
Back of Range
Range Electrical Access,
Cover Removed
Finished Side
Panel
1 1/16” (27mm)
26 3/8” (670mm)
27 5/16” (694mm)
28 13/16” (732mm)
24 1/4” (616mm)
3” (76mm)
Backguard
6” (152mm)
Backguard
37 1/2”
(953mm)
to
35 3/8”
(899mm)
46 1/4” (1175mm)

PLANNING
GUIDE
Web: http://www.Dacor.com
Corporate Phone: [phone]
Specifications are subject to change without notice.
See installation instructions for additional details. 5.11
Epicure™ Ranges
ER30D
050807
Cabinet/Cut-out Dimensions
24”Typ.
(610mm)
25”Typ.
(635mm)
All tolerances: +1/16”, -0 (+1.6mm, -0)
Cabinet Layout
Carefully check the location where the range is to be installed. For best performance, the range should be placed away from drafts
that may be caused by doors, windows, and heating and air conditioning outlets.
To reduce the risk of personal injury and to reduce accumulated smoke in the room, Dacor
®strongly recommends installing a range
hood. A range hood should project horizontally a minimum of five (5) inches beyond the face of the cabinets.
The range may be installed flush to the rear wall.
Dacor recommends installing a non-combustible material on the rear wall above the range and up to the vent hood. If a non-
combustible surface is not installed, a backguard must be installed. It is not necessary to install non-combustible materials behind the
range below the countertop height.
Any openings in the wall behind the appliance or in the floor underneath it must be sealed.
The minimum distance from the sides of the range above the countertop to combustible side walls must be at least 10 inches.
All dimensions shown are based on standard American cabinets, 36 inches (914mm) high at the finished countertop by 24 inches
(610mm) deep, with a 25 inch (635mm) overall countertop depth. When installing the range into nonstandard cabinets, minimum
clearances shown in the diagrams must be maintained.
◊
◊
◊
◊
◊
◊
CUT-OUT DIMENSIONS
“E” “F”
36” (914mm)*
30” (762mm)** 30 1/16” (916mm)*
* Recommended
** Minimum
2/2
