DAEHAN FLEX RGB Series User manual

User Guide 1
SPECIFICATIONS
Use precautions to avoid damages to the product or injuries of users. Any actions against following contents will cause serious
issues such as malfunction, electric shock, or burn.
USE DC12V ONLY
DC12V
DO NOT USE AC INPUT
AC INPUT
Do not cut or rejoion wires while product
is connected wth live power source
Maximum driver quantity per serial
connection is limited. Failure causes overload
of current and damages to the product
Refer to‘WIRE THICKNESS’table to use proper
wire thickness between SMPS and the rst
LED module
Failure will cause dimmed output
Cable length between SMPS and the rst LED
module is limited. Refer to ‘CONNECTION
WITH POWER SUPPLY’ on page 2
Do not use the product under circumstances
listed below
- High temperature spots over 60˚C (140˚F)
- Spots draw extreme moisture or dust
- Spots have corrosive gas or highly eectied
by electromagnetic eld
Avoid performing installation under rain or
high humidity for outdoor use
Do not perform actions listed below
- Alter or modify
- Touch LED lamps with sharp objects
- Put glue or silicon over the LED lamps
PRECAUTIONS
Model
FLEX RGB T20100
Power
Consumption
Min Bending
Radius
R20mm
Viewing
Angle
120°
Weight
98g
Operating
Power
DC12V
Max Serial
Connection
3M (3 Units)
*Electronic dimming control is supported
FLEX RGB Series - T20100
PREPARATION
PREPARE CHANNELS
1. Clean moisture and dust inside 2. Make holes 3. Use bushing to protect wires
1. Wipe out dust, water, and oil inside. 3M tape will come o easily if product is mounted on uncleaned surfaces.
2. Make holes for wires from modules to SMPS.
3. Without bushins, wires will easily be cut and short-circuit will occur.
*Use white paint inside the channels for better reection
SUPPLIES REQUIREDTOOLS REQUIRED
Wire Nuts, Cable Ties, IDC Connectors, VCTF(PLTC) Cable,
Super Glue, Silicon(optional)
Wire Stripper, Drill, Screw Driver, Wiper
SUPER GLUE
IP65
Color
Red
Green
Blue
White
5.0W
3.6W
3.9W
12W
Cut Mark
3cut
DAEHANTRANS CO.,LTD
#7-11 Songdo-Dong, Yeonsu-Gu, Incheon, Korea
Tel. [phone] Fax. [phone] enquir[email protected] / www.daehantrans.com

User Guide 2FLEX RGB Series - T20100
20 mm
40 mm 40 mm
60 mm
40 mm
40 mm
20 mm 40 mm
80 mm
80 mm
CONNECTION WITH
POWER SUPPLY
Output (W)
Model Name
Max Q’TY - T20100*
Recommended
Extension Wire
Output (A)
Max Q’TY - S20100*
Maximum Length
30W
2.5A
PSCS-0030-12
2.5M
2.5M
5M (15FT)
VCTF1.25
AWG18
60W
5A
PSCS-0060-12
5M
5M
5M (15FT)
VCTF2.0
AWG14
120W
10A
PSCS-0120-12
10M
10M
5M (15FT)
VCTF2.0
AWG12
EXTENSION OF POWER SUPPLY LEAD WIRES
*Maximum quantity for S-LED is based on 85% of specied capacity of power supplies for extended lifespan
Maximum driver quantity per serial connection is limited. Using more quantity per run will cause overload from SMPS which
damages all connected products. This will cause voltage drop and also dimmed lighting output.
CONNECTION GUIDE
+
+
-
SMPS
DC12V 123
123
12
More than 4 Units
Ensure each run has less than 5 units
and connect each run in parallel. Refer
to below table for maximum units per
power supply.
Connect each run to the
SMPS in parallel
CAUTION
Keep extension lead wires as short as possible.
Refer to below table for specic length.
+
-
SMPS
DC12V 123
＋
－
&
&
1 to 3 Units
RED
WHITE
CONNECT
&
&
RED
WHITE
RED
WHITE
CONNECT
Use recommended length for pitch between each module to achieve optimum lighting output while maintaining lowest unit
cost. Failure or misplacing will cause dimmed spots or uneven appearance of light on the surface.
LAYOUT DENSITY
GUIDELINES
RECOMMENDED PITCH PER DEPTH
SINGLE
DOUBLE
BEFORE HANDLING
UNITS Do not ex or bend units with less than 20mm in radius, 40mm in
diameter. Refer to left illustration.
When stored in cold weather, units are sti. Connect them with
power supplies and wait until they become soft enough to be easily
fabricated.
R20mm
NO
DAEHANTRANS CO.,LTD
#7-11 Songdo-Dong, Yeonsu-Gu, Incheon, Korea
Tel. [phone] Fax. [phone] enquir[email protected] / www.daehantrans.com

User Guide 3FLEX RGB Series - T20100
INSTALLATION GUIDE 1. DETERMINE LAYOUT
Refer to‘LAYOUT DENSITY GUIDELINES’ on page 2 to
determine spacing and amount of LEDs required.
SUPPORTS FOR OUR SIGNMATES
Ask us to obtain accurate layout
Stroke Width
Channel Depth
Drawn by Brad Han
Date :2009. 1. 1.
Rev.0 Tel: [phone]
www.daehantrans.com
Fax: [phone]
[email protected]
MATERIAL ESTIMATE
Attention to : John Doe Page 1 of 1
NUMBEROF SETInformation Model PowerSupply QuantityColor Quantity
STARC04 WHITE 143EA DC12V120W 2
S-LEDESTIMATE /SET
SUMMARY
POWERESTIMATE /SET
MODULEPITCH
1
QUANTITYPER SET 143EA
TOTALCLUSTERS 143EA
WATTAGEPER SET 187W
TOTALWATTAGE 187W
120mm
*Thisis for estimating purposes only. Material Estimates for S-LED system are based upon given font, letter height, depth, face material, and any special instructions. *Missinginformation will aect the nal results *Powerconsumption is calculated with extra 15% for extended life of power supplies
*Allsigns should be tested for acceptable color, illumination and operation. Use appropriate power supply for testing *Fordetailed information, please refer to the applicable S-LED product found under http://www.daehantrans.com/download/products2007.pdf
AC 200V
to
AC 240V 1856mm 2082mm 2176mm
2246mm (Unit Length) 1768mm 1768mm
SMPS
DC12V
DOUBLE LAYOUT
Stroke Width : 80mm
Channel Depth : 80mm
Channel Size : 2389mm
x 439mm
R30mm
or more
Connection
Connection
R30mm
or more
Connection
R30mm
or more
Connection Connection
R30mm
or more
Connection
CAUTION
When handling the module, avoid twisting or bending unit in
less than R20mm(40mm in diameter)
2. CUT INTO REQUIRED LENGTH
FLEX RGB T20100
TOP
BOTTOM
Soldering Pad
(Solder lead wire here)
Cut only at
‘CUT MARK’
Using predetermined layout and LED placement
from step 1, divide channels into sections and
distribute each section to corresponding power
supplies.
CAUTION
Before connect with power supplies, check
polarity on every connections
4. CONNECT WITH POWER SUPPLY
SUPER GLUE : Units can be secured with super glue.
Use super glue made for outdoor use with moisture
resistance. Do not put glue on the top of LED lamps.
SILICON : If desired, modules can be secured with
silicon. Do not to put silicon on the top of LED lamps.
3. FIX UNITS PERMANENTLY
SUPER GLUE
120W
AC Input
DC Output
60W
AC Input
DC Output
DAEHANTRANS CO.,LTD
#7-11 Songdo-Dong, Yeonsu-Gu, Incheon, Korea
Tel. [phone] Fax. [phone] enquir[email protected] / www.daehantrans.com

User Guide 4FLEX RGB Series - T20100
TROUBLE SHOOTING
LAYOUT GUIDE
SINGLE LAYOUT
1263mm (Unit Length) 1095mm 1139mm 1108mm 1099mm 1244mm
SMPS
DC12V
AC 200V
to
AC 240V
AC 200V
to
AC 240V 1856mm 2082mm 2176mm
2246mm (Unit Length) 1768mm 1768mm
SMPS
DC12V
Stroke Width : 40mm Channel Depth : 40mm Channel Size : 2389mm x 439mm
DOUBLE LAYOUT
Stroke Width : 80mm Channel Depth : 80mm Channel Size : 2389mm x 439mm
R20mm
or more
Connection R20mm
or more
Connection
R20mm or more
Connection
Connection
Connection
Connection
Connection
R20mm or more
R20mm or more
R20mm or more
Connection
Connection
R20mm or more
Connection
R20mm or more
Connection Connection
R20mm or more
Connection
Entire sign or leg does not light after
complete installation.
Check connection from power supply lead to first module. Make sure polarity of connections made at the power
supply lead and any jumper wire is correct. Power supply outputs should be connected red-to-red and white-to-
white.
Check output voltage of power supply using a voltmeter. The output voltage should be 12.0VDC ± 0.5VDC. If there
is no output voltage, have a licensed electrician check input voltage. Make sure power supply is connected
correctly and getting primary power. Probably AC input wire is connected to ground terminal of power supply. If
power supply is connected properly and getting primary power and there is still no output voltage, try a different
power supply.
Still does not light.
If power supply is getting primary power and the modules do not light, there may be a short in the secondary
wiring. Check all connections and cap all loose wires.
Still does not light.
The primary cause of a portion of a S-LED leg not lighting or lighting intermittently is a bad connection or reverse
polarity connection between the modules that light and the modules that don’t light. Check this connection.
Beginning of a leg lights, but the entire
leg does not light or lights intermit-
tently.
S-LED is designed so if one module fails, it will not cause the entire sign or leg to go out. If one module does not
light, but all others in the leg do, replace this module with a new one.
One module does not light, but all
others in the leg light.
Check each run has no more than maximum number of modules. Also ensure that type of the extension wire from
SMPS to the first module is correct. If wires are not thick enough to transmit current from SMPS, this will cause
voltage drop and will dim the modules at the end.
All modules light, but some of them are
dimmed.
Channel depth is too low, or center distance between modules is too far. Refer to 'LAYOUT DENSITY GUIDELINES'
for more information.
Dark spots or dimmed spots occur.
Covering acrylic is not intended for LED illumination. Use light diffusing acrylic sheets which are specially made for
LED light source.
Still has spots.
DAEHANTRANS CO.,LTD
#7-11 Songdo-Dong, Yeonsu-Gu, Incheon, Korea
Tel. [phone] Fax. [phone] enquir[email protected] / www.daehantrans.com
