DAEWOO ELECTRONICS ACP-0108 Series User manual

Service Manual
Car Audio
S/M No : ACP0108EF0
MODEL : ACP-0108 Series
DAEWOO ELECTRONICS CO., LTD
http://svc.dwe.co.kr Mar. 2001
4-Channel high Power (40W x 4Ch)
Electronic Tuning
Electronic Volume/Bass/Treble/Balance/Fader
Control
42 Memory Capability (18FM+12MW+12LW)
Local/DX Switch
Loudness & Mute Control
Compact Disc Player
Detachable Face for Anti-Theft
10 CD-changer control(Option)
Telephone Mute Control
5010Series
CDP-0105A
ACP-5010RDS
ACP-5010RC
ACP-5010C
ACP-5010
AKP-5010RDS
0106Series
ACP-0106A

1. PRODUCT SPECIFICATIONS ..................................................1
2. LINE DRAWING ........................................................................2
3. EMERGENCY TROUBLE SHOOT ............................................3
4. ADJUSTMENTS ........................................................................6
5. SCHEMATIC DIAGRAM ..........................................................11
6. PARTS LOCATION ON P.C.BOARD ......................................12
7. OVERALL EXPLODED VIEW & PARTS LIST .......................15
8. DECK MECHANISM EXPLODED VIEW & PARTS LIST .......16
9. ELECTRICAL PARTS LIST........................................................19
10. FUNCTION OF MICOM IC .....................................................23
11. IC BLOCK DIAGRAM .............................................................29
12. LIQUID CRYSTAL DISPLAY ..................................................33
13. OUTPUT CONNECTION DESCRIPTIONS ............................34
TABLE OF CONTENTS

1
1. PRODUCT SPECIFICATIONS
AUDIO SECTION
Maximum output power : 40watts per channel into 4 ohms.
Load impedance : 4 ohms or 8 ohms
Total harmonic distortion : Less than 10% at 14 watts
Frequency response : 100Hz( 3dB), 20kHz( 3dB)
Control Bass/Treble : 10 3dB at 100Hz/10kHz
CD PLAYER SECTION
Total harmonic distortion : 0.1%
Signal to noise ratio : 80dB
Laser Diode Properties : Meterial - GaAlAs
Wave length - 775~800 nm
Laser out-put Power - Less than 400 uW
TUNER SECTION
(FM) Tuning range : 87.5 to 108MHz
Sensitivity : 10dBuV
Stereo separation : 30dB
Signal to noise ratio
: 60dB
(MW) Tuning range : 522 to 1620KHz at Europe
( 530 to 1710kHz at U.S.A)
Sensitivity : 22dBuV
Signal to noise ratio
: 50dB
Channel space : 9KHz (or 10KHz at U.S.A)
(LW) Tuning range : 144 to 288KHz
Usable Sensitivity : 25dBuV
GENERAL
Power requirements : DC 13.8V (10.8 ~15.6V allowable)
Negative ground
Speaker impedance : 4 or 8 ohm
Output power : Maximum 40Wx4Ch.
Current consumption : 10A (MAX)
Dimension (W x H x D) : 178 x 50 x 156 mm
Chassis size : 195 x64 x14.6 mm
Weight(Net) : 1.75Kg
Design and specifications are subject to changes for improvements without notice.

2
2. LINE DRAWING
2-1. FRONT SIDE
2-2. REAR SIDE
ACP-0108RDS Serise
- RDS Function
- Compact Disc Player
- 4-Channel high Power (40W x 4Ch)
- Electronic Tuning
- Electronic Volume /Bass /Treble /Balance
/Fader Control
- 42 Memory Capability (18FM+12MW+12LW)
- Local/DX Switch
- Loudness & Mute Control
- Detachable Face for Anti-Theft
- 10 CD-changer control(Option)
- Telephone Mute Control
ACP-0108 BASIC Series
- Basic Function
- Compact Disc Player
- 4-Channel high Power (40W x 4Ch)
- Electronic Tuning
- Electronic Volume /Bass /Treble /Balance
/Fader Control
- 42 Memory Capability (18FM+12MW+12LW)
- Local/DX Switch
- Loudness & Mute Control
- Detachable Face for Anti-Theft
- 10 CD-changer control(Option)
- Telephone Mute Control
*ACP-5010RDS, 5010RC *AKP-5010RDS
*ACP-5010C, 5010 *CDP-0105A
*ACP-0106A

3
3. EMERGENCY TROUBLE SHOOT
3-1. General Function
No sound from
speakers
Yes
No
Yes
Output connector
is missing
Output connector
is inferior goods
Put exactly output
connector in.
Change output
connector to
superior goods
Yes
No
Power IC, Output
Socket is inferior
goods
Change Power IC,
Output Socket to
superior goods
Yes
A
A
L.C.D or Lamp
is not turned
off.
Yes
No
Yes
Power is not
supplied Return to
Output voltage of
power IC is little.
Change Regulator
IC and check
output voltage.
Yes
No
LCD or Lamp is
inferior goods.
Change LCD or
Lamp to superior
goods.
Yes
Different each
channel have
output level
(Front, Rear,
Left, Right)
Treble or Bass
is low
unusually
Yes
No
Yes
Balance of front
and rear is in one
side
Balance of Left,
Right is in one
side.
Re-adjust Balance
of front, rear
Ref.
Balance = Center
Front / Rear
Ref.
Balance = Center
Left / Right
Ref.
Balance = Center
Treble / Bass
Ref.
Regulator IC output
Voltage = V
Ref.
Electrical Parts List
L.C.D., Lamp
Re-adjust Balance
of Left, Right
Yes
Yes
Balance of Treble
or Bass is in one
side.
Re-adjust Balance
of Treble or Bass
Yes

4
EMERGENCY TROUBLE SHOOT
3-2. Tuner Function
Hearing noise
only
Yes
No
Yes
No selected the
station
Tuner Module is
inferior goods.
Select exactly
broadcasting
frequency.
Change tuner
module to
superior goods.
Yes
Weak frequency
area caused by
elevations
Change to goods of
R.D.S function.
Yes
A
B
A
Station in
other regions
are not held.
Yes Yes
No selected the
local stations. Return to or
Extreme noise
in broadcast
Weak
separation of
FM stereo
Yes
No
Yes
Antenna
connector is
missing
Put exactly
antenna connector
in his jack
Ref.
CAT-7
Adjustments/Tuner
Function of auto-
switch noise
reduction
Ref.
Yes
Weak frequency
area of FM, MW
Switch
automatically to
mono mode in
weak frequency
area
Yes
B
R1 In case of located Glass Antenna, check if heat wire is cut or not in rear window.
R2 Check Antenna connector part.

EMERGENCY TROUBLE SHOOT
5
Disc is not
inserted.
Yes Yes
There is Disc in
the slot
Take out Disc
from the slot
Disc is inferior
goods
Use only superior
disc
No
Yes
A
Selection time
is longer than
unusually
Yes
Selected PAUSE
function
Release PAUSE
function
Yes
Selected MUTE
function
Release MUTE
function
Yes
Mechanism is
inferior goods
Change
Mechanism to
superior goods
Turn power on
again after turn off.
Yes
Inspect disc for
scratches.
Yes
No sound Yes
No
Yes
disc was inserted
upside down
Insert CD with
label side down
Ref.
DWEC CD Mecha
DCM-400F
Ref.
Power Off/On
Hard Reset
No
No
No
Disc is dirty
Wipe with cleaning
cloth
Yes
A
Ref. Point
Disc is stopped
under eject Yes
It is normal for
CD-Deck or the
slot
Yes
3-3. CD Function

4. ADJUSTMENTS
6
4-1. TUNER MODULE ADJUSTMENT LOCATIONS
CAT-7 (3 Band)
CAT-6 (2 Band)

ADJUSTMENTS
4-2. MW / LW ADJUSTMENT METHOD
7
STEP
MW
LW
Band Covering
Range
IF
522 KHz
522 KHz
603 KHz
V.T point of
AM Board
Output
Output
522 KHz
450 KHz
603 KHz
AMOSC
MAXIMUM
1620 KHz
1620 KHz - 7.6V
MAXIMUM
MAXIMUM
AMIF
AMRF1
AMRF2
1404 KHz
Output 1404 KHz
MAXIMUM
AMRF1
AMRF2
TRACKING
ALIGNMENT TUNING
TEST
POSITION
SSG
FREQUENCY
ALIGNMENT INDICATOR
Band Covering
Range 144 KHz 144 KHz
LWOSC MAXIMUM
TRACKING 220 KHz Output 220 KHz LWRF1
LWRF2
MAXIMUM
-

ADJUSTMENTS
4-3. FM ADJUSTMENT METHOD
8
STEP
1 IF adjust
MPX IC
Separation
Control
98.1 MHz, ANT
input 60dBu, 1kHz
(30% MOD) FM
SSG
ANT jack
and GND
ANT jack
and GND
98.1 MHz, ANT
input 40dBu, 1kHz
(L+R=45%
L-R=45%
PILOT=10% MOD)
The voltage
between CW03
L or R CH SP.
output wire
VTVM and Scope
FM DET
ST
BLEND
Adjust for 0V
0.05V
L, R separation
8dB
2
SUBJECT
FEED SIGNAL
FROM TO MEASURE
OUTPUT ADJUST POINT
ADJUSTMENT

ADJUSTMENTS
9
Definition of Mechanical Mode
No
1
2
3
4
STOP MODE
LOADING
MODE
PLAY MODE
EJECT
MODE
- Disc haven’t been inserted or disc have been ejected. When disc shall be transported
into the unit
Mechanism shall be fixed at this mode.
- Loading device can insert disc thru the slot.
- Floating device being locked.
- Disc have been inserted thru the slot in front of unit. It is transient state between STOP
mode and PLAY mode.
- If disc should be inserted at the state of POWER ON, disc shall be loaded by a series of
operation of specified device.
- After disc have being clamped on the turn-table, disc shall be rotated.
- Disc shall be played.
- Floating device being unlocked.
- Disc is to be ejected at this mode. It is transient state between PLAY mode and STOP
mode.
-
If disc should be mounted at the state of POWER ON and commanded by EJECT key, disc
shall be ejected thru the slot by a series of operation of specified device.
MODE DEFINITION & STATUS
Standard values / Play-ability test
No
1
2
3
4
5
Loading Time
Ejecting Time
Access Time
Disc
Discharge Force
Disc
Take-up Force
7sec + 3sec
6sec + 3sec
< 17 sec
< 15 sec
< 15 sec
< 5 sec
> 120g
> 120g
> 80g
> 90g
During play in
low temp.
> 70g
During play in
low temp.
From insertion up to make sound.
(TCD-784)
From track No.1 Between the EJECT
command and the disc eject completion.
(TCD-784)
From out-most Track, Between the PLAY
command of in-most Track and marking
sound.
Shall be measure when the center of Disc is
correspond with the center of Roller.
Shall be measure when the center of Disc is
correspond with the center of Roller.
ITEMS
CONNEC
TION
SPECIFIED VALUES, CONDITIONS
STANDARD VALUES RELIABILITY LIMITS
TEST CONDITIONS, REFERENCES
4-4. CDP MODE TEST & ADJUSTMENT METHOD

10
No
8
9
10
11
12
13
14
15
16
17
Anti-Vibrational
Performance
Playability
Disc Deflection
Disc
Eccentricity
Jitter
Frequency
Response
Harmonic
Distortion
Dynamic
Range
S/N Ratio
Channel
Separation
0.4mm
0.21mm
< 27 nsec
< 0.03% at 1kHz
> 80dB at 1kHz
> 85dB at 1kHz
> 70dB at 1kHz > 65dB at 1kHz
> 85dB at 1kHz
> 75dB at 1kHz
< 0.05% at 1kHz
20-20kHz 3dB 20-20kHz 3dB
< 33 nsec
0.21mm
0.4mm
equal with
standard values
-Interruption:0.7mm
-Black Dot Disc:0.6mm
-Scratch Disc:0.6mm
- Finger Print Disc:65um
>1.0g/10Hz-20Hz, Z way
>2.0g/30Hz-200Hz, Z way
>0.6g/10Hz-20Hz, X&Yway
>1.2g/30Hz-200Hz, X&Yway
X=side to side
Y=front to back
Z=up to down
Z way only
10Hz-20Hz:0.7g
30Hz-200Hz:1.2g
-The G level should be upped to the sound
skip level from the less level slowly at the
frequency.
-Ignore the sound skip at the near of
resonance frequency(about 100Hz).
-In playing YEDS-10 Tr #5, shall perform with
vibration
-No sound skipping.
-No sound skipping in the specified range.
-The sound skipping does not include any
interpolating noise.
-No sound skipping at the ABEX 731RA Tr
No8
-The sound skipping does not include any
interpolating noise.
-Except from specified item due to the
reliability limits of TEST DISC in the HTO
TEST.
-No sound skipping at the ABEX 713 Tr No8
-The sound skipping does not include any
interpolating noise.
-Except from specified item due to the
reliability limits of TEST DISC in the HTO
TEST.
This measurement may be done at 20Hz,
20kHz, (1kHz=0dB)
400Hz HIGHPASS FILTER
20kHz(-60dB 24kHz) LOWPASS FILTER
20kHz(-60dB 24kHz) LOWPASS FILTER,
60dB AMP IHF-A WEIGHTING FILTER
400Hz HIGHPASS FILTER
20kHz (-60dB 24kHz)LOWPASS FILTER
ITEMS
CONNEC
TION
SPECIFIED VALUES, CONDITIONS
STANDARD VALUES RELIABILITY LIMITS
TEST CONDITIONS, REFERENCES
7
Mechanical
Noise
Loading Eject
< 70dB(A)
Play < 40dB(A)
Access < 70dB(A)
If anything is not
error, shall not
defined.
-Test should be performed in no reverberation
room at the noise level of less than 20dB(A).
-Test should be performed at the 10cm in front
of the unit.
-IHF-A MODE (RMS-FAST)(TCD-792D)
6
Clamping Force > 130g > 130g
ADJUSTMENTS

6-1. PCB MAIN
12
6. PARTS LOCATION ON P.C. BOARD
PART SIDE

13
PARTS LOCATION ON P.C. BOARD for ACP-0108Series
BOTTOM SIDE

PARTS LOCATION ON P.C. BOARD for ACP-0108Series
14
PART SIDE
BOTTOM SIDE
6-2. PCB FRONT

DECK MECHANISM EXPLODED VIEW & PARTS LIST
for ACP-0108 Series
17
8-1. PARTS LIST for DCM-400F
No PART NAME PART CODE EA DESCRIPTION
1 CHASSIS MAIN 97L0603800 1 EGCHSP40R T1.0
2 SUPPORTER D/U -R 97L2502200 1 POM(LUCEL N109-LDK)
3 SPRING SUPPORTER 97L3005700 1 SUS304-WPB
4 SUPPORTER D/U - L 97L2502700 1 POM(LUCEL N109-LDK)
5 PLATE SLIDER -L 97L0903200 1 POM(LUCEL N109-LDK)
6 SPRING DAMPER 97L3005300 3 SUS304-WPB
7 BASE D-U 97L0603600 1 POM(LUCEL MR310)
8 MOTOR SPINDLE 97L8102300 1 PANASONIC (MDN2BL3GRAS)
9 PLATE TURNTABLE 97L0903400 1 PC(TRIREX 3500G20)
10 PICK UP 97Y7500100 1 JVC OPTIMA-725B
11 SUPPORTER PICK UP 97Y2500100 1 SUS304 CSP 3/4H T=0.2
12 FPC PICK UP 97Y6500900 1 FLEXIBLE PCB
13 SHAFT SLED SCREW 97L3606500 1 SUS416
14 GEAR SLED 97L2705600 1 POM(LUCEL N109-LDK)
15 SLED RACK 97Y2701300 1 POM
16 SPRING PLATE SLED 97Y3001700 1 SUS304 CSP 3/4H T=0.2
17 GEAR CENTER 97L2705500 1 ESREL
18 MOTOR FEEDING 97L8102400 1 PANASONIC (PPN7KB10B)
19 GEAR FEED - M 97L2705400 1 POM(LUCEL N109-LDK)
20 SUPPORTER FEED 97L2502300 1 SUS304CSP 3/4H T0.2
21 PLATE CLAMP 97L0903300 1 POM(LUCEL N109-LDK)
22 CHASSIS CLAMP 97L0603900 1 EGCHSP40R T1.0
23 SPRING CLAMP 97L3005200 1 SWPB
24 DAMPER OIL 97L2G00200 3 "RUBBER,Si(OIL)"
25 HOLDER ROLLER 97L2302100 1 POM(LUCEL MR310)
26 SHAFT ROLLER 97L3605800 1 SUS303
27 GEAR ROLLER 97L2705300 1 POM(LUCEL N109-LDK)
28 ROLLER RUBBER 97L3700800 2 RUBBER
29 CHASSIS SIDE 97L0604100 1 EGCHSP40R T1.0
30 SHAFT GEAR A 97L2100300 1 SUM32
31 SHAFT GEAR B 97L2100400 1 SUM32
32 SHAFT GEAR C 97L2100500 1 SUM32
33 PLATE SLIDER -R 97L0903100 1 POM(CAPITAL FT2020)
34 LEVER RACK 97L2602000 1 POM(CAPITAL FT2020)

DECK MECHANISM EXPLODED VIEW & PARTS LIST
for ACP-0108 Series
18
No PART NAME PART CODE EA DESCRIPTION
35 SPRING RACK LEVER 97L3005600 1 SUS304-WPB
36 GEAR LOAD - A 97L2705000 1 POM(LUCEL FW715CS)
37 GEAR LOAD - B 97L2705100 1 POM(LUCEL N109-LDK)
38 GEAR LOAD - C 97L2705200 1 POM(LUCEL N109-LDK)
39 LEVER PUSH 97L2601900 1 PC
40 MOTOR LOADING 97L8102500 1 PANASONIC (PPN13LB11C)
41 BRKT LOADING 97L2401800 1 EGCHSP40R T1.0
42 GEAR WORM 97L2704900 1 POM(LUCEL N109-LDK)
43 SPRING HOLDER ROLLER-L 97L3005000 1 SWPB
44
SPRING HOLDER ROLLER-R 97L3007000 1 SWPB
45 CHASSIS TOP 97L0603700 1 EGCHSP40R T1.0
46 LEVER LOADING 97L2602100 1 EGCHSP40R T0.8
47 LEVER GUIDE - L 97L2601800 1 POM(LUCEL MR310)
48 LEVER GUIDE - R 97L2602500 1 POM(LUCEL MR310)
49 LEVER CD STOPPER 97L2602600 1 POM(LUCEL N109-LDK)
50 SPRING CD STOPPER 97L3007500 1 SUS304-WPB
51 BRKT CD GUIDE 97L2402200 1 POM(LUCEL N109-LDK)
52 SPRING GUIDE LEVER 97L3005500 1 SUS304-WPB
53 CUSHION TOP 97L4202200 1 SPONGE(MOLTO PLENE)
54 LEVER CLUTCH 97L2602200 1 EGCHSP40R T0.6
55 PCB DECK AS 97YCD00800 1 DCM-400F
56 SERVO PCB TOTAL AS 97LA107600 1 DCM-400F
SW SWITCH DETECT 97L0S00600 3 MPU10853MLB4
T1 STOPPER TRANSIST 97Y5700200 1 POM
S1 SCREW MACHINE 97L3102200 2 PAN •’1.7x2.5
S2 SCREW MACHINE 97L3102100 1 PAN •’1.7x3.5
S3 SCREW TAPPTITE 97L3103600 12 TT3 BIN •’2.0x3.5
S4 SCREW MACHINE 97L3101700 2 PAN •’2.0x2.5
S5 SCREW TAPPTITE 97Y3100200 1 TT3 BIN 1.4 X 2.5
W1 WIRE FEED MOTOR 97L3006500 1 UL1571 AWG #30
W2 WIRE LIMIT SWITCH 97L3006600 1 UL1571 AWG #30
W3 WIRE LOADING MOTOR 97L3006800 1 UL1571 AWG #30(BLK)
W4 WIRE LOADING MOTOR 97L3006800 1 UL1571 AWG #30(RED)
W5
CONN. WIRE DETECT S/W AS 97L3006700 1 UL1571 AWG #30(CONN. 4P)
PW POLYSLIDER 97L3900100 2 D2.6 x D5 x t0.25

9-1. MAIN SECTION
CAUTION is a recommendable part for essential stock.
R
9. ELECTRICAL PARTS LIST
for ACP-0108 Series
19
CN103
CW101
CW104
C348
IC101
IC204
IC301
IC302
IC501
IC503
J101
LD101
L501
Q211,Q502
Q213
RV101
10001
B001
CT101
CT201
DZ101
DZ103,DZ501
DZ105,DZ106
Q201
DZ202
DZ502
DZ503
DZ504
L101
L102
Q101,Q319
Q320,Q501
Q102,Q103
Q104,Q109
Q210,Q503
Q504
CONN AS
CONNECTOR
CONN DETACHABLE
C ELECTRO
IC AUDIO
IC CHIP CUSTOM
IC CHIP EVR
IC POWER
IC REGULATOR
JACK ANT
LED
COIL CHOKE
TR
DIODE ZENER
97T8860900
97T6234800
97T62150A0
CEYE1C332E
1SAA6579T-
176S8016X4
1LC75371M-
1TDA8571J-
1K1A7808P1
1K1A7809P-
97T6802500
DLT4H11G41
5LC301PA18
T2SB1566--
T2SD2395--
RV1417504-
PNMAJMKT01
97T65986MA
5XJZ4R332D
5XJZ4R500E
DKTZJ01B--
DKTZJ5R6B-
DKTZJ7R5A-
DKTZJ6R8B-
DKTZJ6R2B-
DKTZJ5R1A-
5LL568K02K
5LL479K03K
TZRC111M--
RCA 100 E3P20(B)
PCE 100D-18RR-K(BK)
FP. S-12-3.2-GG
SD 16V 3300MF (13X25)
SAA6579T
UPD-178016AGC-579-3B9
LC75371M MFP36S
TDA8571J-Y
KIA7808PI
KIA 7809P TO-220AB
9.5X20X27.5
LT4H11G-41(RED)
37X1X5.2 300UH P EI-19MM
2SB1566
2SD2395
H500K-5X5-6N-PC-BS
ACP-0108RT
190X330XT1.6/2
HC-49/S 4.332MHZ 25PPM F
HC-49/S 4.5MHZ 30PPM F
MTZJ 10B 26MM
DKTZJ9R1B- MTZJ 9R1B 26MM
MTZJ 5R6B 26MM
MTZJ 7R5A 26MM
MTZJ 6R8B 26MM
MTZJ 6R2B 26MM
MTZJ 5R1A 26MM
0.56UH K 02 TA 26MM
4.7UH K 03 TA 26MM
KRC111M
TR TZTC3113B-
TZRC102M
KTC 3113B
KRC102M(KEC)
No PART NAME PART CODE DESCRIPTION
R SEMI FIXED
PCB MAIN AS AUTO
PCB MAIN
CRYSTAL QUARTZ
COIL INDUCTOR

9-2. FRONT SECTION
PARTS LIST for ACP-0108Series
20
Q105,Q110
Q106,Q212
Q202,Q301
Q302
Q507,Q508
Q506
TR
TZRA105M--
TZTC3205Y-
TZDTC323TS
TZTC3198Y-
TZTA1267Y-
KRA-105M
KTC3205Y (2236Y)
DTC323TSA SPT
KRC102M(KEC)
KTA1267Y TAPPING
No PART NAME PART CODE DESCRIPTION
CB001
CB010
CB020
CB030
CB040
CB050
CB060
CB070
CB080
CB090
CB100
CB110
CB120
CB140
CB150
CB160
CB170
CB200
CB002
00010
CB130
CB210
CB240
CB270
SUP18
SUP19
SUP25
SUP26
SUP28
CABINET FRONT AS
CABINET FRONT
KNOB PLAY
KNOB TUNING UP
KNOB TUNING DOWN
KNOB SEL
97TCFA60GD
97T0111400
97T13E0600
97T13E0700
97T13E0800
97T13E0900
97T13D9900
97T13E1700
97T13E2100
97T13E2200
97T13E1100
97T13E1200
97T0440000
97T13E1400
97T0440100
97T13E1500
97T0439900
97T2226500
PNCFCA08GD
97T0433200
97T13E1300
97T0111500
97T1609800
97T1001600
97T4227800
97T4227900
97T9610100
97T9610200
97T9610300
ACP-0206RT
ABS XR-404
ACRYL IH-830H
PC LEXAN -121
PC LEXAN -121
PC LEXAN -121
PC LEXAN -121
PC LEXAN -121
PC LEXAN -121
PC LEXAN -121
PC LEXAN -121
ACRYL IH-830H
PC LEXAN - 121
ACRYL IH-830H
PC LEXAN - 121
PC LEXAN - 121
PC LEXAN - 121
ACRYL IH-830H
AFK-8045RC
PP
ABS XR-404
ABS XR-404
ACRYL IH-830H
ACRYL
SPONGE T3.0
SPONGE T3.0
DOUBLE TAPE
DOUBLE TAPE
DOUBLE TAPE
No PART NAME PART CODE DESCRIPTION
KNOB PRESET -L
KNOB PRESET -R
KNOB AF
KNOB TA/DISP
KNOB EJECT
KNOB BAND
CAP KNOB BAND
KNOB LOUD
CAP KNOB LOUD
KNOB AUT
CAP KNOB PLAY
REFLECTION S.W
CASE FRONT AS
CASE FRONT
KNOB REL
CABINET BACK
WINDOW LCD
DECORATION
CUSHION L
CUSHION R
SHEET WINDOW A
SHEET WINDOW B
SHEET DECO A

PARTS LIST for ACP-0108Series
21
11001
CW104
LCD
LD402,LD403
PL501,PL502
PL503,PL504
PL505,PL506
PL507,PL508
SW516,SW517
VR401
0F010
0F020
0F030
0F040
11001
B002
SW501,SW502
SW503,SW504
SW505,SW506
SW507,SW508
SW509,SW510
SW511,SW512
SW513,SW514
SW515,SW516
11002
IC401
PCB FRONT AS
CONN DETACHABLE
LCD
LED
PNFRMBKT00
97T62150B0
97T0L1600P
DDB3803X--
97T82L6W95
5S52643CL1
5V3503A70A
97T2308300
97T2226600
97T9610000
97T0440200
PNFRJMKT00
97T65986FR
5S50101Z02
PCB FRONT AUTO CHIP
1HL14104--
ACP-0106R
FP.P-14-3.4-GG
LS-09058P00
DB3803X(BLUE)
9V50MA
1C-1P SKMA 1018A 260G
SRGP 200 200
PC LEXAN-121H
ACRYL IH-830H
TREPAL D112
ET TO.3
ACP-0106R
190X221X1.6/5 FR-1
1C-19 SKQC10918B 260G
ACP-0106R
HL14104
No PART NAME PART CODE DESCRIPTION
LAMP PILOT
SW TACT
VR ENCODER
HOLDER LCD
REFLECTION LCD
SHEET LCD
COVER LCD
PCB FRONT AS AUTO
PCB FRONT
SW TACT
PNFRJCKT00
IC DRIVER(LCD)
9-3. PCB ISO AS SECTION
B006
CW105
PCB ISO
CONN AS
97T659661S
97T8856100
160X137.5X1.6/9
ISO 16P WITH 10A FUSE
No PART NAME PART CODE DESCRIPTION
