DAEWOO ELECTRONICS KOR-6A0R User manual

Before operating this oven, please read these instructions completely.
Customer Helpline number: 0844 887 2525
OPERATING INSTRUCTIONS
& COOK BOOK
HOW TO TURN ON THE OVEN AT FIRST
MICROWAVE OVEN
KOR-6A0R / KOR-6A0RR / KOR-6A0RC
money
money
money
money
money
money

1
PRECAUTIONS TO AVOID POSSIBLE
EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY
(a) Do not attempt to operate this oven with the door
open since open-door operation can result in harmful
exposure to microwave energy. It is important not to defeat
or tamper with the safety interlocks.
(b) Do not place any object between the oven front face and
the door or allow soil or cleaner residue to accumulate on
sealing surfaces.
(c) WARNING : If the door or door seals are damaged, the
oven must not be operated until it has been repaired by a
competent person : (1) door (bent), (2) hinges and
latches(broken or loosened), (3) door seals and sealing
surfaces.
(d) WARNING : It is hazardous for anyone other than a
competent person to carry out any service or repair
operation that involves the removal of a cover which gives
protection against exposure to microwave energy.
(e) WARNING : Liquids and other foods must not be heated
in sealed containers since they are liable to explode.
(f) WARNING : This appliance can be used by children aged
from 8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given
supervision or instruction concerning use of the appliance
in a safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and
user maintenance shall not be made by children unless
they are aged from 8 years and above and supervised.

2
• PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY1
• IMPORTANT SAFETY INSTRUCTIONS .....................................................................................3
• EARTHING INSTRUCTIONS .......................................................................................................5
• INSTALLATION ............................................................................................................................5
• FEATURES DIAGRAM .................................................................................................................6
• FEATURES DIAGRAM (CONTINUED) ........................................................................................7
• OPERATION PROCEDURE ........................................................................................................8
• CONTROLS .................................................................................................................................9
TURNING AC POWER ON & OFF THE OVEN ...........................................................................9
WEIGHT DEFROSTING..............................................................................................................10
TIME DEFROSTING ...................................................................................................................10
COOKING IN ONE STAGE ........................................................................................................11
COOKING IN TWO STAGE .......................................................................................................12
+30 sec........................................................................................................................................13
ONE TOUCH COOKING ............................................................................................................13
AUTO COOK ..............................................................................................................................14
HOW TO STOP THE OVEN WHILE THE OVEN IS OPERATING .............................................15
TO SET STANDBY POWER "0" MODE......................................................................................15
• CARE OF YOUR MICROWAVE OVEN ......................................................................................16
• QUESTIONS AND ANSWERs ....................................................................................................17
• BEFORE YOU CALL FOR SERVICE .........................................................................................18
• CARE AND CLEANING ..............................................................................................................18
• SPECIFICATIONS ......................................................................................................................19
• COOKING INSTRUCTIONS .......................................................................................................20
• USE YOUR MICROWAVE OVEN SAFELY................................................................................21
• ARCING ......................................................................................................................................21
• MICROWAVING PRINCIPLES ...................................................................................................22
• HOW MICROWAVES COOK FOOD...........................................................................................22
• CONVERSION CHARTS ............................................................................................................22
• COOKING TECHNIQUES...........................................................................................................23
• DEFROSTING GUIDE ................................................................................................................24
• COOKING & REHEATING CHART.............................................................................................25
• VEGETABLE CHART..................................................................................................................27
TABLE OF CONTENTS

3
IMPORTANT SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
WARNING : To prevent fire, burns, electric shock and other
warnings:
Listed below are, as with all appliances, certain rules to follow
and safeguards to assure high performance from this oven:
1. Do not use the oven for any reason
other than food preparation, such as
for drying clothes, paper, or any other
nonfood items or for sterilizing
purposes.
2. Do not use the oven when empty, this
could damage the oven.
3. Do not use the oven cavity for any type
of storage, such as papers, cookbook,
cookware, etc.
4. Do not operate the oven without the
glass tray in place. Be sure it is
properly sitting on the rotating base.
5. Make sure you remove caps or lids
prior to cooking when you cook food
sealed in bottles.
6. Do not put foreign material between
the oven surface and door. It could
result in excessive leakage of
microwave energy.
7. Do not use recycled paper products for
cooking. They may contain impurities
which could cause sparks and/or fires
when used during cooking.
8. Do not pop popcorn unless popped in
a microwave approved popcorn
popper or unless it's commercially
packaged and recommended
especially for microwave ovens.
Microwave popped corn produces a
lower yield than conventional popping;
there will be a number of unpopped
kernels. Do not use oil unless specified
by the manufacturer.
9. Do not cook any food surrounded by a
membrane, such as egg yolks,
potatoes, chicken livers, etc., without
first piercing them several times with a
fork.
10. Do not pop popcorn longer than the
manufacturer's directions. (popping
time is generally below 3 minutes).
Longer cooking does not yield more
popped corn, it can cause scorchings
and fire.
Also, the cooking tray can become too
hot to handle or may break.
11. If smoke is observed, switch off or
unplug the appliance and keep the
door closed in order to stifle any
flames.
12. When heating food in plastic or paper
containers, keep an eye on the oven
due to the possibility of ignition.

4
SAVE THESE INSTRUCTIONS
13. The contents of feeding bottles and
baby food jars shall be stirred or
shaken and the temperature
checked before consumption, in
order to avoid burns.
14. Always test the temperature of food
or drink which has been heated in a
microwave oven before you give it to
somebody, especially to children or
elderly people. This is important
because things which have been
heated in a microwave oven carry on
getting hotter even though the
microwave oven cooking has
stopped.
15. Eggs in their shell and whole hard-
boiled eggs should not be heated in
microwave ovens since they may
explode, even after microwave
heating has ended;
16. Keep the waveguide cover clean at
all times. Wipe the oven interior with
a soft damp cloth after each use. If
you leave grease or fat anywhere in
the cavity it may overheat, smoke or
even catch fire when next using the
oven.
17. Never heat oil or fat for deep frying
as you cannot control the
temperature and doing so may lead
to overheating and fire.
18. Liquids, such as water, coffee, or tea
are able to be overheated beyond
the boiling point without appearing to
be boiling due to surface tension of
the liquid. Visible bubbling or boiling
when the container is removed from
the microwave oven is not always
present. THIS COULD RESULT IN
VERY HOT LIQUIDS SUDDENLY
BOILING OVER WHEN A SPOON
OR OTHER UTENSIL IS
INSERTED INTO THE LIQUID.
To reduce the risk of injury to
persons:
a) Do not overheat the liquid.
b) Stir the liquid both before and
halfway through heating it
c) Do not use straight-sided
containers with narrow necks.
d) After heating, allow the container
to stand in the microwave oven for
a short time before removing the
container.
e) Use extreme care when inserting
a spoon or other utensil into the
container.
19. Children should be supervised to
ensure that they do not play with the
appliance.
20. Only use utensils that are suitable for
use in microwave ovens.
21. Microwave heating of beverages can
result in delayed eruptive boiling,
therefore care must be taken when
handling the container.

5
EARTHING INSTRUCTIONS
This appliance must be earthed. In the event of an
electrical short circuit, earthing reduces the risk of
electric shock by providing an escape wire for the
electric current. This appliance is equipped with a
cord having a earthing wire with a earthing plug.
The plug must be plugged into an outlet that is
properly installed and earthed.
WARNING : Improper use of the earthing plug can
result in a risk of electric shock. Consult a qualified
electrician or serviceman if the earthing instructions
are not completely understood, or if doubt exists as
to whether the appliance is properly earthed.
If it is necessary to use an extension cord, use only a
3-wire extension cord that has a 3-blade earthing
plug, and a 3-slot receptacle that will accept the plug
on the appliance. The marked rating of the extension
cord should be equal to or greater than the electrical
rating of the appliance.
IMPORTANT
The wires in this mains lead fitted to this appliance
are colored in accordance with the following code.
Green-and-yellow : Earth
Blue : Neutral
Brown : Live
As the colors of the wires in the mains lead of this
appliance may not correspond with the colored
markings identifying the terminals in your plug,
proceed as follows : the wire which is colored green-
and-yellow must be connected to the terminal in the
plug which is marked with the letter ‘E’ or by the
earth symbol or green-and-yellow. The wire which is
colored blue must be connected to the terminal
which is marked with the letter ‘N’ or colored white.
The wire which is colored brown must be connected
to the terminal which is marked with the letter ‘L’ or
colored red.
WARNING : The appliance must be earthed.
INSTALLATION
1. Ventilation
Do not block air vents. If they are blocked during
operation, the oven may overheat and eventually
cause a failure. For proper ventilation, allow above
76mm of space between oven sides, rear and the
minimum height of free space necessary above
the top surface of the oven is 100mm.
2. Steady, flat location
This oven should be set on a steady, flat surface.
This oven is designed for counter top use only.
The microwave oven shall not be placed in a
cabinet unless it has been tested in a cabinet.
3. Leave space behind and side
All air vents should be kept a clearance.
If all vents are covered during operation, the oven
may overheat and, eventually, oven failure.
4. Away from radio and TV sets
Poor television reception and radio interference
may result if the oven is located close to a TV,
Radio antenna, feeder and so on. Position the
oven as far from them as possible.
5. Away from heating appliance and water taps
Keep the oven away from hot air, steam or Splash
when choosing a place to position it, or the
insulation might be adversely affected and
breakdowns occur.
6. Power supply
• Check your local power source. This oven
requires a current of approximately 6 amperes,
230V 50Hz.
• Power supply cord is about 0.8 meters long.
• The voltage used must be the same as specified
on this oven. Using a higher voltage may result in
a fire or other accident causing oven damage.
Using low voltage will cause slow cooking. We
are not responsible for damage resulting from
use of this oven with a voltage of ampere fuse
other than those specified.
• If the supply cord is damaged, it must be
replaced by the manufacturer or its service agent
or a similarly qualified person in order to avoid a
hazard.
7. Examine the oven after unpacking for any
damage such as:
A misaligned door, Broken door, A dent in cavity.
If any of the above are visible, DO NOT INSTALL,
and notify dealer immediately.
8. Do not operate the oven if it is colder than
room temperature.
(This may occur during delivery in cold weather.)
Allow the oven to become room temperature
before operating.

6
11Door latch - When the door is closed, it will
automatically shut off. If the door is opened
while the oven is operating, the magnetron
will automatically shut off.
22Door seal - The door seal surfaces prevent
microwaves escaping from the oven cavity.
33Oven cavity
44Oven lamp - Automatically turns on during
oven operating.
55Safety interlock system
66Control panel
77Waveguide cover - Protects the
microwave outlet from splashes of cooking
foods.
88Roller guide - This must always be used
for cooking together with the glass cooking
tray.
99Coupler- This fits over the shaft in the
center of the oven cavity floor.
This is to remain in the oven for all cooking.
00Glass cooking tray - Made of special heat
resistant glass. The tray must always be in
proper position before operating. Do not
cook food directly on the tray.
qqViewing screen - Allows viewing of food.
The screen is designed so that light can
pass through, but not the microwave.
FEATURES DIAGRAM
12 3 45
6
7809q

7
11DISPLAY - Cooking time, power level are
displayed.
22AUTO COOK - Used to cook or reheat
many of favorite food.
33WEIGHT DEFROST - Used to defrost
foods for weight.
44TIME DEFROST - Used to defrost foods for
time.
55POWER - Used to set power level.
66ONE TOUCH COOK - Used to cook or
reheat specific quantities of food.
77TIME SET BUTTON - Used to set the
cooking time and weight.
88STOP/CLEAR - Used to stop the oven
operation or to delete the cooking data.
99START/+30 SEC - Used to start the oven
and also used to set a reheat time.
00-Used to turn the AC power on the
oven.
FEATURES DIAGRAM (continued)
1
0
2
3
4
65
66
7
98

8
Plug power supply cord into 230V AC 50Hz
power outlet.
Press eco button until beep sounds and
display is turned on.
After placing the food in a suitable
container,open the oven door and put it on the
glasstray. The glass tray and roller guide
mustalways be in place during cooking.
Close the door. Make sure that it is firmly
closed.
The oven door can be opened at any time
during operation by pushing the door open
button. The oven will automatically shut off.
To restart the oven, close the door and then
push the START button.
The oven automatically cooks on full power
unless set to a lower power level.
The display will show " : 0" when the oven is
plugged in, press and hold Eco button until
display is turned on and beep sounds.
Display will be returned to the " : 0 " when the
cooking time ends.
When the STOP/CLEAR button is pushed
during the oven operation, the oven stops
cooking and all information retained. To erase
all information, push the STOP/CLEAR button
once more.
If the oven door is opened during the oven
operation, all information is retained.
If the START button is pushed and the oven
does not operate, check the area between the
door and door seal for obstructions and make
sure the door is closed securely. The oven
will not start cooking until the door is
completely closed or the program has been
reset.
Display turns off after 10 minutes.
OPERATION PROCEDURE
This section includes useful information about oven operation.
1
2
3
4
5
6
7
8
9
10
11
Make sure the oven is properly installed
and plugged into the electrical outlet.
WATTAGE OUTPUT CHART
•The power-level is set by push the Power button. The chart shows the display, the power level
and the percentage of power.
once P-HI 100%
twice P-90 90%
3 times P-80 80%
4 times P-70 70%
5 times P-60 60%
6 times P-50 50%
7 times P-40 40%
8 times P-30 30%
9 times P-20 20%
10 times P-10 10%
11 times P-00 0%
Push the Power button Power level (Display) Approximate Percentage of Power

9
CONTROLS
TURNING AC POWER ON & OFF THE OVEN
When the oven is first plugged in , the display will show nothing.
1. Press and hold Eco button until
display is turned on and beep
sounds.
The oven is turned AC power on.
2. Press and hold STOP/CLEAR
button until display is turned off.
The oven is turned off and will
use no power.
NOTE: If the mains power goes off the display disappears until the power comes back on and the Eco
button is pressed and held until a beep sounds.
The oven is automatically powered off if not used for 10 Minutes.
