DAEWOO ELECTRONICS KOR-6N35S Assembly Instructions

2
IMPORTANT SAFETY INSTRUCTIONS
IMPORTANT
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE.
WARNING : To prevent fire, burns, electric shock and other warnings:
Listed below are, as with all appliances, certain rules to follow and safeguards to assure high performance from this oven:
11. Do not use the oven for any reason other than food preparation,
such as for drying clothes, paper, or any other nonfood items or for
sterilizing purposes.
12. Do not use the oven when empty, this could damage the oven.
13. Do not use the oven cavity for any type of storage, such as
papers, cookbook, cookware, etc.
14. Do not operate the oven without the glass tray in place. Be sure it
is properly sitting on the rotating base.
15. Make sure you remove caps or lids prior to cooking when you
cook food sealed in bottles.
16. Do not put foreign material between the oven surface and door. It
could result in excessive leakage of microwave energy.
17. Do not use recycled paper products for cooking. They may contain
impurities which could cause sparks and/or fires when used during
cooking.
18. Do not pop popcorn unless popped in a microwave approved
popcorn popper or unless it's commercially packaged and
recommended especially for microwave ovens. Microwave
popped corn produces a lower yield than conventional popping;
there will be a number of unpopped kernels. Do not use oil unless
specified by the manufacturer.
19. Do not cook any food surrounded by a membrane, such as egg
yolks, potatoes, chicken livers, etc., without first piercing them
several times with a fork.
10. Do not pop popcorn longer than the manufacturer's directions.
(popping time is generally below 3 minutes). Longer cooking does
not yield more popped corn, it can cause scorchings and fire.
Also, the cooking tray can become too hot to handle or may break.
11. If smoke is observed, switch off or unplug the appliance and keep
the door closed in order to stifle any flames.
12. When heating food in plastic or paper containers, keep an eye on
the oven due to the possibility of ignition.
13. The contents of feeding bottles and baby food jars shall be stirred
or shaken and the temperature checked before consumption, in
order to avoid burns.
14. Always test the temperature of food or drink which has been
heated in a microwave oven before you give it to somebody,
especially to children or elderly people. This is important because
things which have been heated in a microwave oven carry on
getting hotter even though the microwave oven cooking has
stopped.
15. Eggs in their shell and whole hard-boiled eggs should not be
heated in microwave ovens since they may explode, even after
microwave heating has ended.
16. Keep the waveguide cover clean at all times. Wipe the oven
interior with a soft damp cloth after each use. If you leave grease
or fat anywhere in the cavity it may overheat, smoke or even catch
fire when next using the oven.
17. Never heat oil or fat for deep frying as you cannot control the
temperature and doing so may lead to overheating and fire.
18. Liquids, such as water, coffee, or tea are able to be overheated
beyond the boiling point without appearing to be boiling due to
surface tension of the liquid. Visible bubbling or boiling when the
container is removed from the microwave oven is not always
present. THIS COULD RESULT IN VERY HOT LIQUIDS
SUDDENLY BOILING OVER WHEN A SPOON OR OTHER
UTENSIL IS INSERTED INTO THE LIQUID.
To reduce the risk of injury to persons:
a) Do not overheat the liquid.
b) Stir the liquid both before and halfway through heating it
c) Do not use straight-sided containers with narrow necks.
d) After heating, allow the container to stand in the microwave oven
for a short time before removing the container.
e) Use extreme care when inserting a spoon or other utensil into the
container.
19. This appliance is not intended for use by persons(including
children) with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a
person responsible for their safety.
20. Children should be supervised to ensure that they do not play with
the appliance
SAVE THESE INSTRUCTIONS
The wires in this mains lead are coloured in accordance with the following code.
Green-and-yellow : Earth
Blue : Neutral
Brown : Live
As the colours of the wires in the mains lead of this appliance may not correspond with the coloured
markings identifying the terminals in your plug, proceed as follows:
The wire which is coloured green-and-yellow must be connected to the terminal in the plug which is
marked with the letter ‘E’ or by the earth symbol or green-and-yellow. The wire which is coloured
blue must be connected to the terminal which is marked with the letter ‘N’ or coloured black.
The wire which is colured brown must be connected to the terminal which is marked with the letter ‘L’
or coloured red.
EL
N
GREEN/YELLOW
Earth
BLUE
Neutral
FUSE
13 Amps
Cord Clamp
BROWN
Live

3
EARTHING INSTRUCTIONS
This appliance must be earthed. In the event of an electrical
short circuit, earthing reduces the risk of electric shock by
providing an escape wire for the electric current. This
appliance is equipped with a cord having a earthing wire with
a earthing plug. The plug must be plugged into an outlet that is
properly installed and earthed.
WARNING : Improper use of th earthing plug can result in a
risk of electric shock. Consult a qualified electrician or
serviceman if the earthing instructions are not completely
understood, or if doubt exists as to whether the appliance is
properly earthed. If it is necesary to use an extension cord,
use only a 3-wire extension cord that has a 3-blade earthing
plug, and a 3-slot receptacle that will accept the plug on the
appliance. The marked rating of the extension cord should be
equal to or greater than the electrical rating of the appliance.
IMPORTANT NOTE
The wires in this mains lead fitted to this appliance are cloured
in accordance with the following code.
Green-and-yellow : Earth
Blue : Neutral
Brown : Live
As the colours of the wires in the mains lead of this appliance
may not correspond with the coloured markings identifying the
terminals in your plug, proceed as follows : the wire which is
coloured green-and-yellow must be connected to the terminal
in the plug whyich is marked with the letter ‘E’ or by the earth
symbol or green-and-yellow. The wire which is coloured blue
must be connected to the terminal which is marked with the
letter ‘N’ or coloured black. The wire which is coloured brown
must be connected to the terminal which is marked with the
letter ‘L’ or coloured red.
WARNING : The appliance must be earthed.
INSTALLATION
Disposal of Used Electrical & Electronic Equipment
1. Ventilation
Do not block air vents. If they are blocked during operation,
the oven may overheat and eventually cause a failure. For
proper ventilation, allow above 3 inches of space between
oven sides, rear and the minimum height of free space
necesary above the top surface of the oven is 100mm.
2. Steady, flat location
This oven should be set on a steady, flat surface. This oven
is designed for counter top use only.
The microwave oven shall not be placed in a cabinet
unless it has been tested in a cabinet.
3. Leave space behind and side
All air vents should be kept a clearance. If all vents are
covered during operation, the oven may overheat and,
eventually, oven failure.
4. Away from radio and TV sets
Poor television reception and radio interference may result
if the oven is located close to a TV, Radio antenna, feeder
and so on. Position the oven as far from them as possible.
5. Away from heating appliance and water taps
Keep the oven away from hot air, steam or Splash when
choosing a place to position it, or the insulation might be
adversely affected and breakdowns occur.
6. Power supply
• Check your local power source. This oven requires a
current of approximately 10 amperes, 230V 50Hz.
• Power supply cord is about 0.8 meters long.
• The voltage used must be the same as specified on this
oven. Using a higher voltage may result in a fire or other
accident causing oven damage. Using low voltage will
cause slow cooking. We are not responsible for damage
resulting from use of this oven with a voltage of ampere
fuse other than those specified.
• If the supply cord is damaged, it must be replaced by the
manufacturer or its service agent or a similarly qualified
person in order to avoid a hazard.
7. Examine the oven after unpacking for any damage
such as:
A misaligned door, Broken door, A dent in cavity. If any of
the above are visible, DO NOT INSTALL, and notify dealer
immediately.
8. Do not operate the oven if it is colder than room
temperature.
(This may occur during delivery in cold weather.) Allow the
oven to become room temperature before operating.
The meaning of the symbol on the product, its accessory or packaging indicates that this product shall not be treated
as household waste. Please, dispose of this equipment at your applicable collection point for the recycling of
electrical & electronic equipments waste. In the European Union and Other European countries which there are
separate collection systems for used electrical and electronic product. By ensuring the correct disposal of this
product, you will help prevent potentially hazardous to the environment and to human health, which could otherwise
be caused by unsuitable waste handling of this product. The recycling of materials will help conserve natural
resources. Please do not therefore dispose of your old electrical and electronic equipment with your household
waste. For more detailed information about recycling of this product, please contact your local city office, your
household waste disposal service or the shop where you purchased the product.

4
OPERATION PROCEDURE
This section includes useful information about oven
operation.
1. Connect the mains lead to an electrical outlet.
2. After placing the food in a suitable container, open
the oven door and put it on the glass tray.
The glass tray and roller guide must always be in
place during cooking.
3. Shut the door. Make sure that it is firmly closed.
When the oven door is opened, the light turns off.
The oven door can be opened at any time during
operation by pulling the door. The oven will
automatically shut off.
4. Set the variable power control to the desired
power level.
* The above % can be changed within ±6%.
5. Set the operating time by turing the timer control
to the desired cook time and the microwave
cooking starts.
• If setting the timer control for less than 2
minutes, turn it past 2 minutes and then back to
the desired time.
6. Microwave energy will be turned off auto matically
when the timer reaches “OFF”. Then food can be
taken out of the oven.
• To prevent the oven from operating with the
door open, your microwave oven is fitted with
safety door interlock switches.
• If you wish to inspect the food while it is cooking
simply open the door. The oven will
automatically stop cooking. To continue
cooking, you simply close the door.
• If you wish to stop cooking, simply turn the timer
knob to the “OFF” position. Cooking can be
reset at any time during the cooking cycle by
turning the timer control.
• Do not let the timer continue to operate after
removing or when there is no food.
CARE OF YOUR MICROWAVE OVEN
Turn the oven off before cleaning.
Keep the inside of the oven clean. When food
spatters or spilled liquids adhere to oven walls, wipe
with a damp cloth. Mild detergent may be used if the
oven gets very dirty. The use of harsh detergent or
abrasives is not recommended.
The outside oven surface should be cleaned with
soap and water, rinsed and dried with a soft cloth.
To prevent damage to the operating parts inside the
oven, water should not be allowed to seep into the
ventilation openings.
If the Control Panel becomes wet, clean with a soft,
dry cloth. Do not use harsh detergents or abrasives
on Control Panel.
If steam accumulates inside or around the outside of
the oven door, wipe with a soft cloth.
This may occur when the microwave oven is operated
under high humidity conditions and in no way
indicates malfunction of the unit.
It is occasionally necessary to remove the glass tray
for cleaning. Wash the tray in warm sudsy water or in
a dishwasher.
The roller guide and oven cavity floor should be
cleaned regularly to avoid excessive noise.
Simply wipe the bottom surface of the oven with mild
detergent water or window cleaner and dry. The roller
guide may be washed in mild sudsy water.
The oven should be cleaned regularly and any food
deposits removed;
Failure to maintain the oven in a clean condition could
lead to deterioration of the surface that could
adversely affect the life of the appliance and possibly
result in a hazardous situation;
1
2
3
4
5
6
7
8
9
BEFORE YOU CALL FOR SERVICE
Refer to following checklist, you may prevent an unnecessary service call.
* The oven doesn’t work :
1. Check that the power cord is securely plugged in.
2. Check that the door is firmly closed.
3. Check that the cooking time is set.
4. Check for a blown circuit fuse or tripped main circuit
breaker in your house.
* Sparking in the cavity :
1. Check utensils. Metal containers or dishes with metal
trim should not be used.
2. Check that metal skewers or foil does not touch the
interior walls.
If there is still a problem, contact the service station.
A list of these stations is included in the oven.
SYMBOL POWER LEVEL
Warm
Defrost
Medium
Medium high
High
OUTPUT POWER
120W
230W
385W
540W
700W

5
ROLLER GUIDE Glass Tray Roller Guide
The ROLLER GUIDE and oven floor should be cleaned
frequently to prevent excessive noise.
The ROLLER GUIDE MUST ALWAYS be used for cooking
together with the Glass Tray.
1
2
GLASS TRAY
DO NOT operate the oven without the Glass Tray in place.
DO NOT use any other Glass Tray with this oven.
If Glass Tray is hot, ALLOW TO COOL before cleaning or
placing it in water.
DO NOT cook directly on the Glass Tray.
(Except for popcorn)
1
2
3
4
COOKING UTENSILS
Only use utensils that are suitable for use in microwave ovens.
To cook food in the microwave oven, the microwaves must be able to penetrate the food, without being reflected or absorbed by the
dish used. Care must therefore be taken choosing the utensil. If the utensil is marked microwave-safe, you do not need to worry.
The following table lists various of utensil and indicates whether and how they should be used in a microwave oven.
●: Recommended use ▲ : Limited Use ✕: Not Recommended
Utensil Safe Comments
Aluminium foil
Crust plate
China and earthenware
Disposable polyester cardboard dishes
Fast-food packaging
• Polystyrene cups containers
• Paper bags or newspaper
• Recycled paper or metal trims
Glassware
• Oven-to-table ware
• Fine glassware
• Glass jars
Metal
• Dishes
• Freezer bag twist ties
Paper
• Plates, cups, napkins and
Kitchen paper
• Recycled paper
Plastic
• Containers
• Cling film
• Freezer bags
Wax or grease-proof paper
Can be used in small quantities to protect areas against
overcooking. Arcing can occur if the foil is too close to the
oven wall or if too much foil is used.
Do not preheat for more than 8minutes.
Porcelain, pottery, glazed earthenware and bone china are
usually suitable, unless deco-rated with a metal trim.
Some frozen foods are packaged in these dishes.
Can be used to warm food. Overheating may cause the
polystyrene to melt.
May catch fire.
May cause arcing.
Can be used, unless decorated with a metal trim.
Can be used to warm foods or liquids.
Delicate glass may break or crack if heated suddenly.
Must remove the lid. Suitable for warming only.
May cause arcing or fire.
For short cooking times and warming. Also to absorb
excess moisture.
May cause arcing.
Particularly if heat-resistant thermoplastic. Some other
plastics may warp or discolour at high temperatures. Do
not use Melamine plastic.
Can be used to retain moisture. Should not touch the food.
Take care when removing the film as hot steam will
escape.
Only if boilable or oven-proof. Should not be airtight. Prick
with a fork, if necessary.
Can be used to retain moisture and prevent spattering.
▲
●
●
●
●
✕
✕
●
●
●
✕
✕
●
✕
●
●
▲
●

56
CONVERSION CHARTS
WEIGHT MEASURES
15 g 1/2oz.
25 g 1 oz.
50 g 2 oz.
100 g 4 oz.
175 g 6 oz.
225 g 8 oz.
450 g 1 lb.
VOLUME MEASURES
30 ml 1 fl.oz.
100 ml 3 fl.oz.
150 ml 5 fl.oz. (1/4 pt)
300 ml 10 fl.oz. (1/2 pt)
600 ml 20 fl.oz. (1pt)
SPOON MEASURES
1.25 ml 1/4tsp
2.5 ml 1/2tsp
5 ml 1 tsp
15 ml 1 tbsp
FLUID MEASUREMENTS
1 Cup = 8 fl.oz. = 240 ml
1 Pint = 16 fl.oz. (UK 20 fl.oz.) = 480 ml (UK 560 ml)
1 Quart = 32 fl.oz. (UK 40 fl.oz.) = 960 ml (UK 1120 ml)
1 Gallon = 128 fl.oz. (UK 160 fl.oz.) = 3840 ml (UK 4500 ml)
Item Power Cooking Time Special Instruction
Level Per lb./450g
MEAT
Beef joint -Rare MEDIUM 6-8 min.
-Medium MEDIUM 7-11 min.
-well done MEDIUM 8-12 min.
Pork Joint HIGH 9-11 min.
Bacon joint HIGH 7-9 min.
POULTRY
Whole chicken HIGH 7-9 min.
Portions chicken MEDIUM 6-8 min.
Breast (boned) MEDIUM 7-9 min.
FISH
Fish Fillets HIGH 4-6 min.
Whole Mackerel, HIGH 4-6 min.
Cleaned and prepared
Whole Trout, Cleaned HIGH 4-6 min.
& Prepared
Salmon steaks HIGH 4-6 min.
NOTE : The above times should be regarded only as a guide. Allow for difference in individual tastes and
preferences. The times may vary due to the shape, cut, and composition of the food.
Frozen meat, poultry and fish must be thoroughly thawed before cooking.
COOKING CHART
- Chilled meat and poultry should be removed from
the refrigerator at least 30 minutes before
cooking.
- Always let the meat and poultry stand, covered
after cooking.
- Brush a little oil or melted butter over the fish, or
add 15~30ml(1-2 tbsp) lemon juice, wine, stock,
milk or water.
- Always let the fish stand, covered, after cooking
ARCING
If you see arcing, turn the timer knob the point “OFF” and correct the problem.
Arcing is the microwave term for sparks in the oven.
Arcing is caused by:
• Metal or foil touching the side of the oven.
• Foil not molded to food (upturned edges act like
antennas).
• Metal, such as twist-ties, poultry pins, or gold rimmed
dishes, in the microwave.
• Recycled paper towels containing small metal pieces
being used in the microwave.

7
"Do not defrost covered meat. Covering might allow
cooking to take place. Always remove outer wrap
and tray. Use only containers that are microwave-
safe.
"Begin defrosting whole poultry breast-side-down.
Begin defrosting roasts fat-side-down.
"The shape of the package alters the defrosting time.
Shallow rectangular shapes defrost more quickly
than a deep block.
"After 1/3of the defrost time has elapsed, check the
food. Toy may wish to turn over, break apart,
rearrange or remove thawed portions of the food.
"During defrost, the oven will prompt you to turn the
over. At this point, open oven door and check the
food. Follow the techniques listed below for optimum
defrost results.
Then, close oven door, touch the START pad to
complete defrosting.
"When defrosted, food should be cool, but softened in
all areas. If still slightly icy, return to microwave oven
very briefly, or let stand a few minutes. After
defrosting, allow food to stand 5-60 minutes if there
are any icy areas.
Poultry and fish may be placed under running cool
water until defrosted
➪Turn over : Roast, ribs, whole poultry, turkey
breasts, hot dogs, sausages, steaks, or chops.
➪Rearrange : Break apart or separate steaks, chops,
hamburger patties, ground meat, chicken or seafood
pieces, chunks of meat such as stew beef.
➪Shield : Use small strips of aluminum foil to protect
thin areas or edges of unevenly shaped foods such
as chicken wings. To prevent arching, do not allow
foil to come within 1-inch of oven walls or door.
➪Remove : To prevent cooking, thawed portions
should be removed from the oven at this point. This
may shorten defrost time for food weighing less than
3 lbs.(1350g).
DEFROSTING GUIDE
DEFROSTING CHART
Item & Weight Defrosting Time Standing Time Special Techniques
BEEF Minced beef
1 lb./450g
Stew Meat
1
1/2
lbs./675g
Patties
4(4oz./110g)
PORK Spareribs
1 lb./450g
Chops
4(5oz./125g)
Minced pork
1 lb./450g
POULTRY
Whole Chicken
2
1/2
lbs./1125g
Chicken Breasts
1 lbs./450g
Fryer Chicken(cut up)
2 lbs./900g
Chicken Thights
1
1/2
lbs./675g
FISH & SEAFOOD
Whole Fish
1 lb./450g
Fish Fillets
1
1/2
lb./675g
Shrimp
1/2
lb./225g
10-12 min.
18-20 min.
9-11 min.
9-11 min.
9-11 min.
9-11 min.
25-28 min.
15-18 min.
20-24 min.
18-20 min.
6-8 min.
12-14 min.
3-5 min.
15-20 min.
25-30 min.
15-20 min.
25-30 min.
25-30 min.
15-20 min.
45-90 min.
15-30 min.
25-30 min.
15-30 min.
15-20 min.
15-20 min.
15-20 min.
Break apart and remove thawed portions
with fork.
Separate and rearrange once.
Turn over after half the time.
Separate and rearrange once.
Separate and turn over once.
Break apart and remove thawed portions
with fork.
Break side down. Turn over after half the
time. Shield as needed.
Separate and rearrange once.
Separate and rearrange once.
Separate and rearrange once.
Turn over after half the time.
Shield as needed.
Separate and turn over once.
Separate and rearrange once.
* The times are approximate because freezer temperatures vary.

8
VEGETABLE CHART
Use a suitable glass pyrex bowl with lid. Add 30-45ml cold water(2-3 tbsp.) for every 250g unless another water
quantity is recommended - see table. Cook covered for the minimum time - see table.
Continue cooking to get the result you prefer. Stir once during and once after cooking. Add salt, herbs or butter
after cooking. Cover during a standing time of 3 minutes.
Hint : cut the fresh vegetables into even sized pieces. The smaller they are cut, the quicker they will cook.
All vegetables should be cooked using full microwave power.
Cooking Guide for fresh vegetables
Vegetables Weight Time Comments
Broccoli
1/2
lb./250g 2-3 min
1 lb./500g 3-5 min
Brussels sprouts
1/2
lb./250g 2-3 min
Carrots
1/2
lb./250g 2-3 min
Cauliflower
1/2
lb./250g 2-3 min
1 lb./500g 3-5 min
Courgettes
1/2
lb./250g 2-3 min
Egg plants
1/2
lb./250g 2-3 min
Leeks
1/2
lb./250g 2-3 min
Mushrooms 0.3 lb./125g 2-3 min
1/2
lb./250g 3-5 min
Onions
1/2
lb./250g 2-3 min
Pepper
1/2
lb./250g 2-3 min
Potatoes
1/2
lb./250g 3-5 min
1 lb./500g 8-10 min
Turnip cabbage
1/2
lb./250g 4-6 min
Prepare even sized florets.
Arrange the stems to the centre.
Add 60-75ml(5-6tbsp.) water.
Cut carrots into even sized slices.
Prepare even sized florets. Cut big florets into halves.
Arrange stems to the centre.
Cut courgettes into slices. Add 30ml(2tbsp.) water or a
knob of butter. Cook until just tender.
Cut egg plants into small slices and sprinkle with 1
tablespoon lemon juice.
Cut leeks into thick slices.
Prepare small whole or sliced mushrooms. Do not add
any water. Sprinkle with lemon juice. Spice with salt and
pepper. Drain before serving.
Cut onions into slices or halves. Add only 15ml(1tbsp.)
water.
Cut pepper into small slices.
Weigh the peeled potatoes and cut them into similar
sized halves or quarters.
Cut turnip cabbage into small cubes.
Cooking Guide for frozen vegetables
Vegetables Weight Time Instructions
spinach 0.3 lb./125g 2-3 min
broccoli
1/2
lb./250g 3-4 min
Peas
1/2
lb./250g 3-4 min
Green beans
1/2
lb./250g 4-5 min
Mixed vegetables
1/2
lb./250g 3-5 min
(carrots/peas/corn)
Mixed vegetables
1/2
lb./250g 4-6 min
(Chinese style)
Add 15ml(1tbsp.) cold water.
Add 30ml(2 tbsp.) cold water.
Add 15ml(1 tbsp.) cold water.
Add 30ml(2t tbsp.) cold water.
Add 15ml(1ttbsp.) cold water.
Add 15ml(1 tbsp.) cold water.

MICROWAVE OVEN
OPERATING INSTRUCTIONS & COOK BOOK
KOR-6N35S
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE
TO EXCESSIVE MICROWAVE ENERGY
(a) Do not attempt to operate this oven with the door open since open door operation can result in harmful exposure
to microwave energy. It is important not to defeat or tamper with the safety interlocks.
(b) Do not place any object between the oven front face and the door or allow soil or cleaner residue to accumulate on
sealing surfaces.
(c) WARNING : If the door or door seals are damaged, the oven must not be operated until it has been repaired by a
competent person : (1) door (bent), (2) hinges and latches(broken or loosened), (3) door seals and sealing surfaces.
(d) WARNING : It is hazardous for anyone other than a competent person to carry out any service or repair operation
which involves the removal of a cover which gives protection against exposure to microwave energy.
(e) WARNING : Liquids or other foods must not be heated in sealed containers since they are liable to explode.
(f) WARNING : Only allow children to use the oven without supervision when adequate instructions have been given so
that the child is able to use the oven in a safe way and understands the hazards of improper use.
(g) WARNING : When the appliance is operated in the combination mode, children should only use the oven under adult
supervision due to the temperature generated. (if provided)
Microwave oven is a Group 2 ISM equipment in which radiofrequency energy is intentionally generated and used in the
form of electromagnetic radiation for the treatment of material. This oven is a Class B equipment suitable for use in
domestic establishments and in establishments directly connected to a low voltage power supply network which
supplies buildings used for domestic purposes.
SPECIFICATIONS
POWER SUPPLY 230V, 6A SINGLE PHASE WITH GROUNDING 50Hz, AC.
POWER CONSUMPTION 1200 W
MICROWAVE ENERGY OUTPUT 800 W, FULL MICROWAVE POWER
FREQUENCY 2,450MHz
OUTSIDE DIMENSIONS (W x H x D) 465 x 279 x 365mm
CAVITY DIMENSIONS (W x H x D) 290 x 220 x 306mm
TIMER 35MIN DUAL SPEED
NET WEIGHT APPROX. 12.7 Kg
POWER SELECTIONS 5 Levels
* Specifications are subject to change without notice.
FEATURES
11Glass cooking tray - Made of special heat resistant glass. The
tray must always be in proper position before operating. Do not
cook food directly on the tray.
22Roller guide - This must always be used for cooking together
with the glass cooking tray.
33Variable Power Control Knob - Used to select a microwave
power level.
44Timer knob - Used in setting cooking time for all functions.
12
4
3

DAEWOO ELECTRONICS SALES UK LIMITED
YOUR PRODUCT GUARANTEE
Dear Customer,
Thank you for buying this Daewoo product. In the unlikely event of a failure all repair work will be carried out by your retailer or
Daewoo approved service centre, for a period of 12 months from date of sale.
Daewoo Electronics Sales UK Ltd., will provide the following services in order to expedite this guarantee.
During this period should a fault occur due to improper materials or workmanship, the retailer, authorised service centre, or
authorised service dealer will carry out repairs at no cost to yourself. Replacement products will be offered at the discretion of
your supplying dealer.
This guarantee will be honoured by Daewoo service networks in other E.C. members states, in accordance with the terms and
conditions which prevail in the member state at the time service is requested.
CONDITIONS
Any claims made under the terms of the guarantee must be supported by the original invoice/bill of sale issued at the time of
sale. Daewoo reserve the right to refuse guarantee should any of the information on the bill of sale be removed or changed in
any way after the original purchase of the product by the consumer from the retailer.
Modifications or adjustments made to the product which enable it to conform to local technical or safety standards in force in
any country other than the one for which the product was originally designed and manufactured, are not included in this
guarantee. Failures arising from such modifications, whether performed properly or not, will not be covered by this guarantee.
THIS GUARANTEE DOES NOT COVER ANY OF THE FOLLOWING:
1) Periodic maintenance, the repair or replacement of parts due to normal wear and tear.
2) Home service transport cost, and other costs and risks of transport relating directly or indirectly to the guarantee of the
product.
3) Damage to this product resulting from: the above and misuse, including but not limited to the failure to use this product for its
normal purpose or in accordance with the instructions on the proper use and maintenance of this product, and the
installation or the use of this product in a manner inconsistent with the technical or safety standards in force in the country
where the product is used.
4) Repairs carried out by non-authorised service centres.
5) Accidents, acts of God, or any cause beyond the control of Daewoo including but not limited to lightning, water, fire and
improper ventilation.
6) Aerial alignment and consumer control adjustments
7) Batteries whether supplied by Daewoo or not which become worn or exhausted in use.
8) Loss or damage caused to any item or article used with this product. This includes (but not limited to)discs, tapes, records,
and films.
This guarantee does not affect your statutory rights as a consumer, nor your rights against the retailer, arising from their sales
or purchase contract.
In the absence of applicable legislation, this guarantee will be the consumers sole and exclusive remedy, and neither Daewoo
nor its subsidiary, or distributor shall be liable for any incidental or consequential damages for breach of any express or implied
guarantee of this product.
For further information regarding this or any other query you may have about Daewoo products or its services please write to:-
Daewoo Electronics Sales UK Limited
Daewoo Building
Wharfdale Road
Winnersh Triangle
Workingham
Berkshire RG11 5TP
IN ALL CASES OF DIFFICULTY-CONSULT YOUR DAEWOO
DEALER FROM WHOM THE PRODUCT WAS PURCHASED

##$$%%$$&&''!
!(())**++,,$$##**--! !$$''((..
/0 123 456
789 :;<= >?
ABOUT THIS MANUAL
ABOUT THIS MANUAL
@@AABCD E
FF..GG&&HH**IIJ&)K7LLMM%NL OPQ H+*R&&
SS..GG&&HH**IIJ&)K7'LM% T U VU
SS!
!WW! !XX! !**! !))H*%WJ (&W',)X
NY
ZY
[[\\LY
>Y
MY
]]^^_``aa
GG**GG&&bcd!eSM!fg h:ij2 ]kl
mno
#$%$&' @ A pqr
,*Is tLuKu77u!F+vs tLuKLtww
uc.u7.NNKx9y!z{ Nd-![|}~ •€ N
uc.uw.NtK•‚ƒ„ …† eJ&)K7LLMM%%(K‡J&)K7LLMM%NLl
