Daewoo Lucoms FR-044RVBE User manual

FR-044RVBE
FR-044RVSE
FR-044RVWE

INSTALLATION
Adjusng temperature inside cabinet

13) Do not use an extension cord with this appliance. If the power cord is too short, have a qualified
electrician install an outlet near the appliance. Use of an extension can negavely affect the
unit’s performance.
•
•
•
•
Cauon: risk of fire
1
1. SAFETY WARNINGS
1) WARNING―Keep ven la on openings, in the appliance enclosure or in the built-in structure,
clear of obstruc on.
2) WARNING―Do not use mechanical devices or other means to accelerate the defros g process,
other than those recommended by the manufacturer.
3) WARNING―Do not damage the refrigerant circuit.
4) WARNING―Do not use electrical appliances inside the food storage compartments of the
appliance, unless they are of the type recommended by the manufacturer.
5) WARNING―DANGER:Risk of child entrapment. Before you throw away your old refrigerator or
freezer:
Take offthe doors
Leave the shelves in place so that children may not easily climb inside.
6) The appliance has to be unplugged before carrying out user maintenance on the appliance.
7) This appliance can be used by children age 8 years and above and persons with reduced physical
sensory or mental capabili es or lack of experience and knowledge if they have been given
supervision or ins concerning use of the appliance in a safe way and understand the
hazards involved. Children should not play with the appliance. Cleaning and maintenance should not
be made by children without supervision.
8) If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or
similar qualified persons in order to avoid a hazard.
9) Please abandon the refrigerator according to local regulaons as the unit contains flammable
blowing gas and refrigerant.
10) Follow local regula ons regarding disposal of the appliance due to flammable refrigerant and
blowing gas. Before you dispose the appliance, please take offthe doors to prevent children from
being trapped.
11) This appliance is intended to be used in household and similar environments such as
staffkitchen areas in shops, offices and other working environments;
farm houses and by clients in hotels, motels and other residen al type environments;
bed and breakfast type environments;
catering and similar non-retail applica
12) Do not store explosive substances such as aerosol cans with a flammable propellant in this
appliance.
IT IS HAZARDOUS FOR ANYONE OTHER THAN AUTHORIZED SERVICE PERSONNEL TO
CARRY OUT SERVICES OR REPAIRS INVOLVING THE REMOVAL OF COVERS.
TO AVOID THE RISK OF AN ELECTRICAL SHOCK DO NOT ATTEMPT REPAIRS YOURSELF.
•
•

2
2. INSTALLTION
2.1 Location
When selecting a position for your unit you should make sure the floor is flat and firm, and the
room is well ventilated. Avoid locating your unit near a heat source, e.g. cooker, boiler or radiator.
Also avoid direct sunlight as it may increase the electrical consumption. Extreme cold ambient
temperatures may also cause the unit not to perform properly. This unit is not designed for use in
a garage or outdoor installation. Do not drape the unit with any covering.
When installing the unit, ensure that 20 cm of free space is left at both sides, 15 cm at the rear
and 20 cm at the top of the unit. This will allow cold air to circulate around the wine cooler and
improve the efficiency of the cooling process. The door can be opened to the right or the left,
depending on what better suits the location. Please ensure there is adequate space for the door
to fully open.
2.2 Reversing the Door Swing
Tools Required: Phillips style screwdriver / Flat blated screwdriver / Hexagonal spanner
◆If you want to have the door swing reversed, we recommend that you contact a
qualified technician. You should only try to reverse the door yourself if you believe that
you are qualified to do so.
◆Ensure the unit is unplugged and empty.
◆Adjust the two levelling feet to their highest position.
◆To take the door of it is necessary to tilt the unit backwards. You should rest the unit on
something solid so that it will not slip during the door reversing process.
◆All parts removed must be saved to do the reinstallation of the door.
◆Do not lay the unit fat as this may damage the coolant system.
◆We recommend that 2 people handle the unit during assembly.
1) Remove the plastic covering from the top door hinge.
2) Unscrew the three screws from the bottom bracket.
Remove the foot from opposite side.

3
3) Place to one side.
4) Slide the Appliance door down about 15cm and off the
top hinge pin and lift away from the Appliance.
5) Remove the two screws from top bracket and replace
on the otherside.You will need to first remove the plastic caps
from the other side.
6) Slide the Appliancedoor back on to the Top hinge,
making sure it’s the right way up.
Screw the bottom hinge into place on the new side.
Replace theother foot on the other side.Replace the
plastic covering by clicking back into position on the
door hinge.
7) Check that the door is aligned horizontally and
vertically and that the seals are closed on all sides
before finally tightening the bottom hinge.
Re-adjust the levelling feet.
2.3 Door Space Requirements
The unit's door must be able to open fully as shown.
W×D≥840mm×995mm
2.4 Levelling the Unit
To do this adjust the two levelling feet at the front of the unit.
If the unit is not level, the door and magnetic seal alignments
will not be covered properly.
W
D

4
2.5 Cleaning Before Use
Wipe the inside of the unit with a weak solution of bicarbonate soda. Then rinse with warm
water using a 'Wrung-out' sponge or cloth. Wash the shelves and salad bin in warm soapy water
and dry completely before replacing in the unit. Clean the exterior of the unit with a damp cloth.
If you require more information refer to the Cleaning section.
2.6 Before Using Your Unit
Before placing any food in your unit, turn it on and wait for 24 hours, to make sure it is working
properly and to allow it time to fall to the correct temperature. Your unit should not be overfilled.
◆Before Plugging in
You must check that you have a socket which is compatible with the plug supplied
with the unit.
◆Before Turning On!
Do not turn on until two hours after moving the unit. The coolant fluid needs time to
settle.
2.7 Interior Accessories
Various glass or plastic storage shelves are included with your appliance - different
models have different combinations.
You should always slide one of the full size glass storage shelves into the lowest set of
guides, above the fruit and vegetable containers, and keep it in this position. To do
this, pull the storage shelf forward until it can be swivelled upwards or downwards
and removed.
Please do the same in reverse to insert the shelf at a different height.
In order to make the most of the volume of the fresh food storage compartment and
frozen-food storage compartment, the user can remove one or more shelves, drawers, out
of the appliance, according to your daily use.
3. PRODUCT OVERVIEW

5
Thermostat
shelf
Pop can bar
Leveler leg
Wire steel bar
Bottle bar
*All images in this instrucon manual are for indicaon only; please refer to your individual unit for details.
4. OPERATION
4.1 Adjusng temperature inside cabinet
The thermostat knob is used to adjust the temperature inside cabinet according to different ambient
temperature. At the same ambient temperature, higher number means lower temperature inside
cabinet, ‘OFF’ means power off of the refrigerator.
If the compressor keep running connuously or frost accumulated inside cabinet, please adjust
the thermostat knob to the smaller number. If the temperature inside cabinet is too high, please
adjust the knob to the higher number. Generally speaking, number ‘3’ is suggested seng for
most situaons.
4.2 Noise Inside the Unit
You may noce that your unit makes some unusual noises. Most of these are perfectly normal,
but you should be aware of them.
These noises are caused by the circulaon of the refrigerant liquid in the cooling system. It has
become more pronounced since the introducon of CFC free gases. This is not a fault and will not
affect the performance of your unit. This is the compressor motor working,as it pumps the
refrigerant around the system.
4.3 Tips for Keeping Food in the Unit
◆ Cooked meats/fishes should always be stored on a shelf above rawmeats/fishes to avoid
bacterial transfer. Keep rawmeats/fishes in a container which is large enough to collect juices
and cover it properly. Place the container on the lowest shelf.
◆ Leave space around your food, to allowair to circulate inside the unit. Ensure all parts of the
unit are kept cool.

6
◆ To prevent transfer of favours and drying out, pack or cover the food separately. Fruit and
vegetables do not need to be wrapped.
◆ Always let pre-cooked food cool down before you put in the unit. This will help to maintain
the internal temperature of the unit.
◆ To prevent cold air escaping from the unit, try to limit the number of mes you open the
door. We recommend that you only open the door when you need to put food in or take food
out.
5. CLEANING
5.1
5.2
Cleaning the Interior and the Exterior of the Unit
◆ Remove all the shelves and the salad bin. To remove the salad bin first remove the lower
door shelf.
◆ Wipe the inside of the unit with a weak soluon of bicarbonate soda and then rinse with
warm water using a“wrung-out”sponge or cloth. Wipe completely dry before replacing the
shelves and salad bin.
◆ Use a damp cloth to clean the exterior, and then wipe with a standard furniture polish. Make
sure that the door is closed to avoid the polish geng on the magnec door seal or inside
the unit.
◆ The grille of the condenser at the back of the unit and the adjacent components can be
vacuumed using a sobrush aachment.
Cleaning Tips
Condensaon may appear on the outside of the unit. This may be due to a change in room
temperature. Wipe of any moisture residue. If the problem connues, please contact a qualified
technician for assistance.
6. MAINTENANCE
6.1 Care When Handling / Moving Your Unit
Hold the unit around its sides or base when moving it. Under no circumstances should it be lied
by holding the edges of the top surface. Avoid damaging the refrigerant tubing when handling,
moving and use of refrigerator.
6.2 Servicing
The unit should be serviced by an authorized engineer and only genuine spare parts should be

No power
1. Unit is not plugged in. Check outlet and circuit.
2. Low voltage.
3. Power failure.
Odor
1. Odorous foods should be ghtly wrapped.
2. Check for anyroen food.
3. Clean the interior.
Long-term operaon of
compressor
1. It is normal for the unit to operate for longer me
during the hoer days when ambient temperature is higher.
2. Do not put too much food in the unit at one me.
3. Wait for food to cool down before placing them in the unit.
4. Frequent opening of refrigerator door.
The refrigerator door do not
close properly
1.Too much food inside the unit and the door is blocked by
food
packages.
2. Adjust the leveling leg.
Noises 1. Check if unit is leveled.
2. Noise caused bythe circulang refrigerant is normal.
