Daewoo AGC-2208RDS User manual

Service Manual
Car Audio
S/M No : AGC2208EF0
MODEL : AGC - 2208 / 2218 Series
2208 Series 2218 Series
DAE OO ELECTRONICS CO., LTD
Email: [email protected] Sep. 2003
MP3 CD, CD Player
Flip-Dow Detachable Face for A ti-Theft
4-Cha el high Power (40W x 4Ch)
Electro ic Volume/Bass/Treble/Bala ce/Fader
Co trol
Electro ic Tu i g
42 Memory Capability (18FM+12MW+12LW)
Local/DX Switch
Loud ess & Mute Co trol
10 CD-cha ger co trol (Optio )
AGC-2208RDS
AGC-2208BASIC
AGC-2206RDS
AGC-2206BASIC
AGC-2218RDS
AGC-2218BASIC
AGC-2216RDS
AGC-2216BASIC

TABLE OF CONTENTS
1. PRODUCT SPECIFICATION
2. LINE DRA ING
3. EMERGENCY TROUBLE SHOOT
4. CD PART
5. SCHEMATIC DIAGRAM
6. PARTS LOCATION ON P.C.BOARD
7. OVERALL EXPLODED VIE & PARTS LIST
8. DECK MECHANISM EXPLODED VIE & PARTS LIST
9. ELECTRICAL PARTS LIST
10. FUNCTION OF MICOM IC
11. IC BLOCK DIAGRAM
12. LIQUID CRYSTAL DISPLAY
13. OUTPUT CONNECTION DESCRIPTIONS
1
2
3
6
8
9
13
15
16
23
25
32
33
--------------------------------
--------------------------------
--------------------------
--------------------------------
--------------------------------
--------------------------
---------
---
--------------------------------
--------------------------------
--------------------------------
--------------------------------
-----------------

1
1. PRODUCT SPECIFICATIONS
AUDIO SECTION
Maximum output power : 40watts per channel into 4 ohms.
Load impedance : 4 ohms or 8 ohms
Total harmonic distortion : Less than 10% at 14 watts
Frequency response : 100Hz(±3dB), 20kHz(±3dB)
Control Bass/Treble : 10±3dB at 100Hz/10kHz
CD PLAYER SECTION
Total harmonic distortion : 0.1%
Signal to noise ratio : 80dB
Laser Diode Properties : Meterial - GaAlAs
Wave length - 775~800 nm
Laser output Power - Less than 400 uW
TUNER SECTION
(FM) Tuning range : 87.5 to 108MHz
Sensitivity : 10dBuV
Stereo separation : 30dB
Signal to noise ratio
: 60dB
(MW) Tuning range : 522 to 1620KHz at Europe
( 530 to 1710kHz at U.S.A)
Sensitivity : 22dBuV
Signal to noise ratio
: 50dB
Channel space : 9KHz (or 10KHz at U.S.A)
(LW) Tuning range : 144 to 288KHz
Usable Sensitivity : 25dBuV
GENERAL
Power requirements : DC 13.8V (10.8 ~15.6V allowable)
Negative ground
Speaker impedance : 4 or 8 ohm
Output power : Maximum 40Wx4Ch.
Current consumption : 10A (MAX)
Dimension (W x H x D) : 178 x 50 x 156 mm
Chassis size : 195 x64 x14.6 mm
Weight(Net) : 1.48Kg
Design and specifications are subject to changes for improvements without notice.

2
2. LINE DRA ING
2-1. FRONT SIDE
2-2. REAR SIDE
AGC-2208 Series (RDS & BASIC Function)
- RDS or No RDS Fu ctio
- MP3, Compact Disc Player
- Flip-Dow Detachable Face for A ti-Theft
- 4-Cha el high Power (40W x 4Ch)
- Electro ic Volume /Bass /Treble /Bala ce
/Fader Co trol
- Electro ic Tu i g
- 42 Memory Capability (18FM+12MW+12LW)
- Local/DX Switch
- Loud ess & Mute Co trol
- 10 CD-cha ger co trol (Optio )
AGC-2218 Series (RDS & BASIC Function)
- RDS or No RDS Fu ctio
- MP3, Compact Disc Player
- Flip-Dow Detachable Face for A ti-Theft
- 4-Cha el high Power (40W x 4Ch)
- Electro ic Volume /Bass /Treble /Bala ce
/Fader Co trol
- Electro ic Tu i g
- 42 Memory Capability (18FM+12MW+12LW)
- Local/DX Switch
- Loud ess & Mute Co trol
- 10 CD-cha ger co trol (Optio )

3
3. EMERGENCY TROUBLE SHOOT
3-1. General Function
No sound from
speakers
Yes
No
Yes
Output connector
is missing
Output connector
is inferior goods
Put exactly output
connector in.
Change output
connector to
superior goods
Yes
No
Power IC, Output
Socket is inferior
goods
Change Power IC,
Output Socket to
superior goods
Yes
A
A
L.C.D or Lamp
is not turned
off.
Yes
No
Yes
Power is not
supplied Return to
Output voltage of
power IC is little.
Change Regulator
IC and check
output voltage.
Yes
No
LCD or Lamp is
inferior goods.
Change LCD or
Lamp to superior
goods.
Yes
Different each
channel have
output level
(Front, Rear,
Left, Right)
Treble or Bass
is low
unusually
Yes
No
Yes
Balance of front
and rear is in one
side
Balance of Left,
Right is in one
side.
Re-adjust Balance
of front, rear
Ref.
Bala ce = Ce ter
Fro t / Rear
Ref.
Bala ce = Ce ter
Left / Right
Ref.
Bala ce = Ce ter
Treble / Bass
Ref.
Regulator IC output
Voltage = V
Ref.
Electrical Parts List
L.C.D., Lamp
Re-adjust Balance
of Left, Right
Yes
Yes
Balance of Treble
or Bass is in one
side.
Re-adjust Balance
of Treble or Bass
Yes

4
EMERGENCY TROUBLE SHOOT
3-2. Tuner Function
Hearing noise
only
Yes
No
Yes
No selected the
station
Tuner Module is
inferior goods.
Select exactly
broadcasting
frequency.
Change tuner
module to
superior goods.
Yes
Weak frequency
area caused by
elevations
Change to goods of
R.D.S function.
Yes
A
B
A
Station in
other regions
are not held.
Yes Yes
No selected the
local stations. Return to or
Extreme noise
in broadcast
Weak
separation of
FM stereo
Yes
No
Yes
Antenna
connector is
missing
Put exactly
antenna connector
in his jack
Ref.
Adjustme ts/Tu er
Fu ctio of auto-
switch oise
reductio
Ref.
Yes
Weak frequency
area of FM, MW
Switch
automatically to
mono mode in
weak frequency
area
Yes
B
R1 I case of located Glass A te a, check if heat wire is cut or ot i rear wi dow.
R2 Check A te a co ector part.

EMERGENCY TROUBLE SHOOT
5
Disc is not
inserted.
Yes Yes
There is Disc in
the slot
Take out Disc
from the slot
Disc is inferior
goods
Use only superior
disc
No
Yes
A
Selection time
is longer than
unusually
Yes
Selected PAUSE
function
Release PAUSE
function
Yes
Selected MUTE
function
Release MUTE
function
Yes
Mechanism is
inferior goods
Change
Mechanism to
superior goods
Turn power on
again after turn off.
Yes
Inspect disc for
scratches.
Yes
No sound
Yes
No
Yes
disc was inserted
upside down
Insert CD with
label side down
Ref.
DWEC CD Mecha
DCM-400B
Ref.
Power Off/O
Hard Reset
No
No
No
Disc is dirty
Wipe with cleaning
cloth
Yes
A
Ref. Point
Disc is stopped
under eject
Yes
It is normal for
CD-Deck or the
slot
Yes
3-3. CD Function

6
Defi itio of Mecha ical Mode
No
1
2
3
4
STOP MODE
LOADING
MODE
PLAY MODE
EJECT
MODE
- Disc have ’t bee i serted or disc have bee ejected. Whe disc shall be tra sported
i to the u it
Mecha ism shall be fixed at this mode.
- Loadi g device ca i sert disc thru the slot.
- Floati g device bei g locked.
- Disc have bee i serted thru the slot i fro t of u it. It is tra sie t state betwee STOP
mode a d PLAY mode.
- If disc should be i serted at the state of POWER ON, disc shall be loaded by a series of
operatio of specified device.
- After disc have bei g clamped o the tur -table, disc shall be rotated.
- Disc shall be played.
- Floati g device bei g u locked.
- Disc is to be ejected at this mode. It is tra sie t state betwee PLAY mode a d STOP
mode.
- If disc should be mou ted at the state of POWER ON a d comma ded by EJECT key, disc
shall be ejected thru the slot by a series of operatio of specified device.
MODE DEFINITION & STATUS
Sta dard values / Play-ability test
No
1
2
3
4
5
Loadi g Time
Ejecti g Time
Access Time
Disc
Take-up Force
Disc
7sec + 3sec
6sec + 3sec
< 17 sec
< 15 sec
< 15 sec
< 5 sec
> 120g
> 120g
> 80g
> 90g
Duri g play i
low temp.
> 70g
Duri g play i
low temp.
From i sertio up to make sou d.
(TCD-784)
From track No.1 Betwee the EJECT
comma d a d the disc eject completio .
(TCD-784)
From out-most Track, Betwee the PLAY
comma d of i -most Track a d marki g
sou d.
Shall be measure whe the ce ter of Disc is
correspo d with the ce ter of Roller.
Shall be measure whe the ce ter of Disc is
correspo d with the ce ter of Roller.
ITEMS
CONNEC
TION
SPECIFIED VALUES, CONDITIONS
STANDARD VALUES RELIABILITY LIMITS
TEST CONDITIONS, REFERENCES
CDP MODE & PLAYABILITY
4. CD PART

7
No
8
9
10
11
12
13
14
15
16
17
A ti-Vibratio al
Performa ce
Playability
Disc Deflectio
Disc
Ecce tricity
Jitter
Freque cy
Respo se
Harmo ic
Distortio
Dy amic
Ra ge
S/N Ratio
Cha el
+ 0.4mm
+ 0.21mm
< 28 sec
< 0.03% at 1kHz
> 80dB at 1kHz
> 85dB at 1kHz
> 70dB at 1kHz > 65dB at 1kHz
> 85dB at 1kHz
> 75dB at 1kHz
< 0.05% at 1kHz
20-20kHz + 2dB 20-20kHz + 3dB
< 33 sec
+ 0.21mm
+ 0.4mm
equal with
sta dard values
-I terruptio :0.7mm
-Block Dot Disc:0.8mm
-Scratch Disc:1mm
- Fi ger Pri t Disc:65um
>1.0g/10Hz-20Hz, Z way
>2.0g/30Hz-200Hz, Z way
>0.6g/10Hz-20Hz, X&Yway
>1.2g/30Hz-200Hz, X&Yway
X=side to side
Y=fro t to back
Z=up to dow
Z way o ly
10Hz-20Hz:0.7g
30Hz-200Hz:1.2g
-The G level should be upped to the sou d
skip level from the less level slowly at the
freque cy.
-Ig ore the sou d skip at the ear of
reso a ce freque cy(about 100Hz).
-I playi g YEDS-10 Tr #5, shall perform with
vibratio
-No sou d skippi g.
-No sou d skippi g i the specified ra ge.
-The sou d skippi g does ot i clude a y
i terpolati g oise.
-No sou d skippi g at the ABEX 731RA Tr
No8
-The sou d skippi g does ot i clude a y
i terpolati g oise.
-Except from specified item due to the
reliability limits of TEST DISC i the HTO
TEST.
-No sou d skippi g at the ABEX 713 Tr No8
-The sou d skippi g does ot i clude a y
i terpolati g oise.
-Except from specified item due to the
reliability limits of TEST DISC i the HTO
TEST.
This measureme t may be do e at 20Hz,
20kHz, (1kHz=0dB)
400Hz HIGHPASS FILTER
20kHz(-60dB 24kHz) LOWPASS FILTER
20kHz(-60dB 24kHz) LOWPASS FILTER,
60dB AMP IHF-A WEIGHTING FILTER
400Hz HIGHPASS FILTER
20kHz (-60dB 24kHz)LOWPASS FILTER
ITEMS
CONNEC
TION
SPECIFIED VALUES, CONDITIONS
STANDARD VALUES RELIABILITY LIMITS
TEST CONDITIONS, REFERENCES
7
Mecha ical
Noise
Loadi g Eject
< 75dB(A)
Play < 40dB(A)
Access < 70dB(A)
If a ythi g is ot
error, shall ot
defi ed.
-Test should be performed i o reverberatio
room at the oise level of less tha 20dB(A).
-Test should be performed at the 50cm i fro t
of the u it.
-IHF-A MODE (RMS-FAST)(TCD-792D)
6
Clampi g Force > 130g > 130g
CD PART

6-1. PCB MAIN / AGC-2208, 2218 Series
9
6. PARTS LOCATION ON P.C. BOARD
PART SIDE

10
PARTS LOCATION ON P.C. BOARD for AGC-2208 Series
AGC-2218 Series
BOTTOM SIDE

PARTS LOCATION ON P.C. BOARD
for AGC-2208 Series
11
PART SIDE
BOTTOM SIDE
6-2-1. PCB FRONT AGC-2208 Series

PARTS LOCATION ON P.C. BOARD
for AGC-2218 Series
12
PART SIDE
BOTTOM SIDE
6-2-2. PCB FRONT AGC-2218 Series

B001 PCB MAIN 97T65A33MA 1 EA 190x330xT1.6/2
CT130 CRYSTAL QUARTZ 5XJZ4R332D 1 EA HC-49/S 4.332MHZ 25PPM F
CT401 CRYSTAL QUARTZ 5XJZ4R500E 1 EA HC-49/S 4.5MHZ 30PPM F
DZ101 DIODE ZENER DKTZJ10B-- 1 EA MTZJ 10B 26MM
DZ130 DIODE ZENER DKTZJ5R1A- 1 EA MTZJ 5R1A 26MM
DZ301 DIODE ZENER DKTZJ3R9B- 1 EA MTZJ 3R9B 26MM
DZ303 DIODE ZENER DKTZJ9R1B- 1 EA MTZJ 9R1B 26MM
DZ351 DIODE ZENER DKTZJ5R1A- 1 EA MTZJ 5R1A 26MM
DZ401 DIODE ZENER DKTZJ6R8B- 1 EA MTZJ 6R8B 26MM
DZ402 DIODE ZENER DKTZJ5R6B- 1 EA MTZJ 5R6B 26MM
DZ403 DIODE ZENER DKTZJ6R8B- 1 EA MTZJ 6R8B 26MM
Q101 TR TZRC111M-- 1 EA KRC111M
Q102 TR TZRA105M-- 1 EA KRA-105M
Q103 TR TZRC102M-- 1 EA KRC102M(KEC)
Q104 TR TZRA105M-- 1 EA KRA-105M
Q105 TR TZRC102M-- 1 EA KRC102M(KEC)
Q106 TR TZTC3113B- 1 EA KTC 3113B
Q107 TR TZTC3113B- 1 EA KTC 3113B
Q108 TR TZ2SD1862R 1 EA 2SD1862R AUTO
Q301 TR TZ2SB1240R 1 EA 2SB1240R
Q302 TR TZRC102M-- 1 EA KRC102M(KEC)
Q303 TR TZRC102M-- 1 EA KRC102M(KEC)
Q309 TR TZDTC323TS 1 EA DTC323TSA SPT
Q310 TR TZDTC323TS 1 EA DTC323TSA SPT
Q351 TR TZDTC323TS 1 EA DTC323TSA SPT
Q352 TR TZDTC323TS 1 EA DTC323TSA SPT
Q353 TR TZDTC323TS 1 EA DTC323TSA SPT
Q402 TR TZRC102M-- 1 EA KRC102M(KEC)
Q405 TR TZTC3199Y- 1 EA KTC-3199Y TAPING
Q406 TR TZ2SB1240R 1 EA 2SB1240R
Q407 TR TZRC102M-- 1 EA KRC102M(KEC)
Q408 TR TZRA101M-- 1 EA KRA101M(AUTO)(2201)
Q409 TR TZRC102M-- 1 EA KRC102M(KEC)
Q471 TR TZTC3199Y- 1 EA KTC-3199Y TAPING
Q490 TR TZTC3198Y- 1 EA KTC3198Y-(1815Y) (AUTO)
9-1. PCB MAIN Ass’y / AGC-2208, 2218 Series
CAUTION is a recommendable part for essential stock.
R
9. ELECTRICAL PARTS LIST
16
Location PART NAME PART CODE DESCRIPTION UnitQ’ty

0F010 HOLDER LCD 97T2308500 1 EA "ABS XR-404,WHITE"
0F020 REFLECTION LCD 97T2227000 1 EA PC LEXAN 121 CLEAR
0F030 BRKT LCD 97T2449100 1 EA SECC T0.6
0F040 SHEET LCD 97T9609100 1 EA PC D114 93.1X26.4
0F050 CONN ZEBRA 97T6229600 1 EA
0F100 CUSHION GUIDE 97T4104500 2 EA FELT 25X4.5X0.3T BK
IC701 IC DRIVER(LCD) 1HL14104-- 1 EA LD4104
B002 PCB FRONT 97T65A23FR 1 EA 190X170X1.6T FR4
SW700 SW TACT 5S50101Z02 1 EA 1C-1P SKQC10918B 260G
SW701 SW TACT 5S50101Z02 1 EA 1C-1P SKQC10918B 260G
SW704 SW TACT 5S50101Z02 1 EA 1C-1P SKQC10918B 260G
SW706 SW TACT 5S50101Z02 1 EA 1C-1P SKQC10918B 260G
SW707 SW TACT 5S50101Z02 1 EA 1C-1P SKQC10918B 260G
SW708 SW TACT 5S50101Z02 1 EA 1C-1P SKQC10918B 260G
SW709 SW TACT 5S50101Z02 1 EA 1C-1P SKQC10918B 260G
SW710 SW TACT 5S50101Z02 1 EA 1C-1P SKQC10918B 260G
SW711 SW TACT 5S50101Z02 1 EA 1C-1P SKQC10918B 260G
SW712 SW TACT 5S50101Z02 1 EA 1C-1P SKQC10918B 260GS
PARTS LIST for AGC-2208 Series
AGC-2218 Series
17
Q501 TR TZRC101M-- 1 EA KRC101M (AUTO)(1201)
Q502 TR TZRA101M-- 1 EA KRA101M(AUTO)(2201)
ANT01 JACK ANT 97T6802500 1 EA 9.5X20X27.5
CWCDP CONNECTOR 97T6234700 1 EA FCZ 100B-18RR-K
CWFR CONNECTOR 97T6225400 1 EA IMSA-9890B-14B-T
CWLO CONNECTOR AS 97T8865000 1 EA E3P 100M/M
IC101 IC AUDIO 1BU1924F-- 1 EA BU1924(SOP)
IC301 IC REGULATOR 1K1A7805P1 1 EA KIA7805API
IC302 IC REGULATOR 1K1A7805P1 1 EA KIA7805API
IC303 IC CHIP EVR 1LC75371M- 1 EA LC75371M MFP36S
IC304 IC POWER 1TDA8571J- 1 EA TDA8571J-Y
IC305 IC REGULATOR 1K1A7809P1 1 EA K1A7809API
IC401 IC CHIP CUSTOM 176S801600 1 EA UPD178016AGC-604-3B9
IC402 IC REGULATOR 1K1A7808P1 1 EA KIA7808API
TU101 TUNER FM/AM 97T7612800 1 EA KST-M4001LVO-10
Location PART NAME PART CODE DESCRIPTION UnitQ’ty
Location PART NAME PART CODE DESCRIPTION UnitQ’ty
9-2.-1 FRONT DETA Ass’y : AGC-2208 Series

W713 SW TACT 5S50101Z02 1 EA 1C-1P SKQC10918B 260G
SW714 SW TACT 5S50101Z02 1 EA 1C-1P SKQC10918B 260G
LCD LCD BLACKMASKING 97T0L1630N 1 EA KXN35844AAB
LD02 LED DSB3372UDW 1 EA SB3372-UDW
LD03 LED DSB3372UDW 1 EA SB3372-UDW
LD04 LED DSB3372UDW 1 EA SB3372-UDW
PL701 LAMP PILOT 97Y82L6W95 1 EA P13.05 9V 50MA R/CAP
PL702 LAMP PILOT 97Y82L6W95 1 EA P13.05 9V 50MA R/CAP
PL703 LAMP PILOT 97Y82L6W95 1 EA P13.05 9V 50MA R/CAP
PL704 LAMP PILOT 97Y82L6W95 1 EA P13.05 9V 50MA R/CAP
PL705 LAMP PILOT 97Y82L6W95 1 EA P13.05 9V 50MA R/CAP
PL706 LAMP PILOT 97Y82L6W95 1 EA P13.05 9V 50MA R/CAP
PL707 LAMP PILOT 97Y82L6W95 1 EA P13.05 9V 50MA R/CAP
PL708 LAMP PILOT 97Y82L6W95 1 EA P13.05 9V 50MA R/CAP
SW715 SW TACT 5S52643CL1 1 EA 1C-1P SKMA 10918A 260G
SW716 SW TACT 5S52643CL1 1 EA 1C-1P SKMA 10918A 260G
SW717 SW TACT 5S52643CL1 1 EA 1C-1P SKMA 10918A 260G
VR701 ENCODER VOLUME 5V3503A71A 1 EA EC22B20-ZZZ
CB001 CABINET FRONT AS 97TCFA61GD 1 EA ACP-0206RT
CB010 CABINET FRONT 97T0111600 1 EA ABS XR-404
CB040 REFLECTION SW L 97T2226700 1 EA PC LEXAN121 CLEAR
CB050 REFLECTION SW R 97T2226800 1 EA PC LEXAN121 CLEAR
CB060 KNOB PRESET 1 97T13F4100 1 EA PC LEXAN-121 MILKY
CB061 KNOB PRESET 2 97T13F7500 1 EA PC LEXAN-121
CB070 KNOB PRESET 3 97T13F4200 1 EA PC LEXAN-121 MILKY
CB080 KNOB PRESET 4 97T13F4300 1 EA PC LEXAN-121 MILKY
CB090 KNOB SEL 97T13F4400 1 EA PC LEXAN-121 MILKY
CB100 KNOB MUTE 97T13F4500 1 EA PC LEXAN-121 MILKY
CB110 KNOB TP/TPST 97T13F4600 1 EA ABS XR 404
CB120 KNOB AF/REG 97T13F4700 1 EA ABS XR 404
CB130 KNOB TUNING DOWN 97T13F4800 1 EA PC LEXAN-121
CB140 KNOB TUNING UP 97T13F4900 1 EA PC LEXAN-121
CB150 KNOB LOUD 97T13F5100 1 EA ACRYL IH-830H
CB160 KNOB AUT 97T13F5200 1 EA ACRYL IH-830H
CB170 KNOB BAND 97T13F5300 1 EA ACRYL IH-830H
CB180 KNOB CD/CDC 97T13F5000 1 EA ABS XR 404
CB200 CAP KNOB LOUD 97T0440600 1 EA PC LEXAN-121 MILKY
CB210 CAP KNOB AUT 97T0440700 1 EA PC LEXAN-121 MILKY
CB220 CAP KNOB BAND 97T0440800 1 EA PC LEXAN-121 MILKY
PARTS LIST of Front Deta. Ass’y
for AGC-2208 Serie s
18
Location PART NAME PART CODE DESCRIPTION UnitQ’ty

PARTS LIST for AGC-2208 Series
AGC-2218 Series
19
CB002 CASE FRONT AS PNCFCA07GD 1 EA AKF-0827R
CF010 CASE FRONT 97T0433200 1 EA PP
CF013 CUSHION
CASE FRONT 97T4212410 1 EA SPONGE T10X10X30 D/GRAY
CB020 CABINET BACK 97T0111700 1 EA PC LEXAN-121
CB030 WINDOW LCD 97T1609900 1 EA ACRYL IH-830H
CB190 KNOB OPEN 97T13E5400 1 EA ABS XR-404
CB240 SUPPORTER BACK L 97T2503600 1 EA ABS XR-404
CB250 SUPPORTER BACK R 97T2503900 1 EA ABS XR-404
CB260 DECORATION 97T1001700 1 EA ACRYL
CB300 SPRING OPEN 97T3015000 1 EA SUS-304
CB310 PLATE PCB 97T0929500 1 EA PC
CB320 SCREW TAPPTITE 7173200812 4 EA TT2 BIN 2X8 MFZN BK
CB370 KNOB VOL 97T13D9400 1 EA ABS XR-401
KP010 KNOB POWER 97T13D9000 1 EA ACRYL IH-830H
Location PART NAME PART CODE DESCRIPTION UnitQ’ty
0F010 HOLDER LCD 97T2308500 1 EA “ABS XR-404,WHITE”
0F020 REFLECTION LCD 97T2227000 1 EA PC LEXAN 121 CLEAR
0F030 BRKT LCD 97T2449100 1 EA SECC T0.6
0F040 SHEET LCD 97T9609100 1 EA PC D114 93.1X26.4
0F050 CONN ZEBRA 97T6229600 1 EA
0F100 CUSHION GUIDE 97T4104500 2 EA FELT 25X4.5X0.3T BK
B002 PCB FRONT 97T65A23FR 1 EA 190X170X1.6T FR4
CB001 CABINET FRONT AS 97TCFA65GD 1 EA ACP-2206ED
CB002 CASE FRONT AS PNCFCA07GD 1 EA AKF-0827R
CB010 CABINET FRONT 97T0112400 1 EA ABS(XR-404)
CB020 CABINET BACK 97T0112500 1 EA PC(LEXAN-121) BK
CB030 WINDOW DISPLAY 97T1610700 1 EA ACRYL IH-830H
CB060 KNOB PRESET 1 97T13F7400 1 EA PC LEXAN-121
CB061 KNOB PRESET 2 97T13F7500 1 EA PC LEXAN-121
CB070 KNOB PRESET 3 97T13F7600 1 EA PC LEXAN-121
CB080 KNOB PRESET 4 97T13F7700 1 EA PC LEXAN-121
CB081 KNOB PRESET 5 97T13F7800 1 EA PC LEXAN-121
CB082 KNOB PRESET 6 97T13F7900 1 EA PC LEXAN-121
Location PART NAME PART CODE DESCRIPTION UnitQ’ty
9-2-2 FRONT DETA Ass’y : AGC-2218 Series

CB090 KNOB SEL 97T13F6800 1 EA PC(LEXAN-121)
CB100 KNOB MUTE 97T13F7300 1 EA PC LEXAN-121
CB110 KNOB REG 97T13F6900 1 EA ACRYL 1H-830H
CB120 KNOB TA 97T13F7000 1 EA ACRYL 1H-830H
CB130 KNOB DSP 97T13F7100 1 EA ACRYL 1H-830H
CB140 KNOB TUNE UP/DN 97T13F6300 1 EA PC(LEXAN-121)
CB150 KNOB LOUD 97T13F7200 1 EA PC LEXAN-121
CB160 KNOB AUT 97T13F6600 1 EA PC(LEXAN-121)
CB170 KNOB BAND 97T13F6500 1 EA PC(LEXAN-121)
CB180 KNOB CD 97T13F6400 1 EA PC(LEXAN-121)
CB190 KNOB OPEN 97T13F6700 1 EA ABS(XR-401)
CB200 CAP KNOB DSP 97T0442200 1 EA PC LEXAN-121
CB240 SUPPORTER BACK L 97T2503600 1 EA ABS XR-404
CB250 SUPPORTER BACK R 97T2503900 1 EA ABS XR-404
CB300 SPRING OPEN 97T3015000 1 EA SUS-304
CB310 PLATE PCB 97T0929500 1 EA PC
CB370 KNOB VOL 97T13F6000 1 EA ABS XR-401
CB380 KNOB POWER 97T13F6100 1 EA PC LEXAN-121
CF010 CASE FRONT 97T0433200 1 EA PP
CF013 CUSHION
CASE FRONT
97T4212410 1 EA SPONGE T10X10X30 D/GRAY
IC701 IC DRIVER(LCD) 1HL14104-- 1 EA LD4104
LCD LCD BLACKMASKING 97T0L1630N 1 EA KXN35844AAB
LD702 LED DLT6GB3-41 1 EA LT6GB3-41-UR BLUE
LD703 LED DLT6GB3-41 1 EA LT6GB3-41-UR BLUE
LD704 LED DLGH3030-- 1 EA LGH3030C-Q1 GREEN
LD705 LED DLT6GB3-41 1 EA LT6GB3-41-UR BLUE
LD706 LED DLGH3030— 1 EA LGH3030C-Q1 GREEN
LD707 LED DLGH3030— 1 EA LGH3030C-Q1 GREEN
LD708 LED DLGH3030— 1 EA LGH3030C-Q1 GREEN
LD709 LED DLGH3030— 1 EA LGH3030C-Q1 GREEN
LD710 LED DLGH3030— 1 EA LGH3030C-Q1 GREEN
LD711 LED DLGH3030— 1 EA LGH3030C-Q1 GREEN
LD712 LED DLGH3030— 1 EA LGH3030C-Q1 GREEN
SW701 SW TACT 5S50101Z02 1 EA 1C-1P SKQC10918B 260G
SW702 SW TACT 5S52643CL1 1 EA 1C-1P SKMA 10918A 260G
SW703 SW TACT 5S52643CL1 1 EA 1C-1P SKMA 10918A 260G
SW704 SW TACT 5S50101Z02 1 EA 1C-1P SKQC10918B 260G
SW705 SW TACT 5S52643CL1 1 EA 1C-1P SKMA 10918A 260G
SW706 SW TACT 5S50101Z02 1 EA 1C-1P SKQC10918B 260G
PARTS LIST of Front Deta. Ass’y
for AGC-2218 Series
20
Location PART NAME PART CODE DESCRIPTION UnitQ’ty

PARTS LIST for AGC-2208 Series
AGC-2218 Series
21
SW707 SW TACT 5S50101Z02 1 EA 1C-1P SKQC10918B 260G
SW708 SW TACT 5S50101Z02 1 EA 1C-1P SKQC10918B 260G
SW709 SW TACT 5S50101Z02 1 EA 1C-1P SKQC10918B 260G
SW710 SW TACT 5S50101Z02 1 EA 1C-1P SKQC10918B 260G
SW711 SW TACT 5S50101Z02 1 EA 1C-1P SKQC10918B 260G
SW712 SW TACT 5S50101Z02 1 EA 1C-1P SKQC10918B 260G
SW713 SW TACT 5S50101Z02 1 EA 1C-1P SKQC10918B 260G
SW714 SW TACT 5S50101Z02 1 EA 1C-1P SKQC10918B 260G
SW715 SW TACT 5S50101Z02 1 EA 1C-1P SKQC10918B 260G
SW716 SW TACT 5S50101Z02 1 EA 1C-1P SKQC10918B 260G
SW717 SW TACT 5S50101Z02 1 EA 1C-1P SKQC10918B 260G
SW718 SW TACT 5S50101Z02 1 EA 1C-1P SKQC10918B 260G
VR701 ENCODER VOLUME 5V3503A71A 1 EA EC22B20-ZZZ
Location PART NAME PART CODE DESCRIPTION UnitQ’ty
B006 PCB ISO 97T659661S 1 EA 160X137.5X1.6/9
CW105 CONN AS 97T8856100 1 EA ISO 16P WITH 10A FUSE
CH140 INSULATION MAIN 97T5603200 1 EA PE T=0.25
Location PART NAME PART CODE DESCRIPTION UnitQ’ty
9-3. PCB ISO Ass’y

PARTS LIST for AGC-2208 Series
AGC-2218 Series
22
CN101 CONN AS 97T8864800 1 EA FFC 18P 150MM 1P
DK010 BRKT DECK FR 97T4454000 1 EA SECC T=1.0
DK011 BRKT DECK FL 97T4454100 1 EA SECC T=1.0
DK020 BRACKET DECK B 97T2449410 1 EA SECC T=1.0
DK050 MP3 PCB SERVO 97T0M00300 1 EA SERVO PCB
DK060 DECK MECHANISM 97T6011700 1 EA DCM-400F
Location PART NAME PART CODE DESCRIPTION UnitQ’ty
9-5 DECK Ass’y
CN200 CONN AS 97T8858300 1 EA "ISO 16P W/PHON,ILL"
PK150 LABEL CONNECTION 97T9340600 1 EA STICKER
PK160 MANUAL
INSTRUCTION 97T9514500 1 EA ART PAPER REF.DES
PK200 LABEL CLASS 1 97T93280GD 1 EA STICKER
PK210 LABEL CAUTION 97T9352000 1 EA STICKER
Location PART NAME PART CODE DESCRIPTION UnitQ’ty
9-6 PACKING Ass’y
B004 PCB ES 97T65990ES 1 EA 160X118XT1.6/3
PL701 LAMP PILOT 97T82L6W95 1 EA PI3.05 9V 50MA R/CAP
SW701 SW TACT 5S52625MP1 1 EA TP1140B
Location PART NAME PART CODE DESCRIPTION UnitQ’ty
9-4. ESCUTCHEON Ass’y
